Harman JBL Professional CSS8018 User manual

JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
JBL CSS8018 REV A
PACKAGE COMPONENT EXPLODED VIEW
01-11
Technical Manual
JBL CSS8018
SPECIFICATIONS
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance: 8 Ohms
• Driver Power Handling: 20W
• Frequency Range (- 10 dB):
Driver/Grille Assembly: 50 Hz - 17 kHz
Installed in CSS-BB
BACKCAN: 90 Hz - 17 kHz
• Driver Sensitivity (mid-range)
(1W [2.83V], 1m, 2k - 6k Hz):97 dB
SYSTEM COMPONENTS:
• Transducer: 200 mm (8 in) speaker, 25 mm (1 in)
diameter voice coil with a Kapton™
coil-former
• DC Resistance: 7.8 ohm
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
25V Input (2.5w Tap), 50 Hz to 18 kHz
PHYSICAL SPECIFICATIONS:
• Net Weight (ea): 3.5 lb (1.58 kg.)
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
• Transformer Taps:
Warranty Card
59660
Instruction Sheet
445673-001
Carton
445678-001
Inner Carton
445677-001
Inside Carton Wrap
Liner
455676-001
Main PE Bag
445674-001
Orange Green Gray Yellow Black
25V 1.3W 2.5W 5W 10W COM
White Blue Brown Orange Black
70V 1.3W 2.5W 5W 10W COM
100V 2.5W 5W 10W N/C COM
Screw (2)
882-31910-10
6 x 3/4
PH,WOOD,BLK ZINC
Transformer
444967-001
10W
Nut (6)
445670-001
M4
Washer (4)
445669-001
M4 Non-Slip
Driver
444965-001
Grille
444960-001
Screw (4)
882-31410-40
6 x 2 1/2
PH,WOOD,BLK ZINC
Accessory Bag
445675-001

CSS8018 INSTALLATION INSTRUCTIONS
Commercial Series Ceiling Speaker
1. Install according to diagram.
2. Connect leads according to Tap Wiring chart.
3. Cut off bare portion of unused leads and
terminate with wire nuts.
Note: Always install in accordance with applicable
electrical and building codes.
Tap Wiring:
Orange Green Gray Yellow Black
25V 1.3W 2.5W 5W 10W COM
White Blue Brown Orange Black
70V 1.3W 2.5W 5W 10W COM
100V 2.5W 5W 10W N/C COM
JBL Professional
8500 Balboa Boulevard, P.O. Box 2200
Northridge, California 91329 U.S.A.
CSS8018 Instr 06/10
Back Can CSS-BB8
Back Can / Tile Rail screws (machine
screws) M4 x 8 mm (4 places, packaged
with back can)
Install screw through thru-hole in
back can, and screw into tile rail.
Tile Rails CSS-TR4/8 (x2)
Secure to ceiling/grids in manner required
by local building code.
CSS8018 Speaker
Speaker screws (sheet metal screws)
M4 x 40 mm (4 places, packaged with
speaker)
Install screw through thru-hole in
speaker, screw into clip nut in back can.
