PepperBall FlashLauncher User manual

FlashLauncher™
PepperBall®User Manual
WARNING
THIS LAUNCHER IS NOT A TOY AND IS INTENDED FOR USE BY MILITARY,
LAW ENFORCEMENT, CORRECTIONAL OFFICERS, PRIVATE SECURITY
GUARDS, BAIL ENFORCEMENT AGENTS AND OTHER AUTHORIZED PERSON-
NEL. THIS PRODUCT LAUNCHES PROJECTILES FROM THE BARREL. MISUSE
MAY CAUSE SERIOUS INJURY OR DEATH. EXCEPT WHEN THE LAUNCHER IS
IN USE, ALWAYS MAKE SURE THAT THE TRIGGER SAFETY IS IN THE “SAFE
MODE”. SEE ADDITIONAL SAFETY GUIDELINES AND USER INSTRUCTIONS IN
THIS MANUAL.

FLASHLAUNCHER
MANUAL

TABLE OF CONTENTS
Warning / Liability.................................................................................................................................. Page 5
Safety..................................................................................................................................................... Page 6-7
Getting Started ...................................................................................................................................... Page 8
Operational Instructions ...................................................................................................................... Page 9
Inserting CO2Cartridge ...................................................................................................................... Page 10
Loading / Firing Projectiles .......................................................................................................... Page 11-12
Cleaning and Maintenance ..................................................................................................................Page 13
Warranty and Repairs ...........................................................................................................................Page 14
Warranty Registration .........................................................................................................................Page 15
FLASHLAUNCHER
MANUAL

FLASHLAUNCHER
MANUAL
THANK YOU
Thank you for your purchase of this PepperBall®launcher.
This launcher has been designed by United Tactical Systems, LLC.
(UTS) for reliability, accuracy and durability. When properly handled,
this launcher will give many years of dependable service. Please take
the time to read through this manual and become familiar with the
safety precautions, parts, operation and maintenance before you
attempt to load or re this launcher. This manual is a supplement to the
recommended training. It should be used when training for proper use,
required certication or performance of recommended maintenance.
By acceptance of this launcher, you and the user assume total
responsibility for its safe and lawful use. The user must observe the
same safety precautions as they would with any rearm and should use
caution at all times when using, maintaining or otherwise handling this
launcher.
Please read this entire user manual before attempting to operate this
launcher.

FLASHLAUNCHER
MANUAL
5
WARNING/LIABILITY STATEMENT
WARNING: This PepperBall®launcher is a dangerous weapon.
The user assumes all liability from unsafe handling or any action that
constitutes a violation of any applicable laws or regulations. United
Tactical Systems, LLC. (UTS) shall not be liable for personal injury, loss
of property or loss of life resulting from the use of this weapon under
any circumstances, including any intentional, reckless, negligent or
accidental discharges. By using this PepperBall®launcher, you release
UTS of any and all liability associated with its use.
All information in this manual is subject to change without notice. UTS
reserves the right to make changes and improvements to products
without incurring any obligation to incorporate such improvements in
products previously sold.
IF YOU DO NOT ACCEPT LIABILITY, DO NOT USE THIS OR ANY
PEPPERBALL®LAUNCHER.
WARNING: This product contains chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm.

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 7
6
SAFETY
SAFETY IS YOUR RESPONSIBILITY!
The safety information below contains important warnings related to
the proper use of the launcher, projectiles and CO2 canisters. Do not
load, discharge or otherwise use this launcher until you have completely
read this manual and are familiar with its safety features, mechanical
operation and handling characteristics.
• DANGER: Never aim at the face, eyes, ears, throat or spine.
• DANGER: Never look down the barrel of the launcher. Accidental
discharge into the eyes may cause permanent injury or death.
• Eye, face and ear protection should be worn by the user.
• Handle this launcher as if it were loaded at all times.
• Keep your nger off of the trigger until ready to re.
• Keep this launcher on safe mode until ready to re.
• Always keep the barrel pointed down or in a safe direction.
• Never point or discharge your launcher at anything you do not intend
to shoot.
• Never discharge your launcher at the personal property of others.
• Do not disassemble this launcher while it is pressurized or attempt to
pressurize while it is disassembled.
• Keep exposed skin away from any escaping gas when in use and
when installing or removing air supply.
• Use only PepperBall®authorized projectiles in this launcher. The use
of any unauthorized projectiles in this launcher will void all warranties.
• The use of any unauthorized accessories or alterations to this
launcher, including the use of aftermarket products, will void all
warranties.
• If any laser is equipped with this launcher, never point laser directly
at eyes and observe all safety warnings associated with the equipped
laser.
• Always verify launcher is in safe mode and stored in a safe and secure
location when not in use.

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 7
6
SAFETY
PROJECTILES
Recommended Pressures for Optimum Operating Performance of the
Equipment
This PepperBall®launcher may have the ability to launch both Round
PepperBall®projectiles and Shaped PepperBall®projectiles.
When launching Round PepperBall®projectiles the recommended
output velocity range is 280-315 FPS. Exceeding velocities over 315
FPS may have an adverse effect on accuracy.
When launching Shaped PepperBall®projectiles the recommended
output velocity range is 280-385 FPS. Exceeding velocities over 385
FPS may increase projectile breakage in the launcher.
Before Use: It is recommended that prior to each use or anytime
that a change is made to the type of projectile launching from this
PepperBall®launcher, or an adjustment to the velocity setting,
the launcher is rst veried with a chronograph to assure that the
velocities are within the recommended output velocity range.
CO2 CANISTERS OR HIGH PRESSURE SYSTEMS
This PepperBall®launcher does not include a CO2 Canister or High
Pressure Air System that is under pressure.
When using this PepperBall®launcher with either a CO2 Canister or
High Pressure Air System that is under pressure, then the following
WARNING, along with any additional warning listed on the Canister or
High Pressure Air System is to be followed.
WARNING - CONTENTS UNDER PRESSURE
Do not puncture or incinerate container. Do not expose to heat or
store at temperatures above 120°F. Keep out of the reach of children.

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 9
8
GETTING STARTED
1. Insert the lanyard through the end opening of the FlashLauncher and
loop through the opening and pull tight (as shown below).
2. Remove the Safety Pin before using the FlashLauncher.
The Safety Pin has been installed as safety against accidental
 r i n g . T h e S a f e t y P i n s h o u l d r e m a i n i n p l a c e w h e n t h e
FlashLauncher is not in use.
3. Secure the Safety Pin by attaching it to the end of the lanyard for
future desired safety and use (as shown below).

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 9
8
FLASHLAUNCHER OPERATIONAL
INSTRUCTIONS
1. Place the FlashLauncher in safe mode.
2. Insert the batteries (on selected products).
A. To install non-rechargeable batteries. Place them in the
Battery Tray following the correct placement of + or -. Attach
the connector and close the battery door.
B. To install rechargeable batteries - disconnect connector
from battery tray (for non-chargeable) and attach the
connector of the rechargeable battery in its’ place.
3. To secure that the battery door is closed, push the latch forward
until it clicks.
FlashLauncher
in Safe Mode
Ready to Fire position
Open and insert batteries
PepperBall®recommends that all operators receive training in the
proper use of this or any PepperBall®launcher system prior to its
deployment. For a list of upcoming PepperBall®training courses,
please visit www.PepperBall.com or call 1-877-887-3773
Non-rechargeable battery
tray
Rechargeable battery with
connector
WARNING: DO NOT leave the
ashlight on when charging the
battery. Leaving the ashlight
on during battery recharge may
result in damaging the LED.

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 11
10
INSERTING CO2CARTRIDGE
1. Unscrew Puncture Ram from cartridge chamber located in the back
of the FlashLauncher.
2. Insert recommended 12 gram CO2 (skinny side rst) into the
cartridge chamber where you removed the Puncture Ram. (CO2is not
included)
3. Re-install Puncture Ram into cartridge chamber and tighten until
Puncture Ram is ush with the back of the unit.
NOTE: PepperBall®recommends the user only install 12 gram cartridges that
have been ASTM certified to meet size standards.
Place small end of 12 gram
CO2 cartridge in rst
Tighten puncture ram by
turning clockwise

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 11
10
LOADING PROJECTILES
1. Remove Projectile Cartridge from the rear of the FlashLauncher by
pushing in and turning approximately 1/8 turn clockwise.
2. A tab on the Projectile Cartridge will line up with a notch in the body
of the FlashLauncher so it can be removed.
3. Place ve PepperBall®projectiles into the Cartridge chamber where
you removed the Projectile Cartridge. Reinsert the Projectile
Cartridge and turn it approximately 1/8 turn counterclockwise until it
locks back into place.
NOTE: Never place more than ve PepperBall®projectiles in the
FlashLauncher.
Remove ball feeder tube
from rear of FlashLauncher

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 13
12
FIRING FLASHLAUNCHER
WARNINGS:
- Never point laser direct into eyes
- Do not shoot at head, neck or spine
- Do not shoot FlashLauncher at unattended target
- Always unload and remove the 12 gram cartridge before storing
1 . T h e F l a s h L a u n c h e r i s n o w r e a d y t o  r e . A i m t h e F l a s h L a u n c h e r a t
the intended target and slide the safety to the forward position. This
will activate the laser and also reveal the red trigger. Place the laser
o n t h e t a r g e t a n d  r m l y p r e s s t h e r e d t r i g g e r d o w n w i t h y o u r t h u m b .
P r e s s t h e R e d T r i g g e r  r m l y u n t i l P r o j e c t i l e i s l a u n c h e d a n d
straight down.
2 . W h e n n o l o n g e r l a u n c h i n g p r o j e c t i l e s a t t h e i n t e n d e d t a r g e t ;  r s t
lower FlashLauncher towards ground and then slide safety rearward
to cover red trigger.
ALWAYS keep red trigger covered when not in use.
3. Replace the 12 gram CO2 c a r t r i d g e a f t e r  r i n g  v e p r o j e c t i l e s o r
any time the FlashLauncher will be stored. NOTE: CO2cartridge
w i l l b e p i e r c e d o n l y a t  r s t t r i g g e r p u s h a f t e r e a c h t i m e t h e
FlashLauncher is reloaded with a new cartridge.
The ashlight can be
activated by pressing the
black rubber ashlight
switch
Press red trigger straight
down rmly to re
FlashLauncher

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 13
12
• WARNING: Never perform cleaning or maintenance on a loaded or
pressurized launcher.
• Remove all projectiles and CO2 cartridges from the magazine and
launcher prior to doing any cleaning or maintenance.
• To clean the launcher, remove the barrel as described in Section 5:
Operation. Use a 68 caliber soft nylon brush or 12 gauge patch tip
with a soft cotton cloth to clean the barrel.
• Keep the barrel of the launcher completely dry. Do not place lubricant
or water in the barrel of the launcher. The launcher is designed to be
used with the barrel completely dry.
• Never use petroleum based cleaning solvents or lubricants.
• Never use cleaning solvents that come in aerosol cans.
CLEANING & MAINTENANCE

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 15
14
WARRANTY, DISCLAIMER OF WARRANTY AND
LIMITATION OF REMEDIES
United Tactical Systems, LLC (UTS) warrants, solely to the end user, law enforcement
agencies, private security rms, or private or public corrections agencies, that the
product is delivered free from defects in materials and workmanship for a period
of one (1) year from the original date of purchase.
Within the one-year warranty period, UTS’s liability and the buyer’s sole and
exclusive remedy hereunder for all claims shall be limited to a refund or credit
to buyer of the purchase price, or replacement of this product, at UTS’s option,
provided that the non-conforming product is (1) returned during the warranty
period and (2) properly packaged and shipped to UTS’s designated facility in
accordance with UTS’s Return Merchandise Authorization (RMA) Policy.
THE REMEDY SET FORTH ABOVE SHALL BE THE SOLE AND EXCLUSIVE REMEDY
FOR BREACH OF THE FOREGOING WARRANTY.
Products which have been improperly handled, stored or shipped, or which have
been subject to abuse, misuse, alteration and/or neglect are not covered by the
warranty. Aftermarket products and the use of non-authorized projectiles are
strictly prohibited by UTS and any indication of their installation or use shall void
all warranties.
DISCLAIMER OF WARRANTY: Except for the express limited warranty set
forth above, UTS makes no warranties or representations of any kind, whether
express or implied, with respect to the product, including any (a) warranty of
merchantability; or (b) warranty of tness for a particular purpose; or (c) warranty
against infringement of intellectual property rights of a third-party, whether
express or implied by law, course of dealing, course of performance, usage of
trade or otherwise. There are no warranties which extend beyond the description
of the face hereof. Buyer shall make no warranty or representation regarding the
products that is inconsistent with the warranty set forth above. UTS shall not be
liable for any injury, loss, or damage, direct or consequential, arising out of the
use or the inability to use this product.
Before Use: the user shall determine the suitability of the product and be fully
trained for its intended use, and user assumes all risks and liability whatsoever in
connection therein. In no event shall UTS be liable or obligated to buyer or to any
third party in any manner for any (a) special, non-compensatory, consequential,
indirect, incidental, statutory, or punitive damages of any kind, including, without
limitation, lost prots and/or lost revenue, regardless of the form of action, whether
in contract, tort, negligence, strict product liability, or otherwise, even if informed
of or aware of the possibility of any such damages in advance, (b) in an amount
greater than the amounts paid to UTS by buyer for the products, or (c) damage
or injury caused by the products, unless due to the gross negligence or willful
misconduct of UTS. The limitations set forth above shall be deemed to apply to
the maximum extent permitted by applicable law and notwithstanding the failure
of the essential purpose of any limited remedies. The parties acknowledge and
agree that they have fully considered the foregoing allocation of risk and nd it
reasonable, and that the foregoing limitations are an essential basis of the bargain
between the parties.

FLASHLAUNCHER
MANUAL
FLASHLAUNCHER
MANUAL 15
14
UTS RETURN MERCHANDISE AUTHORIZE
(RMA) POLICY
For warranty and non-warranty repair:
• Call UTS at 1-260-478-2500
• UTS will issue a Return Authorization (RA) Number
• UTS will provide the shipment address
• Please make sure that the RA Number is clearly marked on the
outside of the package
• Include a brief statement regarding the requested repair, your name,
your return address and a telephone number where you can be
reached during normal business hours with the shipment
• CAUTION: ALWAYS UNLOAD AND REMOVE AIR SOURCE AND
PROJECTILES BEFORE SHIPPING A LAUNCHER
• CAUTION: THE AIR SOURCE MUST BE DISCHARGED
• Postage and delivery charges must be pre-paid. Collect delivery
charges will not be accepted
• Products within the one year warranty period are returned via ground
shipping at no charge
• Out of warranty returns require a pre-payment of shipping charges
prior to return shipment by UTS
• You may request expedited shipping at your expense with charges
paid prior to return shipment
UTS strives to complete the necessary repair work within a reasonable
amount time and return the launcher with standard ground shipping.
WARRANTY REGISTRATION
To ensure that your launcher is properly registered with UTS, please ll
out the warranty registration card provided with your launcher.
Please send to the address indicated on the registration card.

877.887.3773 | 28101 BALLARD DRIVE | LAKE FOREST, ILLINOIS 60045
www.PepperBall.com
