PERCo ST-02 Series Installation and operating instructions

CERTIFICATE
ST-02
Speed Gate
STD-02
and Double-Sided Section

ST-02 Speed gate
and STD-02
Double-sided section
Assembly and Operation Manual

CONTENTS
1Application .............................................................................................................................3
2Operating conditions ..............................................................................................................3
3Technical specifications .........................................................................................................4
4Delivery set............................................................................................................................6
4.1 Standard delivery set.......................................................................................................6
4.1.1 ST-02 Speed gate...................................................................................................................... 6
4.1.2 STD-02 Double-sided section.................................................................................................... 6
4.2 Optional equipment .........................................................................................................7
5Operation and description......................................................................................................7
5.1 Main features...................................................................................................................7
5.2 Device .............................................................................................................................8
5.2.1 Section ....................................................................................................................................... 9
5.2.2 Indication blocks ...................................................................................................................... 10
5.2.3 RC-panel.................................................................................................................................. 11
5.2.4 Control board ........................................................................................................................... 11
5.2.5 Remote terminal block (DIN rail).............................................................................................. 12
5.2.6 Control signals parameters...................................................................................................... 14
5.2.7 Control modes.......................................................................................................................... 15
5.2.8 Speed gate operation algorithm............................................................................................... 15
5.2.9 “Automatic opening in the selected direction” mode................................................................ 17
5.3 Operating devices..........................................................................................................17
5.3.1 RC-panel connection ............................................................................................................... 18
5.3.2 Fire Alarm device ..................................................................................................................... 18
5.3.3 Operation from the ACS .......................................................................................................... 19
5.4 Optional devices connected to the speed gate ..............................................................19
5.4.1 PASS Outputs.......................................................................................................................... 19
5.4.2 Siren......................................................................................................................................... 20
5.4.3 Remote indication blocks......................................................................................................... 20
6Marking and packaging........................................................................................................ 20
7Safety requirements.............................................................................................................21
7.1 Installation safety requirements .....................................................................................21
7.2 Operation safety requirements.......................................................................................22
8Installation ...........................................................................................................................22
8.1 Installation details ..........................................................................................................22
8.2 Tools and equipment required for installation ................................................................ 22
8.3 Cable length ..................................................................................................................23
8.4 Installation procedure ....................................................................................................23
8.5 Mounting surface layout.................................................................................................27
8.6 Speed gate wiring diagram ............................................................................................29
8.7 Installation and dismantling of the speed gate parts and elements ................................ 32
8.7.1 Dismantling and installation of the front end panel.................................................................. 32
8.7.2 Removing the section from the housing .................................................................................. 33
8.7.3 Dismantling and installation of the removable part of the section housing ............................. 34
8.7.4 Installation and dismantling of the central insert...................................................................... 35
8.7.5 Installation and dismantling of the filling glass......................................................................... 36
8.7.6 Installation and dismantling of the sliding panel ...................................................................... 37
8.7.7 Installation and dismantling of side panels .............................................................................. 38
8.7.8 Installation and dismantling of glass covers ............................................................................ 39
8.7.9 The reduction of the passageway width of STD-02.900 section ............................................. 40
9Operation............................................................................................................................. 42
9.1 Switching on the speed gate.......................................................................................... 42
9.2 Pulse control mode........................................................................................................42
9.3 Potential control mode...................................................................................................43
9.4 Actions in case of emergency........................................................................................ 44
9.4.1 "Alarm" mode ........................................................................................................................... 44
9.4.2 "Fire Alarm"mode.................................................................................................................... 44
10 Maintenance ........................................................................................................................45
11 Transportation and storage .................................................................................................. 45
Appendix 1. Operation algorithm in pulse control mode............................................................ 46
Appendix 2. Operation algorithm in potential control mode....................................................... 46

ST-02 Speed gate and STD-02 Double-sided section
3
Dear customers!
Thank you for purchasing PERCo product.
Please follow instructions given in this Manual carefully and this high quality product
will provide many years of trouble-free use.
Assembly and operation manual for the ST-02 speed gate and STD-02 double-sided section
(hereinafter – the Manual) contains the instructions on safe transportation, storage, installation,
operation and maintenance of the above mentioned products. The installation must be carried out
by qualified installers in strict accordance with the Manual.
Abbreviations adopted in the Manual:
PS – power supply;
RC-panel – remote control panel;
WRC – wireless remote control;
ACS – access control system;
Due to continuous improvement of products the Manufacturer reserves the right to modify, without
notice, the product design not aggravating its technical specifications.
1 APPLICATION
ST-02 Speed gate (hereinafter – the speed gate) is a blocking device with sliding panels and is
designed for pedestrian passage control at entrance points of administrative buildings, banks,
shops, railway terminals, airports, etc. The speed gate produced in two versions: ST-02.600 with
passage width of 600 mm and ST-02.900 with passage width of 900 mm.
The speed gate consists of two sections ST-02.600/M (ST-02.900/M) (hereinafter – Master
section) and ST-02.600/S (ST-02.900/S) (hereinafter – Slave section). The speed gate standard
delivery set allows organizing one passage lane.
In order to increase the number of passage lanes, it is necessary to purchase STD-02
double-sided sections (hereinafter – double-sided section). Each double-sided section allows you
to organize one extra passage lane. The double-sided section has two main versions:
STD-02.600 for the organization of passageways with a width of 600 mm and STD-02.900 for the
organization of passageways with a width of 900 mm.
In order to organize a checkpoint with passage lanes of different widths (600 and 900 mm) it is
necessary to use ST-02.600/900 version (includes Master and Slave sections with panels of
different widths that can be supplied on a separate order), and STD-02.900 double-sided section
can be configured so to reduce the extended panel width for the 600 mm-wide passageway.
Note:
It is possible to install access card reader inside of the speed gate
sections that are
produced by PERCo (IR03.1, MR07 OEM, RP-15.2) and third-party manufacturers.
Access
card readers are not included in the standard delivery set!
Selection of the reader and its
installation into equipment is performed by the customer (installer) in accordance with the
checkpoint project and ACS and controller characteristics
. Readers must meet the following
requirements:
overall dimensions............................................................................ max. 230×72×32 mm
passage sensor reading range ........................................................................ min. 40 mm
Also, it is possible to install the ACS controller inside the speed gate section. Dimensions
are limited to ...................................................................................... max. 160×140×40 mm
2 OPERATING CONDITIONS
The product, with regard to resistance to environmental exposure, complies with GOST15150-69
category NF4 (operation in premises with climate control).
Operation of the speed gate is allowed at ambient air temperature from +1°C to +50°C and relative
air humidity of 80% at +25°C.

Assembly and Operation Manual
4
3 TECHNICAL SPECIFICATIONS
Operating voltage ................................................................................................................ 24 VDC
Allowable voltage1.......................................................................................................... 20-28 VDC
Maximum current consumption ..................................................................................... max. 8.5 A2
Power consumption3.................................................................................................... max. 204 W
Throughput rate in single passage mode ..................................................... up to 60 persons / min
Passageway width:
ST-02.600.................................................................................................................. 600 mm
ST-02.900.................................................................................................................. 900 mm
Number of installed passage sensors:
upper level ......................................................................................................................... 30
lower level .......................................................................................................................... 30
RC-panel cable length4.................................................................................................... min 6.6 m
IP-Code ................................................................................................................ IP41 (EN 60529)
Electric shock protection class .................................................................................. III (IEC 61140)
Mean time to failure ................................................................................. min. 2,000,000 passages
Mean lifetime ................................................................................................................ min 8 years
Overall dimensions of the speed gate (length × width × height)5:
ST-02.600............................................................................................. 1923×1364×1482 mm
ST-02.900............................................................................................. 1923×1964×1482 mm
Note:
Use the following formula to calculate the total width of the speed gate when several
passage lanes are arranged (see Fig. 2):
Ltotal= 600N + 382n + 900M + 532m (mm), where:
N – number of passage lanes with a width of 600 mm,
n – number of ST-02.600/ M(S) and STD-02.600 sections,
M – number of passage lanes with a width of 900 mm,
m – number of ST-02.900/M (S) and STD-02.900 sections.
Weight (net):
ST-02.600/ M (ST-02.600/S) section .................................................................... max 198 kg
ST-02.900/ M (ST-02.900/S) section .................................................................... max 224 kg
STD-02.600 double-sided section ........................................................................ max 228 kg
STD-02.900 double-sided section ........................................................................ max 230 kg
sliding panel for ST-02.600,STD-02.600 ................................................................. max 9 kg
sliding panel for ST-02.900,STD-02.900 ............................................................... max 13 kg
filling glass for ST-02.600, STD-02.600 .................................................................... max 5 kg
filling glass for ST-02.900, STD-02.900 .................................................................... max 7 kg
1In case of use of backup power sources such as batteries, etc.
2As a power source for the turnstile, the manufacturer recommends using power supplies with an output
voltage of 24VDC and a maximum load current of at least 10 A.
3Consumption current and power consumption are specified for each ST-02 or STD-02 product separately.
4The maximum length of the RC-panel cable is 40 m (supplied upon request).
5The overall dimensions of the turnstile with one or more passage lanes are shown in Fig. 1, 2.

ST-02 Speed gate and STD-02 Double-sided section
5
Figure 1. Overall speed gate dimensions
Figure 2. Overall dimensions of several passage lanes

Assembly and Operation Manual
6
4 DELIVERY SET
4.1 Standard delivery set
4.1.1 ST-02 Speed gate
Main equipment:
Master1section ......................................................................................................................... 1
Slave1section ............................................................................................................................ 1
glass cover. .............................................................................................................................. 4
filling glass ................................................................................................................................ 2
sliding panel ............................................................................................................................. 2
side panel ................................................................................................................................. 4
central insert ............................................................................................................................. 2
RC-panel with cable ................................................................................................................. 1
intersectional cables kit (DC and CAN cables) .......................................................................... 1
jumper ...................................................................................................................................... 3
\FSS-5 board retainer ............................................................................................................... 4
adjusting plate 1 mm ................................................................................................................ 4
adjusting plate 1.5 mm ............................................................................................................. 8
self-adhesive rubber pad with pictogram .................................................................................. 2
Operational documentation:
Certificate ................................................................................................................................. 1
Assembly and Operation manual .............................................................................................. 1
Packaging:
boxes No.1 and No.2 for the Master section ............................................................................. 2
boxes No.3 and No.4 for the Slave section ............................................................................... 2
4.1.2 STD-02 Double-sided section
Main equipment:
double-sided section1................................................................................................................ 1
glass cover ............................................................................................................................... 2
side panel ................................................................................................................................. 2
filling glass ................................................................................................................................ 1
sliding panel ............................................................................................................................. 2
central insert ............................................................................................................................. 1
RC-panel with cable ................................................................................................................. 1
intersectional cables kit (DC and CAN cables) .......................................................................... 1
jumper ...................................................................................................................................... 3
FSS-5 board retainer ................................................................................................................ 4
adjusting plate 1 mm ................................................................................................................. 2
adjusting plate 1.5 mm .............................................................................................................. 4
self-adhesive rubber pad with mnemonic image ....................................................................... 2
accessories for installation of the sliding panel departure limiter2:
reflector ................................................................................................................................ 1
support ................................................................................................................................. 2
screw M4×8 ......................................................................................................................... 6
template ............................................................................................................................... 1
Operational documentation:
Certificate ................................................................................................................................. 1
Package:
boxes No.1 and No.2................................................................................................................ 2
1All sections are supplied with dismantled parts: swing panels, side panels, filling glasses, glass covers
and central inserts.
2Only for STD-02.900. It shortens the sliding panel sweep up to 280 mm, used for the passageway of a
width of 600 mm.

ST-02 Speed gate and STD-02 Double-sided section
7
4.2 Optional equipment
In addition to the standard delivery set, the following additional equipment can be supplied on a
separate order:
IR03.1 (HID/EMM), or MR07 OEM (Mifare), or RP-15.2 (HID/EMM, Wiegand)
access card readers .......................................................................................... 2 per passage lane
Mounting kit for the mounting surface for each speed gate section:
PFG IH10 anchor (SORMAT, Finland) ..................................................................................... 6
M10×70 bolt with internal hexagon ........................................................................................... 6
washer 10 ................................................................................................................................. 6
Power supply ................................................................................................................................ 1
WRC device1................................................................................................................................ 1
5 OPERATION AND DESCRIPTION
5.1 Main features
•The speed gate can operate in two main modes:
−normally closed mode – speed gate sliding panels are in closed position, when the power
is turned off, the sliding panels remain in the closed position and, if necessary, can be
moved apart manually (not locked);
−normally open mode – speed gate sliding panels are in the open position, when the power
is turned off, the sliding panels remain in the open position and do not lock the passage.
•For normally-closed mode, it is possible to set an additional Automatic opening in the
selected direction operating mode in the pre-selected direction: the sliding panels
automatically open for each passage through the speed gate and close after the passage. The
mode can be set only for one direction; the second direction remains in the main operating
mode.
•In all operating modes the speed gate sends an alarm signal if the passageway is locked for
more than 30 seconds.
•Two levels of the passage sensors are installed along the entire length of the speed gate
passageway. This allows you to track the position of the user within the passageway, and also
allows multiple users to be in the passageway at the same time who are passing in the same
direction.
•If necessary, the number of passage lanes through the speed gate can be increased by
installing STD-02 double-sided sections.
•It is possible to organize a checkpoint with passage lanes of different widths: 600 and 900 mm.
For this purpose, the following products should be used: ST-02.600/900 (supplied upon request)
and STD-02.900 with the sliding panel departure limiter installed on one side.
•When organizing several passage lanes, the front end indication blocks allow the user to
choose the right passage in the right direction.
•The speed gate supports two control modes: pulse and potential.
•Speed gate can operate both as an operating device within the ACS, and as a standalone unit
controlled by operator from the RC-panel.
•It is possible to install an external ACS controller and proximity readers inside the speed gate
section under the glass top cover.
•The speed gate glass top cover features a built-in indication block, which combines a passage
grant/denial indicator and card interrogation zone indicator.
•It is possible to connect remote indication blocks to duplicate the passage grant / denial
indication.
•It is possible to connect a siren to the speed gate in order to warn the operator about
unauthorized passage attempts.
1The WRC kit consists of a receiver, connected to the control board and a transmitter in the form of a fob.

Assembly and Operation Manual
8
•There is a possibility of automatic emergency opening of the passageway when a Fire Alarm
command is sent. The Fire Alarm command can be sent by the safety fire alarm device or by
the operator by means of the emergency button (hereinafter – the emergency passage opening
device).
•Speed gate parts are made of polished stainless steel. The sliding panels and the filling glass
are made of tempered glass with a thickness of 8 mm.
5.2 Device
The speed gate design is shown in Fig. 3, the double-sided section is shown in Fig. 4 . The
numbers of the parts in the text are shown in accordance with Fig. 3 and 4.
Figure 3. ST-02 overall view
1 – sliding panel; 2 – filling glass; 3 – glass cover; 4 – central insert; 5 – upper indication block;
6 – side panel; 7 – front panel; 8 – front end indication block; 9 – DC connection cable;
10 – CAN connection cable; 11 – RC-panel with cable; 12 – power supply cable1;
13 – Fire Alarm1device cable; 14 – lower level of passage sensors;
15 – upper level of passage sensors
1Not included in the standard delivery set.

ST-02 Speed gate and STD-02 Double-sided section
9
Figure 4. STD-02 overall view
1 – sliding panel; 2 – filling glass; 3 – glass cover; 4 – central insert;
5 – upper indication block; 6 – side panel; 7 – front panel; 8 – front end indication block;
9 – DC connection cable1; 10 – CAN1connection cable; 11 – RC-panel with cable;
12 – power supply cable2; 13 – Fire Alarm2device cable;
14 – lower level of passage sensors; 15 – upper level of passage sensors
The speed gate consists of two sections, Master and Slave, as well as the RC-panel (11). The
Slave section is connected to the Master section via two DC and CAN connection cables (9, 10).
Each section has a sliding panel (1) and a fixed filling glass (2).
In order to increase the number of passage lanes, it is necessary to install double-sided sections.
Each double-sided section is also equipped with the RC-panel (11). It has two sliding panels (1):
on the Master side and Slave side. Each sliding panel is driven by its electric drive. The Slave
section of the speed gate (the Slave side of the next double-sided section) is connected to the
Master side with two connection cables (9, 10) from the speed gate delivery set (double-sided
section) (see Fig. 4).
1One pair of DC and CAN cables are supplied with the nearby product.
2Not included in the standard delivery set.
