PERCo WMD-06 Installation and operating instructions

ASSEMBLY AND OPERATION MANUAL
WMD-06
Motorized Electromechanical
Swing Gate

Motorized
Electromechanical
Swing Gate
WMD-06
Assembly and Operation Manual

CONTENTS
1APPLICATION.................................................................................................................3
2OPERATION CONDITIONS ............................................................................................3
3TECHNICAL SPECIFICATIONS .....................................................................................4
4DELIVERY SET...............................................................................................................5
4.1 Standard delivery set ............................................................................................5
4.2 Additional equipment supplied on request ............................................................5
5PRODUCT DESCRIPTION .............................................................................................6
5.1 Main features ........................................................................................................6
5.2 Design...................................................................................................................6
5.3 RC panel ...............................................................................................................9
5.4 Parameters of input and output signals...............................................................11
5.5 Operation contingences during gate operation ...................................................14
6MARKING AND PACKAGING .......................................................................................15
7SAFETY REQUIREMENTS...........................................................................................16
7.1 Installation safety ................................................................................................16
7.2 Operation safety..................................................................................................16
8ASSEMBLY AND INSTALLATION ................................................................................17
8.1 General recommendations..................................................................................17
8.2 Tools and equipment required for installation .....................................................17
8.3 Appropriate length of cables ...............................................................................17
8.4 Installation sequence ..........................................................................................18
9OPERATION .................................................................................................................22
9.1 Power-up.............................................................................................................22
9.2 Pulse control mode .............................................................................................22
9.3 Potential control mode ........................................................................................23
9.4 Emergency situations..........................................................................................24
9.5 Troubleshooting ..................................................................................................24
10MAINTENANCE ............................................................................................................25
11TRANSPORTATION AND STORAGE ..........................................................................25
APPENDIX A. Control signal algorithm in pulse control mode ..................................26
APPENDIX B. Control signal algorithm in potential control mode .............................27

Motorized Electromechanical Swing Gate WMD-06
Dear customer!
Thank you for purchasing the PERCo product.
Please follow instructions given in this Manual carefully, and this quality product
will provide many years of trouble-free use.
The Assembly and Operation Manual (hereinafter – the Manual) contains the instructions
you will need for safe transportation, storage, installation, operation and maintenance of
the WMD-06 electromechanical motorized swing gate.
The product installation must be carried out by qualified installers in strict accordance with
the Manual.
Abbreviations adopted in the Manual:
ACS – access control system;
RC – remote control;
WRC – wireless remote control.
1 APPLICATION
The WMD-06 electromechanical motorized fail-safe swing gate (hereinafter – the swing
gate) is designed for managing pedestrian flows at entrance points of industrial facilities,
banks, administrative buildings, retail outlets, railway terminals, airports, etc. Being an up-
market model, it is recommended for fitting the highest requirements for design and
comfort. It can be installed together with other turnstiles and barriers produced by PERCo
or it can be used as a separate device.
It is recommended to define the number of swing gates necessary to secure fast and
convenient passage in accordance with throughput rate (see Section 3). For example it is
recommended to install one swing gate per every 500 entrants or in accordance with peak
throughput rate not exceeding 12 persons per minute.
2 OPERATION CONDITIONS
The swing gate with regard to resistance to environmental exposure complies with
GOST 15150-69, category U4 (operation in premises with climate control).
Operation of the swing gate is allowed at ambient air temperature from +1°Сto +45°Сand
at relative air humidity of up to 70% at +27°С.
3

Assembly and Operation Manual
3 TECHNICAL SPECIFICATIONS
DC operating voltage ......................................................................................... 24 V ±10%
Current ................................................................................................................ max. 4.4 А
Power consumption ........................................................................................... max.105 W
Throughput rate in single passage mode..................................................... 12 persons/min
Passage modes ................................................................................................................. 3
Passageway width:
with AGG-650 swing panel.............................................................................. 700 mm
with AGG-900 swing panel.............................................................................. 950 mm
Length of RC cable1............................................................................................ min 6.6 m
Ingress protection rating ........................................................................... IP41 (EN 60529)
Electric shock protection class .......................................................................III (IEC 61140)
Mean time to failure ........................................................ min. 500 000 number of passages
Mean lifetime .................................................................................................... min. 8 years
Overall dimensions (L × W × H):
with AGG-650 swing panel............................................................ 795×147×1007 mm
with AGG-900 swing panel.......................................................... 1045×147×1007 mm
Net weight:
with AGG-650 swing panel......................................................................... max. 37 kg
with AGG-900 swing panel......................................................................... max. 41 kg
Figure 1. Overall dimensions
1Maximum length of RC cable is 30 m (supplied on request).
4

Motorized Electromechanical Swing Gate WMD-06
4 DELIVERY SET
4.1 Standard delivery set
Basic equipment:
Gate post ................................................................................................................... 1
Glass panel ............................................................................................................... 1
Note:
Type of panel (AGG-650 or AGG-900)is chosen by the customer.
RC panel with cable .................................................................................................. 1
Hex-nut wrench S1.5 ................................................................................................. 1
Gate installation kit:
PFG IH 10 («SORMAT», Finland) anchor bolt with washer and nut M10 .................. 3
Panel installation kit:
Bolt M10×35 А2.......................................................................................................... 4
Nut M10 A2 ............................................................................................................... 4
Plain washer............................................................................................................... 4
Spring washer ............................................................................................................ 4
Expanded washer ...................................................................................................... 4
Plastic washer ........................................................................................................... 4
Plastic bushing ........................................................................................................... 4
Operational documentation:
Certificate ................................................................................................................... 1
Assembly and Operation manual .............................................................................. 1
Template for gate installation ......................................................................................1
Package:
Box 1 (gate post and remote control panel) ............................................................... 1
Box 2 (swing panel) ................................................................................................... 1
4.2 Additional equipment supplied on request
In addition to the standard delivery set the following equipment can be supplied on
request:
Power supply unit .......................................................................................................1
WRC kit1....................................................................................................................1
1WRC kit consists of a receiver connected to the control board of the gate and two transmitters
(tags) with operation range up to 40 m.
5

Assembly and Operation Manual
5 PRODUCT DESCRIPTION
5.1 Main features
The swing gate can be operated autonomously from the RC panel or WRC as well
as from an access control system (ACS). There are two variants of the gate control
– pulse control mode and potential control mode.
The swing gate can be supplied with two types of swing panel: 650 mm or 900 mm.
Overall dimensions of the gate are shown in Fig. 1.
External components of the swing gate (except for swing panel) are made of
brushed stainless steel. The swing panel is made of 10 mm thick tempered glass.
The swing gate is a normally open unit i.e. in case of power failure the swing panel
can be rotated through an angle of ±90º.
Safe operating voltage – max. 28 V.
Low power consumption – max. 105 W.
5.2 Design
Design of the swing gate is shown in Fig. 2. The numbers of the items in brackets are
given according to Fig. 2, unless stated otherwise.
The gate consists of the stationary base (1), rotary support (7) that holds glass panel (4),
housing (2) and cover (3). Metal ring (5) and plastic ring (12) provide support of housing
(2) and its rotation around stationary base (1). Decorative plate (15) is fixed with a screw
(16).
The gate post is installed on anchors’ studs (9) and fixed with nuts (10) and washers (11)
The gate post contains units providing its operation: rotary electric drive with rotation
sensor, electromagnetic stopper unit, bearing units, drive control board (6).
RC panel is included into delivery set (17).
The gate is operated with +24 V DC voltages via cable (13).
6

Motorized Electromechanical Swing Gate WMD-06
Figure 2. Overall view of the gate
1 – stationary base; 2 – housing; 3 – cover; 4 – glass panel; 5 – metal ring;
6 – control board;7 – rotary support; 8 – screw M3 (3 units); 9 – anchor; 10 – nut M10;
11 – washer; 12 – plastic ring; 13 – power cable;
14 – control cable (from RC panel / WRC device / ACS controller );
15 – decorative plate; 16 – screw M4; 17 – RC panel
7

Assembly and Operation Manual
Figure 3. External view of the control board
XT1, XT2 – connector blocks; 1 – power cable +24 V;
2 – control cable (from RC panel / WRC unit / ACS controller);
3 – cable jumper (installed on default);
4 – connectors (all jumpers are installed on default); 5 – LED indicators.
The control board is installed in the gate post. The external view of the board is shown in
Fig. 3. The board contains:
XT1 and XT2 – connector blocks are designed for power supply, input-output of
control signals and indication. Marking and description of XT1 and XT2 connector’s
contacts of the control board are given in Table 1.
Size – connector is designed for selection of swing panel type installed on the gate.
If the AGG-900 panel is used, the jumper shall be removed, if the AGG-650 panel is
used – the jumper shall be installed. The jumper is removed on default.
Imp / Pot – connector is designed for selection of control mode of the gate. If the
jumper is installed, the gate operates in the pulse mode, if the jumper is not
installed, the gate operates in the potential mode. The jumper is installed on default.
FireAlarmDir – connector is designed for selection of opening direction of the gate
when the Fire Alarm emergency unblocking signal is applied. If the jumper is
installed, the swing panel opens in direction A (see Figure 5), if the jumper is not
installed, the swing panel opens in direction B. The jumper is installed on default.
LED – connector is designed for turn-off of LED indicators located on the control
board. If the jumper is installed, indication is on. If the jumper is not installed,
indication is off. The jumper is installed on default.
8

Motorized Electromechanical Swing Gate WMD-06
Table 1. Contacts of the control board
Connector
block №Item Function of the contact
1 +24 V
2 GND Connection of external power supply
3 NO
4 C
5 NC
Light A relay contacts – connection of remote indicator
for direction А
6 NO
7 C
8 NC
Light B relay contacts – connection of remote indicator
for direction В
9 +12 V “+” of the power supply of RC device
10 GND Negative terminal of the power source
11 Common Common contact for PASS А, PASS Вsignals
12 Pass A PASS A relay contact (passage in direction А)
ХТ1
13 Pass B PASS Вrelay contact (passage in direction В)
1 Fire Alarm
2 GND Input for emergency unblocking device
3 GND Negative terminal of the power source
4 Unlock A
5 Stop
6 Unlock B
Inputs for gate control
7 Led A
8 Stop
9 Led B
Indication outputs of RC panel
ХТ2
10 Sound Sound signal output of RC panel
5.3 RC panel
The RC panel (17) is a small table device made of shockproof ABS plastic that serves for
manual setting of the operating modes and indication thereof. RC panel is connected to
the control board (6) with flexible multicore cable (14), included into delivery set. The
general view of the RC panel is shown in Figure 4.
The RC panel houses three control buttons to set passage modes of the swing gate.
Above the buttons LED indicators are located. The STOP button in the middle serves for
setting the “Always locked” operating mode, the RIGHT and LEFT buttons – for allowing
passage in the chosen direction. The RC panel features a built-in piezoelectric buzzer for
audio signals generation.
The standard orientation of the RC panel in relation to gate opening direction is shown in
Figure 5. The orientation of the RC panel can be changed if necessary, in such case the
connection of RC panel shown in Fig. 11 shall be changed by connecting of cable of the
RC panel to XT2 connector block in accordance with Table 2.
9

Assembly and Operation Manual
Figure 4. General view and dimensions of the RC panel
1, 2, 3 – LEFT, RIGHT, STOP buttons for mode setting;
4, 5 – green indicators «Left», «Right»;
6 – red indicator «Stop»; 7 – cable
Figure 5. Standard orientation of RC panel in relation to gate opening direction
10

Motorized Electromechanical Swing Gate WMD-06
Table 2. Connection of RC panel cable to XT2 connector block in standard and
reversed orientation of the RC panel
Orientation
Number Title Standard Reversed
1 Fire Alarm - -
2 GND - -
3 GND black black
4 Unlock A white green
5 Stop blue blue
6 Unlock B green white
7 Led A yellow red
8 Stop orange orange
9 Led B red yellow
10 Sound brown brown
5.4 Parameters of input and output signals
The microcontroller installed on the control board tracks the status of Unlock A, Stop,
Unlock B and Fire Alarm control input signals, and also tracks output signals from rotation
sensor.
Upon data receiving the microcontroller creates commands to the control mechanism of
the gate, and also signals for connected external indication devices, indication on the
RC panel (Led A, Led Stop and Led B), signals on the performed rotation of the swing
panel on outputs Pass Аand Pass В.
Inputs for control devices connection
The swing gate can be operated with RC panel, WRC device or ACS controller.
A device that sends Fire Alarm signal is used for emergency unblocking of passage.
Note:
Control devices (RC panel, WRC device, ACS controller) can be connected
separately or in any combination with each other.
In case of combined connection the overlapping of signals send by control devices
may occur. In such case the reaction of the gate will correspond with the reaction
towards the generated combination of input signals.
Control devices are connected to Unlock A, Stop and Unlock B control inputs. The gate is
operated by input of a low-level signal to Unlock A, Stop, Unlock B contacts with GND
contact of XT2 connector block.Algorithms of control signals sending are given in
Appendices A and B.
A normally open relay contact or open collector output scheme can be used as a control
element (see Figure 6 and Figure 7).
11

Assembly and Operation Manual
Figure 6. ACS control element, normally open relay contact
Figure 7. ACS control element, open drain output scheme
The device that sends Fire Alarm emergency unblocking signal is connected to Fire Alarm
control input.Emergency unblocking is performed by turn-off of the low-level signal at Fire
Alarm contact and GND contact on XT2 connector block. In such case normally closed
contact or open collector output scheme may be used as control element.
If Fire Alarm input is not used, it is necessary to install a jumper between Fire Alarm and
GND contacts on XT2 connector block. The jumper is installed on default.
The gate can be operated in two control modes: pulse and potential. The control mode is
set by installing or removing of the jumper on Imp/ Pot connector. If the jumper is installed,
the gate is operated in pulse control mode; if the jumper is removed, the gate is operated
in potential control mode. The jumper is installed on default. Algorithms of control signals
sending for each control mode are given in Appendix.
Connection of devices to control inputs is performed in accordance with electrical
connection layout, shown in Fig. 11.
Note:
To create high-level signal on all input contacts (Unlock A, Stop, Unlock B,
Fire Alarm) resistors with 2 kOhm connected to + 5 V power line are used.
Control element shall provide the following specifications of signals:
control element – relay contact:
minimum switching current ........................................................................max. 2 mA
resistance of closed contact
(including resistance of connection cable) .......................................... max. 300 Ohm
control element – open collector output scheme:
voltage at the closed contact
(low-level signal, at the input of the control board) ....................................max. 0.8 V
12

Motorized Electromechanical Swing Gate WMD-06
PASS outputs
PASS A (Pass A and Common contacts of XT1 connector block), PASS B (Pass Вand
Common contacts of XT1 connector block) outputs are basically a relay.
If the power is turned off, control board relays are normally open. In such case Common
contact is not connected to the negative terminal of the gate's power supply (see Fig. 8).
Figure 8. Output stages for PASS A, PASS B
If the status is normalized and the power is turned on, relay coil is energized and PASS A,
PASS B relay contacts are closed.
PASS A, PASS B relays activation/deactivation can be defined by activation/deactivation
of indicators that are installed near related outputs on the control board (see Fig. 3).
Output stages for PASS A, PASS B relay contacts have the following signal specifications:
maximum switching DC voltage ......................................................................... 42 V
maximum switching current ............................................................................. 0.25 А
resistance of closed contact .............................................................. max. 0.15 Ohm
Outputs for external indication connection
Light A and Light B outputs are used for external indication connection and are basically
relay transfer contacts (see Fig. 9). Each output has full contact set on XT1 connector
block: normally open (NO), normally closed (NC) and common (C). Connection is
performed in accordance with electrical connection layout given in Fig. 11.
Figure 9. Output stages for Light A and Light B
Light A (Light B) relay is activated (meaning that its coil is energized) when the passage is
open in direction A (B) and normalized when the passage is closed in the related direction.
Light A (Light B) relays activation/deactivation can be defined by activation/deactivation of
indicators that are installed by near related outputs on the control board.
13

Assembly and Operation Manual
Output stages for Light A (Light B) are relay transfer contacts with the following signal
specifications:
maximum switching DC voltage ........................................................................ 30 V
maximum switching AC voltage ......................................................................... 42 V
maximum switching AC / DC ............................................................................... 3 A
resistance of closed contact ............................................................. max. 0.15 Ohm
5.5 Operation contingences during gate operation
In case of any impediment to the free rotation of the swing gate an automatic switch to
overload mode is provided. The mode is used to avoid damage to electromechanical
elements due to overheating.
If any obstacle impedes rotation of the swing panel three attempts of rotation in the same
direction are made with 3 sec intervals. If the obstacle remains the swing gate is switched
into overload mode. Being in the overload mode the swing panel can be rotated free by
±90º angle that allows removing the obstacle. In such case all three indicators on the
RC panel are blinking, and a sound indication consisting of three short audio signals is
turned on each 20 sec.
The overload mode is switched off by rotating of the swing panel into “Closed” position
manually or by turning the power supply off and them on (in this case the gate will be set
into initial position automatically).
14

Motorized Electromechanical Swing Gate WMD-06
6 MARKING AND PACKAGING
The swing gate has a marking in the form of label located inside rotary post under the
cover. The label contains trademark and contact details of the manufacturer, the
manufacture date, power voltage and power consumption. To get access to the marking
take off the post cover by unscrewing three 3 screws using S1.5 wrench.
The swing gate in the standard package is packed in two boxes that protect it from being
damaged during transportation and storage. The box 1 contains gate post and RC panel,
the box 2 contains swing panel. Boxes have the marking of the packed product and
additional marking in accordance with design documents and delivery set.
Dimensions, (L × W × H):
box 1 ................................................................................................. 121×23×26 cm
box 2 for AGG-650 glass panel ........................................................... 96×12×90 cm
box 2 for AGG-900 glass panel ......................................................... 121×12×90 cm
Gross weight:
box 1 ....................................................................................................... max. 33 kg
box 2 for AGG-650 swing panel .............................................................. max. 28 kg
box 2 for AGG-900 swing panel .............................................................. max. 35 kg
15

Assembly and Operation Manual
7 SAFETY REQUIREMENTS
7.1 Installation safety
Installation should be performed by qualified personnel only, in strict accordance with the
Manual and general electrical safety requirements for electrical and installation work.
Attention!
All the connections should be performed only after the control unit is
disconnected from the power supply.
Only serviceable tools should be used.
Cables should be laid in accordance with electrical safety requirements.
Before first activation of the gate check whether the installation and all
connections are performed correctly.
The installation of power supply unit shall be performed in accordance with general safety
requirements given in its operation manual.
7.2 Operation safety
Observe general safety requirements for use of electrical equipment.
Warning!
Do not use the swing gate in environment different from those given in Section 2.
Do not use the swing gate with power supply unit different from those given in
Section 3.
Power supply unit shall be operated in accordance with general safety requirements given
in its operation manual.
16

Motorized Electromechanical Swing Gate WMD-06
8 ASSEMBLY AND INSTALLATION
Observe safety requirements given in Section 7.1 during installation.
8.1 General recommendations
Proper installation is critical to performance and serviceability of the swing gate. We advise
you to study this Manual before installation work and follow the instructions to the latter.
We recommend:
to mount the swing gate on flat, solid concrete floors (grade 400 or higher), stone or
similar foundations at least 150 mm thick.
to make sure the mounting foundation is horizontal and flat, so that all the mount
points lie in the same plane;
to employ reinforcing elements 450×450×200 mm for softer grounds.
8.2 Tools and equipment required for installation
Use the following tools for the installation works:
1.2÷1.5kW hammer drill;
Ø16 mm hard-alloy drill bits for anchor bolts sleeves;
Phillips head screwdriver №1;
allen key S1.5;
open-end wrench S17;
hobby knife;
level;
measuring tape 2 m.
Note:
The use of different tools is acceptable on condition that they do not reduce the
quality of installation works.
8.3 Appropriate length of cables
Maximum acceptable length RC panel / ACS controller cable ..................................... 30 m
Maximum acceptable length of power supply cable depends on it cross-section and shall
be as following:
for 1.5 mm2cross-section (AWG 15) ......................................................... max. 10 m
for 2.5 mm2cross-section (AWG 13) ......................................................... max. 20 m
17

Assembly and Operation Manual
8.4 Installation sequence
Attention!
The manufacturer shall not be liable for any damage caused in the result of
improper installation and declines any claims arising thereof in case if the installation
is not in compliance with the instructions provided in this Manual.
Item numbers in the installation sequence are given according to Fig. 2, unless stated
otherwise. Electrical connection layout is given in Fig. 11. Location of connector blocks
and jumpers on the control board is given in Fig. 3. Cables used for installation and their
maximum length are set in Section 8.3. Recommendations on surface preparation are
given in Section 8.1. Follow this sequence during gate installation:
1. Unpack the box with equipment, check carefully the delivery set according to
Section 4.
Attention!
Don’t hold the gate by its cover (3) while moving it.
2. Mark and prepare the mounting holes in the floor as per Fig. 10 for anchors (9) to
install the gate post (If necessary, take advantage of the supplied template). Use
Ø16 mm hard-alloy drill for hole preparation. Drilling depth is 60 mm.
Figure 10. Mounting hole pattern
3. Install power supply unit in accordance with its operation manual.
4. If it is necessary to lay power cables (13) and control cables (14) under the floor,
prepare an electrical conduit in the floor in the zone where cables are inserted into
the gate post. Location of the zone is given in Fig. 10.
5. Install anchors in the drilled holes in the floor, so that their shells would not obtrude
out of the floor surface.
18

Motorized Electromechanical Swing Gate WMD-06
Figure 11. Electrical connection layout
Table 3. List of elements of electrical connection layout
Legend Item Comments
А1 Control board
А2Power supply unit of the swing gate +24V DC; 4А
А3Power supply unit of external indicators
A4, A5External indicator
A6.1ACS controller input
A6.2ACS controller output
A7Device sending Fire Alarm (FA) emergency unblocking signal
A8 RC panel PERCo-H6/4
A9WRC device MSRF-4
1 Wire jumper. Installed when the emergency unblocking device (А7) is
not connected.
Installed on
default
Not included in standard delivery set.
19
