Pentax Optio S1 User manual

0
ENG
Thank you for purchasing this PENTAX
Digital Camera.
When you use this camera for the first
time, it is recommended you read this
Quick Guide first in order to gain a feel for
the basic operation of the camera. Refer
to the separately supplied “Operating
Manual” for further explanation of
functions and advanced operations of the
camera.

To users of this camera
• Do not use or store this device in the vicinity of equipment that generates
strong electromagnetic radiation or magnetic fields.
Strong static charges or the magnetic fields produced by equipment such as
radio transmitters could interfere with the monitor, damage the stored data,
or affect the product’s internal circuitry and cause camera misoperation.
• The liquid crystal panel used for the display is manufactured using extremely
high precision technology. Although the level of functioning pixels is 99.99%
or better, you should be aware that 0.01% or fewer of the pixels may not
illuminate or may illuminate when they should not. However, this has no
effect on the recorded image.
• If you point the camera toward an object that is bright, a band of light may
appear on the screen display. This phenomenon is referred to as “smear”
and is not a malfunction of the camera.
• There is a possibility that the illustrations and the screen display in this
manual are different from the actual ones.
• In this manual, SD Memory Cards, SDHC Memory Cards, and SDXC
Memory Cards are referred to as SD Memory Cards hereafter.
• In this manual, the generic term “computer(s)” refers to either a Windows PC
or a Macintosh hereafter.
• In this manual, the term “battery(ies)” refers to any type of batteries used for
this camera and its accessories.

1
We have paid close attention to the safety of this product. When using this
product, we request your special attention regarding items marked with the
following symbols.
Warning
• Do not disassemble or modify the camera. High voltage areas are present
inside the camera, with the risk of electric shock.
• If the camera interior is exposed due to dropping or otherwise damaging the
camera, never touch the exposed portion. There is a risk of electric shock.
• Wrapping the strap around your neck is dangerous. Take care that small
children do not hang the strap around their necks.
• If any irregularities occur during use, such as smoke or a strange odor, stop
use immediately, remove the battery, and contact your nearest PENTAX
Service Center. Continuing to use the camera can cause a fire or electric
shock.
Caution
• Do not place your finger over the flash when discharging the flash. You may
burn yourself.
• Do not cover the flash with clothes when discharging the flash.
Discoloration may occur.
• Some portions of the camera heat up during use. There is a risk of low
temperature burns when holding such portions for long periods.
• Should the monitor be damaged, be careful of glass fragments. Also, be
careful not to allow the liquid crystal to get on your skin, in your eyes or
mouth.
Warning
This symbol indicates that violating this item could
cause serious personal injuries.
Caution This symbol indicates that violating this item could
cause minor or medium personal injuries, or loss of
property.
About the Camera
Using Your Camera Safely

2
• Depending on your individual factors or physical condition, the use of the
camera may cause itching, rashes or blisters. In case of any abnormality,
stop using the camera and get medical attention immediately.
Warning
• Always use the power adapter exclusively developed for this camera, with
the specified power and voltage. Using a power adapter not exclusive to
this camera, or using the exclusive power adapter with an unspecified
power or voltage can cause a fire, electric shock, or camera breakdown.
The specified voltage is 100 - 240V AC.
• Do not disassemble or modify the power adapter. This can cause a fire or
electric shock.
• If the generation of smoke or strange odor from the power adapter or other
abnormality occurs, immediately discontinue use and consult a PENTAX
Service Center. Continuing to use the adapter can cause a fire or electric
shock.
• If water should happen to get inside the power adapter, consult a PENTAX
Service Center. Continuing to use the adapter can cause a fire or electric
shock.
• If a thunder storm should occur while using the power adapter, unplug the
adapter and discontinue use. Continuing to use the adapter can cause
damage to the equipment, fire, or electric shock.
• Wipe off the plug of the power adapter if it becomes covered with dust.
Accumulated dust on the plug may cause a fire.
Caution
• Do not place or drop heavy objects on the power adapter. Doing so may
damage the adapter. Should the power adapter be damaged, consult a
PENTAX Service Center.
• Do not touch or short-circuit the terminal area of the power adapter while
the cord is plugged in.
• Do not handle the power adapter with wet hands. This can cause an electric
shock.
• Do not drop the power adapter, or subject it to violent impact. This can
cause equipment breakdown.
About the Power Adapter

3
• Do not use the power adapter to charge a battery other than a rechargeable
lithium-ion battery D-LI78. This can cause an explosion, or heating, or may
damage the power adapter.
Warning
• Be sure to store the battery out of the reach of small children. Placing it in
their mouths may cause an electric shock.
• If any leakage from the battery should come in contact with your eyes, do
not rub them. Flush your eyes with clean water and get medical attention
immediately.
Caution
• Only use the specified battery with this camera. Use of other batteries may
cause an explosion or fire.
• Do not disassemble the battery. Disassembling the battery may cause an
explosion or leakage.
• Remove the battery from the camera immediately if it becomes hot or
begins to smoke. Be careful not to burn yourself during removal.
• Keep wires, hairpins, and other metal objects away from the + and -
contacts of the battery.
• Do not short the battery or dispose of the battery in fire. This can cause an
explosion or fire.
• If any leakage from the battery should come in contact with skin or clothes,
wash the affected areas thoroughly with water.
• Precautions for D-LI78 Battery Usage:
- USE SPECIFIED CHARGER ONLY.
- DO NOT INCINERATE.
- DO NOT DISASSEMBLE.
- DO NOT SHORT CIRCUIT.
- DO NOT EXPOSE TO HIGH TEMP. (140°F / 60°C)
About the Battery

4
Warning
• Do not place the camera and its accessories within the reach of small
children.
1. If the product falls or is operated accidentally it may cause serious
personal injuries.
2. Wrapping the strap around a neck may cause suffocation.
3. To avoid the risk of a small accessory such as the battery or SD
Memory Cards from being swallowed by mistake, keep them out of
the reach of small children. Seek medical attention immediately if an
accessory is accidentally swallowed.
Keep the Camera and Accessories out of the Reach of Small
Children

5
• When traveling, take the Worldwide Service Network listing that is included
in the package. This will be useful if you experience problems abroad.
• When the camera has not been used for a long time, make sure that it is
still working properly, particularly prior to taking important pictures (such as
at a wedding or when traveling). Contents of the recording cannot be
guaranteed if recording, playback or transferring your data to a computer,
etc. is not possible due to a malfunction of your camera or recording media
(SD Memory Card), etc.
• Storing the battery fully charged may decrease the battery performance.
Avoid storing in high temperatures.
• If the battery is left inserted and the camera is not used for a long time, the
battery will over-discharge and shorten the battery’s life.
• Charging the battery a day before use or on the day of use is
recommended.
• Do not subject the camera to high temperatures or high humidity. Do not
leave the camera in a vehicle, as the temperature can get very high.
• Do not subject the camera to strong vibrations, shocks, or pressure. Use a
cushion to protect the camera from vibrations of motorcycles, automobiles,
or ships.
• The temperature range for camera use is 0°C to 40°C (32°F to 104°F).
• The monitor may appear black at high temperatures, but will return to
normal at normal temperatures.
• The monitor may respond more slowly at low temperatures. This is due to
liquid crystal properties, and is not a malfunction.
• Sudden temperature changes will cause condensation on the inside and
outside of the camera. Place the camera in your bag or a plastic bag, and
remove it after the temperature of the camera and surroundings are
equalized.
Before Using Your Camera
About the Battery
Precautions on Carrying and Using Your Camera
Care to be Taken During Handling

6
• Avoid contact with garbage, mud, sand, dust, water, toxic gases, or salt.
These could cause the camera to breakdown. Wipe the camera to dry off
any rain or water drops.
• Please do not press forcefully on the monitor. This could cause it to break
or malfunction.
• Be careful not to sit down with the camera in your back pocket as this may
damage the exterior of the camera or the display.
• Be careful not to overtighten the tripod screw when using a tripod.
• The lens on this camera is not interchangeable. The lens is not removable.
• Do not clean the camera with organic solvents such as thinner, alcohol or
benzine.
• Use a lens brush to remove dust accumulated on the lens. Never use a
spray blower for cleaning as it may damage the lens.
• Do not store the camera with preservatives or chemicals. Storage in high
temperatures and high humidity can cause mold to grow on the camera.
Remove the camera from its case and store it in a dry and well-ventilated
location.
• Periodic inspections are recommended every one to two years to maintain
high performance.
• Please note that deleting images or sound files, or formatting the SD
Memory Cards or the built-in memory does not completely erase the
original data. Deleted files can sometimes be recovered using commercially
available software. It is user’s responsibility to ensure the privacy of such
data.
Cleaning Your Camera
Storing Your Camera
Other Precautions

7
Checking the Contents of the Package
Check that your camera came complete with the items
listed below.
PCamera (Optio S1) PStrap (O-ST116)
PAV cable (I-AVC116) PUSB cable (I-USB116)
PRechargeable lithium-ion battery
(D-LI78)
PPower adapter (D-PA116)
PSoftware (CD-ROM)
S-SW116
POperating Manual
OQuick Guide (this guide)

8
Front
Back
Remote control receiver
Self-timer lamp
Flash
Battery/card cover
Tripod socket
Speaker
Lens
Microphone
Display
Shutter release button
Zoom button
Qbutton
PC/AV terminal cover
Strap lug
4/Wbutton
3button
Four-way controller
Green/ibutton
Cbutton
Power switch
Names of Parts and Monitor Indicators
In this Quick Guide, the keys on
the four-way controller to be
pressed are expressed as
indicated on the right.

9
Monitor Indicators
Following indicators are displayed in the still picture capture mode.
Battery Level Indicator
You can check the battery level by the indicator on the display.
Prepare your camera for use before you start using it.
Screen Display Battery Status
(green) Adequate power remains.
(green) Battery is running low.
(yellow) Battery is running very low.
(red) Battery is exhausted.
[Battery depleted] The camera will turn off after this message appears.
World Time setting
Battery level
Focus Frame
Shutter speed
14:25
1 4 : 2 5
14:25+1.0
+ 1 . 0
+1.0
38
3 8
38
03/03/2011
03/03/2011
03/03/2011
F3.5
F 3 . 5
F3.5
1/250
1/250
1/250
Memory status
Flash mode
Drive mode
Focus mode
Aperture
EV Compensation
Date Imprint setting
Remaining image
storage capacity
Face Detection
+Built-in memory (without
card)
?SD Memory Card
rCard is write-protected
No icon : Hometown
: Destination
Shooting mode
Digital Zoom icon
D-Range Setting
Camera shake reduction
Date and time

10
Attaching the Strap
Attach the strap supplied with
the camera as shown in the
illustration.
Installing the Battery and an SD Memory
Card
Install the battery and SD
Memory Card as shown in
the illustration.
* The SD Memory Cards are sold separately.
2
5
3
4
Battery/
card cover
Battery
Before using the battery
Charge the battery before using it in the camera for the first time.
Preparing the Camera for Use
1
1
Battery lock lever
SD Memory Card socket
SD Memory Card

11
Press the power switch.
The camera turns on and is ready to take still
pictures. Press the power switch again to turn the
camera off.
Make the Initial Settings.
The [Language/u] screen appears when the camera is turned on for the
first time. Select the desired language and then set the date and time.
Use the four-way controller
(2345) to select the desired
language.
Press the 4button.
The [Initial Setting] screen
appears.
If you accidentally select the wrong
language and press the 4button, press
the four-way controller (5), use the four-
way controller (2345) to select the
desired language, and then press the 4
button. The [Initial Setting] screen appears
in the selected language.
MENU
Cancel
English
Nederlands
Svenska
Italiano
Dansk
OK
Deutsch
Polski
Magyar
Suomi
OK
1
2
2
Memo
Initial Setting
MENU
Cancel
Settings complete
English
DST
OFF
OFF
OFF
Hometown
New York
Turning the Camera On
2
2

12
Press the four-way controller (3)
to move the frame to
[WHometown].
Press the four-way controller (5).
The [WHometown] screen
appears.
Use the four-way controller (45)
to choose a city.
Press the four-way controller (3)
to move the frame to [DST]
(Daylight Saving Time).
Use the four-way controller (45) to select Oor Pand press the
4 button.
The [Initial Setting] screen reappears.
Press the four-way controller (3) to select [Settings complete]
and press the 4button.
The [Date Adjustment] screen appears.
Initial Setting
MENU
Cancel
English
Hometown
NewYork
Settings complete
3
Hometown
City NewYork
DST
MENU
Cancel
OK
OK
4
5
6
7
8

13
Press the four-way controller (5)
to select [mm/dd/yy], then use the
four-way controller (23) to
choose the date format.
Press the four-way controller (5) to select [24h], then use the
four-way controller (23) to select [24h] (24-hour display) or
[12h] (12-hour display).
Press the four-way controller (5), then press the four-way
controller (3) to move the frame to [Date].
Press the four-way controller (5) to select [01] (month),
[01] (day) or [2011] (year), then use the four-way controller (23)
to set the date to the current day.
Press the four-way controller (5), then press the four-way
controller (3) to move the frame to [Time].
Set the time in the same manner as in .
Press the four-way controller (3)
to select [Settings complete] and
press the 4 button.
MENU
Date Adjustment
Cancel
Date Format
Date
Time
Settings complete
mm dd yy
01/01/2011
00:00
// 24h
9
10
11
12
13
14
12
MENU
Date Adjustment
Cancel
Date Format
Date
Time
Settings complete
00:00
mm dd yy// 24h
01/01/2011
OK
OK
15

14
Formatting an SD Memory Card
Use this camera to format (initialize) an SD Memory Card that is unused or
has been used on another camera or digital device. Be aware that formatting
deletes all the data stored in the SD Memory Card.
Press the 3button and use the four-way controller (45) to
display [WSetting] menu.
Use the four-way controller (23) to select [Format], and then
press the four-way controller (5).
Use the four-way controller (23)
to select [Format], and then press
the 4button.
1
2
Format
All data will be deleted
Format
Cancel
OK
OK
O K
OK
3

15
Aim the camera at the subject, then press the shutter release
button. The flash discharges automatically depending on the
brightness.
Frame the subject using the focus frame on the display.
Press the zoom button to change the capture area.
Right (x) Enlarges the subject.
Left (w) Widens the area that is captured by the
camera.
Press the shutter release button halfway.
The focus frame on the display turns green if the subject is in
focus.
Press the shutter release button fully.
The picture is taken.
Recording Movies
Point the camera at your subject in Amode.
Press the Cbutton.
Recording starts.
Press the Cbutton.
Recording stops.
1
2
3
4
1
2
3
Use the Qbutton to switch between the A(capture) mode and
Q(playback) mode.
Taking Pictures A
3
3

16
You can play back the images and movies captured with the
camera on the display.
Press the Qbutton after taking a picture.
The image appears on the display.
Press the four-way controller (45) to play back the previous or
next image.
Press the zoom button to switch to thumbnail/folder/calendar display.
1
14:25
1 4 : 2 5
14:25
100
100-
0038
0 0 3 8
100-0038
03/03/2011
0 3 / 0 3 / 2 0 11
03/03/2011
Edit
Edit
Edit
2
Memo
Playing Back Images Q
4
4

17
Deleting Images
You can delete a single image currently displayed on the display.
Use the four-way controller (45) to choose the image you want
to delete.
Press the ibutton.
The confirmation screen appears.
Use the four-way controller (23) to select [Delete].
Press the 4button.
• You can delete multiple or all files at once.
• You can protect stored images from being accidentally deleted.
1
2
OK
OK
OK
Delete
Cancel
100
100-
0017
0 0 1 7
100-0017
3
4
Memo

18
You can choose the playback function you want to use from the
Playback Mode Palette.
Press the four-way controller
(3) while an image is displayed
in playback mode.
Use the four-way controller
(2345) to choose a
playback mode, then press the
4button.
Selecting a Playback Function
SlideshowSlideshow
OK
OKOK
MENU
CancelCancel
Slideshow
OK
Cancel
For continuously playing
back images. Screen or
sound effects can be set
1 / 21/2
