OWNER’S MANUAL
50 Cycle “J” Series
Centrifugal Pump
© 2017 Pentair plc. All Rights Reserved. U78 (Rev. 11/16/17)
293 WRIGHT STREET, DELAVAN, WI 53115 WWW.STARITE.COM
PH: 8887285551
Important
For best possible performance and continuous, satisfactory operation,
read these instructions before installing your new pump.
Should service be required, this manual can be a valuable guide. It should
be kept near the installation for ready reference. Record nameplate data
from pump in this manual for future reference.

Safety • Specifications 2
Important Safety Instructions
SAVE THESE INSTRUCTIONS - This manual contains
important instructions that should be followed during
installation, operation, and maintenance of the product.
Save this manual for future reference.
This is the safety alert symbol. When you see this
symbol on your pump or in this manual, look for one of
the following signal words and be alert to the potential
for personal injury!
indicates a hazard which, if not avoided, will
result in death or serious injury.
indicates a hazard which, if not avoided,
could result in death or serious injury.
indicates a hazard which, if not avoided,
could result in minor or moderate injury.
NOTICE addresses practices not related to
personalinjury.
The manufacturer cannot anticipate every possible
circumstance that might involve a hazard. The warnings
in this manual, and the tags and decals affixed to the unit
are, therefore, not all-inclusive. If you use a procedure
or operating technique that the manufacturer does not
specifically recommend, you must satisfy yourself that it
is safe for you and others. You must also make sure that
the procedure or operating technique that you choose
does not render the system unsafe.
To avoid risk of serious bodily injury and property
damage, read and follow all safety instructions in this
manual and on equipment carefully before installing this
pump. Keep safety labels in good condition; replace if
missing or damaged.
Electrical Safety
Risk of electric shock. Can shock, burn or
kill. All wiring should be done by a qualified electrician.
• Wire motor for correct voltage. See Electrical section
of this manual and motor nameplate.
• Ground motor before connecting to power supply.
• Meet National Electrical Code and local codes for
allwiring.
• Follow wiring instructions in this manual when
connecting motor to power lines.
General Safety
Risk of explosion. The pump body may
explode if used to boost pressure above the maximum
pressure shown in Specifications. Do not use this pump
with inlet pressure greater than 70 psi (483 kPa). If not
already in the piping system, install a pressure relief
valve in the pump discharge line capable of passing the
full pump flow at maximum rated pressure. If local code
requires installation of a pressure relief valve capable
of handling the full pump flow at a pressure less than
100psi (689kPa), follow the code requirements.
Risk of fire or explosion. To avoid risk of
fire and explosion, Pump Water Only with this pump. Do
not pump salt water, flammable liquids or chemicals. Do
not use the pump near gas pilot lights or where chemical
or gas fumes are present. Use of an electric pump with
liquids other than water or in an atmosphere containing
chemical or gas fumes may ignite those liquids or
gases and cause injury or death due to an explosion
and/orfire.
Risk of burns. If water is trapped in the pump
during operation it may turn to steam. Trapped steam
can lead to an explosion and burns. Never run the pump
with the outlet closed or obstructed.
Risk of freezing. Do not allow pump, piping,
or any other system component containing water to
freeze. Freezing may damage system, leading to injury or
flooding. Allowing pump or system components to freeze
will void warranty.
Not to be used by persons (including children)
having diminished capacity or a lack of experience
unless they have been given supervision
orinstruction.
Children must be supervised to ensure that they do
not play with the appliance.
Only service agent or qualified person should
replace power cord to avoid injury.
A complete power disconnect switch must be
incorporated in the fixed wiring.
Pump approved liquids only with this pump.
Periodically inspect pump and system components.
Wear safety glasses at all times when working on pumps.
Keep work area clean, uncluttered and properly lighted;
store properly all unused tools and equipment.
Keep visitors at a safe distance from the work areas.
Make workshops childproof; use padlocks and master
switches; remove starter keys.
California Proposition 65 Warning
This product and related accessories contain
chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
Specifications
Maximum Water Temperature . . . . . . . . . . 140 °F (60 °C)
Maximum Working Pressure . . . . . . . . . . 145 PSI (10 Bar)
Motor HP Max. Head in Feet (m) Max Flow in GPM (LPM)
1/2 69 (21) 33 (125)
3/4 82 (25) 50 (189)
189 (27) 59 (223)
1-1/2 105 (32) 70 (265)
Motor rated for continuous duty.

Warranty 3
Limited Warranty
STA-RITE warrants to the original consumer purchaser (“Purchaser” or “You”) of the products listed below, that they will be free
from defects in material and workmanship for the Warranty Period shown below.
Product Warranty Period
Water Systems Products — jet pumps, small centrifugal pumps,
submersible pumps and related accessories
whichever occurs first:
12 months from date of original installation,
or 18 months from date of manufacture
Pro-Source®Composite Tanks 5 years from date of original installation
Pro-Source®Steel Pressure Tanks 5 years from date of original installation
Pro-Source®Epoxy-Lined Tanks 3 years from date of original installation
Sump/Sewage/Effluent Products 12 months from date of original installation, or
18 months from date of manufacture
Our warranty will not apply to any product that, in our sole judgement, has been subject to negligence, misapplication, improper
installation, or improper maintenance. Without limiting the foregoing, operating a three phase motor with single phase power
through a phase converter will void the warranty. Note also that three phase motors must be protected by three-leg, ambient
compensated, extra-quick trip overload relays of the recommended size or the warranty is void.
Your only remedy, and STA-RITE’s only duty, is that STA-RITE repair or replace defective products (at STA-RITE’s choice). You must
pay all labor and shipping charges associated with this warranty and must request warranty service through the installing dealer
as soon as a problem is discovered. No request for service will be accepted if received after the Warranty Period has expired. This
warranty is not transferable.
STA-RITE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. THE FOREGOING WARRANTIES SHALL NOT EXTEND BEYOND THE DURATION EXPRESSLY PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on the duration of an
implied warranty, so the above limitations or exclusions may not apply to You. This warranty gives You specific legal rights and
You may also have other rights which vary from state to state.
This Limited Warranty is effective June 1, 2011 and replaces all undated warranties and warranties dated before June 1, 2011.
STA-RITE INDUSTRIES
293 Wright Street • Delavan, WI USA 53115
Phone: [phone] • Fax: [phone] • www.sta-rite.com

Installation 4
R
o
t
a
t
i
o
n
684 0412
Figure 1 - Recommended pump suction and discharge connections.
Figure 2 - NOT recommended pump suction and discharge connections.
Straight run, short as possible
but at least 6 times pipe diameter
(“D”) sloping away from pump.
Union
Eccentric
reducer
Discharge
to service
NOTICE all connections must be air tight.
Tee and priming plug
Solid, level base
Rotated volute
Support suction
pipe as required.
Vent plug
Support discharge
pipe as required.
Street elbow
Short length of straight pipe
between reducer and pump.
Priming plug
Gate valve
Foot valve
As close as
possible.
4 times “D”
minimum.
Pipe diameter “D”
No suction screen to prevent debris
from entering pump suction or to
prevent entrapment hazard.
Pipe submerged
less than 4
times “D” will
cause vortexing.
Long
suction run
Unsupported
pipe
Valve
Concentric
reducer
High lift
Elbow immediately in
front of pump suction.
Use of excess fittings means potential air leaks
Pipe diameter “D” insufficient size
Concentric reducer
causes high spots along
the suction line resulting
in air pockets.
On the discharge avoid:
Quick closing valves
Small ID. pipe
Numerous fittings
Misalignment
Sharp turns in piping run

Installation 5
Piping - General
Support both suction and discharge piping independently
at a point near the pump to avoid putting a strain on the
pump housing. Start all piping at the pump.
Increase pipe diameter at both the suction and discharge
by one (1) standard pipe size (minimum) to obtain
desired pressure and flow rate. Refer to Table I when
sizing pipe for your pumping system.
NOTICE: Do not use pipe with smaller diameter on the
suction side of pump.
Table I - Recommended Pipe Size
Pipe Tapping Size On Pump (in) Recommended Pipe Size (in)
Suction Discharge Suction Discharge
1-1/4 1 1-1/2 1-1/4
1-1/2 1-1/4 2 1-1/2
2 1-1/2 3 2
Suction Pipe
Increase pipe size from pump tapping as shown in
TableI. Figure 1 depicts a recommended run of pipe and
fittings for the suction side of a centrifugal pump. Please
refer to this illustration when choosing pipe and fittings
for your suction connection.
NOTICE: All connections must be air tight!
Figure 2 depicts conditions that are not desirable on
the suction side of a centrifugal pump and may cause
problems in flow rate and priming. Please look this
illustration over carefully before choosing pipe and
fittings for your suction connection.
Discharge Piping
Increase pipe size from pump tapping as show in TableI.
Figure 1 depicts a recommended run of pipe and fittings
for the discharge. Install tee with priming plug as close to
pump as possible. Figure 2 depicts conditions that should
be avoided. Please examine carefully before making
discharge connection.
Priming The Pump
A pump is primed when all air in the suction line and
pump volute has been evacuated and replaced with water.
To prime pump:
1. Close valve in discharge line.
2. Remove priming plug from tee and fill pump and
suction line with water until water is flowing back
out of tee.
3. Replace priming plug.
4. Start pump and slowly open valve until desired water
flow is achieved.
NOTICE: If water is not being pumped, turn off
pump, close valve, and repeat steps 1 thru 4.
If pump volute is rotated as shown in Figure1, loosen
vent plug when priming to evacuate air trapped inside
volute. Tighten when volute is filled with water.
Risk of explosion and scalding. Never run
pump against closed discharge. To do so can boil water
inside pump, causing hazardous pressure buildup and
possible explosion.
Risk of burns. Motor normally operates
at high temperature and will be too hot to touch. It is
protected from heat damage during operation by an
automatic internal cutoff switch. Before handling pump
or motor, stop motor and allow it to cool for 20 minutes.
Risk of flooding. Do not run the pump dry.
This will damage mechanical seal and void warranty. It
may cause burns to person handling pump.
Electrical
See Table II for recommended fusing and wiring data.
Table II - Recommended Fusing And Wiring Data - 50 Cycle, Single Phase, 220 V Motors
Motor HP
Max. Load
Amperes
Branch Fuse*
Rating Amps
Distance In Feet From Motor To Fuse/Breaker
0’ to 100’ 101’ to 200’ 201’ to 300’ 301’ to 400’ 401’ to 500’
Wire Size
1/2 4.4 15 14 14 14 14 12
3/4 6.2 15 14 12 10
1 7.4 14 12
1-1/2 9.6 15 14 10 10
* Time delay fuse or circuit breakers are recommended in any motor circuit.

Installation 6
Wiring
Hazardous voltage. Can shock, burn, or
cause death. Disconnect power to motor before working
on pump or motor. Ground motor before connecting to
power supply.
• Ground motor before connecting to electrical power
supply. Failure to ground motor can cause severe or
fatal electrical shock hazard.
• Do not ground to a gas supply line.
Fire hazard. Incorrect voltage can cause
a fire or seriously damage the motor and voids the
warranty. The supply voltage must be within ±10% of the
motor nameplate voltage.
Wire three phase motors according to diagram on motor
nameplate. For any motor, use wire size specified in
TableII. Connect pump to a separate branch circuit with
no other appliances on it.
1. Install, ground, wire and maintain your pump in
compliance with the local electrical codes and
ordinances that apply. Consult your local building
inspector for code information.
2. Provide a correctly fused disconnect switch for
protection while working on motor. For switch
requirements, consult your local building inspector
for information about codes.
3. Disconnect power before servicing motor or pump.
If the disconnect switch is out of sight of pump,
lock it open and tag it to prevent unexpected
powerapplication.
4. Ground the pump permanently using a wire of the
gauge specified in Table II. Make ground connection
to green grounding terminal under motor canopy
marked GRD. or .
5. Connect ground wire to a ground bus in the service
panel or to a metal underground water pipe or well
casing at least 10 feet long. Do not connect to plastic
pipe or insulated fittings.
6. Protect current carrying and grounding conductors
from cuts, grease, heat, oil, and chemicals.
7. Motor has automatic internal thermal overload
protection. If motor has stopped for unknown
reasons, thermal overload may restart it
unexpectedly, which could cause injury or property
damage. Disconnect power before servicing motor.
8. If this procedure or the wiring diagrams are
confusing, consult a licensed electrician.Pump
Service
This centrifugal pump requires little or no service
other than reasonable care and periodic cleaning.
Occasionally, however, a shaft seal may become
damaged and must be replaced. The procedure as
outlined below will enable you to replace the seal.
NOTICE: Pumps use mechanical seals with a rubber
seat ring or a sealing O-Ring. These seals are completely
interchangeable.
NOTICE: The highly polished and lapped faces of this
seal are easily damaged. Read instructions and handle
the seal with care.
Some models are equipped with an impeller screw,
which has a left hand thread. Before unscrewing the
impeller, remove the impeller screw.
Removal of Old Seal
1. After unscrewing impeller, carefully remove rotating
part of seal by prying up on sealing washer, using
two screwdrivers (see Figure 5A). Use care to not
scratch motor shaft.
2. Remove seal plate from motor and place on flat
surface, face down. Use a screwdriver to push
ceramic seat out from seal cavity (see Figure 5B).
Installation of Floating Seat (Figure 5C)
1. Clean polished surface of floating seat with
cleancloth.
2. Turn seal plate over so seal cavity is up, clean
cavitythoroughly.
3. Lubricate outside rubber surface of ceramic seat with
soapy water and press firmly into seal cavity with
finger pressure. If seat will not locate properly in this
manner, place cardboard washer over polished face
of seat and press into seal cavity using a 3/4” socket
or 3/4” piece of standard pipe.
4. Dispose of cardboard washer. Be sure polished
surface of seat is free of dirt and has not been
damaged by insertion. Remove excess soapy water.

Maintenance 7
Installation of Rotating Part of Seal
Unit (Figure 5D)
1. Reinstall seal plate using extreme caution not to hit
ceramic portion of seal on motor shaft.
2. Inspect shaft to make sure that it is clean.
3. Clean face of sealing washer with clean cloth.
4. Lubricate inside diameter and outer face of rubber
drive ring with soapy water and slide assembly on
motor shaft (sealing face first) until rubber drive ring
hits shaft shoulder.
5. Screw impeller on shaft until impeller hub hits shaft
shoulder. This will automatically locate seal in place
and move the sealing washer face up against seat
facing. Reinstall impeller screw (if used).
5939 0412
Figure 5
A - Seal removal - rotating half
Mechanical seal
stationary half
Polished surface
Shaft shoulder
D - Seal installation - rotating half
Seal plate
3/4” socket or pipe
Rubber
drive ring
C - Seal installation - stationary half
Turn over
Cardboard washer
(supplied with seal)
Sealing
face
Mechanical seal
rotating half
Rubber surface
Impeller
B - Seal removal - stationary half
Risk of electric shock. Can shock, burn or kill. To guard against accidental personal injury, the electric
power to the pump should be turned off when conducting the checking procedures outlined. There are obvious
exceptions, however, and service personnel should take necessary safeguards against the hazard of electrical shock.
Problem Probable Cause(s) Remedy
Pump fails to pump. Pump not properly primed. Make sure pump casing and suction line are
full of water. See priming instructions.
Pump has reduced
capacity and/or head.
Air pockets or leaks in suction line. Check suction piping.
Clogged impeller. Remove and clean.
Pump loses prime.
Air leaks in suction line. Check suction piping.
Excessive suction lift and operating too near
shut-off point. Move pump nearer to water level.
Water level drops while pumping,
uncovering suction piping.
Check water supply. Add length of pipe to
suction to keep submerged end under water.
Mechanical troubles
and noise.
Bent shaft and/or damaged bearings. Take motor to authorized motor repair shop.
Suction and/or discharge piping not properly
supported and anchored.
See that all piping is supported to relieve
strain on pump assembly.
Troubleshooting

Repair Parts 8
1
8A
2
3
10
4
7
5A
5
6
9
9
11
11A
8B
801 0217 GEN
“J” Series - High Head
Key
No.
Part
Description
No.
Used
MOTOR AND HORSEPOWER
5JMB-57
5JHC-62H
5JHC3-62H
5JHCX-62
5JHC3X-62
1/2 HP
5JMC-57
1/2 HP
5JHD-51H
5JHDX-51
3/4 HP
5JHE-69H
5JHE3-69H
5JHEX-69
5JHE3X-69
1 HP
5JHF-53H
5JHF3-53H
5JHFX-53
5JHF3X-53
1-1/2 HP
1* Motor, 115/230V, Single Phase 1J218-573AC J218-573AC J218-574AC J218-575AC J218-864AC
Motor, 3 Phase J218-814AC J218-814AC -J218-816AC J218-817AC
†2 Water Slinger 117351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3Seal Plate 1C3-178 N3-8 C3-178 C3-178 C3-178
†4 Shaft Seal 1U109-6A U109-6A U109-6A U109-6A U109-6A
5Impeller - Single Phase 1C105-92PMX J105-42PJA C105-92PB C105-214PB C105-214P
5Impeller - Three Phase 1C105-92PMXA J105-42PJA -C105-214PBA C105-214PA
5A Impeller Screw - Three Phase 1C30-14SS C30-14SS C30-14SS C30-14SS C30-14SS
6Volute Assembly - Complete 1C101-284B C101-122E C101-284B C101-264BW C101-264BW
7Wear Ring (1) C23-27 C23-27 C23-27 C23-27 C23-27
8A Capscrew - 3/8 - 16 x 1” Lg. (2) U30-74ZP U30-74ZP U30-74ZP U30-74ZP U30-74ZP
8B Capscrew - 3/8 - 16 x 1-1/4” Lg. (2) U30-75ZP U30-75ZP U30-75ZP U30-75ZP U30-75ZP
9Pipe Plug - 1/4” NPT (3) U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV
†10 Gasket - Volute 1C20-121N N20-26N C20-121N C20-122N C20-122N
11 Base 1J104-9F J104-9F J104-9F J104-9F J104-9F
11A Motor Pad 1C35-5S C35-5S C35-5S C35-5S C35-5S
SERVICE KIT
Seal and Gasket Kit 1PP1700 PP1700 PP1700 PP1700 PP1700
NOTE: † Included in Seal and Gasket Kit.
* For repair or service to motors, always give the motor Model Number and any other data found on the Motor Model Plate.

J







5JMB-57
5JHC-62H
5JHC3-62H
5JHCX-62
5JHC3X-62
 1/2
5JMC-57
 1/2
5JHD-51H
5JHDX-51
 3/4
5JHE-69H
5JHE3-69H
5JHEX-69
5JHE3X-69
 1
5JHF-53H
5JHF3-53H
5JHFX-53
5JHF3X-53
 1-1/2
1*
115/230
1J218-573ACJ218-573ACJ218-574ACJ218-575ACJ218-864AC

J218-814ACJ218-814AC-J218-816ACJ218-817AC
†2

117351-000917351-000917351-000917351-000917351-0009
3

1C3-178N3-8C3-178C3-178C3-178
†4

1U109-6AU109-6AU109-6AU109-6AU109-6A
5

1C105-92PMXJ105-42PJAC105-92PBC105-214PBC105-214P
5

1C105-92PMXAJ105-42PJA-C105-214PBAC105-214PA
5A

1C30-14SSC30-14SSC30-14SSC30-14SSC30-14SS
6

1C101-284BC101-122EC101-284BC101-264BWC101-264BW
7

(1)C23-27C23-27C23-27C23-27C23-27
8A
1163/8
(2)U30-74ZPU30-74ZPU30-74ZPU30-74ZPU30-74ZP
8B
163/8
(2)U30-75ZPU30-75ZPU30-75ZPU30-75ZPU30-75ZP
9
NPT   
(3)U78-941ZPVU78-941ZPVU78-941ZPVU78-941ZPVU78-941ZPV
†10

1C20-121NN20-26NC20-121NC20-122NC20-122N
11

1J104-9FJ104-9FJ104-9FJ104-9FJ104-9F
11A

1C35-5SC35-5SC35-5SC35-5SC35-5S
 
1PP1700PP1700PP1700PP1700PP1700
†
.
8
1
8A
2
3
10
4
7
5A
5
6
9
9
11
11A
8B
801 0217 GEN

7
5
 1

 2
 3
 


 5


5939 0412
5
  -    - 
   

 
 
  -    - 
 

 3/4   
 

  -    - 

 )  
(
 

   

 

  -    - 
.  



 






 

 







 


6
. 
 .       . 


 


 
. 

±10%
  
2
  
 
230/220127/115


 1


 2


 3


 
2
 GRD.
   5
10

 6

 7



 8






     
.





 1
5

 2

5
)5
 1
 2

 3




.     



5



.
1

1

1
()     ()    



1
2
232

1
1



  2




.1
1

2




: 
 1
 2

 3
 

 
.1
1


  


. 


20
.  



2

220502
    
*  

 /     
100  0200  101300  201400  301500  401
 
1/2/8.815/15/
/10/8
/812/6
6.2/
15/20/1212/610/1/
/812/6 9.6/19.215/30/1010/10/2


1
2
4
R
o
t
a
t
i
o
n
684 0412

6


ِِِ
 
 

.        
   
  
ُ 
   
.
  
   
.
 
    
. ِِِ
 
 
 
 
.
   4
. 
 
        
.      
   
    4
. 
 

  

ِِِ
 
 
    
. 
         
ِ    
  ِِِ 
     
ِ    
. 
:   
  
    
    
 
    

3



 


:ً  
12
18
5
5
3

12
18

  








  
.2011120111




2

  





 






  





.  

   

 
 

 


 . 

70



100
689
.   






. 


 . 


















60
10
  ()   
 )     
(
1/2216912533
258218950
1278922359
3210526570



J
50

  



U78 (Rev. 11/16/17) © 2017 Pentair plc. All Rights Reserved.
293 WRIGHT STREET, DELAVAN, WI 53115
262-728-5551
262-728-4461
sta-rite.com
