5 of 36 ISSUED: 07-24-12 SHEET #: 180-9023-1
HD Flow Pro Wireless Multimedia Kit provides Full HD 1080p signal transfer, including 3D signal*, without the
hassle of running cables. Create brilliant HD quality multimedia for signage, presentations, or entertainment in
any location,completely un-tethered to your source device!
By simply connecting the Transmitter to a multimedia device such as a computer, set-top box, or Blu-ray™
player and connecting the Receiver to a display device, instant real-time high definition digital audio and video
can be placed into in any commercial or residential setting. HD Flow Pro Wireless Multimedia Kit transmits
through walls and floors to allow the components to be neatly tucked away in an AV rack or media cabinet,
and is the ideal solution for quick and easy installation where running cable is cost prohibitive or simply not an
option.
* Works with passive 3D signals
Features
• Low latency: ≤30ms.
• Supports both digital (HDMI) and analog (Component, Composite) video/audio.
• Supports Wireless or Wired connection - IEEE 802.11n 5 GHz WiFi, LAN connection.
• Two internal antennas (supporting MIMO).
• HDCP v1.1 compliant.
• Supports both DTV & VESA standards: DTV: 1920x1080i60/p60, 1280x720p60, 720x480i60/p60,
VESA : WSXGA+(1680x1050), SXGA(1280x1024), WXGA(1280x800), XGA(1024x768),
SVGA(800x600), VGA(640x480).
• Supports passive 3D content.
• Plug and play setup requires no software programming.
Package Contents
Ensure that the following items are present in the package. If any items are missing or damaged, please call
Peerless-AV Customer Care at 1-800-865-2112 (available 7:00am - 7:00pm CST Monday - Friday).
Transmitter Remote ControlReceiver
IR-Flasher
Component
Adapter
Battery Manual
Stand (2)
Quick Start Guide
AC Adapter (2)IR-Extender
Introduction
Step7 While turning on the display device the HD Flow Pro Wireless Multimedia units will be going through the startup process. This process may
takeupto two minutes to complete . The Power/Link indicator lights on the Transmi tter and the Receiver will be fla shing at first. Flashing indicates
thattheunits are establishing a secure connection. Wait until the connection is successfully established, indicated by the Power/Linkindic ator
lightbecomingsolid.
Minutes
2
1xTransmitter
1xReceiver
2xStand
1xRemote Control
1xIR Flasher
1xIR Extender
1xComponent Adaptor
2xPower Adapter
1xQuick Start Guide
1xUsers Manual
Step2 Connect the provide d IR Flasher to the IR-OUT port on the Transmitter.
Findthelocation of the IR window on your component device and adhere the
IRFlashereye directly over the IR window on your component device.
NOTE:OneIRFlashe r eye is to be used for one com ponent device.
Step4 I rovidedIRExtender in to
theIR-INport on the Receiver and adhering the other end of the IR Extender
toavertical surface near the output device. Ensure that the IR Extender is in
alineof sight to the remote control that controls your source devices.
NOTE:ForMulticastmodels, receivers two, three andfourdonotcome with an IR Extender. AdditionalIRExtenders
(HDS-IRE)canbepurchasedseparately; visit peerless-av.comformoreinformation.
Step6 Turn on your display device (TV, monitor, projector, etc.).
Step3
totheReceiver.
S
1.Plugin the power adapter for the Transmitter and the Receiver to nearby
availablepower outlets.
2.Plugin the power adapter end to the Transmitter and then to the Recei ver.
3.Theunits will automatically turn-on. The average power-on/sync time
isapproximately two minutes.
What’sin the Box
InstallationandSetup
TroubleshootingTips
TipTheIR window
maybeeasierto
locatewithadirect
lightshiningon
sectionsofthe
frontpanelofthe
componentdevice.
Asmallflashlight
workswell.
Power/Source
SelectionButton
TipRepeatSte ps
3-11to
moret
Receiv
(HDS20
HDS20
HDS20
Step1 Connect the Transmitter to the source devices
(Blu-ray™Discplayer,set top b ox, gaming console, etc.).
Step9 Turn on the desired source device that is connected to
theTransmitter.
Step11Play the source device content and enjoy up to Full HD 1080p
wirelessentertainmentexperience.
tCheckthemedia source resolution. The display device must be able
tosupportthe resolution of the media source that is being streamed.
UtilizingtheINFO button will allow you to see the resolution data that
thedisplaydevice supports. If the display device supports the highest
resolutionof720p but the source device is outputting 1080p content,
thecontentneeds tob e down-scaled to the maximum resolution of the
displaydevice,in this case 720p.
ReceiverOutputIndicator Ligh t Blinks:
tMakesurethatyour display device, source device and the HD Flow Pro unit s
areallturned ON and the Receiveris prop erly connected to the outp ut device.
tVerifythatthe Receiver is set to the appropriate output port.
tChecktheresolutionsetting of your source device. This mayneed to be
changedtoa resolution supported by the HD Flow Pro unit. Reference
theResolutionChart in the HD Flow Pro Manual for compatibility.
Referenceyoursourcedev ices’ manual for instruction on changing
theoutputresolution.
Iftheabove troubleshootingtips do not resolve the issues for a unicast setup,
pleasereferencethe Factory Reset Section of the HD FlowPro Manual. For a
multicastsystemconfiguration, please contact Peerless-AVCustomer Care at
800-856-2112forfurther instruction.
Step8 Selecttheoutput that connects the Receiver to the display using
thePower/SourceSelection Button or the provided remote control.
Theoutputindicatorlight will become solid and the HD Flow logo will
appearonthe display device.
Step10 Select the desired source or device input on the Transmitter
usingthePower/SourceSelectionButton on the remote control.
Transmitterand/orReceiverIndicatorLig hts are all Blinking:
tTheHDFlow Pro units are establishing a connection. It can take
uptotwo minutes for the HD Flow Pro units to establish a complete
connection.Ifafter two minutes have passed and the units have not
establishedaconnection, unplug the power cable, wait 30 seconds
andreconnectthe power supply to the units.
TransmitterorReceiverPower Indicator Light is OFF:
tCheckandverify the power supply connection.
TransmitterInputIndicator Light Blink s:
tMakesurethat yours ourcedevice is tur ned ON and the cable
isproperlyconnected.
tVerifythatthe Transmitter is set to the appropriate input port.
tChecktheresolution from your source device. This may need to
bechangedto a resolution supported by the HD Flow Pro Wireless
MultimediaKit.Reference the Resolution Chart in the HD Flow
Manualforcompatibility. Reference your source devices’ manual
forinstructiononchanging the output resolution.
ReceiverPowerIndicatorLight Blinks:
tVerifythatthe HD Flow Pro Transmitter and Receiver are within
therecommendedrange of 131 feet. Physical obstructions such as
walls,floorsand ceilings between the Transmitter and Receiver may
decreasethestrength ofthe connection signal and reduce the over all
transmissionrange.
Ifaconnectionha s been establishedand the HD Flow logo can be seen
onthedisplaydevice, but content is not playing:
tMakesurethat the input/outputcables are properly connected.
tVerifythatthe Transmitter is set to the appropriate input port.
Warning Donotplace the HD Flow
Prounitsnear other devices that
emitexcessiveamounts of heat.
Increasedtemperaturesmay
causetheHD Flow Pro Transmitter
orReceiverunit to malfunction
orstopworking.
