Pelstar Health o meter Professional PORTROD User manual

PORTROD
WALL MOUNTED HEIGHT ROD
USER INSTRUCTIONS
P/N UMPORTROD Rev 1-052112
1

PORTROD
Thank you for your purchase of this Health o meter® Professional product. Please read this manual
r training.
TABLE OF CONTENTS
carefully, and keep it for easy reference o
CAUTIONS AND WARNINGS...............................................................................................3
SPECIFICATIONS ................................................................................................................3
CERTIFICATIONS / DISPOSAL / SERVICE.........................................................................4
WALL MOUNT INSTRUCTIONS...........................................................................................5
HEIGHT MEASUREMENT INSTRUCTIONS........................................................................10
MAINTENANCE ....................................................................................................................11
WARRANTY..........................................................................................................................12
Please register your product for warranty coverage at:
http://www.homscales.com/customer/registration.aspx
For User Instructions updates and revisions please go to:
http://www.homscales.com
2

3
CAUTIONS AND WARNINGS
To prevent injury and damage to your product, please follow these instructions very carefully.
Do not transport the PORTROD while the headpiece is attached.
Be sure the PORTROD is placed on a flat, stable surface when it is being cleaned or being assembled.
For accurate measurement, the PORTROD must be placed on a stable wall surface.
For accurate measurement, verify proper operation according to the procedure described in this manual
before each use.
Do not use in the presence of flammable materials.
When not in use, raise headpiece to a high position, or have it removed and stored.
When wall mounting the PORTROD, ensure that the mounting location is free of electrical lines, gas pipes,
and other safety hazards. Ensure that wall is of construction that can support the PORTROD.
SPECIFICATIONS
GENERAL
The PORTROD Wall Mounted Height Rod has a large headpiece and features a clear indicator, which allows
for accurate measurement of a patient’s height. Each PORTROD is designed to provide accurate, reliable, and
repeatable height measurements, and includes features that make the process of measuring a patient’s height
simple, fast, and convenient. Each PORTROD is set up to determine the height of a stationary patient. Height is
displayed in centimeters (cm), inches (in), and feet/inches.
PORTROD SPECIFICATIONS
Height Range PORTROD: Max 213cm (83”) / Min 60cm (24”)
Environmental Operating temperatures: 5°C to 40°C (41°F to 104°F)
Storage temperatures: 0°C to 50°C (32°F to 122°F)
Atmospheric Pressure: 500hPa to 1060hPa
Maximum Humidity: 85% RH in use or in storage
Accuracy PORTROD: +/- 3mm (1/8”)
Physical Dimensions PORTROD:
Width: 7cm (2.75”)
Depth: 1.3cm (0.50”)
Height: 152.4cm (60.0”)

CERTIFICATIONS / DISPOSAL / SERVICE
CERTIFICATION DESCRIPTIONS
Pelstar, LLC has been officially certified as a manufacturer of
Health o meter®Professional medical devices to be in
compliance with stringent legal requirements. The Pelstar,
LLC quality assurance system covers the development,
production, sales and service of medical scales and
measuring systems.
PORTROD DISPOSAL
This Health o meter®Professional product must be disposed of properly. Follow the national,
regional or local regulations which apply to you for disposal of domestic waste.
SERVICE INFORMATION
The PORTROD Wall Mounted Height Rod Kit is shipped disassembled in one carton. Carefully
inspect the carton for shipping damage before unpacking. If damage is found, contact Customer
Service immediately.
For further information or telephone support, please contact a Health o meter® Professional
Customer Service representative at 1-800-815-6615.
4

5
PORTROD WALL MOUNT INSTRUCTIONS
To avoid damaging the PORTROD when unpacking it, do not use a box cutter, knife, scissors or
any sharp object when opening the protective inner packaging. If damage is found, contact your
shipper or a Health o meter® Professional representative immediately. Claims must be filed with the
shipper as soon as possible after receipt of the package. The following information details what you will
find inside the carton as you unpack the parts for assembly. Set the carton aside for storage.
Parts List
Carton
(1) User instructions
(1) PORTROD
(1) PORTROD headpiece
(2) Pointed wall fasteners
(5) Screws and washers
Tools Required (not included)
Drill, 1.50mm (1/16”) Drill bit, Tape measure, Phillips head screwdriver, Flat head screwdriver,
Hammer

6
PORTROD WALL MOUNT INSTRUCTIONS (CONT.)
PORTROD Preparation (Refer to Figures 1-2)
1. Carefully remove the product from the carton, and place on a flat and dry surface.
2. Unfold the PORTROD and ensure that the PORTROD aligns with the upper and lower parts.
Note: Half the measuring strip is attached to the PORTROD.
3. Remove the backing from the measuring strip.
4. Place the measuring strip into the measuring groove exactly as it is taped in the upper portion of
the PORTROD. Ensure that the measuring strip is straight prior to taping it to the lower position
of the rod.
Wall Mounting Instructions
Caution: When wall mounting the PORTROD, ensure that the mounting location is free of
electrical lines, gas pipes, and other safety hazards. Ensure that wall is of construction that
can support the PORTROD.
Note: Do not mount PORTROD on a door.
Mounting on Plasterboard or Drywall (Refer to Figures 1-6)
1. Determine the location of where the height rod will be mounted.
Note: Ensure mounting area is clear of baseboard, carpeting materials, and any other obstructions.
2. Position the headpiece onto the PORTROD by sliding the headpiece into the PORTROD groove.
3. Position the PORTROD 600mm (23-5/8”) off the floor, and hold in place.
4. Align PORTROD by leveling the bubble on the headpiece.
5. When the PORTROD is level, mark screw hole in center of the bottom slot. To mark screw hole,
use nail, pushpin, or slender screw.
6. Remove PORTROD, and hammer the pointed wall fastener/screw completely into wall. Tighten
screw until fastener is secured. (This locks fastener into wall).
7. Unscrew and remove screw from the fastener.
8. Position the bottom slot of the PORTROD over fastener hole.
9. Insert screw and tighten screw until PORTROD is held gently against wall.
Note: Do not tighten screw completely.
10. Check level bubble, and mark screw hole in the center of top slot.
11. Re-measure distance from floor to the lower end of the PORTROD, and confirm PORTROD
height is 600mm (23-5/8”) inches.
Note: If level or height measurement is off, repeat steps 4 through 11.
12. Tighten screws until board is securely against the wall.
13. PORTROD is now complete and ready for use.

7
PORTROD WALL MOUNT INSTRUCTIONS (CONT.)
Mounting on Wood, Wood studs, or Metal (Refer to Figures 1-2, 4-7)
Caution: When wall mounting the PORTROD, ensure that the mounting location is free of
electrical lines, gas pipes, and other safety hazards. Ensure that wall is of construction that
can support the PORTROD.
Note: For wood, wood studs, or metal walls, use 1.50mm (1/16”) bit.
Note: Do not mount PORTROD on a door.
1. Determine the location of where the height rod will be mounted.
Note: Ensure mounting area is clear of baseboard, carpeting materials, and any other obstructions.
2. Position the headpiece onto the PORTROD by sliding the headpiece into the PORTROD groove.
3. Position the PORTROD 600mm (23-5/8”) off the floor, and hold in place.
4. Align PORTROD by leveling the bubble on the headpiece.
5. When the PORTROD is level, mark screw hole in center of the bottom slot. To mark screw hole,
use nail, pushpin, or slender screw.
6. Remove PORTROD, and drill a hole for the screw with 1.50mm (1/16”) bit.
Note: If drill is not available, start hole by tapping screw with hammer.
7. Position the bottom slot of the PORTROD over the screw hole.
8. Insert screw and washer, and tighten until board is held gently against wall.
Note: Do not tighten screw completely.
9. Check level bubble, and mark center of the top slot.
10. Re-measure distance from floor to the lower end of the PORTROD, it should be 600mm (23-5/8”)
inches.
Note: If level or height measurement is off, repeat steps 3 through 10.
11. Tighten screws until board is firmly against the wall.
12. PORTROD is now complete and ready for use.

PORTROD WALL MOUNT INSTRUCTIONS (CONT.)
Measuring strip
Black knob
PORTROD
8
Figure 1
Head
p
iece
Mounting hardware
PORTROD Upper Measuring strip
Measuring strip
backing
groovePORTROD
PORTROD Lower Measuring stripgroove
Figure 2

PORTROD WALL MOUNT INSTRUCTIONS (CONT.)
Black knob
Leveling bubble
9
Figure 3 Figure 4
Headpiece
Mark hole
Slot
Figure 5 Figure 6
Figure 7

HEIGHT MEASUREMENT INSTRUCTIONS
Height Measurements (Refer to figures 8-11)
Note: A patient needs to be a minimum of 600mm (23-5/8”) in height for the height to be accurately
measured.
1. Loosen the black knob located on the right side of the headpiece.
2. Raise the headpiece above the patient’s head.
3. Position the patient against the PORTROD.
4. Ensure that the patient’s posture is upright, and that the patient’s head is straight and level.
5. Push the headpiece down until it rests on the patient’s head, and tighten the black knob.
6. Determine the patient’s height by reading the value on the measuring strip nearest to the line on
the clear indicator. The clear indicator is located on the right side of the headpiece.
Figure 8 Figure 9
Figure 10 Figure 11
10

11
MAINTENANCE
Maintenance
The following page provides instructions for maintenance and cleaning for the PORTROD product.
Maintenance operations, other than those described in this manual, should be performed by
qualified service personnel.
Caution: Before first use, or after long periods of non-use, check the product for proper
operation and function. If the PORTROD does not operate correctly, refer to qualified
service personnel.
1. Check overall appearance of the PORTROD for any obvious damage or wear and tear.
Cleaning
Proper care and cleaning is essential to ensure a long life of accurate and effective operation.
1. Clean all external surfaces with a clean damp cloth or tissue. Mild antimicrobial or antibacterial
soap and water solution may be used. Dry with a clean soft cloth. Do not use abrasive cleaners.
2. Do not use Isopropyl Alcohol or other solutions to clean the surface.

WARRANTY
Limited Warranty
What does the Warranty Cover?
Health o meter® Professional product are warranted from date of purchase against defects of materials or in
workmanship for a period of one (1) years. If product fails to function properly, return the product, freight prepaid
and properly packed to Pelstar, LLC (see “To Get Warranty Service”, below, for instructions). If the
manufacturer determines that a defect of material or in workmanship exists, the customer’s sole remedy will be
repair or replacement of the product at no charge. Replacement will be made with a new or remanufactured
product or component. If the product is no longer available, replacement may be made with a similar product of
equal or greater value. All parts including repaired and replaced parts are covered only for the original warranty
period.
Who is Covered?
The original purchaser of the product must have proof of purchase to receive warranty service. Please save
your invoice or receipt. Pelstar dealers or retail stores selling Pelstar products do not have the right to alter, or
modify or any way change the terms and conditions of this warranty.
What is Excluded?
Your warranty does not cover normal wear of parts or damage resulting from any of the following:
negligent use or misuse of the product, use on improper voltage or current, use contrary to the operating
instructions, abuse including tampering, damage in transit, or unauthorized repair or alternations. Further, the
warranty does not cover natural disasters, such as fire, flood, hurricanes and tornadoes. This warranty gives
you specific legal rights, and you may also have other rights that vary from country to country, state to state,
province to province or jurisdiction to jurisdiction.
To get Warranty Service make sure you keep your sales receipt or document showing proof of
purchase. Call ([phone] or ([phone] to receive a return authorization (RA) number, which
must be included on the return label. Attach your proof of purchase to your defective product along with your
name, address, daytime telephone number and description of the problem. Carefully package the product and
send with shipping and insurance prepaid to:
Pelstar, LLC
Attention R/A#_____________
Return Department
11800 South Austin Avenue
Alsip, IL 60803
If your product is not covered by warranty, or has been damaged, an estimate of repair costs or replacement
costs will be provided to you for approval, prior to servicing or replacing.
PRODUCT LIFE: 10 YEARS / 100,000 CYCLES
PELSTAR, LLC
11800 South Austin Avenue • Alsip, IL 60803 • USA
1-800-638-3722 or 1-708-377-0600
PLEASE REGISTER YOUR PRODUCT FOR WARRANTY COVERAGE AT:
http://www.homscales.com/customers/registration.aspx
Health o meter® is a registered trademark of Sunbeam Products, Inc. used under license.
Health o meter® Professional products are manufactured, designed, and owned by Pelstar, LLC.
We reserve the right to improve, enhance, or modify Health o meter® Professional product features or specifications without
notice.
© Pelstar, LLC 2012
P/N UMPORTROD Rev 1-052112
12
