PERCo IP-Stile KT-05.4 Installation and operating instructions

IP-Stile
KT-05.4
ASSEMBLY AND OPERATION MANUAL

IP-Stile
KT-05.4
User Guide

CONTENTS
1Application...................................................................................................................3
2Design.........................................................................................................................3
2.1 Indication module ..................................................................................................5
2.2 RC-panel ...............................................................................................................5
3Safety measures .........................................................................................................6
4Power-up.....................................................................................................................6
5Operation by RC-panel................................................................................................7
6Operation as a part of an ACS ....................................................................................9
7ACM, controller events and states indication.............................................................10
8Emergency actions....................................................................................................11
8.1 Emergency exit by use of anti-panic barrier arms................................................11
8.2 Mechanical unlocking..........................................................................................11
8.3 IP-Stile automatic unlocking ................................................................................11

IP-Stile KT-05.4
3
Dear Customer!
Thank you for purchasing PERCo IP-Stile.
Please follow instructions given in this Manual carefully,
and this quality product will provide many years of trouble-free use.
This Manual contains information that is necessary for comprehensive use of capabilities
of the KТ-05.4 IP-Stile.
Abbreviations adopted in the Manual:
RC-panel – remote control panel;
PC – personal computer;
ACM – access control mode;
ACS – access control system;
OD – operating device.
1 APPLICATION
KT-05.4 IP-Stile (hereinafter – IP-Stile) is designed for control of access to a facility by
means of proximity cards. Access control through IP-Stile is performed by the operator with
the RC-panel, which is included in the standard delivery set or, after additional setting,
using PERCo-Web software, with the proximity cards.
IP-Stile can operate either as a standalone unit, without permanent connection to the local
network or a PC, or as a part of PERCo-Web security system. All the registered events are
logged in the nonvolatile memory of the IP-Stile controller. As a part of PERCo-Web ACS
supports all the performance capabilities of the system.
Up to 8 CL-201 controllers can be connected to the IP-Stile. Each controller has a built-in
reader and allows to control one electromechanical (electromagnetic) lock. This gives an
opportunity to provide one-direction access to eight rooms by proximity card presentation.
2 DESIGN
IP-Stile consists of a housing with built-in controller, two proximity-card readers with
indication modules, three barrier arms, RC-panel (ref. Figure 1, parts 1-3, 5 and 9) and
software to work as a part of PERCo-Web ACS. After each passage through IP-Stile the
barrier arms are automatically reset in the home position.
For visual informing on current IP-Stile status both housing end faces are equipped with
indication modules. An access card reader is built-in inside the housing under each
indication module.

User Guide
4
Figure 1. IP-Stile design:
Standard delivery set:
1 – frame; 2 – base; 3 – top cover; (items 1-3 form turnstile housing);
4 – top cover lock; 5 – barrier arm; 6 – cap to cover barrier arms adjusting points;
7 – mechanical release lock; 8 – indication module; 9 – front covers with readers;
10 – turnstile housing side cover; 11 – turnstile housing side cover lock;
12 – RC-panel; 13 – RC-panel cable
Not included in standard delivery set:
14 – LAN connection cable; 15 – power cable;
16 – data cable to additional devices via RS-485;
17 – cable to emergency opening device, ID and siren

IP-Stile KT-05.4
5
2.1 Indication module
To inform on a current status of the turnstile both front sides of the turnstile housing
feature indication modules (ref. Figure 1, parts 8), with card readers built-in under, on the
internal side of the cover. The indication module has 3 mnemonic indicators (ref. Figure 2):
–
Green indicator of authorized passage.
IP-Stile is unlocked in this direction.
–
Yellow indicator: card presentation or operator command are expected.
IP-Stile is locked in this direction.
–
Red indicator of passage ban.
IP-Stile is locked in this direction.
Figure 2. Visual indicators of the indication module
2.2 RC-panel
The RC-panel is designed as a small desktop device with a shock-proof ABS plastic case
and is intended for setting and indicating operating modes when the turnstile is operated
manually. The RC-panel overall view is shown in Figure 3.
Figure 3. RC panel overall view
1, 2, 3 – buttons LEFT, RIGHT, STOP for setting the passage mode;
4, 5 – green indicators «Left», «Right»; 6 – red indicator «Stop», 7 – RC cable.
There are three control buttons on the RC front panel intended for setting the turnstile
operating modes. The LED indicators are located above the buttons. The middle button on
the RC-panel (hereinafter — the STOP button) is intended to set the turnstile to the
“Always locked” mode. The left (LEFT) and the right (RIGHT) buttons are intended to
unlock the turnstile for passage in the chosen direction.

User Guide
6
3 SAFETY MEASURES
The IP-Stile is to be operated with observance of safety requirements mentioned in
Section 7.2 of its Assembly & Operation Manual.
Warning!
•Do not use the IP-
Stile under conditions that do not comply with the requirements
of the operation documentation.
•Do not use the IP-Stile at
supply voltage that does not comply with the technical
characteristics of the equipment.
•Do not move through the IP-
Stile passage area any objects with dimensions
exceeding the width of the passageway.
•Do not jerk and hit any elements of the IP-Stile so a
s to prevent their mechanical
deformation.
•Do not dismantle or adjust mechanisms ensuring operation of the IP-Stile.
•
Do not use substances that may cause mechanical damage or corrosion of
the surfaces for cleaning the IP-Stile.
4 POWER-UP
At IP-Stile power-up follow this sequence of actions:
1. Make sure all connections are correct.
2. Make sure the barrier arms are in the home position (the passageway is blocked
with a barrier arm).
3. Make sure the mechanical release lock is closed.
4. Connect the power supply to the mains with electric parameters as per its
documentation.
5. Turn the power on.
Attention!
When the controller configuration is changed with the jumpers, the controller
internal memory is automatically formatted.
This procedure lasts for about 2
minutes. After that the IP-
Stile configuration should be transmitted to the controller
by the Soft or Web-interface.
6. At the first powering the «Control» ACM is set for both directions. Yellow indicators
(middle ones) of the indication modules are on and the red “Stop” indicator above
the middle button on the RC-panel is on. Both passage directions are blocked.
7. If the formatting has not been performed, the ACM and the indication, set for each
passage direction before power failure, is saved.
8. The IP-Stile is ready for operation right after the power-up. The operator can send
command for locking / unlocking of both passages from the RC-panel. In order to
arrange passage with proximity cards the additional configuration is to be used.

IP-Stile KT-05.4
7
5 OPERATION BY RC-PANEL
Attention!
Set the “Control” ACM to operate the IP-Stile from the RC-panel or the WRC.
The passage directions are independent of each other, i.e. setting an operating mode in
one direction will not change an already set operating mode to another.
Setting of the operating modes by the remote control panel/wireless remote control and
the corresponding indication is given in Table 1. Please kindly note that:
•At first powering the «Control» ACM is set for both directions. Both passage
directions are blocked
•For «Single passage in the set direction» mode. IP-Stile locks automatically after
passage completion in the set direction or in case the passage has not been
completed within the Holding in unlocked state timing.The initial settings of this
timing is 4 seconds and it does not depend on the control impulse length. The time
of holding in unlocked state is counted from the moment when the command from
the RC panel or the wireless remote control is received.
•The «Single passage in the set direction» mode can be changed to the «Free
passage in the set direction» or «Always locked» mode.
•The «Free passage in the set direction» can be changed only to «Always locked»
mode.
•For «Bidirectional single passage». After the passage completion in one direction
the Holding in unlocked state timing countdown for another direction begins.
Table 1. IP-Stile operating modes
№ Operating mode
Actions by the
operator
RC
indication
Turnstile
indication
IP-Stile status
1
«Always locked»
(IP-Stile is closed for
both entrance and
exit)
Press the Stop
button shortly The red
indicator is on
The amber
indicators for
both directions
are on
The barrier arms are
locked in the home
position. The
passageway is blocked
by the barrier arm.
2
«Single passage in
the set direction
(IP-Stile is open for a
single passage by one
person in the set
direction and closed
for passage in another
direction)
Press shortly the
Go button
responsible for
the authorized
direction
The green
indicator
above the Go
button
responsible
for the
authorized
direction is on
The green
indicator for
the authorized
direction and
the amber
indicator for
another
direction are on
The barrier arms are
unlocked for a single
turn in the authorized
direction. After the turn
the arms are locked.
3
«Bidirectional single
passage»
(IP-Stile is open for a
single passage in
each direction)
Press both Go
buttons together
shortly
Both green
indicators are
on
The green
indicators for
both directions
are on
The barrier arms are
unlocked for
consecutive single
turns in each
authorized direction.
After each turn the
arms are locked in the
corresponding
direction.

User Guide
8
№ Operating mode
Actions by the
operator
RC
indication
Turnstile
indication
IP-Stile status
4
«Free passage in the
set direction»
(IP-Stile is open for
free passage in the
authorized direction
and closed in another
Press shortly
the Stop button
together with the
Go button
responsible for
the authorized
direction
The green
indicator
above the Go
button
responsible
for the
authorized
direction is
on
The green
indicator for the
authorized
direction and
the amber
indicator for
another
direction are on
The barrier arms are
unlocked indefinitely for
multiple turns in the
authorized direction
5
«Free passage in the
set direction and a
single passage in
the opposite
direction»
(IP-Stile is open for
free passage in the
authorized direction
and a single passage
in another)
Press shortly the
Stop button
together with the
Go button
responsible for
the free passage
direction; then
press the other
Go button
shortly
Both green
indicators are
on
The barrier arms are
unlocked indefinitely for
multiple turns in the
free passage direction
and a single turn in the
single passage
direction
6
«Free passage in
both directions»
(IP-Stile is open for
free passage in both
directions)
Press shortly the
three buttons
together
Both green
indicators are
on
The green
indicators for
both directions
are on
The barrier arms are
unlocked indef
initely for
multiple turns in both
directions

IP-Stile KT-05.4
9
6 OPERATION AS A PART OF AN ACS
ACM change is performed at the command from the PC or Web-interface independently
for each passage direction. The controller, as an element of the ACS, provides ACM
through the OD:
ACM «Open» –free passage mode.
•OD is unlocked until the ACM change.
•Pressing the RC-panel buttons and wireless remote control button («Exit») is
ignored.
ACM «Control» – main operation mode as a part of ACS.
•OD is locked.
•If the presented card matches the criteria of access granting, the OD is unlocked for
Holding in unlocked state time.
ACM «Closed»– locked mode.
•OD is locked until the ACM change.
•RC-panel and remote control commands («Exit») are ignored.
•Any card presentation is registered as the access violation.
ACM «Security»1.
•OD is locked until the ACM change.
•RC-panel and remote control commands («Exit») are ignored.
•Arming mode, including the OD.
•Passage through the OD (forced entry) turns the protected zone into «Alarm»
mode.
1ACM «Security» is available for CL-201 second level controllers.

User Guide
10
7 ACM, CONTROLLER EVENTS AND STATES INDICATION
IP-Stile controller indication is displayed on the indication blocks.
Note:
•
When reading the proximity card identifier in any ACM, the audio signal of
0.5 sec. is sent, the yellow light indicator changes its status for 0.5 se
c. Other
identifiers don’t change their status.
•
If the access with the proximity card is granted, the light indication is turned to
Holding in unlocked state time
, or until the moment of the next passage. If
the access is banned, the indication is turned on for 2 seconds.
Possible indication variants are stated in Table. 2.
Table 2. Controller indication
Card presentation ACM
Indicators
Green Yellow Red
Sound
(sec.)
No configuration
No
2 Hz
2 Hz
2 Hz
off
No
«Open»
on
off
off
off
«Control»
off
on
off
off
«Security»
off
1 Hz
1Hz
off
«Closed»
off
off
on
off
Access denied
«Open»
on
off
off
0,5
«Control»
off off on 1
«Security»
Any card
«Closed»
Access granted
«Open»
on off off 0,5
«Control»
«Security»
off
off
on
1
Access granted, arming/ disarming
authorization
«Open»
on off off 0,5
«Control»
«Security»2
Repeated card
presentation with
arming/disarming
authorization
Arming (turn to
«Security» ACM)
«Security» off 1 Hz 1Hz 0,5
Non-arming3(up
to the return to
initial ACM)
«Open» off off 1sec 1
«Control»
Waiting for verification/ double-check
access Any off 2Hz off 0,5
2Presenting the card with disarming authorization in the «Security» ACM, the following
operations happen: protected zone disarming and OD unlocking for the Holding in unlocked
state time. After this period of time OD turns to the ACM, set before the protected zone arming
(«Open» or «Control»).
3Light and audio indication turns on for 1 sec.

IP-Stile KT-05.4
11
8 EMERGENCY ACTIONS
Attention!
For a fast safe escape from facilities in case of fire, natural disaster or other
emergencies, an emergency exit is often required. BH-02 railings with «Anti-
panic»
hinged section can serve as such an exit.
8.1 Emergency exit by use of anti-panic barrier arms
An additional emergency exit can be arranged by means of anti-panic barrier arms. The
design of the barrier arms enables arranging of a free escape passage without any special
means or tools.
To make the passageway free, just pull the horizontal barrier arm along its axis outwards
the hub until released, then fold the arm down (ref. Figure 4).
Figure 4. Anti-panic barrier arms operation
8.2 Mechanical unlocking
The mechanical unlocking feature is designed for unlocking the barrier arms in case of
emergency, e.g. if the power supply is down.
Proceed as follows to mechanically unlock IP-Stile:
•insert the key into the mechanical release lock (part 7 in Figure 1);
•turn the key clockwise until it stops (open the lock, the lock internal mechanism
moving out);
•make sure IP-Stile is unlocked by manually rotating the barrier arms a few turns in
each direction.
To lock IP-Stile mechanically:
•set the barrier arms in the home position;
•press the internal lock mechanism recessing it into the housing until it clicks;
•make sure IP-Stile is locked and the barrier arms cannot be rotated in either
direction.
8.3 IP-Stile automatic unlocking
Operating as a part of PERCo-Web,in case the fire breaks out or in any other emergency
situation, the IP-Stile can be turned to Fire Alarm mode by the emergency unlocking
device. In this mode the IP-Stile unlocks for passage in both directions. Other commands
at this mode are ignored.

PERCo
Polytechnicheskaya str., 4, block 2
194021, Saint Petersburg
Russia
Tel: [phone]
E-mail: [email protected]
[email protected]
www.perco.com

www.perco.com
