Pelonis FW23-A1 User manual

9” TWIN WINDOW FAN
MODEL: FW23-A1
SKU: 18859843
READ AND SAVE THESE INSTRUCTIONS
OWNER’S MANUAL

Read Rules for Safe Operation and Instructions Carefully.
1. To reduce the risk of fire or electric shock, do not use this fan with any solid-state
speed control device.
2. This appliance has a polarized plug (one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended to fit in a polarized outlet only one
way. If plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not attempt to defeat this safety feature.
3. Do not leave the fan running unattended.
4. Please make sure the voltage of the power supply is the same as shown on the
fan nameplate.
When using electrical appliances, basic precautions should always be followed to
reduce the risk of fire, electric shock and injury to persons, including the following:
1．The rules about cord and plug as below:
(1) This product employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing instructions (follow
product marking for proper fuse rating) and check the products. If the
replacement fuse blows, a short-circuit may be present and the product should
be discarded or returned to an authorized service facility for examination and/
or repair.
(2) Do not operate any fan with a damaged cord or plug. Discard fan or return to
an authorized service facility for examination and/or repair.
(3) Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be tripped over.
2. Never insert fingers, pencils, or any other object through the grille when fan is
running.
3. Disconnect fan when moving from one location to another, before putting on or
taking off parts.
4. Disconnect fan when removing grilles for cleaning.
5. Do not operate in the presence of explosive and/or flammable fumes.
6. Do not place fan or any parts near an open flame, cooking or other heating
appliance.
7. Always use on a dry, level surface, do not use outdoors.
8. Do not let the cord hang over the edge of a table, counter, or come in contact
with hot surfaces.
9. To disconnect grip plug and pull from wall outlet. Never yank on cord.
1
CAUTION
WARNING
RULES FOR SAFE OPERATION

2
INSTALLATION INSTRUCTION
This window fan comes fully assembled and is
ready for immediate installation.
This window fan has been designed to fit
double-hung, slider and casement windows with
minimum openings of 24” Wide and 13” high.
This fan is designed and recommended for used
with your window screen in place.
1. Make sure rotary switches are
in the OFF position.
2. Plug into 120V AC electric outlet.
3. Set the individual fan motors on
either IN, OUT or EXCH using
the control lever.
4. Turn the Thermostat Control to
its highest setting (fully clockwise).
5. To start the unit turn the rotary switches to desired speed.
6. While the window fan is on, turn the Thermostat Control counter-clockwise
towards the smaller dots until the fan stops (Away from Cooler ). This is the
selected comfort level.
7. If the fan is stopped and you want to turn it back on, turn the Thermostat
Control clockwise until the fan starts, towards the larger dots (Towards Cooler).
OPERATING INSTRUCTIONS
USER SERVICING INSTRUCTIONS
1. Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord.
2. Open fuse cover. Slide open fuse access cover on top of
attachment plug towards blades.
3. Remove fuse carefully. Push the fuse from the other side or turn fuseholder
over to remove fuse.
4. Risk of fire. Replace fuse only with 2.5 Amp, 125 Volt fuse (provided with
product.)
5. Close fuse cover. Slide closed the fuse access cover on top of attachment plug.
6. Risk of fire. Do not replace attachment plug. Contains a safety device (fuse)
that should not be removed. Discard product if the attachment plug is damaged.
Notice: 1. When you replace fuse, please don’t operate suddenly or overexert, or
else the product will be damaged or cause accident.
2. When you feel it hard to be operated, please make sure you have got the
right way.

3
The fan requires little maintenance. Do not try to fix it by yourself. Refer it to
qualified service personnel if service is needed.
1. Before cleaning and assembling, do not plug the pins into the socket.
2. To ensure adequate air circulation to the motor. Keep vents at the rear of the
motor housing from dust, fluff and etc. A vancuum cleaner can not be used to
clean these vents before unplug. Do not disassemble the fan remove fluff.
3. Please wipe the exterior parts with a soft cloth soaking a mild detergent.
Do not use any abrasive detergent or solvents to avoid scratching the sufrace.
Do not use of the following as a cleaner: gasoline, thinner, bending.
4. Do not allow water or any other liquid into the motor housing or interior parts.
CLEANING
MAINTENANCE INSTRUCTION
1. Be sure to unplug the power cord from the outlet before cleaning.
2. Plastic parts should be cleaned with mild soap and damp cloth or sponge.
Thoroughly remove soap film with clean water.
3. Be sure not to get water or other liquid enter the inside of the motor.
4. Dry all parts completely before reassembling and reconnecting to power
source.
PRINTED IN CHINA

4
SERVICE & SUPPORT
In the event of a warranty claim or if service is required for this fan, please contact us at the
following:
Tel: [phone]
For questions or comments, please write to:
Midea America Corp.
Att: Warranty Department
11800 NW 100th Rd., Suite 4
Medley, FL 33178 USA
For your records, staple your sales receipt to this manual and record the following:
DATE OF PURCHASE:_____________________________________________
PLACE OF PURCHASE:____________________________________________
SERIAL NUMBER:________________________________________________
(STAPLE SALES RECEIPT HERE)
NOTE: PROOF OF PURCHASE IS REQUIRED FOR
ALL WARRANTY CLAIMS
