Peopeo Voodoo User manual
owner’s guide
®SPEAKER
CONTENTS
3
introduction
what’s in the box
set up
set up system
charging the VOODOO®
turn on and off the speaker
system use
control buttons
led indicator
AUX-IN devIce cONNecTION
BLUeTOOTH devIce cONNecTION
MULTIPLe devIceS cONNecTION
BLUeTOOTH / MINI-JAcK
true wireless stereo
MINI-JAcK / MINI-JAcK
battery use
accessories
options
important safety information
information to note and keep
positionning tips
TRANSPORT AdvIceS
maintenance and care
PROBLeM SOLvING
cleaning
limited warranty
cUSTOMeR SeRvIce
4
5
6
7
8
9
10
11
13
14
15
16
17
18
19
21
23
24
25
26
28
29
31
INTrOduCTION
4
ABouT THe VOODOO® sPeAKer
The VOODOO® voodoo speaker is a powerful boombox made in france. it
connects wirelessly and / or with mini-jack to your smartphone, tablet or
other bluetooth and / or mini-jack device output so you can enjoy your
music, videos and games anytime and everywhere.
SYSTEM FEATURES
• You can charge your phone with a USB port directly to your speaker.
• The lithium-ion battery allows you to listen to music for hours. The battery
is rechargeable.
• The charger has to be plug directly into the speaker.
• You can connect an audio device thanks to the AUX-IN.
• You can connect one ore more VOODOO® to each other thanks to the AUX-
OuT .
• You can bring the VOODOO® everywhere thanks to its backpack function.
“HANDMADE PRODUCT”
The material used and the manufacturing process of the VOODOO® speaker
gives a unique aesthetic to the speaker. The exclusivity of the product does
not alter in any way its performance.
A team is working full time on the manufacture of your product to offer you a
quality speaker “Handmade in the Alps”.
Unpack carefully the elements and check if all these components are present:
COMMENT:
If any components look damaged, do not try to use it. Please contact
immediately PEOPEO’s customer service: sa[email protected].
WHAT’S IN THE BOX
5
X1 SPEAKEr VOODOO®
X1 MINI-JACK CABLE
X1 CHArGEr
X2 SLINGS
LEfT rIGHT
SET uP
THe sLings
6
To set up the slings on your speaker:
1. Differentiate the left shoulder sling and the right sling inside the box.
2. Attach the hooks on the top of the sling to the hooks on the top of the
speaker and attach the lower hooks of the sling to the hooks on the bottom
of the speaker.
3. Adjust your slings according to your needs. Slide the loop on the slings to
shorten or lengthen the strap to nd the perfect length.
SET uP SYSTEM
7
CHArging THe VOODOO®
Before using your speaker for the rst time, connect it to the power outlet
and charge the battery.
1. Connect the power cord to the charger connector of the VOODOO®
speaker.
2. Connect the other end of the power cord to the AC power cord.
3. Connect the power cord to a powered electrical outlet.
COMMENT :
Use the right adapter for your country.
The battery indicator is orange when it is charging.
The indicator turns green when the speaker is fully charged.
The charging time is about two and half hours.
1.
2.
3.
SET uP SYSTEM
8
Press the button on the interface to turn on your speaker. A green light
appears.
Turn on And oFF THe sPeAKer
SYSTEM uSE
9
ConTroL BuTTons
You can, with the control buttons:
1. Turn your speaker on or off.
2. Control the volume of your speaker.
3. Select the audio source: Bluetooth connection, mini-jack connection or
both.
4. Disconnect any connected Bluetooth device and connect a new one.
5. Pair two VOODOO® speakers.
12
2
4
5
3
COMMENT :
After turn off the speaker, wait few
seconds before turning it back on.
COMMENT:
The auxiliary mini-jack is
automatically activate.
SYSTEM uSE
10
Led indiCATor
AuX-IN dEVICE CONNECTION
11
Mini-JACK CABLe use
With the IN input you can connect your speaker to:
- A smartphone, tablet, computer, or any other type of audio player.
- A mic.
- A musical instrument (for example: a guitar)
- A mixing deck.
The INput jack accepts a 3.5mm male stereo mini jack (included).
COMMENT: a 6.3 mm jack cable can be connected by using an adapter (not
supplied).
OuT
IN
V1
V1. Function indicator light. The indicator is illuminated when the speaker
in on. The indicator is off when the speaker is no longer on. The indicator is
ashing red when the maximum sound power is reached.
V2. Bluetooth indicator light.
V3. Bluetooth source selected indicator via AUX.
V4. Mini-jack source selected indicator via AUX.
V5. True Wireless Stereo indicator light.
V2
V3
V4
V5
AuX-IN dEVICE CONNECTION
12
Mini-JACK CABLe use
IN
1. Turn on your speaker.
2. The led indicator AuX is automatically alight.
3. Using a 3.5mm stereo cable, connect your device to the AUX -IN connector
on the speaker.
4. Press play on your audio player.
5. Press the button +to activate the sound of your speaker.
ADVICE: For an optimal sound, increase the volume of your connected device
(the maximum is recommended). Then, use the volume control buttons of
your speaker.
BE CAREFUL:
Never connect at the same time your
mini-jack cable on the plug IN and OuT.
You risk to damage the system.
IN
OuT
BLuETOOTH dEVICE CONNECTION
13
PAiring A MoBiLe deViCe
With the Bluetooth system you can connect wirelessly your speaker to any
mobile device having a Bluetooth function.
1. Turn on your speaker.
2. Press the button AuX until the Led Bluetooth indicator light turns on. The
Bluetooth indicator V2 is ashing, searching for the device.
Pairing a mobile device :
1. Turn on the Bluetooth feature in the Settings of your mobile device.
2. Select PEOPEOxxx in your device list.
3. The Bluetooth indicator V2 stops ashing when your mobile device is
connected to your speaker.
4. Play your music. Press the button +to activate the sound on your speaker.
Remember to adjust the volume on your mobile device and on your speaker
with the +and –buttons.
BE CAREFUL:
It is recommended to place your mobile and your speaker at 10 meters of
each other.
Over 15 meters, the speaker will no longer receive the signal.
MuLTIPLE dEVICES CONNECTION
BLueTooTH / Mini-JACK ConneCTion
It is possible to connect a device with a mini-jack cable and at the same time
connect a mobile device with a Bluetooth connection
1. Connect your mobile device with a mini-jack cable (see page 12). The led
mini-jack indicator V4 lights up. Press the button +to activate the sound on
your speaker. Adjust the volume with the control buttons.
2. Connect your second device to Bluetooth (see page 13). Your connected
mini-jack source will stop while you adjust your Bluetooth source. Press the
button + to turn on the sound of your speaker. Adjust the volume.
3. Press the button AuX, to light the led mini-jack indicator V4 and the led
bluetooth indicator V3. Then press the button +. Both devices will be ready
to be heard.
4. If you press the buttons +and -, the volume of each source will increase or
decrease from the presets you made.
1 2
3&4
5
2
3 & 4
MuLTIPLE dEVICES CONNECTION
True wireLess sTereo
BE CAREFUL:
This feature only works if the audio source is connected in Bluetooth. The
volume of each speaker is dissociated and can be set separately. To dis-
connect all your Bluetooth connected devices, press the Bluetooth button
(see page 9).
IN
IN
It is possible to create a Hi-Fi stereo system by connecting two VOODOO®
speakers together.
1. Turn on your speakers.
2. Press the button AuX and choose the Bluetooth function on each speaker.
3. Choose your “slave” speaker. This speaker is the device which is not
connected to the sound source.
4. On the « slave » speaker, press the button True Wireless Stereo for more
than three (3) seconds The V5 indicator ashes slowly.
5. The second speaker is the « master ». Briey press the True Wireless Strereo
button. The led indicator ashes quickly. Connect your device to Bluetooth.
6. The True Wireless Stereo is working when all indicators stop to ash.
7. Press the button +to activate the sound of your speaker.
14
MASTEr SLAVE
16
MuLTIPLE dEVICES CONNECTION
Mini-JACK / Mini-JACK
You can connect your mobile device to multiple speakers.
1. Using a 3.5mm mini-jack cable, connect your device to the AUX-IN connector
on the speaker.
2. Then connect a 3.5mm mini - jack cable to the AUX - OuT connector of your
speaker and to the AUX - IN connector on the second VOODOO® speaker.
3. Adjusting the volume of the speaker connected to the source will affect the
volume of the second speaker. However the second speaker can be adjusted
again by increasing or decreasing the volume directly with its control buttons.
ADVICE:
If you want even more power, you can repeat it with as many VOODOO®
speakers as you want.
COMMENT:
You can do the same by connecting your mobile device in Bluetooth.
x
BATTErY uSE
When the battery is fully charged you can use your speaker for 15 hours in
a normal use.
The battery discharge time varies depending on the features used (USB
charger, Bluetooth connection, True Wireless Stereo connection ...)
COMMENT:
Your speaker will be fully charged after 2h30.
To increase the battery autonomy, reduce the sound volume.
BATTerY LiFe
LiFe CYCLe
rePLACing THe BATTerY
After 500 cycles of use, the battery autonomy will decrease by 10%. The
battery will last 13h instead of 15h initially.
BE CAREFUL:
The user must not repair or replace the battery supplied with the system. It
is necessary to contact PEOPEO customer service for any problem related to
the battery.
17
IN IN
OuT
CHArging Your MoBiLe deViCes
You can charge different types of mobile devices such as a mobile phone,
tablet or electronic cigarette thank to the USB plug on the side of your
speaker.
ACCESSOrIES
18
rAin CoVer
The VOODOO® was made for an outdoor and indoor use.
It has made to resist to a « normal » climate and environment. It meets the
IP44 waterproof standard.
The rain cover protects your speaker from bad weather such as heavy rain.
Easy to put on, you have to place it on the front of the VOODOO® speaker.
ADVICE :
When not in use, it is better to store and protect it in a well-ventilated area
away from high temperatures, dust and moisture.
COMMENT:
To prevent any malfunction, the VOODOO® must be protected from bad
weather. When the VOODOO® speaker is not used, it is better to store it in
a clean and dry place.
OPTIONS
side PoCKeTs
BE CAREFUL:
The side pockets must be added when the speaker is manufactured.
It is impossible to ad this option after the speaker is delivered, except if
you send it back to PEOPEO company.
For any request, please contact PEOPEO Customer Service s[email protected]
19
OPTIONS
side PoCKeTs
To set up your pockets:
Step 1: Unscrew the screws on the left and right sides of your speaker: 10
screws to remove.
Step 2: Take these screws and add the male part of the clips. Rescrew it at
the same place.
Step 3: Clip your pockets on the side.
COMMENT:
If one of the component looks damaged, do not try to use it. Contact imme-
diately PEOPEO Customer Service.
20
IMPOrTANT SAfETY INfOrMATION
Read these informations carefully and keep it for future reference.
WARNINGS:
• The aesthetic of the speaker is unique: resulting from specic technology
and manufacturing techniques.
• This product is weatherproof but not waterproof! (IP44)
• Never put the speaker into water.
• To reduce the risk of malfunction, never expose without protection, your
speaker to the rain for too long.
• Do not spill any liquid on the speaker.
• Do not leave the speaker outside without protection for several days.
• Do not clean the speaker with water.
• Never place aming objects, such as lighted candles, on the speaker.
• Do not use another battery charger than the one supplied with your speaker.
• Do not connect the same mini-jack cable to the AUX-IN and AUX-OUT jack
at the same time.
• The speaker should be stored and kept out of reach of babies and children
under 6 years old.
• The speaker should not be used at a high volume level in the presence of
young children.
• Do not keep in charge the battery of your speaker for long periods without
use.
• After long periods without use, the speaker may be discharged.
• The battery life is better when the speaker is used in a place at a normal
temperature (between 5 ° C and 20 ° C).
• The user must not repair or replace any component of the speaker. You must
contact PEOPEO customer service for any problem.
• Do not open the speaker.
21
12
3
22
BE CAREFUL: any unauthorized modication may compromise your safety,
the respect of regulations and the speaker’s functioning, and invalidate the
warranty.
WARNING: this product contains magnetic components. Contact your doctor
for any questions regarding the effect of these components on an implanted
medical device.
1. Read these instructions carefully.
2. Keep these instructions.
3. Respect all warnings.
4. Follow all instructions.
5. Use only a dry dust-cloth for cleaning.
6. Never block the air vents.
7. Follow the manufacturer’s instructions for installation.
8. Do not install this product close to any heat source.
9. Use only accessories specied by the manufacturer.
10. Unplug the speaker during thunder, storms or any long unused periods.
11. Contact PEOPEO to any repairs. A repair is necessary when the unit has
been damaged in any way.
Any modication not expressly authorized by PEOPEO may cancel the user’s
right to use this device.
Treatment of electrical and electronic appliances at home.
PEOPEO declares this product meets the criteria and other
applicable provisions of the European Directives.
It meets UL 94 V ammability requirements.
Lithium-Ion battery used, meets Safety IEC 62133 (2012) and UN 38.3 standards.
23
INfOrMATION TO NOTE ANd
CONSErVE
The name of the model and the serial number are written below the speaker.
Serial number: _______________________________________
Model: VOODOO® speaker
Purchase date:___________________________________________
We advise to keep your receipt with this guide.
Phone number (France) : +33(0)7 67 20 22 79
IMPOrTANT SAfETY INfOrMATION
OPErATION
24
Place the speaker only on its base. Standing the speaker on any other side
can cause damage to the speaker and badly affect the sound quality.
BE CAREFUL:
It is imperative not to put the speaker on a wobbly and/or fragile base
because of the size and the weight of the VOODOO®. The VOODOO®
speaker must to be carried by its handle or slings.
ADVICE:
The sound quality is even better when the VOODOO® is on the ground.
To avoid wireless interference:
• Keep other wireless equipment away from the speaker.
• Do not place the speaker and your mobile device on a metal shelf and away
from any audio/video equipment and direct heat source.
TrANSPOrT AdVICE
25
inside THe PLAne
You have to respect some rules when you transport the VOODOO® speaker.
• Unintentional activation of the speaker must be made impossible in your
luggage. Make sure your speaker is completely discharged.
• Electronic mobile devices between 100 WH and 160 WH can be transpor-
ted in the cabin and as checked baggage with the prior airline company’s
approval.
BE CAREFUL:
Each airline company has specicities. It is important to contact before your
trip, your airline company or your tour operator to know all the regulations.
oTHer MeAns oF TrAnsPorT
BE CAREFUL:
The speaker may be carried on your back provided you do not endanger
your safety and health.
It is strongly not recommanded to carry your speaker on the back while
traveling by motorbike, scooter or ski/snowboard.
PEOPEO is in no way responsible for any injury related to the transport of
the VOODOO® speaker.
MAINTENANCE ANd CArE
ProBLeM soLVing
MAINTENANCE ANd CArE
ProBLeM soLVing
PrOBLEMS SOLuTIONS
No power (sector) • Secure the power cord at both ends.
• Connect the power cord to a power electri-
cal outlet.
• Use the AC adapter supplied with your
speaker.
No power (battery). It is possible your battery is uncharged.
Connect the power cord to a power electrical
outlet.
The speaker is not
connected to the mobile
device.
• On your mobile device: - Disable and
enable the Bluetooth function. - Delete the
speaker from your device list. Pair it again.
• Put the mobile device closer to the speaker
and away from sources of interference or
obstructions.
• Pair it to another mobile device.
No sound on your mobile
device. • Turn on the speaker.
• Increase the volume of your speaker, your
mobile device and the music source.
• Press AUX and make sure you use the right
mobile device.
• Put the mobile device closer to the speaker
and away from sources of interference or
obstructions.
• Try with another mobile device.
• Pair your speaker with another mobile
device.
• On your mobile device: - Disable and enable
the Bluetooth function. - Delete the speaker
from your device list. Pair it again.
• Make sure your mobile device is compatible.
Bad sound quality from
your mobile device. • Try with another music source.
• Pair it to another mobile device.
• Disable the second mobile device.
• Put the mobile device closer to the speaker
and away from sources of interference or
obstructions.
No sound on the auxi-
liary device. • Turn on the auxiliary device and start to
play.
• Connect the 3.5mm cable correctly to
the AUX connector on the speaker and the
auxiliary device.
• Increase the volume on the speaker and on
the auxiliary device.
• Use another AUX cable.
• Connect another auxiliary device.
Inhabitual noise. • Try with another music source.
• Pair it with another mobile device.
• Disable the second mobile device.
• Put the mobile device closer to the speaker
and away from sources of interference or
obstructions.
• Check that the screws on the speaker are
properly tightened.
Red led indicator lights
up continuously • Turn off the speaker, wait 5 secondes and
turn back on.
26 27
CLeAning
MAINTENANCE ANd CArE
• You can clean the surface of the system with a soft, clean and dry dust-
cloth.
• Do not use aerosols near the system. Do not use solvents, chemicals, or
cleaning uids containing alcohol, ammonia, or abrasives substances.
• Make sure that no liquid enters the gaps.
• Do not try to disassemble parts of the speaker in order to clean them or
for any other reason.
• For the maintenance of the slings, they must be unhooked from the spea-
ker. Then clean them with cold water by using a clean sponge.
LIMITEd WArrANTY
29
Your system is guaranteed by a limited warranty.
Content of the commercial warranty:
PEOPEO guarantees your product free of charge against any failure, any
defect (including defects in material and workmanship) and any malfunction
of your product.
This warranty applies only to the original purchaser or the person receiving
the product as a gift and may not be extended to any other subsequent
beneciary.
If any breakdown, defect or malfunction appearing on your product during
the period of the guarantee, PEOPEO engages automatically and without
any expenses for the customer to (at the choice of PEOPEO): 1 / to repair
the product 2 / to replace the product 3 / refund the purchase price of the
product in exchange for the return of product.
Time of the commercial warranty:
The speaker’s warranty is valid only for a period of two (2) years from the
date of the delivery.
Terms and deadlines for implementing the commercial guarantee:
The customer must to contact PEOPEO customer service by email sav@
peopeo.io or by phone +33(0)7 67 20 22 79.
Before providing a warranty service, PEOPEO may request to provide proof
of purchase including a receipt or invoice. The commercial warranty will not
apply if the serial number has been removed from the product.
Warranty disclaimer :
PEOPEO’s commercial warranty does not cover damage to the product that
results from normal wear and tear of the product, operating fault, improper
use of the product, improper maintenance of the product, or damage to
the product, accidental breakage, no respect of these instructions in this
document.
Any unauthorized intervention on the product by the customer, disassembly,
modication, personalization or a repair performed by anyone other than
PEOPEO void the commercial warranty.
28
30
Legal warranty rights:
You have the following legal rights:
Article R. 211-4 of the French Consumer Code:
In contracts concluded between professionals on the one hand and non-
professionals or consumers on the other, the professional can not contrac-
tually guarantee the goods to be delivered or the service to be rendered
without clearly mentioning that in any event, the legal warranty that obliges
the professional seller to guarantee the buyer against all consequences of
defects or latent defects of the thing sold or service rendered.
Article L. 217-4 of the French Consumer Code:
The seller delivers a property in accordance with the contract and answers
for the lack of conformity existing during the delivery. It also responds to
any lack of conformity resulting from the packaging, the assembly instruc-
tions or the installation when it was charged to it by the contract or was
carried out under its responsibility.
Article L. 217-5 of the French Consumer Code:
The property is in accordance with the contract:
1 ° If it is t for the customary use of a similar good and, where applicable:
- if it corresponds to the description given by the seller and
possesses the qualities that he has presented to the buyer in the form of a
sample or a model;
- it has the qualities that a buyer can legitimately expect given
the public statements made by the seller, the producer or his representa-
tive, including advertising or labeling;
2 ° Or if it has the characteristics dened by mutual agreement by the par-
ties or is suitable for any special use by the buyer, made known to the seller
and that the latter has accepted.
LIMITEd WArrANTY
31
Article L. 217-12 of the French Consumer Code:
The action resulting from the lack of conformity is prescribed by two years
from the delivery of the property.
Article 1641 of the French Civil Code:
The seller is bound by the guarantee by reason of the hidden defects of the
product sold which render it unsuitable for the use for which it is intended,
or which diminish the use so much that the buyer would not have acquired
it, or would have given a lower price, if he had known them.
Article 1648 §1 of the French Civil Code:
The action resulting from latent defects must be brought by the purchaser
within two years from the discovery of the defect.
LIMITEd WArrANTY
CuSTOMEr SErVICE
For any further question, please contact PEOPEO customer service :
- by e-mail sav@peopeo.io
- by phone +33(0)7 67 20 22 79
You can also go one our website www.peopeo.io and visit our Support page.
Table of contents
