Pepperl+Fuchs LAL-SRW3 User manual

ISO9001
LAL-SRW3
WARNING DEVICE
WARNANLAGE
SYSTÈME D'ALARME
ALARMSYSTEM
EN
DE
FR
DA
PROCESS AUTOMATION
MANUAL

With regard to the supply of products, the current issue of the following docu-
ment is applicable: The General Terms of Delivery for Products and Services of
the Electrical Industry, published by the Central Association of the Electrical In-
dustry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its
most recent version as well as the supplementary clause: "Expanded reservation
of proprietorship"
Es gelten die Allgemeinen Lieferbedingungen für Erzeugnisse und Leistungen
der Elektroindustrie, herausgegeben vom Zentralverband Elektroindustrie
(ZVEI) e.V. in ihrer neusten Fassung sowie die Ergänzungsklausel: "Erweiterter
Eigentumsvorbehalt".
Les conditions de vente générales pour les produits et les services de l'industrie
des équipements électriques publiées par la Fédération de l'industrie électron-
ique (ZVEI) s'appliquent dans leur toute dernière version, tout comme la clause
complémentaire "Réserve de propriété élargie".
De almene leveringsbetingelser for produkter og ydelser fra elektronikindustrien,
der er udgivet af Zentralverband Elektroindustrie (ZVEI) e.V. i den seneste ud-
gave samt tillægsklasulen: "Udvidet ejendomforbehold" er gældende".
EN
DE
FR
DA
WARNING DEVICE LAL-SRW3

WARNING DEVICE LAL-SRW3
Content
232971 2011-03
EN - 1
EN
1 Safety................................................................................... 3
1.1 General safety instructions ............................................................................3
1.2 Used Symbols...............................................................................................3
1.3 Declaration of Conformity..............................................................................4
1.4 Intended Use ................................................................................................4
1.5 Maintenance .................................................................................................5
1.6 Delivery, Transport and Storage ....................................................................5
1.7 Installation and Commissioning ....................................................................6
1.8 Installation in connection with intrinsically safe circuits..................................6
1.9 Repair ...........................................................................................................7
1.10 Disposal........................................................................................................7
1.11 Applied Standards and Directives .................................................................7
2 Product Specifications....................................................... 8
2.1 Function........................................................................................................8
2.2 Product Program...........................................................................................8
2.3 Design and Dimensions................................................................................9
3 Installation......................................................................... 10
3.1 Mounting of the Sensors.............................................................................10
3.2 Mounting of the Warning Device .................................................................15
3.3 Connection .................................................................................................16
4 Commissioning................................................................. 24
4.1 Configuring the Warning Device using DIP Switches ..................................24
5 Operation........................................................................... 26
5.1 Alarm Signals..............................................................................................26
5.2 Resetting the Alarm Signal..........................................................................26
5.3 Function Testing..........................................................................................27

232971 2011-03
2 - EN
WARNING DEVICE LAL-SRW3
Content
EN
6 Troubleshooting ............................................................... 29
6.1 Troubleshooting and Alarm States.............................................................. 29
6.2 System Care............................................................................................... 30
7 Technical specifications .................................................. 31
7.1 Warning Device LAL-SRW3 ....................................................................... 31
7.2 Overflow Sensor NVF-104/34-PF............................................................... 32
7.3 Oil Level Sensor KVF-104-PF .................................................................... 32
7.4 Sludge Level Sensor SLU-103-** ............................................................... 33
7.5 Cable Connector LAL-SK2......................................................................... 33

WARNING DEVICE LAL-SRW3
Safety
232971 2011-03
EN - 3
EN
1Safety
1.1 General safety instructions
The operator of the system is responsible in terms of planning, mounting,
commissioning, operating, maintenance and dismounting.
Installation and commissioning of all devices must be performed by a trained
professional only.
Protection of operating personnel and the system is not ensured if the product is
not used in accordance with its intended purpose.
Laws and regulations applicable to the usage or the intended purpose must be
observed. The devices are only approved for appropriate and intended use.
Ignoring these instructions will void any warranty and absolve the manufacturer
from any liability.
The Declaration of Conformity, Certificate of Compliance, Statement of
Conformity, EC-type-examination certificate and data sheets are an integral part of
this document.
The data sheet contains the electrical data of the Declaration of Conformity, the
Certificate of Compliance and the EC-type-examination certificate.
The documents mentioned are available from http://www.pepperl-fuchs.com or
contact your local Pepperl+Fuchs representative.
1.2 Used Symbols
Safety-relevant Symbols
Danger!
This symbol indicates a warning about a possible danger.
In case of ignoring the consequences may range from personal injury to death.
Warning!
This symbol indicates a warning about a possible fault or danger.
In the event the warning is ignored, the consequences may course personal injury
or heaviest property damage.
Caution!
This symbol warns of a possible fault.
In case of ignoring the devices and any connected facilities or systems may be
interrupted or fail completely.

232971 2011-03
4 - EN
WARNING DEVICE LAL-SRW3
Safety
EN
Informative Symbols
Action
This symbol marks an acting paragraph.
1.3 Declaration of Conformity
All products have been developed and manufactured taking into consideration
applicable European standards and regulations.
The manufacturer of this product, Pepperl+Fuchs GmbH in 68307 Mannheim,
Germany, has a certified quality assurance system in conformity with ISO 9001.
1.4 Intended Use
The warning device is a compact alarm system for monitoring sensors in the
Zone 0 hazardous area of oil/petrol separators.
The warning devices must only be installed in a suitable control cabinet or
NVO5-KV installation housing.
The warning device was designed to detect:
■the oil layer thickness, the maximum level of the liquid or the sludge level if
one sensor is connected,
■the oil layer thickness and the maximum level of the liquid if two sensors are
connected or
■the oil layer thickness, the maximum level of the liquid and the sludge level if
three sensors are connected.
Note!
This symbol brings important information to your attention.
Note!
A Declaration of Conformity can be requested from the manufacturer.
ISO9001

WARNING DEVICE LAL-SRW3
Safety
232971 2011-03
EN - 5
EN
Only the following sensors must be connected to the warning device:
1.4.1 Designation
1.5 Maintenance
The device must not be cleaned with caustic fluids.
The devices are maintenance-free. However, to guarantee perfect operation of
the complete alarm system, check the operation, including all sensors, at least
once a year.
1.6 Delivery, Transport and Storage
Check the packaging and contents for damage.
Check if you have received every item and if the items received are the ones you
ordered.
Keep the original packaging. Always store and transport the device in the original
packaging.
Always store the device in a clean and dry environment. The permitted storage
temperature (see data sheet) must be considered.
Description Type cod e
Overflow sensor, for detecting excessively high liquid level NVF-104/34-PF
Oil level sensor, for detecting of oil layer thickness KVF-104-PF
Sludge level sensor, for detecting sludge levels SLU-103-**
Warning device
Pepperl+Fuchs GmbH
Lilienthalstrasse 200, 68307 Mannheim, Germany
LAL-SRW3
BVS 09 ATEX E 137
II (1)G [Ex ia] IIB

232971 2011-03
6 - EN
WARNING DEVICE LAL-SRW3
Safety
EN
1.7 Installation and Commissioning
1.7.1 Installation of the warning device
The device must only be installed outside potentially explosive zones.
The device must not be installed in places with potentially aggressive vapors.
The device must be free of voltage during installation and maintenance.
The warning system must only be connected to the supply voltage after complete
mounting and connection of the sensors.
The identification plate must not be removed.
1.7.2 Connection to sensors for potentially explosive zone
In oil/petrol separators, only sensors that are certified for installation in potentially
explosive zones may be connected.
The type of protection of the external equipment must comply with the protection
type specified for the total system.
1.7.3 Sensor cables
Sensor cables must not be installed in cable or conductor bundles together with
other current circuits. Avoid installing sensor cables parallel to other cables that
may transmit interfering signals, which impair the sensor signal and thus the alarm
function. The sensor itself must not be grounded.
If you extend the sensor cable, observe the applicable ATEX specifications with
regard to color, quality and durability. Use unshielded 2-wire cables with a
cross-section of 1 mm²for each sensor.
1.8 Installation in connection with intrinsically safe circuits
Installation of the intrinsically safe power circuits of the devices is permitted in
potentially explosive zones, whereby, in particular, safe separation from all
non-intrinsically safe power circuits must be guaranteed.
The intrinsically safe current circuits must be installed according to valid setup
regulations.
For the interconnection of the intrinsically safe field devices and the intrinsically
safe power circuits of the associated devices, the respective maximum values of
the field device and the associated device with regard to explosion protection
must be observed (proof of intrinsic safety). EN 60079-14/IEC 60079-14 must be
observed.

WARNING DEVICE LAL-SRW3
Safety
232971 2011-03
EN - 7
EN
1.9 Repair
The devices must not be repaired, changed or manipulated. If there is a defect,
the product must always be replaced with an original device.
1.10 Disposal
Disposal of devices and their packaging material must be performed in
compliance with the applicable laws and guidelines of the corresponding country.
The devices do not contain batteries which need to be disposed of separately
from the products.
1.11 Applied Standards and Directives
EN 60079-0:2009
EN 60079-11:2007
EN 60079-26:2007
EN 50178
EN 61326-1:2006
NAMUR NE21:2007
EN 61000-6-4:2007
ATEX Directive 94/9/EC
EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC

232971 2011-03
8 - EN
WARNING DEVICE LAL-SRW3
Product Specifications
EN
2 Product Specifications
2.1 Function
The warning device monitors the status of
■an overflow sensor, a sludge level sensor or an oil level sensor, or
■a combination of an overflow sensor and an oil level sensor or
■a combination of an overflow sensor, a sludge level sensor and an oil level
sensor
in an oil/petrol separator.
LEDs at the device indicate alarm, sensor fault and system and sensor status. In
the event of an alarm, an additional acoustic signal sounds.
2.2 Product Program
Warning device
Sensors
Accessories
Description Type code
Intrinsically safe warning device, 230 V AC LAL-SRW3
Description Type code
Overflow sensor, for detecting excessively high liquid level NVF-104/34-PF
Oil level sensor, for detecting of oil layer thickness KVF-104-PF
Sludge level sensor, for detecting sludge levels SLU-103-**
Description Type code
Cable connector IP68 for one sensor LAL-SK2
Mounting set for one sensor NVO5-B
Installation housing with DIN mounting rail NVO5-KV

WARNING DEVICE LAL-SRW3
Product Specifications
232971 2011-03
EN - 9
EN
2.3 Design and Dimensions
Figure 2.1
1DIP switches
2LEDs
3Connections for power supply and potential-free contacts
4Reset button
5Sensor connections
LAL-SRW3
ALARM
RESET
OIL LEVEL
ALARM
OVERFLOW
ALARM
SLUDGE
ALARM
SYSTEM
OK
68307 Mannhei m Ge rma ny
www.pepperl-f uchs.com
Separator Alarm System
70 58
86
54
4
23
51

232971 2011-03
10 - EN
WARNING DEVICE LAL-SRW3
Installation
EN
3 Installation
3.1 Mounting of the Sensors
Read the Safety chapter, paying particular attention to the section covering
Installation and Commissioning (see chapter 1.7) before mounting the sensor. Do
not remove the identification plate.
During installation, refer to the instructions provided by the oil/petrol separator
manufacturer. Ensure that the suspension mechanism keeps the sensor
permanently at the correct height. Where possible, secure the device in a position
where it can be reached from the manhole opening so that it can be removed
when emptying (disposal) or carrying out maintenance work on the oil/petrol
separator.
Warning!
Risk of short circuit
Injuries and damage to the device are possible when working with live parts.
■Before working on the device, always disconnect the supply voltage.
■Connect the device to the supply voltage only after completion of the work.
Note!
Further information on the installation of the sensor is available in the manuals of
the sensors.

WARNING DEVICE LAL-SRW3
Installation
232971 2011-03
EN - 11
EN
The precise height of the sensor depends on how it is mounted. When mounting
in a concrete tank, for example, use the NVO5-B mounting set (see figure below).
For containers, tanks or separators made from other materials, such as plastic or
metal, use the appropriate alternative mounting options (screws and dowels).
Figure 3.1 Mounting using cable connector and mounting set
1Mounting set for one sensor NVO5-B
2Cable connector for one sensor LAL-SK2
21

232971 2011-03
12 - EN
WARNING DEVICE LAL-SRW3
Installation
EN
3.1.1 Mounting the NVF-104/34-PF Overflow Sensor
Usually, the sensor is mounted with the lower edge a few centimeters above the
normal liquid level (water zero line) in a position so close to the water zero line that
the switching point is surrounded by liquid when an overflow occurs. This occurs
■if the coalescence filter is dirty,
■if the automatic closure device is blocked, or
■if another situation causes the oily liquid to overflow or become contaminated.
The switching point is at the same level as the 5 mm hole on the side of the
sensor.
Figure 3.2 Mounting the overflow sensor
1Overflow sensor NVF-104/34-PF
AAir
BOil
CWater
LWater zero line
SSensor switching point
XAlarm limit (maximum liquid level)
B
C
A
1
L
S
X

WARNING DEVICE LAL-SRW3
Installation
232971 2011-03
EN - 13
EN
3.1.2 Mounting the SLU-103-** Sludge Level Sensor
The sensor must be immersed when the liquid is at its normal level (water zero
line).
The exact immersion depth depends on
■the type of oil/petrol separator,
■its design
■and the height of the maximum sludge layer thickness.
The sensor must always be immersed in the liquid. The switching point of the
sensor is located at the same level as the reflectors.
Figure 3.3 Mounting the sludge level sensor
1Sludge level sensor SLU-103-**
AAir
BOil
CWater
DSludge
LWater zero line
SSensor switching point
XAlarm limit (maximum sludge layer thickness)
C
A
D
1
L
S
B
X

232971 2011-03
14 - EN
WARNING DEVICE LAL-SRW3
Installation
EN
3.1.3 Mounting the KVF-104-PF Oil Level Sensor
The sensor must be immersed a few centimeters when the liquid is at its normal
level (water zero line).
The exact immersion depth depends on
■the type of oil/petrol separator,
■its design
■and its capacity.
The sensor must always be immersed in the liquid. The sensor switching point is
located between the insulated connecting piece and the top metal section.
Figure 3.4 Mounting the oil level sensor
1Oil level sensor KVF-104-PF
AAir
BOil
CWater
LWater zero line
SSensor switching point
XAlarm limit (maximum oil layer thickness)
L
S
B
C
A
1
X

WARNING DEVICE LAL-SRW3
Installation
232971 2011-03
EN - 15
EN
3.2 Mounting of the Warning Device
Mount the warning device on the DIN mounting rail
Clip the device on the DIN mounting rail as follows:
Figure 3.5
Note!
If the device is installed in a housing or switch cabinet, note the mounting
instructions of the housing or switch cabinet manufacturer.
Caution!
Overheating
If the external temperature exceeds a maximum of 60 °C, the device may be
damaged.
■Ensure sufficient ventilation at the installation location.
■Maintain a minimum distance of 5 mm between the devices on the
DIN mouting rail.
Click!

232971 2011-03
16 - EN
WARNING DEVICE LAL-SRW3
Installation
EN
3.3 Connection
Read the Safety chapter, paying particular attention to the section covering
Installation and Commissioning (see chapter 1.7) before connecting the device.
Do not remove the identification plate.
Take care not to reverse the polarity when connecting the sensor cable. The loop
resistance of the extension cable should not exceed
■20 Ωfor the sensor KVF-104-PF, SLU-103-**.
■10 Ωfor the sensor NVF-104/34-PF.
Warning!
Risk of short circuit
Injuries and damage to the device are possible when working with live parts.
■Before working on the device, always disconnect the supply voltage.
■Connect the device to the supply voltage only after completion of the work.

WARNING DEVICE LAL-SRW3
Installation
232971 2011-03
EN - 17
EN
Figure 3.6
Connecting and configuring the warning device with overflow sensor
1Overflow sensor connection
2Overflow sensor NVF-104/34-PF
3DIP switches
4Power supply
bu blue
bn brown
OFF
ON
13 15 22 24
18 20
10 11 12123 567
12345678
bubn
230 V AC
32
4
1

232971 2011-03
18 - EN
WARNING DEVICE LAL-SRW3
Installation
EN
Figure 3.7
Connecting and configuring the warning device with sludge level sensor
1Sludge level sensor connection
2Sludge level sensor SLU-103-**
3DIP switches
4Power supply
bu blue
bn brown
OFF
ON
10 11 12123 567
12345678
230 V AC
13 15 22 2418 20
3
4
2
1
bubn
