Pelican PRO-RO6 User manual

品牌故事
Brand Story
我们是谁
我们是 Pelican，湃能
全球无盐软水引领者
科技，见匠心
湃 能 ，相 信 科 技 的 力 量
可以让生活更加美好
这是湃能的全球视野
基于广泛的品 质认可
冠勋所至 源自我们
为当下改变未来的执着
这是湃能革新科技
让水的净化 察之以微
让生活进化 易见深远
2007 年诞生与于美国，在美国湃能全新致力于净水领域的创新研发，不仅树立了软水领域的行业标准，旗下产品更执美国同专业领域牛耳。
湃能还远赴欧亚诸多国家，如德国、意大利、沙特、迪拜等，在这些发达国家和地区，湃能同样保持卓越的市场占有率与口碑认可。
每一个由湃能净水科技所呵护的家庭，都无时无刻在享受着全屋净水带来的健康新体验，更从诸多益处中体会到——湃能专利级的领先滤水
与无盐软水的技术用心。
湃能旗下的多款净水与软水产品，将针对您居家生活中的不同水质条件，给予不同净水方案。
经由湃能全屋净水系统提供的二次供水优化，不仅实现了对健康的呵护，剔除了有害元素对您身心的侵扰，还适时为您与家人的饮用水中，科
学的加注诸多健康因子。
这也将延长家居设备的使用寿命。
创 新 ，见 远 心
湃 能 ，为 未 来 赋 能
更多可能
我们是谁
我们是湃能 全屋净水管家
全心科技 全新生活
湃能，从生命之源走来，由点滴之水开始，反思生活也反补生命的持久能量。
技术的革新，是驱动生活创新的核心动力——从有盐到无盐的净水软水，将不仅改变频繁换芯的低效能时间生活现状，
更实现了引领性生活的未来持久。

植入生活
深入生活
序言
湃 能 ，进 化 中
新 物 种 ，新 未 来
在未来，湃能全屋净水系统，将进化为一套“家居新零售模式”。
它将不仅仅作为“一件隐形家具”存在，更深入到空间设计阶段，成为整体居家生活定制方案的衍生，并由虚拟现实更多的互动，
全面打通生活方式体验空间、实体居家空间、虚拟场景空间，并触通线上线下销售通路，真正实现万物互联的未来生活。
从生产线到您的家，从海外到中国。湃能始终以更专业的姿态，进入千家万户之门。
关于产品安装，湃能将提供上门设计配置、上门安装调试、上门跟踪回访、上门维护检修，上门水质检测等更多服务。
如果您有更多问题，湃能相信这本内容翔实的安装手册，将会最大程度解答您的所有疑问。
本册为湃能产品的实用安装手册，其中内容为湃能专业团队与专业工程师，针对产品设计数据与实际安装事项，给予了最专业和最官方的解答
方案。本册将作为您深入了解湃能产品的一项依据和途径，如您还有更多问题可随时致电我们的服务平台工作人员。
服 务 ，见 本 心
湃 能 相 信 ，服 务 的 驱 动
能让我们与您更近
这是湃能 水管家服务体系
正在为您带来的美好生活
湃能尽心 您尽可放心
湃能净水管家，是基于湃能整合化的净水服务资源，为客户提供更多元的专属体验，诞生于客户动念选择净水产品服务之时，
它将不仅帮助湃能的潜在客户们，更加精准的选择适合全屋和全家人的湃能产品，同时还整合更专业的技术专家、设计师、
工程师团队及客服中心，针对您的需求，带来更加省心的安装、迁移、维护等可持续、无差别、标准化的流程服务。
湃能承诺所有净水产品核心部件都将由美国总部统一提供
并由专业的安装团队针对您爱居的空间布局，交付最合理的设计方案。
基于物联网智能家居技术的加持，湃能自主研发的水质监测系统
也让湃能——这位看不见的净水管家更加如您随心
实时而及时担当全家人用水的守护者与监察者
即便您不在家也可以随时了解掌握家中水质状况
定 时 采 集 、整 合 、分 析 、形 成 定 向 问 题 解 决 方 案

目录
Directory
DIRECTORY 目录
专业级反渗透矿泉水系统简介 .................................15
有限保修 .....................................................................16
产品性能数据表 .........................................................17
系统性能 ...............................................................17
系统维护 ...............................................................17
砷物质概况说明 .........................................................18
系统规格.....................................................................19
尺寸和重量 ...........................................................19
性能规格 ...............................................................19
进水要求 ...............................................................19
水龙头安装.................................................................20
进水口排水口连接 .....................................................21
进水口连接 ...........................................................21
排水口连接 ...........................................................21
系统激活与冲洗 .........................................................22
系统激活与检查 ....................................................22
初次冲洗步骤........................................................22
安装程序检验表 ........................................................23
维护.............................................................................23
滤芯更换 ...............................................................23
后置过滤器更换 ....................................................24
Introduction to the PRO-RO.......................................4
Limited Warranty ........................................................5
Performance Data Sheet ...........................................7
System Performance ..........................................7
System Maintenance..........................................7
Arsenic Fact Sheet ......................................................8
System Specifications ................................................9
Performance Specifications ...............................9
Dimensions and Weight ....................................9
Feed Water Requirements .................................9
Faucet Installation ......................................................10
Feed and Drain Connection ......................................11
Feed Connection .................................................11
Drain Connection ................................................11
System Activation and Flushing ................................12
System Activation and Inspection .....................12
Initial Flushing Procedure ...................................12
Installation Checklist ..................................................13
Maintenance ..............................................................13
Cartridge Replacement ......................................13
Post Filter Replacement ......................................14

WARRANTY
ONE YEAR LIMITED WARRANTY ON 6RO DRINKING WATER PURIFIER
Warrantor: Pelican Water Systems
Pelican Water Systems warrants to the original owner (under normal use): all products and parts to be free from
defects in material and workmanship for a period of one (1) year from the date of purchase. Any replacement
products furnished will be free from defects in material and/or workmanship for the remainder of the original
warranty period or 30 days, whichever is longer. This warranty does not cover: (1) defects not reported within
the above time period, (2) problems arising from failure to comply with Pelican Water Systems instructions,
(3) problems and/or damage arising from acts of nature, abuse, misuse, negligence or accident by any party
other than Pelican Water Systems, (4) problems and/or damage resulting in whole or in part from alteration,
modication, repair or attempted alteration, modication or repair by any party other than Pelican Water Systems,
(5) noncompliance with applicable codes/ordinances.
If a defect in workmanship and/or material in a product or part covered by the warranty should arise, Pelican
Water Systems, at its sole discretion, will repair or replace the defective product or part (Pelican Water Systems
will consider the customer’ s preference in good faith).
All claimed defective product must: (1) be authorized for return by Pelican Water Systems with an RGA number
(2) include proof of the purchase date of the product or part (3) returned to Pelican Water Systems prior to the
expiration of the warranty date at the customer’ s expense, shipment pre-paid (4) be accompanied by a letter
detailing the Model Number, Serial Number (if any), and a brief description of the problem.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, PELICAN WATER SYSTEMS DISCLAIMS
ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO THE
IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH
REGARD TO THE PRODUCTS, PARTS AND ANY ACCOMPANYING WRITTEN MATERIALS.
To the maximum extent permitted by applicable law, Pelican Water Systems shall not be liable for any
damages whatsoever (including, but not limited to, loss of time, inconvenience, expenses, labor or material
charges incurred in connection with the removal or replacement of the products or parts, special, incidental,
consequential, or indirect damages for personal injury, loss of business prots, business interruption, loss
of business information, or any other pecuniary loss) arising out of the use of or inability to use the defective
products or parts even if Pelican Water Systems has been advised of the possibility of such damages.
Pelican Water System’ s maximum liability under any provision of this Limited Warranty shall be limited to the
amount actually paid for the products or parts.
This warranty is effective if the Pelican Water Purier is operated at water pressured between 30-100 psig and
a water temperature between 40-100°F. Furthermore, the purier must not be subject to mistreatment, system
modication, disregard, freezing, carelessness, or damage as a result of any unusual force of nature (i.e.
hurricane, flood, earthquake, or tornado). Warrantor is excused if failure to perform its warranty obligations is the
result of material shortages, government regulation, strikes, or any other circumstances beyond its control.
04. PELICAN PRO-RO 6 Instruction Manual

Introduction to the PRO-RO
Congratulations on your purchase of the PRO-RO six stage reverse osmosis system. The PRO-RO features a four-stage
prelter, membrane and postlter housed in a single cartridge. The nal two stages consist of a granular activated carbon
polishing lter and a calcite remineralizing lter.
When properly maintained, this system will provide you with years of trouble-free service. The next sections contain
important information on the proper care and maintenance of your system, please take a few minutes to read through this
information.
The cartridges in this system must be replaced on a regular basis to maintain efciency and to ensure high water quality.
These cartridges work together and must be replaced every 6-12 months. Any signicant change in performance of the
system should be investigated promptly to avoid secondary damage or deterioration to other parts of the system.
Normally, the reverse osmosis membrane is replaced during an annual lter change. However, if at any time you notice a
reduction in water production or an unpleasant taste in the reverse osmosis water, it could be time to replace the
membrane. Pelican recommends replacing the membrane when TDS reduction falls below 85%.
Improperly installed systems could result in water
damage due to leaks or flooding. Proper installation
of this system requires familiarity with standard sink
plumbing and proper use of common hand and power
tools. If you are not familiar with standard sink plumbing
and proper use of common hand and power tools or have
any difculty with the installation of this system, consult
a licensed professional, such as a contractor or plumber.
CAUTION：
This system and installation must comply with state and
local laws and regulations.
NOTE：
Stage Description Replacement
Interval
Part
Number
1-4
4-Stage Cartridge
1.20 micron sediment prelter
2.Granular activated carbon (GAC) prelter
3.Reverse osmosis membrane
4.Granular activated carbon postlter
18 months 104863
5-6 Granular activated carbon (GAC) and calcite
(remineralization) postlter 6-12 months 104851
.05
PELICAN PRO-RO 6 Instruction Manual

Incidental and Consequential Damages Limitation: The Manufacturer will not be responsible for any
incidental or consequential damages as a result of the failure of this unit to comply with express or implied warranties or
any defect in the unit, including but not limited to, lost time, inconvenience, damage to personal property, loss of revenue,
commercial losses, postage, travel, telephone expenditures, or other losses of this nature. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so this exclusion may not apply to you.
Owner’ s Warranty Responsibilities: As a condition of this Limited Warranty, the owner must ensure periodic
maintenance of the system is performed as described in the literature enclosed with the system. Neglect, improper
maintenance, abuse, modication or alteration of the unit will invalidate this Warranty. Should your unit develop a defect
or otherwise fail to perform in accordance with this warranty, you should contact the retailer from whom the product was
originally purchased.
Implied Warranties: The implied at-law warranties of merchantability and tness for a particular purpose shall
terminate on the date one year after the date of purchase. Note: some states do not allow limitations on how long an
implied warranty lasts, so the above limitations may not apply to you.
Other Rights: This Warranty gives you specic legal rights and you may also have other rights which vary from state
to state.
06. PELICAN PRO-RO 6 Instruction Manual

Performance Data Sheet
This system has been tested according to NSF/ANSI 58 for reduction of the substances listed below. The concentration of
the indicated substances in water leaving the system was reduced to a concentration less than or equal to the permissible
limit for water leaving the system, as specied in NSF/ANSI 58. Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the system. Systems certied for cyst reduction may be used
on disinfected water that may contain lterable cysts.
This system has been tested for the treatment of water containing pentavalent arsenic (also known as AS(V), As +5, or
arsenate) at concentrations of </= 300 ppb. This system reduces pentavalent arsenic, but may not reduce other forms of
arsenic. This system is to be used on water supplies containing a detectable free chlorine residual at the system outlet or
on water supplies that have been demonstrated to contain only pentavalent arsenic. Treatment with chloramine (combined
chlorine) is not sufcient to ensure complete conversion of trivalent arsenic to pentavalent arsenic. Please see the Arsenic
Facts section of the Performance Data Sheet for further information.
Testing was performed under standard laboratory conditions, actual performance may vary. Incoming water must be free
of potential membrane foulants such as Iron, Hydrogen Sulde and Manganese. Efciency rating means the percentage
of the influent water to the system that is available to the user as reverse osmosis treated water under operating conditions
that approximate typical daily usage.Recovery rating means the percentage of the influent water to the membrane portion
of the system that is available to the user as reverse osmosis treated water when the system is operated without a storage
tank or when the storage tank is bypassed.
This reverse osmosis system contains a replaceable component critical to the efciency of the system. Replacement of the
reverse osmosis component should be with one of identical specications, as dened by the manufacturer, to ensure the
same efciency and contaminant reduction performance. Feed water conditions may affect replacement intervals.
System Performance
System Maintenance
Model Number: PRO-RO Avg Daily Production Rate: 67.76 L/d (17.9 gpd)
Avg. Recovery: 30.7% Avg Efciency: 17.8%
Temperature: 4℃-38℃(40 ℉-100 ℉) Pressure: 2.81-5.62 kg/cm2(40-80 psi)
Influent
Challenge
Concentration
Maximum
Allowable
Concentration
Actual
Minimum %
Reduction
Average
Percent
Reduction
Arsenic (pentavalent) 50 ppb 10 ppb 98.1 99.0
Barium 10.0mg/L±10% 2.0 mg/L 95.0 98.8
Cadmium 0.03 mg/L±10% 0.005 mg/L 94.0 98.3
Chromium6 (Hexavalent) 0.3 mg/L±10% 0.1 mg/L 95.5 98.3
Chromium 3 (Trivalent) 0.3 mg/L±10% 0.1 mg/L 98.4 99.0
Copper 3.0 mg/L±10% 1.3 mg/L 95.0 98.4
Cysts Min 50,000/mL 110 counts/mL >99.99 >99.99
Fluoride 8.0 mL±10% 1.5 mL 87.0 93.8
Lead 0.15 mL±25% 0.010 mL 90.4 96.8
Radium 226/228 25 pCi/L±10% 5 pCi/L 95.0 98.8
Selenium 0.10 mg/ L±10% 0.05 mg/L 94.4 97. 9
Turbidity 11±1NTU 0.5 NTU 96.4 98.7
TDS (Total Dissolved Solids) 740mL 187 mL 86.6 93.1
Part Number Description Replacement Interval
104863 TF50, 4 stage cartridge 12 months
104851 5th stage inline post lter 6-12 months
.07
PELICAN PRO-RO 6 Instruction Manual

Arsenic Fact Sheet
Arsenic (AS) is a natually occuring contaminant found in many ground waters. Arsenic in water has no color, taste or odor.
It must be measured by a lab test. Public water utilities must have their water tested for arsenic. You can get the results
from your water utility. If you have your own well, you can have the water tested. The local health department or the state
environmental health agency can provide a list of certied labs. The cost is typically $15 to $30. Information about arsenic
in water can be found on the Internet at the US Environmental Protection Agency website: www.epa.gov/safewater/arse-
nic.html.
There are two forms of arsenic: pentavalent arsenic (also called AS(V), As +5 , and arsenate) and trivalent arsenic (also
called AS(III), As+3, and arsenite). In well water, arsenic may be pentavalent, trivalent, or a combination of both. Special
sampling procedures are needed for a lab to determine what type and how much of each type of arsenic is in the water.
Check with the labs in your area to see if they can provide this type of service.
Reverse osmosis (RO) water treatment systems are very effective at removing pentavalent arsenic. RO systems do not
remove trivalent arsenic from water very well. A free chlorine residual will rapidly convert trivalent arsenic to pentavalent
arsenic. Other water treatment chemicals such as ozone and potassium permanganate will also change trivalent arsenic to
pentavalent arsenic. A combined chlorine residual (also called chloramine) may not convert all the trivalent arsenic. If you
get your water from a public water utility, contact the utility to nd out if free chlorine or combined chlorine is used in the
water system.
The PRO-RO system is designed to remove pentavalent arsenic. It will not convert trivalent arsenic to pentavalent arsenic.
The system was tested in a lab. Under those conditions, the system reduced 300 ppb pentavalent arsenic to 10 ppb (the
USEPA standard for drinking water) or less. The performance of the system may be different at your installation. Have the
water tested for arsenic to check if the system is working properly.
The RO component of the PRO-RO system must be replaced yearly to ensure the system will continue to remove pentava-
lent arsenic. The component identication and location where you can purchase the component are listed in the installa-
tion/operation manual.
08. PELICAN PRO-RO 6 Instruction Manual

A
B
J
E
F
G
D
K
LM
I
H
C
System Specifications
A. Product water storage tank
B. Tank valve
C. Tank tubing (3/8 〃white)
D. Air-gap faucet
E. Drain connection assembly
F. Drain tubing (3/8 〃white)
G. Quick connect tting
H. Drain tubing (1/4〃black)
I. Faucet tubing (3/8 〃blue)
J. Four-stage desalinator
K. Feed water tubing (1/4〃green)
L. Feed valve assembly (with adapter and
shut-off valve).
M. Two-stage remineralizing post-lter
This system has been designed for installation by a licensed professional such as a contractor or plumber. Proper completion
of this installation will require basic familiarity with standard sink plumbing and proper use of common hand and power tools.
Improperly installed systems could result in water damage due to leaks or flooding.
System Dimensions
9.72〃W×13.75 〃D×15.38 〃H
( 24.7×34.9×39.1 cm), 11 lbs. (5 kg.)
Dimensions and Weight
Performance Specifications Feed Water Requirements
Membrane Production 50 GPD
System
Production 14.61GPD
TDS Rejection 96.5%
Recovery126.76%
System tested at 50 psig, 750ppm TDS at 77°F.
1 The percentage of the feed water available
as reverse osmosis treated water under
normal operating conditions.
Pressure 40-80 psi (275 kPa-552 kPa)
Temp 40°F-100°F (4°C-38°C)
TDS <2000 mg/L
Chlorine <1.0 mg/L
Turbidity <1 NTU
SDI <5
pH 4-8
Feed water must be potable, municipal water. Must
be free of potential membrane foulants such as Iron,
Hydrogen Sulfide and Manganese.
Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection
before or after the system.
(behind cover)
(not shown)
.09
PELICAN PRO-RO 6 Instruction Manual

10. PELICAN PRO-RO 6 Instruction Manual
1. Drill a 1 1/4〃hole for installation of the air-gap faucet on your
countertop. If you already have a hole large enough, please see
step 2.
2. Place the RO unit underneath the sink in the area you plan on
having it for the nal installation.
3. Place the rubber seal onto base of faucet, tting around the
faucet barbs.
4. Put the faucet stem down through the countertop hole.
5. From underneath the sink, slide the large washer, and the
white plastic spacer, open end up, onto the threaded faucet stem,
tting around the faucet barbs.
6. Place the lock washer onto the faucet stem. Thread the lock
nut onto the faucet stem.
7. Orient the faucet on the countertop and then securely tighten
the lock nut.
8. Push the 3/8 〃white tubing onto the 3/8 〃tting (larger barb)
located on the faucet base. See Fig. 2.
9. Push the 1/4 〃black drain tubing, attached to the system, onto
the 1/4 〃tting (smaller barb) located on the faucet base.
10. Thread the faucet quick-connect adapter, located in the system
parts bag, onto the end of the the faucet stem.
11. Firmly push the end of the 3/8" blue tubing into this 3/8"
adapter.
Running the black and white tubing under
warm water for 2-3 minutes will soften the
tubing and allow for easier installation on the
two air-gap barbs.
NOTE
Faucet Installation
The white tubing provided is typically longer
than is required for your installation. Be sure
to cut the white tubing to the proper length
to reach the drain installation (see following
page). Discard any excess tubing.
NOTE
This connection should be hand-tightened only.
NOTE
Escutcheon
(attached)
Large
washer
Spacer
Lock washer
Lock nut
Faucet
connector
Small barb,
1/4 〃black tubing
Large barb,
3/8 〃white tubing
Fig 2: Closeup of faucet barbs
Rubber seal
Countertop Countertop
Fig 1: Faucet and fittings

.11
PELICAN PRO-RO 6 Instruction Manual
Feed and Drain Connection
1. Locate and turn off the angle stop valve on the cold water line feeding the sink.
This valve will usually be located under the sink on the pipe coming out of the wall.
2. When the angle stop valve is closed, relieve pressure in the line by momentarily
opening the cold water tap on the sink.
3. Disconnect the cold water faucet feed line at the angle stop valve.
4. Install the feed valve assembly into the angle stop. (Fig. 1)
5. Firmly press the green 1/4〃tubing into the 1/4 〃connector on the feed valve assembly.
6. Connect the cold water faucet feed line into the feed valve assembly.
7. Make sure the small shut-off valve on the feed valve assembly is closed. Turn on
the feed water connection valve. Check for leaks.
8. Attach the small feed valve warning tag from the parts bag to the feed valve.
9. Attach the Shutoff Warning label to the system so that it is directly visible. Fill out
the Date of Installation label and attach to the side of the system.
1. You will need an electric drill with a 3/8 〃bit and a screwdriver for this portion of
the installation.
2. Obtain the drain saddle assembly, two 1 ½〃bolts, two 3/8 〃hex nuts, and the
small adhesive foam pad from the small parts bag (Fig. 2).
3. Place the adhesive foam pad on the inside of the the drain saddle front, aligning
the holes.
4. Position the drain saddle on the drain pipe under the sink between the “P”trap
and the sink connection. Orient the drain saddle so that the opening is on the
side of the drain pipe.
5. Using the bolts and hex nuts, hand tighten the saddle bracket evenly until the
saddle grips the pipe snugly. Use a Phillips screwdriver to fully tighten the bolts.
Do not overtighten.
6. If necessary, remove the drain saddle connector nut from the opening of the
drain saddle. Using the connector opening in the side of the drain saddle as a
guide, drill a 3/8" hole through the wall of the drain pipe.
7. Extend the drain tubing from the RO dispensing faucet to the drain saddle and
measure for length. The tubing must be routed so that water can run downhill for
the entire length of the tubing from the faucet. Avoid low spots or loops. Cut the
tubing shorter, if necessary.
8. Insert the drain tube from the R.O. dispensing faucet through the drain saddle
connector nut. Tighten the connector nut onto the drain saddle.
Feed Connection
Drain Connection
Fig. 2
Fig. 1
The drain saddle assembly must be
installed before the 'P' trap. Do not
install the drain saddle assembly
between the 'P' trap and the wall.
The feed valve adapter may be
congured to t either a 3/8" or 1/2"
angle stop connection by changing
the location of the adapter.
NOTE
NOTE
Shut-off valve
Angle stop
Adapter

12. PELICAN PRO-RO 6 Instruction Manual
1. Check all tubing connections to ensure they are rmly seated. CHECK TO SEE THAT THE CARTRIDGE RETAINER
CLIP IS PROPERLY ENGAGED AND LOCKED. Failure to keep the retaining clip in place will result in accidental leaks
and flooding.
2. Open the dispensing faucet at the sink. Close the tank shut-off valve. Make sure the feed valve for the incoming water
is open. Open the small feed shut-off valve on the green feed line.
3. Observe all tubing and connections for several minutes to detect any leaks. In approximately 5 minutes, (assuming
normal feed water pressure) the dispensing faucet should begin dripping.
4. Allow the faucet to run for up to 15 minutes, then close the faucet.
5. Check for leaks at all connections.
6. Open the tank shut-off valve.
1. Before the system can be used for drinking water production it must be adequately flushed. Each reservoir tank is
dosed with a small amount of powdered sanitizer before shipment, typically a chlorinating agent, in order to ensure tank
internal cleanliness. Also, the carbon lter cartridge will release a small amount of carbon nes during the rst tankful of
flow. This flushing procedure will allow any sanitizer or carbon nes to pass from the system.
2. Initial tank lling will take approximately one hour (based on average feed pressure). When the tank is full, the water
pressure will have risen to the point where the automatic shut-off valve inside the system will stop the feed flow through
the system. Actuation of the automatic shut-off valve can be determined by either checking for a lack of brine flow to the
drain saddle, or by listening very closely near the dispensing faucet for absence of water flow sound though the air gap.
When the tank has lled for the rst time, it should be left undisturbed for at least 8 hours to ensure proper sanitization.
3. After 8 hours has elapsed, open the dispensing faucet fully and allow the product water to run out to drain at maximum
flow. The initial discharge will be dark with the bulk of the carbon particle wash out. There may also be the scent of chlo-
rinated water from the sanitizing agent. When the flow has diminished to a fast drip or small stream, close the dispensing
faucet.
4. Fill and flush the tank at least three times prior to use. If necessary, repeat until the chlorination scent has disappeared.
It is important that the flush be done at maximum flow (e.g. the tank must be full) to assist in rapid wash out. After this
flushing procedure the system is ready for normal use.
System Activation and Inspection
Initial Flushing Procedure
System Activation and Flushing

.13
PELICAN PRO-RO 6 Instruction Manual
Installation Checklist
Maintenance
1. System is located where it will not be subject to physical impacts or rough contact by heavy objects.
2. Feed water pressure to the unit is no less than 40 psi and no greater than 80 PSI.
3. Ensure the plastic retainer clip that holds the desalinator cartridge in place is fully engaged and locked in place. The
slide locks must snap into place in the slots. If the clip does not snap easily into place through the slots it means the
cartridge is not fully inserted into the connectors. Press top or bottom of cartridge to engage connectors until it snaps
into place properly.
4. All tubing connections, especially push-in quick connections, are fully inserted.
5. Tubing connected between the faucet and the drain saddle tting (the tting attached to the sink drain pipe) runs "down-
hill〃 to the drain. There should be no loops or places where water would not flow out to the drain.
6. Feed water valve is open.
7. Within one to two hours after initial application of water pressure, check again for leaks especially at the tank, faucet tub-
ing and connectors. These parts will not see full pressure until approximately 2 hours after the system is activated.
8. Flush three tankfuls of product water to drain. If a chlorine scent persists, repeat flushing procedure.
1. Close the small shut-off valve on the feed valve assembly.
2. Close the tank shut-off valve.
3. Open the dispensing faucet to relieve system pressure. Close dispensing faucet when flow has stopped.
4. Remove the cover from the front of the system. Remove the retaining clip. Pull the cartridge off the system evenly at
top and bottom. Dispose of used cartridge.
5. Install the new cartridge, rocking gently from side to side as necessary until the cartridge tubes are properly engaged in
the unit connectors. Install the retaining clip, ensuring the slide locks snap into place in the slots. If the clip does not
snap easily into place through the slots it means the cartridge is not fully inserted into the connectors. Press the top or
bottom of the cartridge to engage the connector so that it snaps fully into place. Failure to properly install the retaining
clip will result in accidental leaks and flooding.
6. Open the small shut-off valve on the feed valve assembly. Open the dispensing faucet.
7. Close dispensing faucet after water starts running.
8. Observe system for any leaks, especially at newly re placed cartridge.
9. Open the tank shut-off valve.
10. The system should be flushed at least once as described above under Section 8.
Cartridge Replacement

14. PELICAN PRO-RO 6 Instruction Manual
1. Close the small shut-off valve on the feed valve assembly.
2. Close the tank shut-off valve.
3. Open the dispensing faucet.
4. Close the dispensing faucet when the water stops flowing.
5. Locate the inline lter on the faucet line.
6. Remove the tubing by depressing the collet towards the lter and pulling the blue tubing from the lter.
7. Remove the other side of the blue tubing as described above.
8. Reverse the above steps to install the new inline lter, making sure that the tubing is pressed in as far as possible.
9. Open the small shut-off valve on the feed valve assembly. Observe system for any leaks, especially at newly re placed
cartridge.
10. Open the tank shut-off valve.
11. The system should be flushed at least once as described in System Activation and Flushing.
Please ll out the following information at the time of installation. Save for future reference.
Post Filter Replacement
Model:
Date Code:
Install Date:
Sold by:
Installed By:
Service Center
Phone Number:
Pelican PRO-RO

.15
湃能 PRO-RO 6 使用说明书
湃能全屋水管家向原始购买者（在正常使用情况下）保证：自购买之日起一年内，所有产品和部件的材料和工艺
均不存在缺陷。任何更换的产品在原始保修期的剩余保修时间内或 30 天内（以较长的时间为准）在材料和制造
工艺上均不存在缺陷。本保修不包括：（1）上述时间内未报告的产品缺陷，（2）未遵守湃能水系统操作说明引起
的问题，（3）非湃能全屋水管家的其他方造成的自然灾害、滥用、误用、疏忽或意外而引起的问题或损害，（4）全
部或部分由于非湃能全屋水管家的任何一方的变更、修改、修理或企图改装而导致的问题或损害，（ 5）不遵守适
用的守则或条例。
如果出现保修范围内产品或部件的工艺或材料缺陷，湃能全屋水管家将自行决定维修或更换有缺陷的产品或部件
（ 我 们 会 认 真 考 虑 客 户 的 喜 好 ）。
所有声称有缺陷的产品必须：（1）由湃能全屋水管家授权 RGA 退回编号（2）退回产品或零件购买日期的证明（3）
在保修期届满之前退回湃能全屋水管家，由客户自付运费（4）用纸条附上产品型号、序列号（如果有的话）以及产
品问题。
在适用法律允许的最大范围内，湃能全屋水管家拒绝承担所有其他明示或默示保证，包括但不限于就产品、部件
和相关随附书面材料对适销性和特定用途适用性的默示保证。
在适用法律允许的最大范围内，湃能全屋水管家不承担因使用或无法使用有缺陷产品或部件而带来的任何损失（包
括但不限于因移除或更换产品或部件而产生的时间、不便、费用、劳力或材料费，人身受到特殊、意外、后果性或
间接损失，业务利润损失，业务中断，商业信息丢失或任何其他金钱损失），即使湃能全屋水管家已被告知可能发
生此类损失。
湃能全屋水管家在本有限保修条款下的最大赔偿金不高于产品或部件实际支付的金额。
如果湃能净水器在水压 2-7bar 和温度 4-38℃下运行，则此保修有效。不得因任何异常的自然力量（如飓风、洪水、
地震或龙卷风）而导致本系统被错误对待、修改、疏忽、冻结，粗心对待或损坏。如果由于材料短缺、政府监管、罢
工或任何其他不可控的情况造成保证人未能履行其保修义务，则保证人可以免责。
保修书
湃能 RO 反渗透矿泉水系统一年有限保修期
保证人：湃能全屋水管家

16. 湃能 PRO-RO 6 使用说明书
专业级反渗透矿泉水系统简介
感谢您购买了专业级六阶段反渗透矿泉水系统。专业级反渗透矿泉水系统的滤芯内设一个四阶段前置过滤器、过滤膜和后置
过滤器。剩余两阶段为颗粒活性炭精过滤和方解石再矿化过滤。
如果维护得当，本系统能多年无故障运作。下一节内容为如何正确保养和维护系统，请您花几分钟时间阅读这些重要信息。
必须定期更换本系统中的滤芯，以确保过滤效率高，水质好。系统内所有滤芯共同工作，必须每 6-12 个月更换一次。发现任何
系统性能上的重大变化应立即查看，确保不发生二次损坏或系统其他部分受损。
通常情况下，每年更换一次过滤器时同时需更换反渗透膜。但是如果您在任何时候注意到产水量减少或水流有异味，则可能
需要更换反渗透膜。我们建议在总溶解固体物指数降至 85％以下时更换反渗透膜。
系统安装不正确会因泄漏或溢水而导致其他物品的损坏。正确安装该系统需熟悉水槽管道标准及普通手动和电动工
具的正确使用方法。如果您不熟悉这些，或者在安装本系统时遇到任何困难，请咨询有执照的专业人员，如承包商或
水管工。
本系统及其安装必须符合所在地区的法律法规。
提醒
注意
阶段 描述 更换时间 组件编号
1-4
4 阶段过滤器
1. 20 微米沉淀前置过滤器
2. 颗粒活性炭（GAC）前置过滤器
3. 反渗透膜
4. 颗粒活性炭后置过滤器
18 个月 104863
5-6 颗粒活性炭（GAC）和方解石（再矿化）过滤器 6-12 个月 104851

.17
湃能 PRO-RO 6 使用说明书
产品性能数据表
本系统经过性能数据表 NSF / ANSI 标准 58 对下列物质进行过滤程度的测试。根据 NSF / ANSI 58 检测结果，本系统过滤的水
所含有的指定物质浓度有所降低，降至小于或等于过滤系统过滤水的浓度允许值。在使用系统前后不要使用不健康或水质未
知未消毒的水。经认证用于囊孢减量的过滤系统适用于过滤可能含有可过滤性囊孢的消毒水。
该系统进行了浓度小于或等于 300 十亿分率的含五价砷（也称为 AS（V），As + 5 或砷酸盐）水的过滤测试。该系统可以降低
五价砷的含量，但没有过滤掉其他形式的砷。该系统用于过滤检测到含有游离氯残留物的系统出水口水源或已证实仅含有五
价砷的水源。使用氯胺（化合氯）不足以完全确保三价砷能转化为五价砷。请参阅性能数据表的砷含量了解更多信息。
过滤测试在标准实验室条件下进行，与实际性能可能会有所不同。进水中必须不含潜在的膜污染物，如铁、硫化氢和锰。过滤
效率是指在接近日常使用条件下，进水比可供用户使用的反渗透水的百分比。回收率是指当系统在没有储水箱或储水箱与旁
通管的情况下运行时，反渗透水比可供用户使用的过滤系统膜部分进水的百分比。
本反渗透系统含有可更换部件，能有效提高系统效率。反渗透矿泉水系统更换的组件应采用制造商规定的相同规格之一，以确
保达到相同的系统效率，降低污染物。进水的水质可能会影响更换周期。
系统性能
系统维护
模型编号：PRO-RO 平均每日生产率：67.76
平均回收率：30.7% 平均过滤效率：17.8%
温度：4°C - 38°C (40°F - 100°F) 压强：2.81-5.62 千克 / 平方厘米（40-80 磅 / 平方英寸）
进水浓度范围 最大允许浓度范围 实际最小减少百分比 平均减少百分比
砷（五 价） 50 十亿分率 10 十亿分率 98.1 99.0
钡10.0 毫克 / 升 ± 10% 2.0 毫克 / 升 95.0 98.8
镉0.03 毫克 / 升 ± 10% 0.005 毫克 / 升 94.0 98.3
铬 6（六 价） 0.3 毫克 / 升 ± 10% 0.1 毫克 / 升 95.5 98.3
铬 3（三 价） 0.3 毫克 / 升 ± 10% 0.1 毫克 / 升 98.4 99.0
铜3.0 毫克 / 升 ± 10% 1.3 毫克 / 升 95.0 98.4
囊孢 最小 5000 每毫升 110 每毫升计数 >99.99 >99.99
氟化物 8.0 毫克 / 升 ± 10% 1.5 毫升 87.0 93.8
铅0.15 毫克 / 升 ± 10% 0.010 毫升 90.4 96.8
镭25 皮居里 / 升 ± 10% 5 皮居里 / 升 95.0 98.8
硒0.10 毫克 / 升 ± 10% 0.05 毫克 / 升 94.4 97.9
浊度 11 ± 1 浊度 0.5 浊度 96.4 98.7
总 溶 解 固 体 物（T D S） 740 毫升 187 毫升 86.6 93.1
组件编号 内容描述 更换周期
104863 TF50，4 阶段滤芯 12 个月
104851 第五阶段内嵌后置过滤器 6-12 个月

18. 湃能 PRO-RO 6 使用说明书
砷物质概况说明
砷（AS）是大部分地下水中都会发现的一种污染物，这种砷自然产生、无色无味，须通过实验来检测衡量。公用事业单位必须
对所供的水进行砷测试，您可以从他们那拿到检测结果。如果您有自己的取水井，你可以进行水体砷测试，当地卫生部门或环
境卫生机构可以提供经认证的实验检测，费用通常是 15 美元到 30 美元之间。有关水中砷物质的信息可以在美国环境保护署
的网站上找到：www.epa.gov/safewater/arse?nic.html。
砷物质有两种形式：五价砷（也称为 AS（V），As + 5 和砷酸盐）和三价砷（也称为 AS（III），As + 3 和亚砷酸盐）。 井水中可以
有五价砷、三价砷或者都有。实验室需进行特殊的取样程序来确定水中各类砷的类型和含量。请咨询您所在地区的实验室是
否可以提供此类服务。
反渗透（RO）水处理系统能高效去除五价砷，但在去除水中三价砷方面较弱。残留的游离氯会迅速将三价砷转化为五价砷。其
他水处理化学品，如臭氧和高锰酸钾，也会将三价砷转化为五价砷。残留的氯化合物（也称为氯胺）可能不会转化所有的三价砷。
如果您是自来水厂供水，请联系自来水厂查看水系统中是否使用了游离氯或化合氯。
专业级反渗透系统旨在去除五价砷，不会将三价砷转化为五价砷。该系统在实验室进行了测试。在实验条件下，专业级反渗透
矿泉水系统将五价砷的含量从 300 十亿分率降至 10 十亿分率（美国环境保护局饮用水标准）及以下。安装时反渗透系统的性
能可能会有所不同。检测砷含量以确保系统正常工作。
专业级反渗透系统的反渗透组件必须每年更换一次，才能确保系统持续有效地去除五价砷。安装 / 操作手册中列出了组件标
识和组件购买点。

.19
湃能 PRO-RO 6 使用说明书
系统规格
A
B
J
E
F
G
D
K
LM
I
H
C
A. 产品储水箱
B. 储水箱阀门
C . 储 水 箱 水 管（3 / 8 英 寸 白 色）
D. 气隔式水龙头
E. 排水管接头
F. 排 水 管（3 / 8 英 寸 白 色）
G. 快速连接管件
H . 排 水 管（1 / 4 英 寸 黑 色）
I . 水 龙 头 管（3 / 8 英 寸 蓝 色）
J. 四阶段淡化器
K . 进 水 管（1 / 4 英 寸 绿 色 ）
L. 进水阀组件（带适配器和关闭阀）
M. 二阶段再矿化后置过滤器
9.72 英寸宽 ×13.75 英寸长 ×15.38 英寸高
（24.7 x 34.9 x 39.1 厘米），11 磅 （5 公斤）
尺寸和重量
系统尺寸
性能规格 进水要求
过滤盖下方
未画出
本系统专为承包商或管道工等专业人士安装系统而设计的。正确完成安装需要对标准水槽管道和普通手动和电动工具的正
确使用方法熟悉。错误安装的系统可能会因泄漏或溢水而导致其他物品因水损坏。
在使用系统前后请勿使用不健康或水质未知未消毒的水
膜产出量 50 加仑 / 日
系统
产出 14.61 加仑 / 日
总溶解固体物过滤率 96.5%
回收率 1 26.76%
本系统在 77 华氏度，50 磅 / 平方时表压，总溶解固
体物 750 百万分率下经测试。
在系统正常运作下进水转为反渗透处理水的百分比。
压强
温度
总溶解固体物
氯
浊度
污染指数
pH 值
进水必须是可饮用的政府用水。必须不含潜在的膜
污 染 物 ，如 铁 、硫 化 氢 和 锰 。
40-80磅/平方英尺
（275 千帕 -552 千帕）
40 华氏度 -100 华氏度
（4 摄氏度 -38 摄氏度）
<2000 毫克 / 升
<1.0 毫克 / 升
<1 浊度
<5
4-8
