OWNER’S MANUAL
16" Oscillating Table Fan
READ AND SAVE THESE INSTRUCTIONS

CAUTION
Read Rules for Safe Operation and Instructions Carefully.
WARNING
1. To reduce the risk of fire or electric shock, do not use this fan with any solid
state speed control device.
2. This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit in a polarized
outlet only one way. If plug does not fit fully in the outlet, reverse plug. If it
still does not fit, contact a qualified electrician. Do not attempt to defeat this
safely feature.
3. Do not leave the fan running unattended.
RULES FOR SAFE OPERATION
1. Fan should be used under rated voltage.
2. Connect power after the fan be fully assembled.
3. Never insert fingers, pencils, or any other object through the guard when fan is
running.
4. Unplug from outlet when not in use. When moving fan from one location to
another before putting on or taking off parts and before cleaning.
5. Disconnect fan when removing grilles for cleaning.
6. Be sure fan is on a stable surface when operating to avoid overturning.
7. DO NOT use fan in window. Rain may create electrical hazard.
8. The rules about cord and plug as below:
(1) This product employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing instructions (follow
product marking for proper fuse rating) and check the products. If the
replacement fuse blows, a short-circuit may be present and the product
should be discarded or returned to an authorized service facility for
examination and/ or repair.
(2) Do not operate any fan with a damaged cord or plug. Discard fan or return to
an authorized service facility for examination and/or repair.
(3) Do not run cord under carpeting. Do not cover cord with throw rugs, runners,
or similar coverings. Do not route cord under furniture or appliances.Arrange
cord away from traffic area and where it will not be tripped over.
1

PARTS NAME
BASE ASSEMBLY
1. Detach screw from base of the fan.
2. Match locking tab to base and click into position.
3. Tighten the screw in the base to secure the fan to the base.
ASSEMBLY OF BLADE AND GRILLS
1. Take the spinner from the instruction manual bag and unscrew the plastic nut
counter-clockwise to remove it.
2. Set the rear grill in the proper position with the handle up.
3. Screw on plastic nut tightly to attach grill.
4. Install the blade onto the shaft until the retaining pin fits into the notch on
the blade.
5. Screw spinner on to motor shaft counterclockwise.
6. Mount the Front Grill and join both Grills together using the Clips.
OPERATION INSTRUCTION
Speed control
Speed is controlled by the button switch or rotary switch
Off-Off L--Low M--Medium H--High
Oscillation control
To make the fan oscillate, push down on the oscillation knob located on the top
of the motor housing. To stop the fan down from oscillating in the position desired,
push on the oscillating knob once more.
Alternative, there is a oscillation switch on the fan body, push down the switch,
you can also make the fan oscillate.
Tilting control
The airflow can be adjusted upward or downward by tilting the fan head to a
vertical angle as desired.
Base
Front Guard
Blade
Plastic Nut
Rear Guard
Motor Shaft Oscillating
Fan Body
Piano-key
Spinner
unscrew
2

a) Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord.
b) Open fuse cover. Slide open fuse access cover on
top of attachment plug towards blades.
c) Remove fuse carefully. Insert the tip of your tool into
fuse slot (close with the terminal), then prize the fuse
gradually and slowly, but not overexert. If you feel tight,
you can try it at several times and prize the fuse little by little. When one side of
the fuse has been prized, then you can get the fuse out entirely.
d) Risk of fire. Replace fuse only with 2.5 Amp, 125 Volt fuse.
e) Close fuse cover. Slide closed the fuse access cover on top of attachment plug.
f) Risk of fire. Do not replace attachment plug. Contains a safety device (fuse)
that should not be removed. Discard product if the attachment plug is damaged.
Notice:
1. When you replace the fuse, please don’t operate suddenly or overexert, or else
the product will be damage or cause accident.
2. When you feel it hard to be operated, please make sure you have got the right
way.
USER SERVICING INSTRUCTIONS
1. Be sure to unplug from the electrical supply source before cleaning.
2. Plastic parts should be cleaned with mild soap and damp cloth or sponge.
Thoroughly remove soap film with clean water.
3. Be sure not to make water or other liquid into the motor.
PRINTED IN CHINA
CLEANING
