Pepperl+Fuchs HiD2822 User manual

Release date 2016-06-16 14:16 Date of issue 2016-06-16 121448_eng.xml
HiD2822
1
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group USA: [phone] Singapore: [phone]Germany: [phone]
www.pepperl-fuchs.com [email protected].com [email protected].com [email protected]
Switch Amplifier
Zone 0, 1, 2
Div. 1, 2
HiD2822
I
II
10 kΩ
1.5 kΩ
10 kΩ
1.5 kΩ
I
II
SL2 SL1
+
-
8a
7a
8b
7b
10a
9a
9b
10b
11
14
17
18
12
15
13
16
5a
5b
+
-
1a
1b
1
4
2
5
+
-
+
-
+
-
+
-
+
-24 V DC
FAULT
1a, 1b
2a, 2b
6b
Termination Board
Connection
Assembly
• 2-channel isolated barrier
• 24 V DC supply (bus powered)
• Dry contact or NAMUR inputs
• Usable as signal splitter (1 input and 2 outputs)
• 2 relay contact outputs per channel
• Line fault detection (LFD)
• Up to SIL 2 acc. to IEC 61508
Function
This isolated barrier is used for intrinsic safety applications. It
transfers digital signals (NAMUR sensors/mechanical
contacts) from a hazardous area to a safe area.
The proximity sensor or switch controls two form A normally
open relay outputs for the safe area load. The module output
changes state when the input signal changes state. The
normal output state can be reversed with the selector switches
on the side of the unit.
Line fault detection (LFD) can be selected or disabled via a
selector switch.
During an error condition, the relay reverts to its de-energized
state and the LEDs indicate the fault. A separate fault output
bus is available. The fault conditions can be monitored via a
Fault Indication Board.
This module mounts on a HiD Termination Board.
2
Features
HiD
2822
2 ch
Switch
Amplifier
PWR
CH 2
STATUSFAULT
CH 1
Front view
LEDs red:
Fault channel 1 ... 2
LED green:
Power supply
LEDs yellow:
Status output
channel 1 ... 2
Switch 1 ... 4
Place for
labeling

Release date 2016-06-16 14:16 Date of issue 2016-06-16 121448_eng.xml
Technical data HiD2822
2
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group USA: [phone] Singapore: [phone]Germany: [phone]
www.pepperl-fuchs.com [email protected].com [email protected].com [email protected]
General specifications
Signal type Digital Input
Supply
Connection SL1: 1a(-), 1b(-); 2a(+), 2b(+)
Rated voltage Un20.4 ... 30 V DC via Termination Board
Rated current In15 mA at 24 V, relay energized (per channel)
Power dissipation 0.35 W at 24 V (per channel)
Input
Connection SL2: 5a(+), 5b(-); 1a(+), 1b(-)
Rated values acc. to EN 60947-5-6 (NAMUR)
Connectable sensor types potential free contact or proximity sensor
Switching point contact open 0.2 ... 1.2 mA, contact closed 2.1 ... 6.5 mA
Line fault detection breakage 0 ... 0.2 mA, short-circuit 6.5 mA ... maximum value
Output
Connection SL1: 8a, 7a, 8b, 7b; 10a, 9a, 10b, 9b
Output signal: relay DPST per channel, phase selectable
Response time 20 ms
Contact loading 50 V DC / 0.5 A non-inductive
Mechanical life 107switching cycles
Error message output
Connection SL1: 6b
Output type open collector transistor (internal fault bus)
Transfer characteristics
Switching frequency < 10 Hz
Electrical isolation
Output/power supply functional insulation acc. to DIN EN 50178, rated insulation voltage 50 Veff
Output/Output functional insulation acc. to DIN EN 50178, rated insulation voltage 50 Veff
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)
Conformity
Electrical isolation EN 50178:1997
Electromagnetic compatibility NE 21:2006
For further information see system description.
Degree of protection IEC 60529:2001
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Relative humidity 5 ... 90 %, non-condensing up to 35 °C (95 °F)
Mechanical specifications
Degree of protection IP20
Mass approx. 140 g
Dimensions 18 x 106 x 128 mm (0.7 x 4.2 x 5 inch)
Mounting on Termination Board
Coding pin 1 and 2 trimmed
For further information see system description.
Data for application in connection
with Ex-areas
EC-Type Examination Certificate CESI 02 ATEX 086
Group, category, type of protection ¬II (1)G [Ex ia Ga] IIC , ¬II (1)D [Ex ia Da] IIIC
Input Ex ia, Ex iaD
Voltage Uo13.2 V
Current Io20 mA
Power Po66 mW
Supply
Maximum safe voltage Um250 V AC (Attention! Umis no rated voltage.)
Statement of conformity PF 11 CERT 2109 X
Group, category, type of protection,
temperature class
¬II 3G Ex nA nC IIC T4 Gc
Electrical isolation
Input/input safe electrical isolation acc. to EN 60079-11:2007, voltage peak value 60 V
Input/Output safe electrical isolation acc. to EN 60079-11: 2007, voltage peak value 375 V
Input/power supply safe electrical isolation acc. to EN 60079-11: 2007, voltage peak value 375 V
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013 , EN 60079-11:2012 , EN 60079-15:2010
International approvals

Release date 2016-06-16 14:16 Date of issue 2016-06-16 121448_eng.xml
Technical data HiD2822
3
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group USA: [phone] Singapore: [phone]Germany: [phone]
www.pepperl-fuchs.com [email protected].com [email protected].com [email protected]
Configure the device in the following way:
• Push the red Quick Lok Bars on each side of the device in the upper position.
• Remove the device from Termination Board.
• Set the DIP switches according to the figure.
CSA approval
Control drawing 366-005CS-12B (cCSAus)
General information
Supplementary information EC-Type Examination Certificate, Statement of Conformity, Declaration of Conformity, Attestation of
Conformity and instructions have to be observed where applicable. For information see www.pepperl-
fuchs.com.
Channel 3 and 4 (switch 5 ... 8) only for HiD2824.
The pins for this device are trimmed to polarize it according to its safety parameter. Do not change!
For further information see system description.
Configuration
Input CLOSE/Relay de-energised
Input OPEN/Relay energised
Lead fault detection LFD enable
Switch positions
Phase CH 1 LFD CH 1 Phase CH 2 LFD CH 2 Phase CH 3 LFD CH 3 Phase CH 4 LFD CH 4
SWITCH SETTINGS
INPUT/OUTPUT
OPERATION
1
CH1
3
CH2
5
CH3
7
CH4
OPEN-ENERGIZED
CLOSE-DE-ENERGIZED
ON ON ON ON
CLOSE-ENERGIZED
OPEN-DE-ENERGIZED
OFF OFF OFF OFF
INPUT FAULT
DETECTION
2
CH1
4
CH2
6
CH3
8
CH4
FAULT ENABLE ON ON ON ON
FAULT DI SABLE OFF OFF OFF OFF
1 2 3 4 5 6 7 8
ON
CAUTION
Refer to the instruction
manual to install and
operate the unit
SELECTION
1 2
CH 1
NOTE: CH 3 and CH 4 only for Mod. 2824
3 4
CH 2
5 6
CH 3
7 8
CH 4
ON
NOT IN USE
FOR THIS MODEL

Release date 2016-06-16 14:16 Date of issue 2016-06-16 121448_eng.xml
Technical data HiD2822
4
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Pepperl+Fuchs Group USA: [phone] Singapore: [phone]Germany: [phone]
www.pepperl-fuchs.com [email protected].com [email protected].com [email protected]
The maximum number of switching cycles is depending on the electrical load and may be higher when reduced currents and
voltages are applied.
Maximum switching power of output contacts
1
I (A)
10050 U (V) 30
0.5
0.3
Electrical life
max. 1 x 105switching cycles
Electrical life
max. 5 x 104switching cycles
Resistive load DC
