Performance Tool W87032 User manual

OWNER'S MANUAL
WARNING: READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY
RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL
VOID WARRANTY.
VACUUM PUMP &
BLEEDER KIT
Item Number W87032

2
TOOL FEATURES
6
7
1
4
• 2 in. Pressure gauge for accurate measurements.
• Reservoir jar with operation and transport lids.
• Collection of popular adapters, connectors and plugs.
5
8
11
10
14
15
13
9
12
2
3
EXPANDED PARTS LIST
1 Vacuum Pump ....................... 1
2 2 in. Pressure Gauge .......... 1
3 Vacuum Release Control .... 1
4 Operation Jar Lid ................ 1
5 Transport Jar Lid................. 1
6 Reservoir Jar....................... 2
7 24 in. x 1/4 in. I.D. Hose ..... 2
8 1/4 in. I.D. Vacuum Hoses... 3
9 Tapered Hose Adapters..... 6
10 “T” Hose Connector ........... 1
11 Straight Hose Connector ... 1
12 Brake Bleeder Screw Adapter 2
13 Universal Cup Adapter....... 1
14 Plug.................................... 2
15 Vacuum Hose Adapter....... 1
No. Description Qty. No. Description Qty.

3
Gauge..................................................................................2 in. Diameter
Gauge Scale................................ 0,- 25 in/Hg (0<->63.5 cm/Hg) Vacuum
Long Vacuum Hose ................................................ (2) 1/4 in. I.D. X 24 in.
Small Vacuum Hose ............................................................ (3) 1/4 in. I.D.
Reservoir Jar. .................................................................................... 4 oz.
Net Weight..................................................................................... 1.8 lbs.
SPECIFICATIONS:
Specifications are subject to change without notice.
This instruction manual is intended for your benefit. Please read and follow the safety, installation,
maintenance and troubleshooting steps described within to ensure your safety and satisfaction. The
contents of this instruction manual are based upon the latest product information available at the
time of publication. The manufacturer reserves the right to make product changes at any time
without notice.
SAFETY GUIDELINES / DEFINITIONS

WARNING: Read and understand this entire instruction manual before attempting to
assemble, install, operate or maintain this product. Failure to comply with the instructions may
result in serious personal injury and/or property damage!
The following signal words are used to emphasize safety warnings that must be
followed when using this product:
DANGER:
Indicates an imminently
hazardous situation that, if not avoided,
WILL result in death or serious injury.
WARNING:
Indicates a potentially
hazardous situation that, if not avoided,
COULD result in death or serious injury.
CAUTION:
Indicates a potentially
hazardous situation that, if not avoided, MAY
result in minor or moderate injury.
NOTE: Indicates important information,
which if not followed, MAY cause damage to
equipment.
• When unpacking, check to make sure all the parts shown on pg. 2 are included. If any parts
are missing or broken, please call customer support at 1-800-497-0552
UNPACKING
GENERAL SAFETY
• Stay alert. Watch what you are doing, and use common sense when operating the
Vacuum Pump. Do not use the tool while tired or under the influence of drugs, alcohol,
or medication. A moment of inattention while operating the tool may result in serious
personal injury.
• Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your
hair, clothing, and jewelry away from moving parts. Loose clothes, jewelry, or long hair
can be caught in moving parts.
• Do not overreach. Keep proper footing and balance at all times. Proper footing and
balance enables better control of the power tool in unexpected situations.
• Use safety equipment. Always wear eye protection. Safety equipment such as dust
masks, non-slip safety shoes, helmets or ear protection used in appropriate conditions
will reduce the risk of injury.

4
• Maintain a safe working environment. Keep the work area well lit. Make sure there is
adequate surrounding workspace. Always keep the work area free of obstructions,
grease, oil, trash, and other debris. Do not use the Vacuum Pump in areas near
flammable chemicals, dusts, and vapors. Do not use this product in a damp or wet
location.
• Maintain labels and nameplates on this product. These carry important information. If
unreadable or missing, contact Performance Tool for a replacement.
• Keep the handles of the Vacuum Pump dry, clean, and free from brake fluid, oil, and grease.
• Prior to using the Vacuum Pump make sure to read and understand all warnings,
safety precautions, and instructions as outlined in the vehicle manufacturer’s
instruction manual. Every vehicle has specific measurement values for vacuum related
readings. It is beyond the scope of this manual to properly describe the correct
procedure and test data for each vehicle.

WARNING: Carbon monoxide is produced while a vehicle’s engine is operating and is
deadly in a closed environment. Early signs of carbon monoxide poisoning resemble the
flu, with headaches, dizziness, or nausea. If you have these signs, the work area may not
be vented properly. Get fresh air immediately.
• Prior to using the Vacuum Pump, make sure to place the vehicle’s transmission in
“PARK” (if automatic) or “NEUTRAL” (if manual). Then, block the tires with chocks.
• Be alert for hot engine parts to avoid accidental burns.
• Avoid accidental fire and/or explosion. Do not smoke near engine fuel and battery
components.
• Use the Brake Bleeder only with brake fluid. Do not attempt to use the tool to siphon
any other liquids. Damage to the internal chamber and seal, or future brake fluid
contamination ma result.
• Follow guidelines for proper brake fluid disposal. Used brake fluid should be removed
from the vehicle and properly recycled. Many states require recycling. Contact your local
solid/liquid waste authority for information on recycling. Do not reuse old brake fluid.
• Brake fluid is corrosive. Avoid spilling it on the vehicle’s exterior, it can harm automobile paint.

WARNING: People with pacemakers should consult their physician(s) before using this
product on a running engine. Electromagnetic fields in close proximity to a heart
pacemaker could cause interference or failure of the pacemaker. In addition, people with
pacemakers should adhere to the following: Caution is necessary when near the coil, spark
plug cables, or distributor of a running engine. The engine should always be off if
adjustments are to be made to the distributor.

WARNING: Always release the vacuum in the Vacuum Pump before performing any
inspection, maintenance, or cleaning.
• Before each use: Inspect the general condition of the Vacuum Pump. Check for
misalignment or binding of moving parts, cracked or broken parts, damaged Hoses, loose
connections, and any other condition that may affect its safe operation. If a problem
occurs, have the problem corrected before further use. Do not use damaged equipment.

WARNING: The warnings, precautions, and instructions discussed in this manual cannot
cover all possible conditions and situations that may occur. The operator must understand
that common sense and caution are factors which can not be built into this product, but
must be supplied by the operator.
PRODUCT WARNINGS

5
NOTE: Measurements and illustrations are for reference only.
Your test results may vary.
NORMAL ENGINE
1. With the vacuum pump connected to an intake manifold
vacuum port.
2. Start engine, bring to normal temperature and let idle.
3. Look at the needle’s movement on the gauge. At idle,
the needle should read 16-22 in. of Hg and hold steady.
This is your base line, indicating everything
functioning normal.
WEAK OR BROKEN VALVE SPRING
• A sign of weak valve springs are when the pointer on the
vacuum pumps gauge fluctuates rapidly between 10 and 21
in. of Hg at idle. As the engine speed increases the
fluctuations will increase too.
• A broken valve spring will still cause the needle to fluctuate
rapidly at regular intervals. The difference can be seen every
time the cylinder fires and the valve attempts to close.
STICKING VALVE
• A valve that’s sticking will exhibit a rapid drop intermittently
from a normal pointer indication. This is because a sticking
valve or valves don’t always stick on each cycle of the
engine. To pin-point a sticking valve apply lightweight oil
directly to each valve guide using a syringe with a fine tip. As
the oil coats the guide the sticking valve will temporarily
function normal. The needle on the gauge will be steady until
the oil burns off.
BURNED OR WORN-LEAKING VALVE
• At idle, the pointer on the gauge will drop then return to
normal. This would happen at regular interval. Every time the
cylinder fires with the bad valve it will cause the needle to
drop to a low reading. The needle will drop from 1 to 7 in. of
Hg, then return to a normal reading.
WORN VALVE GUIDES
• A worn valve guide lets air into the cylinder, this changes the
air/ fuel mixture. The needle on the gauge will run lower than
normal, approx. 3 in. of Hg and will fluctuate rapidly. When
you increase the speed of the engine the needle will stop
fluctuating.
BLOWN CYLINDER HEAD GASKET
• At idle, the needle will fluctuate from normal to a low reading.
Each time the affected cylinder reaches firing position the
needle will drop sharply. You should see about 10 in. of Hg
drop from normal, then return.
ENGINE DIAGNOSTICS
