Perlick H80CIM SERIES User manual

FORM NO. Z2547
REV. A-05/01/2018
PERLICK RESIDENTIAL UNDERCOUNTER ICE MAKERS
To prevent appliance damage and injury, read these instrucons
thoroughly prior to installaon.
H80CIM/-AD
PRODUCT MANUAL
H80CIM* 15” SIGNATURE SERIES CUBELET ICE MAKER
H80CIM*-AD 15” ADA COMPLIANT CUBELET ICE MAKER
1A5237-01

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
2| perlick.com/residential
INTRODUCTION
Congratulaons on your purchase of a Perlick Residenal
undercounter appliance. This manual has been prepared to
assist you in the installaon of your undercounter ice maker.
We dedicate considerable me to ensure that our products
provide the highest level of customer sasfacon. We thank
you for selecng Perlick products for your home and assure you
of our connuing interest in your sasfacon.
WARRANTY REGISTRATION
To register your Perlick product, visit our website at
www.perlick.com/RegisterMyPerlick and ll out the form.
Once completed, click on the ‘Submit Warranty Registraon’. Be
sure to register your product immediately upon installaon to
receive the warranty from installaon date instead of shipment
date. If le blank, the date will revert back to shipment date.
CONTENTS
3 Safety Consideraons
5 Prior To Installaon
6 Niche / Product Dimensions / Connecons
10 Construcon
11 Electrical / Refrigerant
12 Installaon Instrucons
20 Setup
21 Electrical Connecon
22 Water Supply And Drain Connecons
23 Final Checklist
24 Operang Instrucons
25 Startup
26 Maintenance
32 Preparing The Appliance For Periods Of Non-Use
33 Disposal

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 3
DANGER
!
SAFETY CONSIDERATIONS
IMPORTANT SAFETY INFORMATION
This manual should be read carefully before the ice maker
is installed and operated. Only qualied service technicians
should install, service, and maintain the ice maker. Read the
warnings contained in this booklet carefully as they give
important informaon regarding safety. Please retain this
booklet for any further reference that may be necessary.
DAN This indicates that a hazardous situaon
may occur when instrucons are not followed. It is imperive
that direcons in this guide are followed to prevent possible
serious injury or death.
This indicates a situaon where minor
injury, product or cabinet damage may occur if the following
instrucons are not followed.
This highlights informaon that is of
signicant importance.
WARNING
DANGER
!
CAUTION
This ice maker should be desned only to
the use for which it has been expressly conceived. Any other
use should be considered improper and therefore dangerous.
The manufacturer cannot be held responsible for eventual
damage caused by improper, incorrect, and unreasonable
use. To reduce the risk of death, electric shock, serious injury,
or re, follow basic precauons including the following:
Only qualied service technicians should
install and service the appliance.
The appliance must be installed in
accordance with applicable naonal, state, and local codes
and regulaons.
The appliance requires an independent
power supply of proper capacity. See the nameplate for
electrical specicaons. Failure to use an independent power
supply of proper capacity can result in a tripped breaker,
blown fuse, damage to exisng wiring, or component failure.
This could lead to heat generaon or re.
THE APPLIANCE MUST BE GROUNDED:
The appliance is equipped with a NEMA 5-15 three-prong
grounding plug to reduce the risk of potenal shock hazards.
It must be plugged into a properly grounded, independent
3-prong wall outlet. If the outlet is a 2-prong outlet, it is your
personal responsibility to have a qualied electrician replace
it with a properly grounded, independent 3-prong wall outlet.
Do not remove the ground prong from the power cord and
do not use an adapter plug. Failure to properly ground the
appliance could result in death or serious injury.
Do not use an extension cord.
To reduce the risk of electric shock, do not
touch the control switch or plug with damp hands. Make sure
the control switch is in the “OFF” posion before plugging in
or unplugging the appliance.
Do not use an appliance with a damaged
power cord. The power cord should not be altered, jerked,
bundled, weighed down, pinched, or tangled. Such acons
could result in electric shock or re. To unplug the appliance,
be sure to pull the plug, not the cord, and do not jerk the
cord.
Do not make any alteraons to the
appliance. Alteraons could result in electric shock, injury,
re, or damage to the appliance.
Do not place ngers or any other objects
into the ice discharge opening.
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
4| perlick.com/residential
The appliance is not intended for use by
persons (including children) with reduced physical, sensory,
or mental capabilies, or lack of experience and knowledge,
unless they have been given supervision or instrucon
concerning use of the appliance by a person responsible for
their safety.
Young children should be properly
supervised around the appliance.
Do not climb, stand, or hang on the
appliance or appliance door or allow children or animals to
do so. Serious injury could occur or the appliance could be
damaged.
Be careful not to pinch ngers when
opening and closing the door. Be careful when opening and
closing the door when children are in the area.
Do not use combusble spray or place
volale or ammable substances near the appliance. They
might catch re.
Keep the area around the appliance clean.
Dirt, dust, or insects in the appliance could cause harm to
individuals or damage to the appliance.
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
DANGER
!
SAFETY CONSIDERATIONS

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 5
PRIOR TO INSTALLATION
Protect the oor when moving the appliance
to prevent damage to the oor.
Follow the water supply, drain connecon,
and maintenance instrucons carefully to reduce the risk of
costly water damage.
In areas where water damage is a concern,
install in a contained area with a oor drain.
Install the appliance in a locaon that stays
above freezing. Normal operang ambient temperature must
be within 45°F to 100°F (7°C to 38°C).
If using the oponal drain pump (63802A),
test its operaon every me the appliance is cleaned and
sanized. See Oponal Drain Pump 63802A (pg 31) for details. If
the oponal drain pump is not operang properly, water could
back up and overow, leading to costly water damage.
To help ensure the storage bin drain remains
clear, follow the instrucons in Storage Bin Drain (pg 30) once
every 3 months or as oen as necessary for condions. If the
storage bin drain becomes clogged, water could build up in the
bin and overow, leading to costly water damage.
If water collects in the bin and will not drain,
turn o the appliance and close the water supply line shut-o
valve. Call for service.
If water seeps from the base of the appliance,
turn o the appliance and close the water supply line shut-o
valve. Call for service. Failure to do so could lead to costly water
damage.
Do not leave the appliance on during
extended periods of non-use, extended absences, or in sub-
freezing temperatures. To properly prepare the appliance
for these occasions, follow the instrucons in Preparing the
Appliance for Periods of Non-Use (pg 32).
Keep venlaon openings, in the appliance
enclosure or in the built-in structure, clear of obstrucon.
Do not place objects on top of the appliance.
The storage bin is for ice use only. Do not
store anything else in the storage bin.
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING
WARNING

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
6| perlick.com/residential
NICHE / PRODUCT DIMENSIONS/CONNECTIONS
1. H80CIMS-L/R
Units: mm [in.]

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 7
NICHE / PRODUCT DIMENSIONS/CONNECTIONS
2. H80CIMW
Units: mm [in.]

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
8| perlick.com/residential
NICHE / PRODUCT DIMENSIONS/CONNECTIONS
3. H80CIMS-ADL/R
Units: mm [in.]

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 9
NICHE / PRODUCT DIMENSIONS/CONNECTIONS
Units: mm [in.]
4. H80CIMW-AD

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
10 | perlick.com/residential
CONSTRUCTION
Top Panel
Ice Discharge
Opening
Scoop Holder
Front Panel
Control Switch
Louver
Bin Control
Thermostat
Bulb
Slope
Magnet
Catch
Door
Power Cord

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 11
ELECTRICAL/REFRIGERANT
The nameplate provides electrical and refrigerant data. The
nameplate is located inside the storage bin. For cercaon
marks, see the nameplate.
We reserve the right to make changes in specicaons and
design without prior noce.
Model Number H80CIMS-L
H80CIMS-R
H80CIMW
H80CIMS-ADL
H80CIMS-ADR
H80CIMW-AD
Electrical Supply 115-120V, 60 Hz., Phase 1
Power/Cord Type/ Length NEMA 5-15P w/6’ power cord
Design Pressure HI-240PSI LO-120PSI
Refrigerant 134a 3.92 OZ.

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
12 | perlick.com/residential
INSTALLATION INSTRUCTIONS
The appliance must be installed in
accordance with applicable naonal, state, and local codes
and regulaons.
CHOKING HAZARD: Ensure all components,
fasteners, and thumbscrews are securely in place aer
installaon. Make sure that none have fallen into the storage
bin.
A. Checks Before Installaon
Visually inspect the exterior of the shipping container
and immediately report any damage to the carrier. Upon
opening the container, any concealed damage should also be
immediately reported to the carrier.
Remove the shipping carton, tape, and packing material. If any
are le in the appliance, it will not work properly.
Remove the package containing the accessories.
Remove the protecve plasc lm from the panels. If the
appliance is exposed to the sun or to heat, remove the lm
aer the appliance cools.
See the nameplate inside the storage bin, and check that your
voltage supplied corresponds with the voltage specied on the
nameplate.
B. Locaon
1. General
The appliance is approved for indoor or outdoor use.
Normal operang ambient temperature
must be within 45°F to 100°F (7°C to 38°C); Normal operang
water temperature must be within 45°F to 90°F (7°C to 32°C).
Operaon of the appliance, for extended periods, outside
of these normal temperature ranges may aect appliance
performance.
The appliance will not work at sub-freezing
temperatures. To prevent damage to the water supply line,
drain the appliance if the air temperature is going to go below
32°F (0°C).
The appliance should not be located next to ovens, grills, or
other high heat producing equipment.
The locaon must provide a rm and level foundaon for the
appliance.
DANGER
!
DANGER
!
The appliance requires no side or top clearance. But allow
enough space at rear for water supply and drain connecons
and at least 15” (38 cm) clearance at front.
The appliance must be at oor level on a nished oor even
if under a cabinet. In areas where water damage is a concern,
install in a contained area with a oor drain.
Do not let the weight of the counter rest on
the appliance.
Do not install the appliance in a corner where
the door will interfere with other equipment or where the
appliance cannot be pulled out for service.
WARNING
WARNING
WARNING
WARNING

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 13
INSTALLATION INSTRUCTIONS
H80CIMS
H80CIMW
Min. 34"
(864 mm)
H80CIMS-AD
H80CIMW-AD
Min. 32"
(814 mm)
Min. 15"
(381 mm)
Between Two Cabinets Between a Cabinet and
the End of a Counter
Support: Do not
let the weight of
the counter rest
on the appliance
Min. 15"
(381 mm)
H80CIMS
H80CIMW
Min. 34"
(864 mm)
H80CIMS-AD
H80CIMW-AD
Min. 32"
(814 mm)
Min. 23"
(584 mm)
Oven Appliance
Between a Cabinet and a Wall
or Tall Cabinet
In a Corner
Secure: Do not let
the weight of the
counter rest on
the appliance
Installaon Space
Model Height Width Depth
H80CIMS
H80CIMW 34" (864 mm) minimum
15" (381 mm) minimum 24" (610 mm) mini-
mum
H80CIMS-AD
H80CIMW-AD 32" (814 mm) minimum

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
14 | perlick.com/residential
INSTALLATION INSTRUCTIONS
()()
()
()()()
()
()
()
()
H80CIMW Overlay Panel Specicaon
Panel Height 29 17/32" (750 mm)
Panel Width 14 13/16" (376 mm)
Panel Thickness 5/8" (16 mm) min;
3/4" (19 mm) max
Panel and Door Weight (total) 20 lb. (9 kg) max
H80CIMW
Overlay Panel Parts
No. Descripon Part Number Qty.
1 Threaded Wood Insert 4A4004-01 6
2 T2 Screw 4x8 SS 7P32-0408 3
3 Pan Head Screw M4x25 SS 7C12-0425 4
4 Truss Head Screw M4x8 SS 7C32-0408 2
5 Canoe Clip 4A5835-01 2
6 Sheet Metal Bracket 4A3998-01 1
OVERLAY PANEL SPECIFICATION
Use the specicaon that applies to your appliance (H80CIMW
or H80CIMW-AD) and the direcons that follow to prepare your
overlay panel.
OVERLAY PANEL FABRICATION AND ATTACHMENT
The overlay panel must be craed by a professional cabinet
maker to ensure quality results.
PARTS
Ensure that all parts required for the overlay panel assembly are
contained in the accessories bag.
1 2 3 4 5
6

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 15
H80CIMW-AD Overlay Panel Specicaon
Panel Height 27 9/16" (700 mm)
Panel Width 14 13/16" (376 mm)
Panel Thickness 5/8" (16 mm) min;
3/4" (19 mm) max
Panel and Door Weight (total) 20 lb. (9 kg) max
()()
()
()()()
()
()
()
()
INSTALLATION INSTRUCTIONS
FABRICATION OF OVERLAY PANEL
Fabricate the overlay panel as outlined in the specicaon on
the previous page and the instrucons below.
1) Rout a channel at the boom of the overlay panel
to the proper dimensions. See “(C) Routed Area” in the
specicaon diagram and Fig. 1.
2) Drill six 1/4” diameter (hardwood may require slightly
larger diameter) holes 3/8” (10 mm) deep in the
locaons designated.
WARNING
Routed Channel
Fig. 1
Fig. 2
Holes Holes
3) Screw the 6 threaded wood inserts into the 1/4” holes
drilled in the previous step. Make sure that the inserts
are threaded straight and that the tops of the inserts
are ush to the overlay panel surface. Otherwise, the
overlay panel cannot be properly fastened to the door.
4) Mount the door handle hardware. Perlick recommends
that the door handle hardware be mounted on the
edge opposite of the door hinge side (oponal hinge
reversal is covered in step 6. Countersunk screw heads
are required to ensure that the hardware fasteners do
not interfere with the overlay panel ng ush with
the door.
H80CIMW-AD Use care when drilling holes for mounng
hardware. All drilled holes must be straight and drilled to the
correct diameter and depth.
See “(A) Threaded Inserts” and “(B) Threaded Inserts” in
the specicaon diagram and Fig. 2.

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
16 | perlick.com/residential
INSTALLATION INSTRUCTIONS
6) If you would like to reverse the door hinges, do the
following:
a) Contact your local distributor to purchase Perlick
70084. The kit contains “hinge (A)-le.”
b) Remove the 2 bolts securing the top panel, then li
it o (See Fig. 4).
Hinge (A)-Le
Bracket Screw
Top Brace
Gasket Notch
Screw
Hinge (A)-Right
Not Needed
Fig. 4
Bolts
Top Panel
d) Remove hinge (B) from the right side of the
appliance and the 2 ller screws from the le side.
Aach the 2 ller screws to the right side and aach
hinge (B) to the le side (See Fig. 6).
e) Rotate the top panel 180° from its previous posion.
This brings the notch that was previously in the
right rear to the le front (See Fig. 7). Hook the rear
part of the panel on the body, then secure the front
with the 2 bolts removed in step 6a.
f) Remove hinge (C1) from the top right part of the
door, ip it and reaach to the boom le. Remove
hinge (C2) from the boom right part of the door,
ip it and reaach to the top le (See Fig. 8).
Proceed to step 7.
Fig. 6
Hinge (B)
Filler
Screws
Screws
c) Remove hinge (A)-right and the bracket from the
right side of the appliance. Set aside hinge (A)-right;
it is not needed. Remove the top brace from the le
side. Fasten hinge (A)-le and the bracket to the le
side and the top brace to the right side (See Fig. 5).
Note: When on the proper side, the gasket notch for hinge (A) is
to the inside.
Fig. 3
Hinge Stop Pin
Hinge (B)
Hinge (A)
5) While maintaining a hold on the door, remove the
hinge stop pin from hinge (B). Pull out the boom of
the door slightly and gently remove the door from
hinge (A) (See Fig. 3). If you are leaving the door right
hinged, skip to step 7. If you would like to reverse the
door hinges, proceed to step 6.
Fig. 5

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 17
Notch
Top Panel
Fig. 7
Hinge (C1)
Hinge (C2)
Fig. 8
Screws
Screws
7) Remove the bushings from hinge (C1) and hinge (C2)
(the hinges aached to the door) (See Fig. 9).
8) Remove the gasket from the door (See Fig. 10).
Hinge
Bushing
Fig. 9
Gasket
Fig. 10
9) Temporarily fasten the overlay panel to the door using
2 of the M4×25 pan head screws provided.
Ensure that the back surface of overlay panel
is at before aaching (See Fig. 11).
WARNING
Screws
Fig. 11
10) Mark the centerpoint of the hinge (C1) and hinge (C2)
holes that extend over the overlay panel (See Fig. 12).
11) Remove the overlay panel from the door.
12) Drill 3/8” diameter holes 1/4” (7 mm) deep where you
marked on the overlay panel to accommodate the
hinge (C1) and hinge (C2) bushings.
Fig. 12
Mark the center point.
Overlay Panel
Door
Hinge
INSTALLATION INSTRUCTIONS

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
18 | perlick.com/residential
INSTALLATION INSTRUCTIONS
ATTACHMENT OF OVERLAY PANEL TO DOOR
1) Fasten the sheet metal bracket to the overlay panel
using the two M4×8 truss head screws provided. Snug
the screws, but do not ghten (See Fig. 13).
2) Temporarily fasten the overlay panel to the door using
2 of the M4×25 pan head screws provided (See Fig. 14).
Screws
Fig. 14
Fig. 13
Sheet Metal Bracket
Overlay Panel
Snug the screws,
but do not ghten.
3) Adjust the sheet metal bracket so that it is ush with
the boom of the door (See Fig. 15).
4) Remove the overlay panel from the door and ghten
the two M4×8 truss head screws securing the sheet
metal bracket to the overlay panel (See Fig. 16).
Door
Sheet Metal Bracket
Fig. 15
Sheet Metal Bracket
Overlay Panel
Tighten the screws.
Fig. 16

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service [phone] | 19
INSTALLATION INSTRUCTIONS
5) Fasten the overlay panel to the door using the four
M4×25 pan head screws provided. Snug the screws,
but do not ghten (See Fig. 17).
6) Fasten the sheet metal bracket to the boom of the
door with the three T2 screws provided. Tighten the
screws to the door (See Fig. 18).
8) Replace the door gasket in its proper orientaon.
Reinsert the bushings into hinge (C1) and hinge (C2)
(the hinges aached to the door) (See Fig. 20).
Snug the screws,
but do not ghten.
Fig. 17
Sheet Metal Bracket
Screws
Overlay Panel
Door
Fig. 18
7) Tighten the four M4×25 pan head screws installed in
step 5 (See Fig. 19).
Fig. 19
Tighten the screws.
Bushing
Bushing
Gasket
Fig. 20
9) Aach the door to hinge (A), then connue to maintain
a hold on the door. Screw the hinge stop pin into hinge
(B) unl it is ght (See Fig. 21).
10) Insert the 2 canoe clips included in the accessory bag
into the holes on top of the door (See Fig. 22).
Hinge Stop Pin
Hinge (B)
Fig. 21
Canoe Clips
Fig. 22

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
20 | perlick.com/residential
SETUP
SETUP
1) Posion the appliance in the selected permanent
locaon.
2) Level the appliance from side-to-side and front-to-rear
by adjusng the feet.
