FORM NO. Z2517
REV. D-10/03/2018
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKERS
To prevent appliance damage and injury, read these instrucons
thoroughly prior to installaon.
H50IMS/-AD
PRODUCT MANUAL
H50IMS
H50IMS-AD
15” SIGNATURE SERIES CLEAR ICE MAKER
15” ADA COMPLIANT CLEAR ICE MAKER

2| perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
TABLE OF CONTENTS
INTRODUCTION
Congratulaons on your purchase of a Perlick Residenal
undercounter appliance. This manual has been prepared to
assist you in the installaon of your undercounter ice maker.
We dedicate considerable me to ensure that our products
provide the highest level of customer sasfacon. We thank
you for selecng Perlick products for your home and assure you
of our connuing interest in your sasfacon.
CONTENTS
3 Safety Consideraons
4 Construcon
5 Electrical / Refrigerant
6 Niche / Product Dimensions / Connecons
10 Prior To Installaon
11 Installaon Instrucons
18 Setup
18 Electrical Connecon
19 Water Supply And Drain Connecons
20 Final Checklist
20 Startup
21 Maintenance
26 Preparing The Appliance For Periods Of Non-Use
27 Warranty Informaon

perlick customer service [phone] | 3
PERLICK RESIDENTIAL ICE MAKER MANUAL
SAFETY CONSIDERATIONS
DANGER
!
IMPORTANT SAFETY INFORMATION
This manual should be read carefully before the ice maker
is installed and operated. Only qualied service technicians
should install, service, and maintain the ice maker. Read the
warnings contained in this booklet carefully as they give
important informaon regarding safety. Please retain this
booklet for any further reference that may be necessary.
DAN This indicates that a hazardous situaon
may occur when instrucons are not followed. It is
imperave that direcons in this guide are followed to
prevent possible serious injury or death.
This indicates a situaon where minor
injury, product or cabinet damage may occur if the following
instrucons are not followed.
This highlights informaon that is of
signicant importance.
WARNING
DANGER
!
CAUTION
This ice maker should be desned only to
the use for which it has been expressly conceived. Any other
use should be considered improper and therefore dangerous.
The manufacturer cannot be held responsible for eventual
damage caused by improper, incorrect, and unreasonable
use. To reduce the risk of death, electric shock, serious injury,
or re, follow basic precauons including the following:
▪This unit requires an independent power supply. See the
nameplate for proper voltage and breaker/fuse size. Failure
to use a proper breaker or fuse can result in a tripped
breaker, blown fuse, or damage to exisng wiring. This
could lead to heat generaon or re.
▪THIS APPLIANCE MUST BE GROUNDED: This unit is
equipped with a 3-prong grounding plug to reduce the
risk of potenal shock hazards. It must be plugged into a
properly grounded, independent wall outlet. If the outlet is
a 2-prong outlet, it is your personal responsibility to have
a qualied electrician replace it with a properly grounded,
independent 3-prong wall outlet. Do not remove the
ground prong from the power cord and do not use an
adapter plug.
▪Do not use an extension cord.
▪Make sure the control switch is in the “OFF” posion
before plugging in or unplugging the unit to reduce the risk
of electric shock.
▪Do not use a unit with a damaged power cord. The power
cord should not be altered, jerked, bundled, weighed
down, pinched, or tangled. Such acons could result in
electric shock or re. To unplug the unit, be sure to pull the
plug, not the cord, and do not jerk the cord.
▪To reduce the risk of electric shock, do not touch the plug
or control switch with damp hands.
▪This unit should be disassembled or repaired only by
qualied service personnel to reduce the risk of electric
shock, injury, or re.
▪Do not make any alteraons to the unit. Alteraons could
result in electric shock, injury, re, or damage to the unit.

4| perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
CONSTRUCTION
Top Panel
Ice Making
Mechanism
Scoop Holder
Slope
Front Panel
Control Switch
Power Cord
Louver
Magnet
Catch
Door
Bin Control
Thermostat
Bulb

perlick customer service [phone] | 5
PERLICK RESIDENTIAL ICE MAKER MANUAL
ELECTRICAL / REFRIGERANT
The nameplate provides electrical and refrigerant data. The
nameplate is located inside the storage bin. For cercaon
marks, see the nameplate.
We reserve the right to make changes in specicaons and
design without prior noce.
Model Number H50IMS-R
Electrical Supply 115-120V, 60 Hz., Phase 1
Service 3.4 amp circuit
Power/Cord Type/ Length NEMA 5-15P w/6’ power cord
Design Pressure HI-240PSI LO-120PSI
Refrigerant 134a 4.2 OZ.

6| perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
NICHE / PRODUCT DIMENSIONS / CONNECTIONS

perlick customer service [phone] | 7
PERLICK RESIDENTIAL ICE MAKER MANUAL
NICHE / PRODUCT DIMENSIONS / CONNECTIONS

8| perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
NICHE / PRODUCT DIMENSIONS / CONNECTIONS

perlick customer service [phone] | 9
PERLICK RESIDENTIAL ICE MAKER MANUAL
NICHE / PRODUCT DIMENSIONS / CONNECTIONS

10 | perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
PRIOR TO INSTALLATION
The appliance must be installed in
accordance with applicable naonal, state, and local codes
and regulaons.
CHOKING HAZARD: Ensure all components,
fasteners, and thumbscrews are securely in place aer
installaon. Make sure that none have fallen into the storage
bin.
A. Checks Before Installaon
Visually inspect the exterior of the shipping container
and immediately report any damage to the carrier. Upon
opening the container, any concealed damage should also be
immediately reported to the carrier.
Remove the shipping carton, tape, and packing material. If any
are le in the appliance, it will not work properly.
Remove the package containing the accessories.
Remove the protecve plasc lm from the panels. If the
appliance is exposed to the sun or to heat, remove the lm
aer the appliance cools.
See the nameplate inside the storage bin, and check that your
voltage supplied corresponds with the voltage specied on the
nameplate.
B. Locaon
General
The appliance is approved for indoor or outdoor use.
Normal operang ambient temperature
must be within 45°F to 100°F (7°C to 38°C); Normal operang
water temperature must be within 45°F to 95°F (7°C to 35°C).
Operaon of the appliance, for extended periods, outside
of these normal temperature ranges may aect appliance
performance.
The appliance will not work at sub-freezing
temperatures. To prevent damage to the water supply line,
drain the appliance if the air temperature is going to go below
32°F (0°C). See “V. Preparing the Appliance for Periods of
Non-Use.”
The appliance should not be located next to ovens, grills, or
other high heat producing equipment.
The locaon must provide a rm and level foundaon for the
appliance.
DANGER
!
DANGER
!
The appliance requires no side or top clearance. But allow
enough space at rear for water supply and drain connecons
and at least 15” (38 cm) clearance at front.
The appliance must be at oor level on a nished oor even
if under a cabinet. In areas where water damage is a concern,
install in a contained area with a oor drain.
Do not let the weight of the counter rest on
the appliance.
Do not install the appliance in a corner where
the door will interfere with other equipment or where the
appliance cannot be pulled out for service.
WARNING
WARNING
WARNING
WARNING

perlick customer service [phone] | 11
PERLICK RESIDENTIAL ICE MAKER MANUAL
INSTALLATION INSTRUCTIONS
H50IMS-R/L
H50IMW
Min. 34"
(864 mm)
H50IMS-ADR/ADL
H50IMW-AD
Min. 32"
(814 mm)
Min. 15"
(381 mm)
Between Two Cabinets Between a Cabinet and
the End of a Counter
Support: Do not
let the weight of
the counter rest
on the appliance
Min. 15"
(381 mm)
H50IMS-R/L
H50IMW
Min. 34"
(864 mm)
H50IMS-ADR/ADL
H50IMW-AD
Min. 32"
(814 mm)
Min. 23"
(584 mm)
Oven Appliance
Between a Cabinet and
a Wall or Tall Cabinet
In a Corner
Secure: Do not let
the weight of the
counter rest on
the icemaker
Installaon Space
Model Height Width Depth
H50IMS-R/L
H50IMW 34" (864 mm) minimum
15" (381 mm) minimum 24" (610 mm) minimum
H50IMS-ADR/ADL
H50IMW-AD 32" (814 mm) minimum
105° minimum door swing for
convenient access to ice bin
4-7/8” minimum distance from corner to
achieve desired door opening clearance

12 | perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
INSTALLATION INSTRUCTIONS
2. H50IMW, H50IMW-AD
OVERLAY PANEL FABRICATION AND
ATTACHMENT
The overlay panel must be craed by a
professional cabinet maker to ensure quality results.
PARTS
Ensure that all parts required for the overlay panel
assembly are contained in the accessories bag.
CAUTION
Overlay Panel Parts
No. Descripon Part Number Qty.
1 Threaded Wood Insert 4A4004-01 6
2 T2 Screw 4×8 SS 7P32-0408 3
3 Pan Head Screw M4×25 SS 7C12-0425 4
4 Truss Head Screw M4×8 SS 7C32-0408 2
5 Canoe Clip 4A5835-01 2
6 Sheet Metal Bracket 4A3998-01 1
1 2 3 4 5
6
OVERLAY PANEL SPECIFICATION
Use the specicaon that applies to your appliance
(H80CIMW or H80CIMW-AD) and the direcons that
follow to prepare your overlay panel.
()()
()
()()()
()
()
()
()
H50IMW Overlay Panel Specicaon
Panel Height 29 17/32" (750 mm)
Panel Width 14 13/16" (376 mm)
Panel Thickness 5/8" (16 mm) min;
3/4" (19 mm) max
Panel and Door Weight (total) 20 lb. (9 kg) max
H50IMW

perlick customer service [phone] | 13
PERLICK RESIDENTIAL ICE MAKER MANUAL
INSTALLATION INSTRUCTIONS
H50IMW-AD Overlay Panel Specicaon
Panel Height 27 9/16" (700 mm)
Panel Width 14 13/16" (376 mm)
Panel Thickness 5/8" (16 mm) min;
3/4" (19 mm) max
Panel and Door Weight (total) 20 lb. (9 kg) max
()()
()
()()()
()
()
()
()
H50IMW-AD FABRICATION OF OVERLAY PANEL
Fabricate the overlay panel as outlined in the specicaon on
the previous page and the instrucons below.
1. Rout a channel at the boom of the overlay panel
to the proper dimensions. See “(C) Routed Area” in the
specicaon diagram and Fig. 1.
2. Drill six 1/4” diameter (hardwood may require slightly
larger diameter) holes 3/8” (10 mm) deep in the
locaons designated.
Use care when drilling holes for mounng
hardware. All drilled holes must be straight and drilled to the
correct diameter and depth.
See “(A) Threaded Inserts” and “(B) Threaded Inserts” in
the specicaon diagram and Fig. 2.
WARNING
Routed Channel
Fig. 1
Fig. 2
Holes Holes

14 | perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
3. Screw the 6 threaded wood inserts into the 1/4” holes
drilled in the previous step. Make sure that the inserts
are threaded straight and that the tops of the inserts
are ush to the overlay panel surface. Otherwise, the
overlay panel cannot be properly fastened to the door.
4. Mount the door handle hardware. Perlick recommends
that the door handle hardware be mounted on the
edge opposite of the door hinge side (oponal hinge
reversal is covered in step 6. Countersunk screw heads
are required to ensure that the hardware fasteners do
not interfere with the overlay panel ng ush with
the door.
5. While maintaining a hold on the door, remove the
hinge stop pin from hinge (B). Pull out the boom of
the door slightly and gently remove the door from
hinge (A) (See Fig. 3). If you are leaving the door right
hinged, skip to step 7. If you would like to reverse the
door hinges, proceed to step 6.
Fig. 3
Hinge Stop Pin
Hinge (B)
Hinge (A)
INSTALLATION INSTRUCTIONS
6. Remove hinge (A)-le from the accessory bag. Remove the
2 screws securing the top panel, then li it o. (See Fig. 4).
7. Remove hinge (A)-right and the bracket from the right
side of the unit. Set aside hinge (A)-right; it is not needed.
Remove the top brace from the le side. Fasten hinge (A)-
le and the bracket to the le side and the top brace to
the right side. See Fig. 5. Note: When on the proper side,
the gasket notch for hinge (A) is to the inside.
Hinge (A)-Right
Not Needed
Hinge (B)
Screws
Filler
Screws
Fig. 6
Fig. 4
Top Panel
Screws
Fig. 5
Gasket Notch
Bracket
Screw
Hinge (A) Le
8. Remove hinge (B) from the right side of the unit and the 2
ller screws from the le side. Aach the 2 ller screws to
the right side and aach hinge (B) to the le side.
(See Fig. 6).
Screw
Top Brace

perlick customer service [phone] | 15
PERLICK RESIDENTIAL ICE MAKER MANUAL
INSTALLATION INSTRUCTIONS
Fig. 7
Top Panel
Notch
Fig. 8 Screws
Hinge (C2)
Hinge (C1)
Screws
9. Rotate the top panel 180° from its previous posion. This
brings the notch that was previously in the right rear to
the le front. See Fig. 7. Hook the rear part of the panel
on the body, then secure the front with the 2 screws
removed in step 6a.
10. Remove hinge (C1) from the top right part of the door, ip
it and reaach to the boom le. Remove hinge (C2) from
the boom right part of the door, ip it and reaach to
the top le. See Fig. 8.
11. Remove the bushings from hinge (C1) and hinge (C2)
(the hinges aached to the door). See Fig. 9.
12. Remove the gasket from the door. See Fig. 10.
Fig. 11
Fig. 10
13. Temporarily fasten the overlay panel to the overlay
panel to the door using 2 of the M4x25 pan head screws
provided. See Fig. 11.
Fig. 9
Hinge
Bushing
Gasket
Screws

16 | perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
INSTALLATION INSTRUCTIONS
Fig. 12
14. Mark the center point of the hinge (C1) and hinge (C2)
holes that extend over the overlay panel. See Fig. 12.
15. Remove the overlay panel from the door.
16. Drill 3/8” diameter holes 1/4” (7 mm) deep where you
marked on the overlay panel to accomodate the hinge
(C1) and hinge (C2) bushings.
Ensure that the back surface of overlay panel
is at before aaching.
WARNING
Mark the center point.
Hinge
ATTACHMENT OF OVERLAY PANEL TO
DOOR
1. Fasten the sheet metal bracket to the overlay panel
using the two M4×8 truss head screws provided. Snug
the screws, but do not ghten (See Fig. 13).
2. Temporarily fasten the overlay panel to the door using
2 of the M4×25 pan head screws provided (See Fig. 14).
Screws
Fig. 14
Fig. 13
Sheet Metal Bracket
Overlay Panel
Snug the screws,
but do not ghten.

perlick customer service [phone] | 17
PERLICK RESIDENTIAL ICE MAKER MANUAL
INSTALLATION INSTRUCTIONS
3. Adjust the sheet metal bracket so that it is ush with
the boom of the door (See Fig. 15).
4. Remove the overlay panel from the door and ghten
the two M4×8 truss head screws securing the sheet
metal bracket to the overlay panel (See Fig. 16).
Door
Sheet Metal Bracket
Fig. 15
Sheet Metal Bracket
Overlay Panel
Tighten the screws.
Fig. 16
5. Fasten the overlay panel to the door using the four
M4×25 pan head screws provided. Snug the screws,
but do not ghten (See Fig. 17).
6. Fasten the sheet metal bracket to the boom of the
door with the three T2 screws provided. Tighten the
screws to the door (See Fig. 18).
Snug the screws,
but do not ghten.
Fig. 17
Sheet Metal Bracket
Screws
Overlay Panel
Door
Fig. 18
7. Tighten the four M4×25 pan head screws installed in
step 5 (See Fig. 19).
Fig. 19
Tighten the screws.

18 | perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
INSTALLATION INSTRUCTIONS / SETUP / ELECTRICAL CONNECTION
8. Replace the door gasket in its proper orientaon.
Reinsert the bushings into hinge (C1) and hinge (C2)
(the hinges aached to the door) (See Fig. 20).
Bushing
Bushing
Gasket
Fig. 20
9. Aach the door to hinge (A), then connue to maintain
a hold on the door. Screw the hinge stop pin into hinge
(B) unl it is ght (See Fig. 21).
10. Insert the 2 canoe clips included in the accessory bag
into the holes on top of the door (See Fig. 22).
Hinge Stop Pin
Hinge (B)
Fig. 21
Canoe Clips
Fig. 22
SETUP
1. Posion the appliance in the selected permanent
locaon.
2. Level the appliance from side-to-side and front-to-rear
by adjusng the feet.
ELECTRICAL CONNECTION
Electrical connecon must meet naonal,
state, and local electrical code requirements. Failure to meet
these code requirements could result in death, electric shock,
serious injury, re, or damage.
The appliance requires an independent
power supply of proper capacity. See the nameplate for
electrical specicaons. Failure to use an independent power
supply of proper capacity can result in a tripped breaker,
blown fuse, damage to exisng wiring, or component failure.
This could lead to heat generaon or re.
THE APPLIANCE MUST BE GROUNDED:
The appliance is equipped with a NEMA 5-15 three-prong
grounding plug to reduce the risk of potenal shock hazards.
It must be plugged into a properly grounded, independent
3-prong wall outlet. If the outlet is a 2-prong outlet, it is your
personal responsibility to have a qualied electrician replace
it with a properly grounded, independent 3-prong wall outlet.
Do not remove the ground prong from the power cord and
do not use an adapter plug. Failure to properly ground the
appliance could result in death or serious injury.
Do not use an extension cord.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands. Make sure
the control switch is in the “OFF” posion before plugging in
or unplugging the appliance.
Do not use an appliance with a damaged
power cord. The power cord should not be altered, jerked,
bundled, weighed down, pinched, or tangled. Such acons
could result in electric shock or re. To unplug the appliance,
be sure to pull the plug, not the cord, and do not jerk the
cord.
The GREEN ground wire in the factory-
installed power cord is connected to the appliance. If it
becomes necessary to remove or replace the power cord, be
sure to connect the power cord’s ground wire to this screw
upon reaachment.
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!

perlick customer service [phone] | 19
PERLICK RESIDENTIAL ICE MAKER MANUAL
WATER SUPPLY AND DRAIN CONNECTIONS
A plumbing permit and services of a licensed plumber may be
required in some areas.
A water supply line shut-o valve and drain valve must be
installed.
Be sure there is sucient extra water supply line and drain line
for the appliance to be pulled out for service.
Drain line should not be piped directly to the sewer system.
Water line installaon to the appliance is not
warranted by Perlick.
Water-hammer issues must be resolved
by a qualied plumber before installing the appliance. Water
hammer can cause appliance damage that may lead to water
leakage or ooding.
A minimum of 1/2” nominal ID hard pipe
or equivalent is required for the drain line. Installing a smaller
diameter drain line will reduce water ow and may lead to
water leakage or ooding.
If using the oponal drain pump (63802A),
test its operaon every me the appliance is cleaned and
sanized. See “IV.E. Oponal Drain Pump 63802A” for details. If
the oponal drain pump is not operang properly, water could
back up and overow, leading to costly water damage.
Usually an electrical permit and services of a licensed electrician
are required.
The maximum allowable voltage variaon is ±10 percent of the
nameplate rang.
For oponal drain pump (63802A) installaon, refer to the
instrucons included with the pump.
WATER SUPPLY AND DRAIN
CONNECTIONS
Water supply and drain connecons must
be installed in accordance with applicable naonal, state, and
local regulaons.
Normal operang water temperature must be
within 45°F to 95°F (7°C to 35°C). Operaon of the appliance,
for extended periods, outside of this normal temperature range
may aect appliance performance.
Water supply pressure must be a minimum
of 10 PSIG and a maximum of 113 PSIG. If the pressure exceeds
113 PSIG, the use of a pressure reducing valve is required.
External lters, strainers, or soeners may be
required depending on water quality. Contact your local Perlick
Cered Service Representave or local Perlick distributor for
recommendaons.
Connect to potable water supply only. Do not
connect to a hot-water supply.
In areas where water damage is a concern,
install in a contained area with a oor drain.
WARNING
DANGER
!
WARNING
WARNING
WARNING
WARNING
Water Supply Inlet Minimum Water Supply Line Size Drain Outlet Minimum Drain Line Size
1/2" Female Pipe Thread (FPT) 1/4" Nominal ID Copper
Water Tubing or Equivalent
1/2" Female Pipe Thread (FPT) 1/2" Nominal ID
Hard Pipe or Equivalent
WARNING
WARNING
WARNING
WARNING
Fig. 23
Piping to approved drain. Leave a 2-inch (5-cm)
vercal air gap between the end of the pipe and
the drain.
2-inch (5-cm)
air gap
Floor
Drain
Shut-O Valve
Drain Valve
Water Supply Inlet
1/2" FPT
Drain Outlet
1/2" FPT
Vented Tee Connecon
Be sure there is sucient extra water supply line
and drain line for the appliance to be pulled out
for service.

20 | perlick.com/residential
PERLICK RESIDENTIAL ICE MAKER MANUAL
WATER SUPPLY AND DRAIN CONNECTIONS / FINAL CHECKLIST / STARTUP
An air gap of a minimum of 2 vercal inches (5 cm) must be
between the end of the drain pipe from the appliance and the
oor drain.
For gravity drain installaon, drain must have 1/4” fall per foot
(2 cm per 1 m) on horizontal runs to get good ow. A vented
tee connecon is also required for proper ow. Extend the vent
at least 12” (30 cm) above the drain outlet. For oponal drain
pump (63802A) installaon, refer to the instrucons included
with the pump.
FINAL CHECKLIST
CHOKING HAZARD: Ensure all components,
fasteners, and thumbscrews are securely in place aer
installaon. Make sure that none have fallen into the
storage bin.
1. Is the appliance level?
2. Is the appliance in a site where the ambient temperature
is within 45°F to 100°F (7°C to 38°C) and the water
temperature within 45°F to 95°F (7°C to 35°C) all year
around?
3. Have the shipping carton, tape, and packing material been
removed from the appliance? Has the protecve plasc
lm been removed from the panels?
4. Have all electrical and water connecons been made? Do
electrical and water connecons meet all naonal, state,
and local code and regulaon requirements?
5. Has the power supply voltage been checked or tested
against the nameplate rang? Is the power supply a
properly grounded, independent 3-prong wall outlet?
6. Are the water supply and drain lines sized as specied?
Are the water supply line shut-o valve and drain valve
installed? Has the water supply pressure been checked to
ensure a minimum of 10 PSIG and a maximum of 113 PSIG?
7. Are all components, fasteners, and thumbscrews securely
in place?
8. Has the end user been given this instrucon manual,
and instructed on how to operate the appliance and the
importance of the recommended periodic maintenance?
9. Has the end user been given the name and telephone
number of an authorized service agent?
10. Has the warranty tag been lled out and forwarded to the
factory for warranty registraon?
DANGER
!
STARTUP
All parts are factory-adjusted. Improper
adjustments may adversely aect safety, performance,
component life, and warranty coverage.
If the appliance is turned o, wait for at least
3 minutes before restarng the appliance to prevent damage to
the compressor.
At startup, conrm that all internal and
external connecons are free of leaks.
1. Open the water supply line shut-o valve.
2. Make sure the control switch is in the “OFF” posion. Plug
the appliance into the electrical outlet.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands. If you
have to slide the appliance back for a built-in installaon,
make sure you do not damage or pinch the water supply line,
drain line, or power cord.
3. If required by sanitaon code in your area, seal the
perimeter where the appliance touches the oor with
approved caulk compound in a smooth and easily cleanable
manner.
4. Move the control switch to the “ICE” posion to start the
automac ice making process.
5. Once the appliance starts to produce ice, allow it to run for
another 30 minutes.
6. Move the control switch to the “OFF” posion.
DANGER
!
WARNING
WARNING
DANGER
!
