PERFECT FRY COMPANY PFC570-HB User manual

Counter Model Electric Fryer System
Perfect Fry PFC570-HB
Perfect Fry Company
39 Sheep Davis Road
Pembroke, NH 03275-3705
Phone: [phone]
Fax: [phone]
www.perfectfry.com
Place this manual in the appropriated
section of your Equipment Manual
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual for the
life of the equipment.
Model # ______________________________________
Serial # ______________________________________
Date Purchased ________________________________
Installation & Operation Manual
PFC570-HB
L20-435 R0 (5/2016)
CONTENTS
WARRANTY 2
INTRODUCTION 3
SAFETY 4
APPROVALS 5
PARTS IDENTIFICATION/FUNCTION AND EXPLODED VIEW 6
EQUIPMENT SET-UP AND CLOSE PROCEDURES 7
OPERATION AND CONTROL 18
TROUBLESHOOTING 29
PERFECT FRY FIRE SUPPRESSION SYSTEM 32
WIRING DIAGRAM 35

2
McDonald's ORIGINAL STANDARD EQUIPMENT LIMITED WARRANTY
General Warranty
Perfect Fry warrants to the original purchaser of its commercial cooking appliances and related equipment that said appliances and related
equipment will be free from defects in material and workmanship under normal use for a period of two (2) years from the date of installation, with
appropriate documentation, to a maximum of twenty-eight (28) months from the date of manufacture, subject to the following additions, exceptions,
exclusions and limitations.
What is covered
This warranty is limited to the repair or replacement at the Company’s option, without charge, of any part found to be defective within the warranty
period and reasonable expenses incurred for freight and material for the installation of such part; in addition, the Company’s obligation shall be limited
to reimbursement for normal labor on such parts.
Perfect Fry, Inc. agrees to pay the Authorized Service and Parts Distributor, for any labor and material required to repair or replace, at the Company’s
option, any part which may fail due to defects in material or workmanship during the above general warranty period.
How to Keep Your Warranty in Force
• Make sure any shipping damages are reported immediately. Damages of this nature are the responsibility of the carrier and must be
reported by the receiver.
• Install the appliance properly. This is the responsibility of the installer and the procedures are outlined in the manual.
• Do not install the appliance in a home or residence.
• Maintain the appliance properly. This is the responsibility of the purchaser of the appliance and the procedures are outlined in the manual.
• Replace the air lter at regular intervals to prevent lter saturation. Failure to do so could result in a non-warranty main fan failure due to
grease build up.
• Adjustments, such as calibration, leveling, tightening of fasteners or plumbing or electrical connections normally associated with initial
installation are outlined in the manual and are not covered under warranty.
• Damages as a result of re, ood or other acts of God are not covered under this warranty.
• Use the appliance for what it is intended. If the appliance is used for a purpose other than for which it was intended or designed, resulting
damages are not covered under the warranty.
• Make sure that the appliance has the correct voltage. If a failure is due to incorrect or erratic voltage, these damages are not covered under
the warranty
• Do not materially alter or modify the appliance.
• Do not obliterate, remove or alter the serial number rating plate.
• Use only Genuine OEM parts from Perfect Fry or its Authorized Parts and Service Distributors. Repairs are not covered by the warranty if
non-OEM parts or non-Authorized Parts and Service Distributors are used.
• Failures that are not attributable to a defect in materials or workmanship are not covered.
This warranty specically excludes parts which wear or would be replaced under normal usage, including, but not limited to, electric lamps, fuses,
interior or exterior nishes, lters and gaskets.
Limits to the Warranty
Charges for mileage over one hundred (100) miles and travel time over two (2) hours from the Authorized Service and Parts Distributor are not covered
under this warranty. Extended mileage charges are the responsibility of the individual or rm requesting these services.
If any oral statements have been made regarding the appliance, these statements do not constitute warranties and are not part of the contract of sale.
This limited warranty constitutes the complete, nal and exclusive statement with regard to warranties.
THIS LIMITED WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ALL OTHER WARRANTIES WHETHER WRITTEN, ORAL OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR WARRANTY
AGAINST LATENT DEFECTS.
Limitations of Liability
In the event of a warranty or other claim, the sole obligation of Perfect Fry will be limited to the repair or replacement, at the Company’s discretion,
of the appliance or the component part. This repair or replacement will be at the expense of Perfect Fry except as limited by this warranty statement.
Any repair or replacement under this warranty does not constitute an extension in time to the original warranty. Parts covered under this warranty
will be repaired or replaced, at the Company’s discretion, with new or functionally operative parts. The liability of Perfect Fry on any claim of any
kind, including claims based on warranty, express or implied contract, negligence, strict liability or any other legal theories will be limited to the
repair or replacement of the appliance. This liability will not include, and the purchaser specically renounces any right to recover special, incidental,
consequential or other damages of any kind, including, but not limited to, injuries to persons, damage to property, loss of prots or anticipated loss of
the use of this appliance.
If any provision of this warranty is unenforceable under the law of any jurisdiction, that provision only will be inapplicable there, and the remainder of
the warranty will remain unaffected.
The maximum exclusion or limitation allowed by law will be substituted for the unenforceable provision.
How to Obtain Warranty Service
Direct your claim to the Perfect Fry Authorized Service and Parts Distributor, http://www.perfectfry.com closest to you giving complete model and serial
numbers, voltage, and description of the problem. Proof of the date of installation and/or the sales slip may also be required. If there are questions
about this procedure, write the National Service Manager, Perfect Fry, P. O. Box 501, Concord, NH. 03302-0501. USA
This warranty gives you certain specic legal rights; you may have other rights which vary from state to state.
WARRANTY

3
FRYER ACTIVATION
SEE THIS LCD DO THIS GET THIS LCD
1. Enter your warranty activation code
2. Press
3. Your Perfect Fryer is now perma-
nently activated.
For temporary access, enter 123456 then press .
Temporary access is valid for 90 days.
INTRODUCTION
Now that you have registered and activated your fryer;
• Take comfort in knowing that the management and staff at Perfect Fry Company are ded-
icated to ensure that you, the owner and operator of a Perfect Fryer, receive a top quality
product that is thoroughly inspected and tested prior to shipment.
• Take comfort in knowing that our local Authorized Service network is committed to supply-
ing your service and warranty needs. Each Authorized Service and Parts Provider (ASAP)
has dedicated service staff that is able to answer any questions you may have regarding
the operation of your Perfect Fryer. We also have an online knowledgebase available
24/7/365 at www.perfectfry.com with many great tips and solutions.
HEATING PRESET
70°F
HASHBROWNS
THANK YOU FOR
PURCHASING A PERFECT
FRYER SN# XXXXX
GO ONLINE OR CALL
ENTER WARRANTY CODE
AND PRESS START

In order to activate please contact Perfect Fry Company, to register your warranty by:
Registering online anytime at www.perfectfry.com
or
Call 1-603-225-6684 (Mon - Fri 8:00-5:00 EST)

4
SAFETY
It is the owner’s responsibility to:
• Insure the Perfect Fry PFC is properly maintained.
• Allow only properly trained personnel to operate, clean and maintain a Perfect Fry PFC.
• Contact local authorities having jurisdiction to insure that the installation conforms to all local
re, building and health regulations.
• Schedule and maintain documentation that the appropriate inspection and maintenance of the
PFS Automatic Extinguisher has been completed.
• Insure that the model ready for installation matches the supply voltage.
• Insure that the main power supply is disconnected before the Perfect Fry PFC is serviced.
• Insure that all safety devices are intact.
• Insure that a proper surface is provided for the Perfect Fry PFC to sit on.
• Insure that proper clearances are kept.
• Operate and store the Perfect Fry PFC above 32°F (0°C).
• Return the Perfect Fry PFC for recycling when it reaches end of life.
SAFETY FIRST
LIFTING & MOVING:
• Your Perfect Fry PFC’s gross shipping weight is 100 lb. (45 kg). Net weight = 80 lb. (36 kg).
DEEP FRYING:
• Cooking oil is very hot, 359ºF (182ºC). Hot oil can cause severe burns. DO NOT TOUCH THE
COOKING OIL UNLESS YOU ARE SURE IT HAS COOLED.
HEATER MODULE:
• DO NOT DROP
• DO NOT IMMERSE IN WATER
CLEANING:
• Before cleaning fryer or removing oil, let fryer cool to 122ºF (50ºC). DO NOT TOUCH HEATER
MODULE, VAT OR OIL UNLESS YOU ARE SURE IT HAS COOLED.
COOKING OIL MAINTENANCE:
• For sanitation and safety, we recommend that the cooking oil is replaced when it no longer meets
quality requirements. Use a McDonald’s approved deep-fryer cooking oil. OLD OIL HAS A REDUCED
FLASH POINT. OLD OIL AND OVER-WET FOOD ARE PRONE TO SURGE BOILING.
SERVICING:
• DISCONNECT THE POWER SOURCE BEFORE SERVICING THE FRYER. There is no need to
unplug your PERFECT FRYER for normal cleaning or maintenance.
STORAGE:
• Do not store your Perfect Fry PFC below 0°C (32°F)
• Intended for indoor use only

5
REGULATIONS
Installation of your Perfect Fry PFC must conform to all local re and health regulations and building
codes. The installation use and maintenance is to be in accordance with the Standard for Ventilation
Control and Fire Protection of Commercial Cooking Operations, NFPA 96 - 2004.
The table below describes the standards that your Perfect Fry PFC has been tested to and the
corresponding listing marks.
STANDARD DESCRIPTION LISTING MARK
UL 197
UL710B
Commercial electric cooking appliances.
Commercial electric cooking appliances with recirculating systems.
UL 197 & UL 197 SB supplement also reference the following
standards which your PERFECT FRYER meets applicable parts thereof:
• UL 1046: Grease Filters for Exhaust Ducts.
• UL 300: Fire Testing of Fire Extinguishing Systems for Protection
of Restaurant Cooking Areas.
• UL 900: Standard for Air Filter Units
• NFPA 17A: Wet Chemical Extinguishing Systems.
• NFPA 96: Standard for Ventilation Control and Fire Protection of
Commercial Cooking Operations.
• EPA 202: Determination of Condensible Particulate Emissions for
Stationary Sources.
CSA 22.2
No. 109-M1981
Commercial Cooking Appliances forming part of Canadian Electrical
Code, Part 2 Safety Standards for Electrical Equipment.
NSF 4 Commercial Cooking, Rethermalization, and Powered Hot Food Holding
and Transport Equipment.
APPROVALS

6
PARTS IDENTIFICATION/FUNCTION AND EXPLODED VIEW
1
2
3
4
5 6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Item Description Part No. Item Description Part No.
1 Kit, Assembly Front Panel 3HT716-C 18 Assembly, Basket Lift 3HT740-C
2Kit, Odor and Passive Filter 2FK001 19 Assembly, Element 5.7kW 240V 8ET900-C
3 20 Assembly, Female Connector 3CT765-C
4Assembly, Bracket Cage 6ST730-C 21 Plug, Cover Female Connector 6CT100
5Module, Airow 2HT723-C 22 Gasket, Molded Silicone 6FR021
6 Kit, Main Fan 2DT951-C NS Kit, Door Springs PFC 2DT957-C
7 Fire Damper 6HT588 NS Assembly, Air Filter Switch 3HT724-C
8Assembly, Grease Filter 3HT727 NS Switch, Grease Filter/Door 6HT566
9Assembly, Grease Filter Tray 6ST728-C NS Assembly, Filter Drain Hose B6698901-C
10 Assembly, Elec. Box Module 2WS805-C NS Assembly, Remote Buzzer HB B5311801-C
11 Access Control Panel 6ST732-C NS Kit, Control Fan 12VDC 6DT952-C
12 Assembly, Firemaster System 2GT001-C NS Feet, Adhesive (4 per PFC) 6HV026
13 Spring, Extension 40lbs 6GT67401 NS Kit, Fusible Link 250°F 6FP00701-C
14 Assembly, PFC Basket Motor 2HT689-C NS Switch, Front Panel Proximity 6HT567
15 Assembly, Spill Tray 6ST734-C NS Kit, Firemaster Wet Chemical 2DT943-C
16 Kit, Oil Vat PFC w/ Valve 2DT018-C NS Latch, Vice Wing Non-Locking 6DA100
17 Assembly, Drip Tray PFC 6ST105-C NS Hinge, Door Lift and Turn 6HT503

7
EQUIPMENT SET-UP AND CLOSE PROCEDURES
INSTALLATION
Electrical Power Supply
• Your Perfect Fry PFC must be connected to a dedicated electrical circuit that meets your
fryer’s requirements (see table below).
• Improper installation may damage the fryer and void you warranty.
• If your Perfect Fry PFC’s plug does not t your wall outlet receptacle, have an electrician
install the appropriate NEMA receptacle within 4 feet of the fryer.
• See the manufacturer’s label on your Perfect Fry PFC for the electrical Model No. PFC570,
then check off your Model Number.
PERFECT
FRY MODEL VOLTAGE AMPS CIRCUIT AMPS WATTAGE NEMA NUMBER
NEMA
RECEPTACLE
Put a check mark in the box beside the Model Number of your Perfect Fry PFC.
PFC570 240 24.0 30 5700
L6-30P
6-30P
Pin & Sleeve
30A, 250V, 2 Pole
PFC570 208 20.6 30 4281
All models are single phase, 50/60 hertz.
L6-30R
6-30R
IEC 60309
30A, 250V, 2P

8
EQUIPMENT SET-UP AND CLOSE PROCEDURES
INSTALLATION (Continued)
16" 40.62
17" 43.18
23" 58.42
Prepare Counter-top Area
Required Clearances
1” on sides
2” on rear
0” on top
Unpack
1. Cut straps on shipping box.
2. Remove box top and sleeve.
3. Remove outer plastic wrapping and keep box along with foam corners and
sides until installation of your Perfect Fry PFC is complete.

9
4. Lift your Perfect Fry PFC onto counter top.
5. Remove all foam stufng and parts.
6. Put check mark in box once the part is removed.
• Your Perfect Fry PFC weighs 80lb (36kg). Lift it carefully with additional help, as needed and
place it in its nal location.
EQUIPMENT SET-UP AND CLOSE PROCEDURES
INSTALLATION (Continued)
Unpack
1 Air Filter Cage
2Air Filtration Odor Filter
3Air Filtration Passive Filter
4Grease Filter
5Grease Filter Tray
6Basket Lift Assembly
7 Heater Module
8Drip Tray
9Oil Vat
10 Oil Spill Tray
11 Drain Hose
12 Rear Plug Cover
1
2
3
5
4
6
7
9
8
10

10
11
EQUIPMENT SET-UP AND CLOSE PROCEDURES
INSTALLATION (Continued)
Unpack
BLOW OFF CAPS
12
REAR PLUG
COVER HOLDER
7. Ensure that blow-off caps on re extinguisher nozzles are kept in place.
8. When removing item 12, please relocate to upper holding location designated Rear Plug Cover
Holder in the diagram below.
A
12

11
EQUIPMENT SET-UP AND CLOSE PROCEDURES
ASSEMBLY
1. Clean parts and inside of cabinet (all except air ltration cartridges).
a. Wash in warm soapy water.
b. Rinse with hot water
2. Plug in fryer and press
Note: LCD will display what is missing and will
beep twice when part is installed
SYSTEM ERROR
PLEASE CHECK/CHANGE
HEATER BOX
GREASE FILTER
AIR FILTER REPLACEMENT
FRONT PANEL
• The heater box must NOT be immersed in water, or any other liquid.
3. Install grease lter into grease lter tray.
4. Install grease lter/grease lter tray into lter compartment
by sliding along rails and towards the rear of unit.
5. Fit air lter cage over air lter cartridges as shown. Ensure
arrows are pointed upwards on both lters and write
installation date on odor ltration cartridge in space
provided.

12
EQUIPMENT SET-UP AND CLOSE PROCEDURES
ASSEMBLY (continued)
6. Slide air lters rmly back into lter compartment
and fasten down latch.
7. Install spill tray into bottom cooking compartment.
Note: Indents on bottom of spill tray
should t into matching indents on
bottom of cabinet.
8. Set heater module onto oil vat.
Note: “^” grooves on bottom of heater module
should t onto back of oil vat.
A
9. Pour frying oil into oil vat. Fill to COLD level mark.
Use McDonald’s approved deep-fry cooking oil.
DO NOT OVERFILL. (image cut away for clarity)
A

13
EQUIPMENT SET-UP AND CLOSE PROCEDURES
ASSEMBLY (continued)
10. Slide heater module/vat into cooking
compartment and push in all the way.
Ensure electrical connection is complete
with a rm push on the heater module.
A
A
11. Install drip tray in-front of oil vat. Drip tray
will t snug between front edge of oil
vat and inside edge of spill tray.
Note: If drip tray does not t, press
heater module in further to complete
connection.
12. Install basket lift
a. Hold basket tray vertical
b. Install rod into pivot hole - left side
c. Install rod into motor coupling - right side
d. Pivot basket tray forward from
vertical position and insert arms
into spill tray.
13. Install and close front panel. Turn latches 1/4 turn clock wise and press down.
14. The fryer will now begin heating. In a few minutes, Perfect Fry PFC will be ready to start cooking.

14
EQUIPMENT SET-UP AND CLOSE PROCEDURES
CLEANING
Supplies
KAY® QSR Heavy Duty Degreaser Solution (HDD)
KAY® SolidSense™ All Purpose Super Concentrate Solution (APSC)
KAY® SolidSense™ Sanitizer Solution
KAY® Specialty Cleaner & Polish
KAY® NO-SCRATCH Pad (White)
KAY Hi-Temp Pad (black pad for fryer tool)- to scrub inside oil vats
KAY® Hi-Temp Detail Brush (White Bristles)-As needed for coils
Clean towel bucket
Soiled towel bucket
Clean sanitizer-soaked towels
Clean sanitizer-soaked grill cloths
Heat-Resistant Gloves
Safety Apron for Heat Protection
Safety Face Shield
CAUTION: Do not touch heater module vat or oil unless heat resistant gloves are worn.
CAUTION: Do not unplug the fryer and always make sure the fryer is turned off.
Daily Cleaning Procedures : For more information, reference ECOLAB® Cleaning Procedure.
1. Put on heat resistant gloves and ensure oil is cool before cleaning.
2. Remove the fryer baskets, drip tray, skimmer, and all fryer cooking utensils and wash them at
the 3-compartment sink in hot, fresh KAY® SolidSense™ All Purpose Super Concentrate Cleaner
solution (APSC). Rinse them under hot, fresh water then sanitize in sanitizer solution for 1 minute.
Allow to air dry.
3. Open the fryer door and clean the inside of the fryer area by spraying a clean, sanitizer-
soaked grill cloth with KAY® QSR Heavy Duty Degreaser solution (HDD) and wipe down the
front of the oil vat, inside the door, and other interior areas that may have crumbs or oil.
Discard the soiled grill cloth in the soiled towel bucket.
NOTE: If cooking oil remains in the oil vat during cleaning, do not spray cleaner solution
inside the fryer area. Spray the cleaner solution directly onto the grill cloth only.
4. Rinse the interior fryer areas with a separate clean, sanitizer-soaked grill cloth. Discard the
soiled grill cloth in the soiled towel bucket.
5. Clean the exterior of the fryer by spraying a clean, sanitizer-soaked towel with KAY® QSR
HDD solution then wipe clean. If polishing is needed for the exterior fryer, spray a clean
paper towel with KAY® Specialty Cleaner & Polish and wipe the exterior until dry.
NOTE: Do not clean the outside or any stainless steel part with abrasive cleaners.
6. Check the oil level on the back of the vat to make sure it is up to the cold line (at room
temperature). If not, add oil as necessary.

15
EQUIPMENT SET-UP AND CLOSE PROCEDURES
CLEANING (continued)
NOTE: Before cleaning fryer or removing oil, let fryer cool.
CAUTION: Do not touch the heater module, oil vat or oil unless it has cooled or if heat
resistant gloves are worn.
1. Put on heat resistant gloves, safety apron, and safety face shield.
2. Press Cancel and 0 keys simultaneously to initiate Drain/Clean mode. Allow the fryer to reach
122°F/50°C before proceeding with draining the fry vat. Ensure display reads Drain/Clean before
proceeding.
3. Open front panel, install drain hose assembly and drain oil into appropriate oil containment device
(varies per restaurant). Discard the used cooking oil.
4. Turn the fryer OFF. Keep the fryer plugged in.
5. Open the front panel door and clean the inside and outside of the door with a clean, sanitizer-
soaked towel sprayed with KAY® QSR HDD solution. Rinse with a separate clean, sanitizer-soaked
towel. Discard the soiled towel in the soiled towel bucket after use.
NOTE: If the door panel is heavily soiled, remove the panel by lifting and turning latches
and lift it off of the hinges and take it to the 3-compartment sink and allow to soak in KAY®
SolidSense™ APSC solution. Scrub the door panel with a towel or NO-SCRATCH™ Pad then
rinse in water and allow to air dry.
6. Remove the air lter cartridge and set aside.
CAUTION: Do not wash the air lter cartridges.
7. Remove the grease bafe tray from the cabinet. Remove the grease bafe from the tray and drain
any oil that has accumulated.
8. Remove the fryer baskets, basket lift, drip tray, skimmer, and all fryer cooking utensils.
9. Take the grease bafe, grease bafe tray, fryer baskets, basket lift, drip tray, skimmer and all fryer
cooking utensils to the 3-compartment sink to wash in KAY® SolidSense™ APSC solution. Rinse in
hot, fresh water. Sanitize in KAY® Solidsense™ Sanitizer solution for 1 minute. Allow to air dry.
10. Remove the heater module coils from the fryer vat and scoop out the sediment and remaining
cooking oil that may have solidied in the base of the fryer vat with a scraper.
CAUTION: Do not submerge the heater box in water or
other liquid.
11. Remove drain hose assembly and return to its designated
storage area.
12. Take the oil vat and heater module coils back to the 3-compartment sink to soak in Heavy Duty
Degreaser solution. Fill the oil vat with Heavy Duty Degreaser concentrate and ll the vat ¼ full of
degreaser. Fill the vat with hot water until full. Place the coils into the vat to soak. Make sure the vat
and coils are fully covered with the degreaser. Allow the vat and coils to soak for 30 minutes.
Cleaning - When cooking oil is disposed: For more information, reference ECOLAB® Cleaning Procedure.

16
EQUIPMENT SET-UP AND CLOSE PROCEDURES
CLEANING (continued)
Cleaning - When cooking oil is disposed(continued) :
CAUTION: Keep the electrical box on the heater module coils away from water. The heater
box must NOT be immersed in water or other solutions. Do not spray the male connector.
13. Remove the coils and scrub the coils with a KAY® Hi-Temp Pad. If heavy build-up occurs and
it is difcult to remove soil from in between the coils, use the KAY® Hi-Temp Detail Brush Head
(cleaning tool head that is part of the fryer cleaning tools with white bristles) to scrub inside the
coiled areas. Rinse off the coils with hot , fresh water. Allow to air dry.
14. Scrub the interior and exterior of the oil vat with a KAY® Hi-Temp Pad. Rinse with hot, fresh
water then sanitize in SolidSense™ Sanitizer solution for 1 minute. Allow to air dry.
15. Remove the spill tray from the fryer and drain any oil that has accumulated. Take the spill tray
to the 3-compartment sink to wash in APSC solution. Rinse the spill tray in hot, fresh water then
sanitize in SolidSense™ Sanitizer solution for 1 minute. Allow to air dry.
NOTE: Place the Yellow Protective Cover that comes with the fryer unit, back on top of
the female connector at the interior back of the unit behind the vat before interior cabinet
cleaning begins. Do not spray the female connector.
16. With the interior components removed from the fryer, clean the interior of the fryer and the front
panel door with a clean, sanitizer-soaked towel sprayed with KAY® QSR HDD solution and wipe
until clean. Rinse with a separate clean, sanitizer-soaked towel.
17.Spray countertop with KAY® QSR HDD solution. Discard the soiled towel in the soiled towel
bucket after use.
18.Clean the exterior of the fryer equipment by spraying a clean, sanitizer-soaked towel with KAY®
QSR HDD solution then wipe clean. If polishing is needed for the exterior fryer, spray a clean paper
towel with KAY® Specialty Cleaner & Polish and wipe the exterior until dry.
19.After cleaning is complete, remove the Yellow Protective Cover from the female connector body.
NOTE: Return the Yellow Protective Cover to its holding area in the upper cabinet for storage.
20.Ensure that the blow-off caps on re extinguisher nozzles are kept in place.
21.Re-install the clean parts inside the fryer (see assembly instructions).

17
EQUIPMENT SET-UP AND CLOSE PROCEDURES
CLEANING (continued)
Cleaning - Periodic Maintenance
Air Filter Cartridge Replacement
• Replace the air lter cartridge at least once every 3 months,
more often for higher volume usage. Replacement is safer
and easier when the fryer is cool rather than hot.
• Only Perfect Fry lters may be used in your Perfect Fry
PFC.
Steps to replace air lter cartridge:
1. Open front panel by turning latches.
2. Release latch on air lter cage, and remove air lter
cage and air lter cartridges from lter compartment.
3. Remove old used air lter cartridges from air lter cage.
4. Wipe air lter cage clean
5. Fit air lter cage over new air lter cartridges (as
shown) and write date on cartridge (Arrows up).
6. Install air lter cage and new air lter cartridge rmly
back into lter compartment and latch in place.
7. Close front panel and latch shut.
A
A
PFS Automatic Extinguisher
• The PFS automatic extinguisher must be inspected
monthly by the owner/operator and semi-annually by
authorized service personnel as per NFPA 17A. It
is important that a maintenance program is set up
with a local re service company to ensure that local
jurisdictional codes are being met. Please refer to
PFS automatic extinguisher manual (L20-361) for more
information.

18
OPERATION AND CONTROL
Operation Instructions
READY PRESET
359°F
HASHBROWNS
Keypad
• Easy to use, just a rm
touch with your nger tip.
• A smooth at surface that’s
easy to keep clean.
Active Mode
• Shows which of the six
modes your Perfect Fry
PFC is currently in.
Preset Name
• Shows which preset is
currently cooking.
LCD Screen
• Displays user information
Left Arrow Key
• Adjusts cook time up by 10
second increments.
Number Keys
• 0 to 9
Preset Key
• Choose any of the default
presets.
On/Off Key
• To turn ON
• To turn OFF
• To put in STANDBY
Preset Mode
• Shows which preset mode
the Perfect Fry PFC is
currently in.
Oil Temperature
• Always displayed
• Choose between °C & °F
Right Arrow Key
• Adjusts cook time down by
10 second increments.
Start Key
• Begins a cook cycle
Cancel Key
• Stops a cook cycle
• Resets the screen
Table 1 - Preset Mode Functionality
Feature Manual
Mode
Preset
Mode
Preset Locked
Mode
Manually enter cook time   
Automatically enters preset time   
Remains in same mode after cook cycle   

19
OPERATION AND CONTROL
Operation Instructions (continued)
YOU DO THIS
1. Press for 1/2 second
Perfect Fry PFC does this
1. Now in heating mode
2. Oil temperature rising to operating
temperature
Starting Up
HEATING PRESET
70°F
2. Allow 10 to 30 minutes for oil
to reach operating temperature
(359°F or 182°C)
3. Once operating temperature is
reached, unit is READY to start
cooking.
READY PRESET
359°F
Preset Times
Cooking Time & Names (Factory Defaults)
Preset Name Time Preset Name Time Preset Name Time
1HASHBROWNS 3:00 4 <AVAILABLE> 0:00 7 <AVAILABLE> 0:00
2<AVAILABLE> 0:00 5 <AVAILABLE> 0:00 8 <AVAILABLE> 0:00
3<AVAILABLE> 0:00 6 <AVAILABLE> 0:00 9 <AVAILABLE> 0:00
NOTE: Pressing repetitively will toggle between MANUAL mode, PRESET mode and
PRESET LOCKED mode.
NOTE: The default presets are programmed at the factory. Please refer to ADDITIONAL
PRODUCT SETTINGS if additional presets are needed.

20
OPERATION AND CONTROL
Operation Instructions (continued)
Preset Lock Mode
YOU DO THIS
1. Press two times
Perfect Fry PFC does this
1. Now in PRESET LOCK mode.
2. PRESET is displayed on LCD
2. Put food in basket.
3. Open door.
4. Set basket on basket lift.
5. Close door.
6. Press 1, cook cycle starts
immediately.
3. LCD displays HASHBROWNS,
default setting is 3:00.
4. Brief pause, basket lowers into oil.
5. COOKING cycle begins.
6. Fryer counts down time remaining.
READY PRESET
359°F
COOKING PRESET
3:00
HASHBROWNS
359°F
7. Wait for "Beep"
8. Open door.
9. Remove Basket
10. Follow steps 2 through 6 to cook
another order this way.
7. COOKING cycle is complete.
8. Basket raised out of oil.
9. Basket drains.
10. Fryer "beeps" to inform you that
food is cooked.
NOTE: Fryer remains in PRESET
READY PRESET
359°F
Canceling a cook
YOU DO THIS
1. Press to erase cooking
time.
Perfect Fry PFC does this
1. Cooking time erased, unit returned
to READY mode.
READY PRESET
359°F
Standby Mode
READY PRESET
359°F
STANDBY PRESET
275°F
1. Press and together.
2. Release both
NOTE: Temperature will decrease
to 275ºF.
SEE THIS LCD DO THIS GET THIS LCD
Note: During slow periods, using standby mode reduces energy costs, allows a
quick recovery and minimizes oil breakdown.
