Performax 242-1452 User manual

2
541-242
traCgnidleW
Owner’s Manual
Weight Capacity
Weight Capacity
100 lbs
Overall Dim.
28″H x 27-3/4″D x 15-1/2″W
TM

Important Safety Information .…………………………………………………….
Assembly Instructions ……………………………………………………………..
Operation …………………………………………………………………………..
3
4
5
5
5
6
Parts List and Diagram ……………………………………………………………..
Warranty ……………………………………………………………………….………
TABLE
TABLE
TABLE
TABLE OF
OF
OF
OF CONTENTS
CONTENTS
CONTENTS
CONTENTS
2
Maintenance …………………………………………………………………………

3
Important Safety Information
Assembly Precautions
1.
Assemble only according to these
instructions. Improper
assembly
can
create hazards.
2.
Wear ANSI-approved safety
goggles
and heavy-duty
work
gloves
during assembly.
3.
Keep assembly area clean and well lit.
4.
Keep bystanders out of the
area during
assembly.
5.
Do not assemble when tired
or when under the influence
of drugs or medication.
6.
Weight capacity and other product
capabilities apply to properly and
completely assembled product only.
Use Precautions
1.
This product is not a toy. Never allow
children to play or come near this item.
2.
3.
Inspect before every use; do not use
if parts are loose or damaged.
4.
Do not exceed listed weight capacity,
evenly distributed and balanced.
Be aware of dynamic loading!
Sudden load movement may
briefly create excess load
causing product failure.
5.
Maintain product labels and
nameplates. These carry
important safety information.
6.
Operate and store the Cart on
a flat, dry, level surface.
7.
Read welding equipment
manual before use.
8.
If using gas cylinders, be especially
careful to prevent tipping or damage
to the cylinders. Follow gas cylinder
supplier’s and gas supplier’s
safety instructions at all times.
Only use as intended.

4
Assembly Instructions
Read the
ENTIRE
IMPORTANT SAFETY INFORMATION
section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
Note:
When attaching hardware, hand tighten only until the unit
When attaching hardware, hand tighten only until the unit
is
together,
then use the appropriate tools to tighten all hardware.
1.
Put a Wheel
(2) on the end of the
Axle
(9) and secure it with Washer
and Cotter Pin
(11). See
Figure
A.
Repeat on the other side.
Figure
A:
Wheel Attachment
2.
Using four Bolts, Washers, and
Nuts
(10), attach a Caster
(3)
to the Bottom Shelf
(1). See
Figure
B. Repeat on other side.
Figure
B:
Caster (3) Attachment
3.
Connect the bottom (note the hole
locations in the diagram) of the
Left
Support (7a) to the Bottom
Shelf
(1)
using Bolts, Washers, and Nuts
(10).
See
Figure
C. Repeat on other
side with Right Support
(7b).
Figure
C:
Connection of Bottom
Shelf
(1)
and Left Support (7a)
4.
Attach the Middle Shelf (5) to the Left
and Right Supports (7a,7b) using
Bolts, Washers, and Nuts
(10).
5.
Place a Hook
(8) over the holes on the
outside of the top of a Support
(7a/7b),
and place the Bolts (10) through both
the Hook
(8), Support (7a/7b), and the
Top Shelf (6). Secure with Washers
and Nuts
(10). Repeat on other side.
6.
Attach the Back Panel (4) to the
Bottom Shelf (1) using Bolts,
Washers, and Nuts
(10).
7.
Attach the Back
Panel
(4) to the Middle
Shelf
(5) and the Top Shelf
(6) using
Bolts, Washers, and Nuts
(10).
8.
Insert the Chains (13) through the
holes in the Back Panel (4).
9.
Wrench tighten all of the hardware.
7a
7b

5
Parts List and Diagram
Part
Description
Description
Qty
Qty
1
Bottom Shelf Asm.
1
2
Wheel
2
3
Swivel Caster
2
4
Back Panel
1
5
Middle Shelf
1
6
Top Shelf
1
7a
Left Support
1
Part
Description
Description
Qty
Qty
7b
Right Support (not shown)
Right Support (not shown)
1
8
Hook
2
9
Axle
1
10
Bolt, Washer, Nut (set) M6x12
Bolt, Washer, Nut (set) M6x12
33
11
Flat Washer, Cotter Pin (set)
Flat Washer, Cotter Pin (set)
2
12
Cap
2
13
Chain
2
a
Operation
1.
Make sure that the welder and all
accessories combined do not exceed
the weight capacity of this cart.
2.
Place any gas cylinders on the
back shelf, and secure in place with
both chains. Adjust chains’ length
to hold the cylinder(s) securely.
3.
Place the welder on the top
shelf and the other accessories
on the other shelves.
4.
Make sure everything is secure
and the cart is well balanced.
If
the
welder is unstable or does
not fit securely on the shelf, do not
use that welder with this cart.
Maintenance
1.
Periodically tighten all of the hardware.
2.
Make sure the casters and wheels
are free of all dirt, debris, or grease.

6
PERFORMAX
PERFORMAX
PERFORMAX
PERFORMAXTM
TM
TM
TM
TM
TM
TM
WARRANTY
WARRANTY
WARRANTY
WARRANTY
30-DAY
30-DAY
30-DAY
30-DAY MONEY
MONEY
MONEY
MONEY BACK
BACK
BACK
BACK GUARANTEE:
GUARANTEE:
GUARANTEE:
GUARANTEE:
This PERFORMAX brand welding cart carries our 30-Day Money Back
Guarantee. If you are not completely satisfied with your PERFORMAX brand
welding cart for any reason within thirty (30) days from the date of purchase,
return the welding cart with your original receipt to any MENARDS retail store,
and we will provide you a refund – no questions asked.
2-YEAR
2-YEAR
2-YEAR
2-YEAR LIMITED
LIMITED
LIMITED
LIMITED WARRANTY:
WARRANTY:
WARRANTY:
WARRANTY:
This PERFORMAX brand welding cart carries a 2-Year Limited Warranty to the
original purchaser. If, during normal use, this PERFORMAX welding cart breaks
or fails due to a defect in material or workmanship within two (2) years from the
date of original purchase, simply bring this welding cart with the original sales receipt
back to your nearest MENARDS®
®
retail store. At its discretion, PERFORMAX
agrees to have the welding cart or any defective part(s) repaired or replaced with
the same or similar PERFORMAX product or part free of charge, within the stated
warranty period, when returned by the original purchaser with original sales
receipt. Not withstanding the foregoing, this limited warranty does not cover any
damage that has resulted from abuse or misuse of the Merchandise. This
warranty: (1) excludes expendable parts ; (2) shall be void if this welding cart
isused for commercial and/or rental purposes; and (3) does not cover any losses,
injuries to persons/property or costs. This warranty does give you specific legal
rights and you may have other rights, which vary from state to state. Be careful,
welding carts are dangerous if improperly used or maintained. Seller’s employees
are not qualified to advise you on the use of this Merchandise. Any oral
representation(s) made will not be binding on seller or its employees. The rights
under this limited warranty are to the original purchaser of the Merchandise and
may not be transferred to any subsequent owner. This limited warranty is in lieu
of all warranties, expressed or implied including warranties or merchantability
and fitness for a particular purpose. Seller shall not be liable for any special,
incidental, or consequential damages. The sole exclusive remedy against the
seller will be for the replacement of any defects as provided herein, as long as
the seller is willing or able to replace this product or is willing to refund the
purchase price as provided above. For insurance purposes, seller is not allowed
to demonstrate any of these power tools for you.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free at: 1-866-915-8626 (M-F 9am-5pm EST)
SAVE
SAVE
SAVE
SAVE YOUR
YOUR
YOUR
YOUR RECEIPTS.
RECEIPTS.
RECEIPTS.
RECEIPTS. THIS
THIS
THIS
THIS WARRANTY
WARRANTY
WARRANTY
WARRANTY IS
IS
IS
IS VOID
VOID
VOID
VOID WITHOUT
WITHOUT
WITHOUT
WITHOUT THEM.
THEM.
THEM.
THEM.
