A personal color scanner for high-quality images and documents
in the office or on the road
•Small, compact design – Measuring 1.5” in height, 2.0” in depth, 11” in length and
weighing only 12.2 ounces allows the DSmobile 600 to fit on your desktop or be a perfect
traveling companion.
•No job too small or too large – The DSmobile 600 provides the versatility to scan
media from business card size to 8.5 x 14” paper size.
•Just add a PC – The unique USB power/data interface draws power directly from the PC
and comes with a detachable USB cable.
•High performance with low power consumption – The DSmobile 600 connects to a
high-speed USB 2.0 interface yet consumes only 0.2W of power when in standby mode
and a maximum of 2.0W of power when scanning.
•Just a touch away from scanning – One touch of the button on the DSmobile 600 will
launch your choice of compatible scanning programs. Make a preferred scanning
program your default and that one touch will initiate that program.
•The DSmobile 600 is not just a scanner – it is a powerful scanning package - The
Pentax DSmobile 600 scanner come with everything you need to scan, straight out of the
box…including the following windows® software:
DSmobileSCAN – This program allows scanned documents to be automatically saved as
Adobe® Acrobat® format files. An added feature to this software is the ability to initiate a scan
from the DSmobile scanner button.
PageManager® Version 7 – An updated version of the popular software used with the DSmobile
USB, this software allows a user to scan and organize digitized files with the ability to view, edit,
send and save files in many formats.
TWAIN – This driver allows a user to control all scanner details and settings. A user will have an
array of scanning applications to choose from because TWAIN is compatible with any software
application that uses TWAIN device input.
Note: TWAIN for Apple MAC OSX is available for download at www.pentaxtech.com

When exceptional quality scanning is a must and space is an issue – reach for the
perfect solution - the PENTAX DSmobile 600 scanner
Scanner Specifications
Interface Image Sensor
USB (Universal Serial Bus) CMOS CIS (Contact Image Sensor)
2.0 (High Speed)
No external power supply needed
Optical Resolution Scanning Modes
600 dpi (dots per inch) 48-bit internally, outputs 24-bit
8-bitgrayscale
1-bit black and white (bi-level)
Scan Area Scan Speed
Maximum 8.5” x 14” (216mm x 356mm) 8.5” x 11 letter size @200 dpi
3 pages/min (color)
5 pages/min (gray scale)
5 pages/min (B&W)
Scanner Weight Dimensions (LxWxH)
12 oz. (345 g) 11.0” x 2.0” x 1.5” (279mm x 51mm x 38mm)
Cable Length Paper Thickness
6ft. (2m) detachable cable 0.1mm – 0.8mm
Paper Sensor Power Consumption
Electro-Mechanical 0.01 W sleep mode
0.2W standby
2.0 W during Scan
Software for Windows® on CD ROM Operating Systems
DSmobileSCAN Windows XP, 2000, ME, 98 SE
PageManager® Version 7 Mac OSX 10.3 and later (downloadable
TWAIN driver from www.pentaxtech.com)
Required Device driver
Computer System Requirements
Interface: USB (Universal Serial Bus) 2.0 (High Speed) is recommended for best performance.
Compatible with USB 1.1 (at a slower speed)
Processor: Pentium II 300 MHz or higher processor
Memory: 128 MB RAM (256 MB RAM for Windows XP). 200 MB free hard disk space or more
Monitor: VGA or Super VGA
Shipset for the PENTAX DSmobile 600 scanner includes: DSmobile 600 scanner, 6’ (2m)
USB detachable cable, Installation CD, User Manual (printable from the installation CD), 2
Calibration sheets, 1 cleaning sheet, 2 photo sleeves for scanning pictures, and a carrying bag for
scanner protection.
600 12th Street • Suite 300 • Golden, CO 80401 • 800-877-0155 • 303-799-8000 • 303-460-1628 Fax
www.pentaxtech.com
