PERFORMANCE ADVANTAGE COMPANY K5026-JL User manual

¼-20 x 1-3/4 S.S.
Flat Head Screw
P/N 2092
SPREADER BASE KIT P/N K5026-JL INSTALLATION INSTRUCTIONS
PERFORMANCE ADVANTAGE COMPANY 12-2016
CAUTION
To avoid the risk of personal injury, property damage or product damage, please use the included
fasteners for mounting.
* The bracket must be securely mounted to a stable surface and material.
* When mounting bracket to PAC TRAC aluminum products P/N 7000, P/N 7020, P/N 7040,
P/N 7050 with the included Trac Lok inserts P/N 7016, torque the screws to a maximum 15 in-lbs.
* PAC recommends regular and frequent inspections to be certain of proper operation and installation.
For additional assistance call 888-514-0083 between 8AM-5PM EST or email: [email protected]om
INS-K5026-JL
www.pactoolmounts.com
P/N 2069LN
FIGURE 1
(Thru Mounting Method)
P/N 3017 (2)
P/N 2069LN (2)
CAN BE MOUNTED TO
FLOOR OR WALL
3-7/8”
17/64”
HOLES (2)
P/N 2092 (2)
5.75”
17/64” DIA. (2)
JUMBO LOK ATTACHMENT
STANDARD MTG. HARDWARE QTY
¼-20
Nylon Locking Nut
2
2
PAC Fastener Packet P/N 7042 (PARTIAL)
P/N 2069LN
JUMBO LOK
STANDARD MTG. HARDWARE QTY
¼-20
Nylon Locking Nut
2
2
PAC Fastener Packet P/N 7048
P/N 3017
P/N 2069LN
¼-20 x 1 S.S.
S.S. Pan Head Screw
POCKET
www.rskequipment.com

PERFORMANCE ADVANTAGE COMPANY 12-2016
CAUTION
To avoid the risk of personal injury, property damage or product damage, please use the included
fasteners for mounting.
* The bracket must be securely mounted to a stable surface and material.
* When mounting bracket to PAC TRAC aluminum products P/N 7000, P/N 7020, P/N 7040,
P/N 7050 with the included Trac Lok inserts P/N 7016, torque the screws to a maximum 15 in-lbs.
* PAC recommends regular and frequent inspections to be certain of proper operation and installation.
FIGURE 2
(PAC TRAC Mounting)
For additional assistance call 888-514-0083 between 8AM-5PM EST or email: [email protected]om
INS-K5026-JL
www.pactoolmounts.com
SPREADER BASE KIT P/N K5026-JL INSTALLATION INSTRUCTIONS
P/N 7016 (2)
P/N 2022 (2)
JUMBO LOK ATTACHMENT
P/N 7016 (2)
P/N 2047(2)
CAN BE MOUNTED TO
FLOOR OR WALL
MTG. HARDWARE for PAC TRAC QTY
Trac Lok Insert
2
2
PAC Fastener Packet P/N 7034
P/N 2047
P/N 7016
#10-24 x 1-1/4 S.S.
S.S. Pan Head Screw
MTG. HARDWARE for PAC TRAC QTY
Trac Lok Insert
2
2
P/N 7016
P/N 2054 (2)
PAC Fastener Packet P/N 7042 (PARTIAL)
JUMBO LOK
POCKET
P/N 2022 #10-24 x 1-7/8 S.S.
Flat Head Screw
#10 S.S.
Flat Washer
P/N 2054
2
