Environmental protection /
Scrapping
Recycle any unwanted material, do not
throw it in the household rubbish. All
machines, accessories and packaging
must be sorted and left at a recycling center and
disposed of in an environmentally friendly
manner.
Safety and precautions
WARNING: Basic safety precautions should
always be followed when using the tool to reduce
the risk of personal injury and other damage.
Read all instructions before using this product!
Keep the work surface clean. Disorder invites
accidents.
• Observe the conditions in the work area. Do
not use machinery or power tools in damp
or wet locations. Do not expose to rain. Keep
the work area properly lit. Do not use power
tools in the presence of ammable gases or
liquids.
• Keep children away. Children should never
be allowed in the work area. Do not allow
them to handle machinery, tools or extension
cords.
• Store equipment that is not in use. When not
in use, tools should be stored in a dry place
to prevent them from rusting. Always lock
up tools and keep away from children. Do
not force the tool. It will make the job better
and safer in the capacity it was intended for.
Do not use inappropriate accessories in an
attempt to exceed the tool’s capabilities.
• Use the right tool for the job. Do not try to
make a small tool or accessory do the job of
a larger industrial tool. Do not modify this tool
or use it for a purpose for which it was not
intended.
• Dress appropriately. Do not wear loose
clothing or jewelry, as they can get caught in
moving parts. Protective, electrically
non-conductive clothing and non-slip shoes
are recommended during work. Wear hair
protection to keep long hair out.
• Be alert. Watch what you’re doing and use
common sense. Do not use tools when you
are tired.
• Spare parts and accessories. Use only
identical spare parts when servicing. Using
other parts will void the warranty. Use only
accessories intended for use with this tool.
• Maintenance. For your safety, service and
maintenance should be done regularly by a
qualied technician.
WARNING: Warnings, precautions and
instructions in this user manual cannot cover
all possible conditions and situations that may
arise. The operator should understand that
common sense and caution are factors that
cannot be built into the product, but must come
from the operator himself.
Save this manual
You will need the manual for safety and
precautions, assembly instructions, operating
and maintenance procedures, list and parts
diagram. Keep your invoice together with this
manual. Write the invoice number on the inside
of the front cover. Keep the manual and invoice in
a safe and dry place for future use.
Features
1. This 1220 mm heavy duty body panel
prole gauge can measure up to 230mm
depth differences.
2. Quickly and simply locks in the shape you
want to copy.
3. Powder-coated body with stainless steel
prole for durability.
4. Replicating a gradual panel curve for a fender,
roof, door, panel and more.
Unpacking
When unpacking, check to make sure that all
parts shown in the parts diagram are included. If
any parts are missing or broken, please contact
the seller.
Assembly
Note: For additional information regarding the
parts listed in the following pages, refer to the
Parts Diagram.
1. Assemble the Gauge (2#) to the Body (1#) by
using eight Knobs (3#) and eight Washers(4#).
Operation
This Body Panel Prole Gauge makes it easier to
replicate a gradual panel curve for a fender, roof,
door panel and more.
1. Loosen the Knobs (3#).
2. Place the Gauge (2#) against a gradual panel
curve.
3. Tighten the Knobs (3#).
Specifications
Gauge Dimension.....................................1220mm
Maximum Curve Depth...............................230mm
