OWNER'S MANUAL
WARNING: READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND
WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY
RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL
VOID WARRANTY.
LEVER ACTION
BARREL PUMP
Item Number W54268

2
Specifications are subject to change without notice.
SPECIFICATIONS
FEATURES & BENEFITS
Pump Height...................................................................................................................18 in.
Stroke Length ...................................................................................................................6 in.
Flow Rate ............................................................................................................ 9 oz./Stroke
Hose Length ........................................................................................................... 12 - 36 in.
Chemical Resistance............................................................................................ Viton Seals
Bing Adapter............................................................................................1-1/4 & 2 in. Thread
Applicable Drum ..............................................................................35, 55 and some 15 Gal.
Applicable Pail...............................................................................................................5 Gal.
COMPATIBLE CHEMICALS
Nitric Acid 10% Solution Ethyl - Ethanol
Nitric Acid 50% Solution Ethylene Glycol
Nitric Acid 20% Solution Isopropyl - Isopropanol
Phosphoric Acid 40% Solution Glycerin
Sodium Bicarbonate 10% Diesel Fuel
Ammonia Liquids Diesel exhaust uid
Blue Def Diesel Exhaust Fluid
Ultra-pure Automotive Grade Urea 32.5%
NON RECOMMENDED CHEMICALS
Hydrochloric/Muriatic Acid 100% Sulfuric Acid 10% - 75%
Hydrouoric Acid 75% Sulfuric Acid 75% - 100%
Hydrouoric Acid 100%
• Manual operation for quick, clean transferring of fuel or water based and acidic solutions.
• Dispenses approximately 9 ounces per stroke
• Designed for use with 5 gallon to 55 gallon containers
• 36 in. Telescopic suction tube adjusts to t various barrels
• Steel lift rod and curved discharge spout
This instruction manual is intended for your benefit. Please read and follow the safety, installation,
maintenance and troubleshooting steps described within to ensure your safety and satisfaction. The
contents of this instruction manual are based upon the latest product information available at the
time of publication. The manufacturer reserves the right to make product changes at any time
without notice.
SAFETY GUIDELINES / DEFINITIONS

WARNING: Read and understand this entire instruction manual before attempting to
assemble, install, operate or maintain this product. Failure to comply with the instructions may
result in serious personal injury and/or property damage!
The following signal words are used to emphasize safety warnings that must be
followed when using this product:
DANGER:
Indicates an imminently
hazardous situation that, if not avoided,
WILL result in death or serious injury.
WARNING:
Indicates a potentially
hazardous situation that, if not avoided,
COULD result in death or serious injury.
CAUTION:
Indicates a potentially
hazardous situation that, if not avoided, MAY
result in minor or moderate injury.
NOTE: Indicates important information,
which if not followed, MAY cause damage
to equipment.

IMPORTANT SAFETY INFORMATION
 WARNING: READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS
BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY RESULT IN DEATH, PERSONAL
INJURY AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY.
 WARNING: THE USER IS RESPONSIBLE FOR OPERATING THIS PUMP IN CONFORMANCE
WITH O.S.H.A. GUIDELINES FOR DISPENSING AND TRANSFERRING HAZARDOUS,
FLAMMABLE OR COMBUSTIBLE LIQUIDS.
GENERAL SAFETY INFORMATION AND IMPORTANT GUIDELINES:
• Always follow electrical and safety codes when using a hand pump.
• Information regarding NEC (National Electrical Codes) and NFPA (National Fire
Protection Association) Codes can be obtained from the National Fire Protection
Association, Inc., Battery march Park, Quincy, MA 02269, phone number 1-800-344-
3555 or online at www.nfpa.org.
• Make sure pump containers are grounded when using with ammable liquids to avoid
static electricity.
• Flush out pump prior to using. Processing lubricants could contaminate the uid.
• Know the pump uses, limitations and all potential hazards before using this pump.
Take note of all warning statements which indicate potentially dangerous situations for
the operator, bystanders or equipment.
FOR THE PERSONAL SAFETY OF THE OPERATOR AND OTHERS WHO MAY COME
INTO CONTACT WITH ANY PUMPS OF THIS NATURE AND FLAMMABLE LIQUIDS:
• When pumping hazardous chemicals, wear a face shield, proper attire and approved
respiratory equipment.
• Keep your work area clean and clear of clutter with sufcient lighting for proper visibility
and in creased safety.
• Visitors and observers should remain at a safe distance from the area of work, unless
the precautions above have been observed.
• The work area should be child-proof. Install padlocks, master switches and remove all
starter keys for the safety of all children.
 WARNING: WHEN FILLING DRUMS, CANS OR OTHER CONTAINERS WITH FLAMMABLE
LIQUIDS, BOTH CONTAINERS SHOULD BE GROUNDED AND SECURELY FASTENED TO
DISCHARGE STATIC ELECTRICITY AND MINIMIZE SPARKS CAUSED BY STATIC ELECTRICITY.
• This pump should only be used with liquids compatible to the component material of
the pump (See Specications for component materials). The chemical supplier may
be contacted with questions regarding chemical compatibility and the proper use and
handling of the chemical.
• Misuse of this pump or use of incompatible liquids will void the warranty.
• Dispensing and/or transferring hazardous, ammable or combustible liquids should
only be done in areas suitable for this purpose.
• All warnings and instructions pertain not only to petroleum fuel, oils, kerosene, diesel
fuel, lubricating oil & antifreeze (ethylene-glycol), but to any hazardous, ammable or
combustible liquids.
• Only store hazardous, ammable or combustible liquids in a cool location. Keep stored
hazardous, ammable or combustible liquids far from open ames or heat.
• Always keep hazardous, ammable or combustible liquids, other fuels and cleaners
out of reach of children.
• A maintained re extinguisher should be kept nearby when working with hazardous,
ammable or combustible liquids.
 WARNING: THIS PUMP IS SUITABLE FOR MANY LIQUIDS, BUT NOT ALL LIQUIDS.
KNOW YOUR PUMP AND THE LIQUIDS YOU WILL BE PUMPING THROUGH THE PUMP.

4
1. Phillips screw driver 2. Adjustable wrench 3. PTFE Tape
TOOLS REQUIRED
CONTENTS
1 Pump Body ......................... 1
2 Handle................................. 1
3 Discharge Spout ................. 1
4 Retainer Nut........................ 1
5 Machine Screw ................... 2
6 Lock Nut ............................2
7 Washer...............................4
8 Suction Tube w/Strainer ....1
9 Suction Tube Extension .....1
10 Base Suction Tube.............1
No. Description Qty. No. Description Qty.
1
2
3
45
6
7
8
9
10
• Provide positive shut-off valves on all xed fuel supplies. Fuel lines must be made of
steel piping, leak-free and securely fastened.
• Adequate ventilation is essential! Clean up all spills immediately when pumping or
handling ammable liquids.
• ABSOLUTELY NO SMOKING!
• DO NOT use torches or apply re or ames to this pump, pump components or any
containers used with this pump.
• Be sure that the discharge line is secure before pumping. An insecure discharge line
may slide, possibly causing personal injury and/or damage to property.
• Over tightening non-metallic ttings will strip threads. Once tting is “hand tight” turn one
more full rotation, this is usually enough to prevent leaking. Thread sealant can be used
on all threaded joints, including the delivery spout.
• Before each use, check hoses for weak or worn spots. Check the security of all connections.
• Occasionally inspect the pump and components, performing routine maintenance
when required.
• Dispel all liquids from the pump and components before performing routine maintenance.
IMPORTANT SAFETY INFORMATION

WARNING: AFTER USE, STORE ALL PUMPS USED FOR TRANSFERRING HAZ-
ARDOUS, FLAMMABLE OR COMBUSTIBLE LIQUIDS IN A WELL-VENTILATED AREA.

5
1. Read and understand instruction before
beginning. Flush with water prior to use.
Use PTFE tape on all plastic threaded joints.
2. Connect the Handle (2) to the Pump Body
(1) and lift rod with Machine screws (5),
Lock Nuts (6) and Washers (7). See Fig. 1.
3. Slide Retainer Nut (4) onto Discharge
Spout (3). See Fig. 2.
4. Attach Discharge Spout (3) onto Pump
Body (1) using Retainer Nut (4). Make
sure to use PTFE tape. See Fig. 3.
5. Attach Suction Tube with Strainer (8) to
bottom of Pump Body (1). Make sure to
use PTFE tape. See Fig. 4.
6. To attach 24 in. telescopic suction tube
slide Suction Tube with Strainer (8) into
Base Suction Tube (10) and attach
Suction Tube with Strainer (8) into bottom
of Pump Body (1). Make sure to use
PTFE tape. See Fig. 5.
7. To attach 36 in. telescopic suction tube
attach 24 in. suction tube from step 6 to
Suction Extension Tube (9) and then
attach Suction Extension Tube (9) to
bottom of Pump Body (1). Make sure to
use PTFE tape.
ASSEMBLY INSTRUCTIONS
4
3
Fig. 2
Fig. 3
Fig. 4
3
4
1
8
1
Fig. 5
8
10
1
2
Fig. 1

1. Determine the proper length of suction
tube for your application and attach
to pump.
2. Insert suction tube through bung hole
located on container lid and submerge
into liquid to be transfered. See Fig. 6.
3. Attach bung nut located on the bottom of
the Pump Body (1) to the container lid.
See Fig. 7.
4. Pump the handle several times to prime
the pump.
5. Continue pumping until the desired
volume of solution is delivered.
OPERATION
Fig. 6
Fig. 7
DEF (DIESEL EXHAUST FLUID)- USE
1. The overall purity of DEF is critical for the system to function properly. Before pumping
DEF for filling the onboard systems, the pump needs to be flushed. This is done by
dispensing DEF fluid into a portable container. This fluid should be disposed of in the
proper manner in accordance with local regulations. “Do not return it to the drum or use
it in a vehicle.”
2. After pumping the desired amount of fluid, reverse the direction of rotation. This will
return and dispense fluid still in the pump back into the barrel. This is required because
fluid left in the pump will crystallize and cause the pump to malfunction. Crystallized
DEF fluid would contaminate the next fluid dispensed.
3. If the pump has not been used for an extended length of time, or has had low usage the
pump should be flushed and cleaned. This is critical when pumping DEF as it can
harden and crystallize.
Note: If you have used the pump for DEF, use it ONLY for DEF and no other materials.
A sticker has been provided to label the pump once the unit has been used for DEF. Use
de-ionized water to flush the pump.

CARE AND MAINTENANCE
A variety of chemicals, especially combinations of chemicals, are suitable for periodic use.
They may affect the performance for the pump if left to dry. In these cases cleaning of the
pump after each use is mandatory. Other chemicals may harden or cause the internal parts to
swell. This prohibits the pumps operation and should be avoided unless cleaned after every
use. If the pump has not been used for an extended length of time, or has had low usage the
pump should be flushed and cleaned.
PUMP IS NOT WORKING
1. Check the suction tubes to be sure they are airtight. The pump will not pump if the suction
tube allows air to enter. Thread sealing PTFE tape is recommended during assembly.
2. Lubricate the external moving parts with a multi-purpose lubricant.
3. Rinse pump with water or the appropriate solution in regards to what was just pumped.
Some chemicals may harden or cause the internal parts to swell, this prohibits the
pumps operation. You may need to open the pump body and clean the internal parts.
While inside, visually review the vane for chemical permeation or swelling. If this has
occurred replace the pump.
TROUBLESHOOTING

1 YEAR WARRANTY
PERFORMANCE TOOL® extends only the following warranties, and only to original
retail purchasers. These warranties give specific legal rights. Except where prohibited
by local law, the law of the State of Washington governs all warranties and all
exclusions and limitations of warranties and remedies. There may be other rights which
vary from state to state.
PERFORMANCE TOOL® warrants the product to be free from defects in materials and
workmanship under normal use and service. A defective product may be returned for
a free replacement within 90 days from the date of purchase, provided that product is
returned to place of purchase immediately after discovery of defect. After 90 days and
up to one year from date of purchase, PERFORMANCE TOOL® will replace at no
charge any parts which our examination shall disclose to be defective and under
warranty. These warranties shall be valid only when a sales receipt showing the date of
purchase accompanies the defective product or defective part (s) being returned. For
part (s) after 90 days, please remit your request, postage prepaid to:
PERFORMANCE TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, hoses, and other
consumables which must be replaced under normal use and service. These warranties
shall not apply to any product or part which is used for a purpose for which it is not
designed, or which has been repaired or altered in any way so as to affect adversely
its performance or reliability, nor shall these warranties apply to any product or part
which has been subject to misuse, neglect, accident or wear and tear incident to
normal use and service.
PERFORMANCE TOOL® does not authorize any other person to make any warranty or
to assume any liability in connection with its products.
Except for warranties of title and the limited express warranties set forth above,
PERFORMANCE TOOL® makes no express or implied warranties of any kind with
respect to its products. In particular, PERFORMANCE TOOL® makes no implied
warranty of merchantability and no implied warranty of fitness for any particular
purpose, except that for goods purchased primarily for personal, family or household
use and not for commercial or business use, PERFORMANCE TOOL® makes an
implied warranty of merchantability (and, if otherwise applicable, an implied warranty
of fitness for a particular purpose), but only for the particular qualities or
characteristics, and for the duration, expressly warranted above.
The laws on limitation of implied warranties may differ from state to state, so the
above limitations may not apply in all cases.
PERFORMANCE TOOL® shall not be liable for consequential, incidental or special
damages resulting from or in any manner related to any product, or to the design, use,
or any inability to use the product. The sole and exclusive remedy for a defective
product or part shall be the repair, or replacement thereof as provided above. The laws
on limitation of remedies or on consequential, incidental or special damages may vary
from state to state, so the above limitations may not apply in all cases.
© Copyright 2020 WILMAR CORPORATION, P.O. Box 88259 Tukwila, WA 98138
