Peri UP Flex Staircase 100 with Deck UDG Assembly instructions

PERI UP Flex
Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to NASC SG4:15 – dition 01 | 2019

Amendment L g
Version Details Issue Date
0 First Issue Jan. 2019

Overview 1
Intr ducti n 3
Safety c nsiderati ns 4
Part A
Assembling and Dismantling
A1 Assembling the base 5
A2 Assembling the first level 7
A3 Assembling additional levels 10
A4 Assembling the top level 13
A5 Anchoring 15
A6 Dismantling 17
Applicati n
A7 Base reactions 20
Page
C ntent
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

Overview
1
Presentati nal reference:
The illustrations on the front cover of these instructions
are intended to be system representations only. The
assembly steps presented are examples using the
illustrated component sizes. They are also valid for
alternative component sizes.
Key
Pict gram │ Definiti n
Safety Instructions
Note
Visual check
Tip
Dimensi nal specificati ns
Dimensions are specified in mm. Other
units of measurement (cm) are used in
product descriptions.
C nventi ns
Instructions are numbered in
sequence: 1. 2. 3. etc.
Components are labelled with
numbers corresponding to the
overview drawing and are referenced
within the text in brackets thus (1).
Multiple component numbers
indicating alternatives are represented
with a slash: 1 / 2 etc.
Arr ws
Arrows represent an action
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

Overview
C mp nents:
1. Adjustable Base Plate UJB
2. Base Standard UVB 24
3a. Ledger UH 250, UH 250 Plus*
3b. Ledger UH 200, UH 200 Plus*
3c. Ledger UH 100, UH 100 Plus*
4. Ledger UH 125, UH 125 Plus* (for Stair Tower 125)
5. Standard UVR 300
5a. Standard UVR 200
6. Stair Stringer UA 250/100
7. Stair Step UAR 100
7a. Stair Step UAR 125 (for Stair Tower 125)
8. nd Step UA 100
*Ledger UH may be replaced by Ledger UH Plus
**Steel Deck UDG may be replaced by Industrial Deck UDI
8a. nd Step UA 125
9a. Industrial Deck UDG 25x100
9b. Industrial Deck UDG 25x200
9c. Industrial Deck UDG 25x125 (for Stair Tower 125)
9d. Industrial Deck UDG 25x250 (for Stair Tower 125)
10. Node Brace UBK 250/200
11a. Ledger Brace UBL 200/200
11b. Ledger Brace UBL 250/200 (for Stair Tower 125)
12a. H-Brace UBH Flex 250/100
12b. H-Brace UBH Flex 100/100
12c. H-Brace UBH Flex 250/125 (for Stair Tower 125)
12d. H-Brace UBH Flex 125/125 (for Stair Tower 125)
13. Toeboard UPY 100
14. Toeboard UPY 200
2
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15
12a
12b
5a
3a
5
3c
2
1
11
10
9a
9b
3b 67
3b
8

Intr ducti n
Intended use
Pr duct descripti n
These Instructions for Assembly and
Dismantling are supplementary to the
P RI UP Flex Staircase 100 and 125
with Deck UDG Assembly Instructions
for Standard Configuration. All notes
and data contained therein remain valid.
They describe the configuration for stair
towers as a means of access for
temporary work to be carried out on
working areas situated above ground
level.
The assembly and dismantling
sequences describe a short-lift system
of work in compliance with NASC
SG4:15 Preventing Falls in Scaffolding
Operations.
3
Presentati nal reference
The illustrations indicate the sequences for
one bay size option. They are valid for both
1.00m. and 1.25m. bay options.
Components highlighted in red indicate
temporary installed components removed
before completion of the tower.
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

Safety c nsiderati ns
4
Pers nal Pr tecti n
nsure persons are clipped to suitable
anchor point before moving on and off
temporary platforms.
For the scaffolds in this manual, safe
connection points are:
Any Rosette within a completed
scaffold lift.
Any Rosette up to 1m above a top
platform level.
Any Ledger connected between two
uprights within a completed scaffold
lift.
Any Ledger connected between two
uprights up to 1m above a top
platform level.
Inspecting the anch ring
All anchor connections to the supporting
structure should be tested in
accordance with NASC TG4:17
Anchoring Systems for Scaffolding.
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

Always begin erecting at the highest
point, preferably at an internal corner.
A1.1 L ad distributing base area
recting the scaffold must follow the
sequence described below!
Settlement must be av ided! The
scaff ld must nly be erected n
suitable distributi n plates n gr und
r structure capable f withstanding
all imp sed l ads!
Lay the Ledgers UH 250 (3a), Ledgers UH
200 (3b) and Ledgers UH 100 (3c) down to
determine the length of the surface to be
scaffolded. This will fix the distance between
the Adjustable Base Plates UJB (1)
A1.2 Adjustable Base Plates UJB
Position Adjustable Base Plates (1) at the
ends of the Ledgers UH 250 (3a), Ledgers
UH 200 (3b) & Ledgers UH 100 (3c).
UJB 38-80/55
Yellow handle
A – Assembly and Dismantling
A1 Assembling the base
UJB 38-50/30
Red handle
Fig.A1-2
Fig.A1-3
5
Fig.A1-1
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15
A1.3 Changes in base level
Steps, slopes and changes in level can be
accommodated using adjustment of the
Adjustable Base Plates / Base Spindles.
Base Spindles TR 38-70/50, without
coloured handles, may be used instead of
Adjustable Base Plates UJB (1). xtension
range = 47mm – 535mm to top of collar
handle.
Adjustable Base Plates UJB 38-50/30 with
red handles have a maximum extension of
355mm to top of collar handle. Adjustable
Base Plates UJB 38-80/55 with yellow
handles have a maximum extension of 595
mm. to top of collar handle. Check with
P RI for suitability of use.

A1.4 Base Standard UVB
Place Base Standards UVB 24 (2) over the
Adjustable Base Plates UJB (1) and
position at the required distance from the
wall. nsure all UVB Ø11 holes are aligned
in same direction.
2
1
A1.5 Ledger UH & Base Decks
Form a base frame by connecting the Base
Standard UVB 24 (2) with the Ledger UH
250 (3a), Ledger UH 200 (3b) and the
Ledger UH 100 (3c).
Two red Ledgers UH 250 (3a) are
Temporary, they will be removed later.
nsure all Ledgers UH are level by
adjusting the Adjustable Base Plates (1).
Place Steel Decks UDG 200 (9b) on the
Ledgers UH 100 (3c) as an assembly aid
to check squareness.
Four red Decks UDG 25x200 (9b) are
Temporary, they will be removed later.
Do not secure Ledger wedges at this stage
The decks used at the base are an aid to
erection only, they may be removed later.
Ø11
h le
A1 Assembling the base
Fig.A1-6
Fig.A1-4
Fig.A1-5
Fig.A1-8
6
Fig.A1-7
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

A2 Assembling the first level
A2.1 Vertical Standards UVR
P RI recommend using UVR 300 (5) at the
first level.
Attach UH Ledgers (3b, 3c) to the Rosette
on the Vertical Standards UVR (5), then
securely fix all wedges at UVB level using
a 500g hammer.
Place provisional Ledgers UH 100 (3c)
shown in red, they will be removed later.
A2.2 First level Ledgers UH
2
Ø11
h le
Ø11
h le
Fig.A2-1
Fig.A2-2
Other combinations of standards (e.g. UVR
200 inside with UVR 300 outside) are
structurally acceptable, but the customer
must ensure safe method of erection &
striking.
Fix UBK 250/200 (10) to the uppermost
Rosette of 2 No UVR 300 (5) shown as
pre-assembly.
Insert Vertical Standards UVR 300 (5) into
the Base Standards UVB (2) ensuring
alignment of the Ø11 holes.
7
Fig.A2-3
Fig.A2-2a
Pre-assembly
Fig.A2-2b
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

A2 Assembling the first level
A2.3 Sec nd level Ledgers UH and
guardrails
Place Steel Decks UDG 200 (9b) on
Ledgers 100 (3c).
Attach UH Ledgers (3b, 3c) to the Rosett
on the Vertical Standards UVR (5), then
securely fix all wedges at UVB level using
a 500g hammer.
Place provisional Ledgers UH 100 (3c)
shown in red, they will be removed later.
Fig.A2-4
8
A2.4 Stair Stringers & Decks
Fig.A2-5
Fig.A2-5b Fig.A2-5c
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15
Remove provisional red Ledger UH 250
(3a) and attach Stair Stringer UA (6) and
UH 200 (3b). (Fig A2-5)
Install Steel Deck UDG 100 (9a) onto stair
stringers UA.
Insert UBL 200/200 (11a) into the Ledgers
UH 200 (3b).
Wear a harness clipped to an approved
attachment point at all stages. From a
standing position on Decks D & C,
reposition Steel Decks UDG 200 (9b) A &
B up 1m on Ledgers 100 (3c). From a
seating position on Decks A & B, place
Deck C at the opposite end of the Ledger
100 (3c). Then from a standing position
insert Deck D.
Fig.A2-5a
ABC
D
9a
6
3b
A
DCB

A2 Assembling the first level
A2.5 Stairs Steps
Place first stair step UAR (7) with the riser
on the deck.
Move step forward to the pins on the
stringer. Rotate stair step towards the
stringer.
Position the second step (7) with the front
side on the first step. Push the step
forwards into the support of the Stair
Stringers UA (6). The upturned edges
engage in the slits. (Fig. A2.7b)
Turn the step upwards. The slits support
the upturned edges and connect both
steps. The top of the step rests against the
Stair Stringers UA. (Fig. A2.7c)
Repeat procedure up to the last step.
Lift the last step (7) slightly out of the
holder. Horizontally position nd Step UA
(8) on the last step (7). (Fig. A2.7d)
The upturned edges engage in the slits.
The nd Step UA (8) and the last step
are wedged together.
Pull back the nd Step UA (8) together
with the last step, and then swivel up. nd
Step UA (8) engages on the Ledger. Last
step engages in the Stair Stringers UA (6).
Last stair step is secured by tightening of
the bolts on the stringer (8).
Attach UBK 250/200 (10) as intermediate
guardrails and remove temporary Ledger
UH 100 (3c) above stairs.
First lift c mpleted.
A2.6 Guardrails
9
Fig.A2-8
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15
9a
6
7
Fig.A2-7a
Fig.A2-7b Fig.A2-7c
Fig.A2-7
Fig.A2-7d
78
6
3c

A3 Assembling additional levels
A3.1 Vertical Standards UVR
P RI recommend using UVR 200 (5a) at
the additional levels.
Other combinations of standards (e.g. UVR
200 inside with UVR 300 outside) are
structurally acceptable, but the customer
must ensure safe method of erection &
striking.
Fix UBK 250/200 (10) to the uppermost
Rosette of 2 No UVR 200 (5a) shown as
pre-assembly.
Insert Vertical Standards UVR 200 (5a)
into the lower Standards UVR ensuring
alignment of the Ø11 holes.
10
A3.2 First level Ledgers UH and UBH
Fig.A3-2
All additional levels, except for the top level
repeat the following steps.
Fig.A3-1
Pre-assembly
Fig.A3-2a
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15
Fig.A3-2b
Attach UH Ledgers (3b, 3c) to the Rosett
on the Vertical Standards UVR (5), then
securely fix all wedges at UVB level using
a 500g hammer.
Place provisional Ledgers UH 100 (3c)
shown in red, it will be removed later.
Place Horizontal Brace UBH 250/200
(12a):
Attach hook in the round hole of the
rosette. (Fig. A3.2a)
On the opposite side of the Horizontal
Brace, unlock the lock and pull back the
slider. Attach the hook from below.
When pushing the slider forward, the
securing device drops down and holds the
Horizontal Brace UBH. (Fig. A3.2b)

A3 Assembling additional levels
A3.3 Sec nd level Ledgers UH and
guardrails
Place Steel Decks UDG 200 (9b) on
Ledgers 100 (3c).
Attach UH Ledgers (3b, 3c) to the Rosette
on the Vertical Standards UVR (5), then
securely fix all wedges at UVB level using
a 500g hammer.
Place provisional Ledgers UH 100 (3c)
shown in red, they will be removed later.
Attach Horizontal Braces UBH 100/100
(12b) before next stage.
A3.4 H-Braces UBH
11
Fig.A3-4
Fig.A3-3
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

A3 Assembling additional levels
A3.5 Decks level
Reposition Steel Decks UDG 300 (9b) to
position shown over UBH 100/100 (12b).
Attach Stair Stringer UA (6) and UH 200
(3b). (Fig A3-7)
Install industrial deck UDG 100 (9a) onto
stair stringers UA.
Assemble Stair Steps repeating the
detailed sequence in section A2.5
A3.7 Guardrails
Attach UBK 250/200 (10) as intermediate
guardrails and remove temporary Ledger
UH 100 (3c) above stairs.
Additi nal lift c mpleted.
Repeat steps as required according to
tower height.
A3.6 Stair Stringers. Steps and St p
Fig.A3-7
Fig.A3-6
12
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

A4 Assembling the top level
A4.1 Vertical Standards UVR & Ledgers
Fix UBK 250/200 (10) to the uppermost
Rosette of 2 No UVR 200 (5a) shown as
pre-assembly.
Insert Vertical Standards UVR 200 (5a)
into the lower Standards UVR ensuring
alignment of the Ø11 holes.
Attach UH Ledgers (3b, 3c) to the Rosette
on the Vertical Standards UVR (5a), then
securely fix all wedges at UVB level using
a 500g hammer.
Place provisional Ledger UH 100 (3c)
shown in red, it will be removed later.
13
Fig.A4-1
Fig.A4-2
A4.2 Guardrail
Move Steel Decks UDG 200 (9b) on
Ledgers 100 (3c).
Attach UH Ledgers (3b, 3c) to the Rosett
on the Vertical Standards UVR (5), then
securely fix all wedges at UVB level using
a 500g hammer.
Place UBL 200/200 (11a).
Pre-assembly
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

A4 Assembling the top level
A4.3 Decks level
Reposition Steel Decks UDG 200 (9b) to
position shown.
Attach Stair Stringer UA (6) and UH 200
(3b). (Fig A4-4)
Install industrial deck UDG 100 (9a) onto
stair stringers UA.
Assemble Stair Steps repeating the
detailed sequence in section A2.5
A3.7 Guardrails
Attach UBK 250/200 (10) as intermediate
guardrails and remove temporary Ledger
UH 100 (3c) above stairs.
T p lift c mpleted.
Install Toeboards UPY 200 (14) and
Toeboards UPY 100 (13) to all platforms if
required
A4.4 Stair Stringers. Steps and St p
Fig.A4-4
Fig.A4-3
14
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15
9a
3b
6
10
13
14

A5 Anchoring
15
Anch rs are n t designed t carry
vertical l ads!
- Anchors should be installed
progressively along with the erection of
the scaffolding.
- Fix with suitable fixings in accordance
with NASC TG4:17.
- The load-bearing capacity of the
connecting components between the
Wall Ties and anchoring base must be
verified by the contractor.
- Install the first row of anchors at a
height of 8.0 m. The position of the
other anchors is given in P RI UP Flex
Staircase 100 and 125 with Deck UDG
Assembly Instructions for Standard
Configuration.
- Install anchors only in the levels which
have been braced with Horizontal
Braces..
A5.1Triangulated anch rs
For shorter wall spacing, both corner
standards must be connected with
triangular anchors at 45°.
Fix the Standard Couplers (16) to the
Corner Standards with Wall Ties UWT 45
or scaffold tube (15). (Fig.A5-1a)
Fix Wall Ties or scaffold tubes to the wall.
Fig.A5-1
Fig.A5-2
Fig.A5-1a
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

A5 Anchoring
A5.3 Single Wall Ties with bracing
For large wall spacing up to max. 200 cm,
single Wall Ties and crossed diagonals are
to be used.
Fix Wall Ties, UWT 140 or scaffold tube
(15a), to the Corner Standards using
Standard Couplers (16).
Fix Wall Ties UWT 140 or scaffold tube to
the wall
Fix Scaffold Tubes (18) to the Wall Ties
UWT 140 or scaffold tube using Swivel
Couplings (17). (Fig. A5-3a and Fig. A5-4)
At the intersection point of the diagonal
Scaffold Tubes, use Swivel Couplers to
connect both Scaffold Tubes.
(Fig. A5-3 and Fig. A5-4)
Fig.A5-3
16
Fig.A5-4
Fig.A5-3a
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15

A6 Dismantling
17
A6.2 T p level
Fig.A6-1
Remove all toeboards UPY 100 (13) and
UPY 200 (14).
Attach Ledger UH 100 (3c1) as guardrail at
top of stairs and from within the UBK
Guardrails (10) remove the nd Step UA
(8) and progressively remove the Stair
Steps UAR (7) and lower Deck UDG (9a).
Attach Ledger UH 100 (3c2) as guardrail at
bottom of stairs
Remove intermediate level UBK 250/200
(10).
Attach Ledger UH 100 (3c) as guardrail at
bottom of stairs
Progressively move down by 1m Steel
Decks UDG 200 (9b) on to Ledgers 100
(3c). In a reverse to the assembly
sequence described in section A2.4.
Remove highlighted Ledgers UH 200 (3b)
and UH 100 (3c). (Fig.A6-2).
Progressively move down by 1m Steel
Decks UDG 200 (9b) on to Ledgers 100
(3c) once more.
Remove Ledgers UH 250 (3a), UH 200
(3b) and UH 100 (3c).
Remove UVR 200 (5a) and UBK 250/200
(10). (Fig.A6-3)
T p lift rem ved
Fig.A6-2
Fig.A6-3
A6.1 Anch rs
- Remove the anchors progressively with
the staircase from top to bottom.
- In the event of work disruptions, the top
level must not be extended more than
3.0m. beyond the last anchor position.
Dismantle in reverse order from top to
bottom as shown in the assembly procedure.
PERI UP Flex Staircase 100 and 125 with Deck UDG
Instructions for Assembly and Dismantling – Short lift system to SG4:15
3c1
3c2
