Permobil Explorer Mini Reference guide

ICS –Quick reference card
V4.10 dd 12-11-2015
For additional information see manual: OM_xx_ICS_OnBoard_Configuration (xx = Language code)
1 of 2
General Settings
User weight
Entry:Button 2 and 4
(all led’s green
– led 7 off / led 8 flashes red)
Setting:Button 1 or 5
Save:Button 8 (2 sec)
0-50 kg / 0-110 lb 121-135 kg / 266-300 lb
51-75 kg / 111-165 lb 136-160 kg / 301-350 lb
76-100 kg / 166-220 lb 161-180 kg / 351-400 lb
101-120 kg / 121-265 lb 181-200 kg / 401-450 lb
LED indication level
Entry:Button 2 and 4
(all led’s green –
led 7 off / led 8 flashes red)
Setting: Button 3 or 7
Save: Button 8 (2 sec)
Level 1 All LEDs off. No indications. (Use with “single page” layouts.)
Level 2 Only displays Green LEDs No indication of Drive Speed or Actuator Limits.
Level 3 Only displays Solid LEDs No indication of Actuator Limits (Only Drive Speed.)
Level 4 All Indications Displayed (Default Setting)
NOTE: Flashing RED LEDs (Actuator Errors) are displayed in every Indication Level.
Switch box Layout
Entry: Button 1 and 3
(all led’s green
– led 7 flashes green
/led 8 cont. red)
Setting: Button 1 or 5
Save: Button 8 (2 sec)
Note:
*1 Only for CorpusVS
CorpusAPE/CorpusVS
CorpusII
/ Corpus3G
VS
K450
1 A A D J
2 B B E K
3 C C F
4 D D G
5 E M
6 F
7 G
*1
L
12 L
Other General Setting
Entry:Button 2, 7 and 8
(all led’s green –
led 7 and 8 toggle green)
Next page:Button 4
Prev. page:Button 8
Page 1: Led 7 and 8
toggle green
Page 2: Led 7 flashes green
and Led 8 Off
Page 3: Led 7 cont. green
and Led 8 Off
Save: No action required
Setting:
Page
LED
Button
Green Red
1 1 1 Actuators blocked while driving Actuators enabled while driving
1 2 5 Low backrest installed (C3G) Standard (High) backrest installed
1 3 2 -5 Tilt adapter installed No -5 Tilt adapter installed
1 4 6 Pause tilt at 0º No pause Tilt at 0º
1 5 3 Leg rest pauses before reducing speed Leg rest does not pauses before reducing speed
1 6 7 Enable IRM (Independent Repositioning Mode) Disable IRM (Independent Repositioning Mode)
2 1 1 Push leg rest on Push leg rest off
2 2 5 Push back on Push back off
2 3 2 Invert Elevator: up is rear button Invert Elevator: up is front button
2 4 6 Invert Tilt: forward is rear button Invert Tilt: forward is front button
2 5 3 Invert Backrest: forward is rear button Invert Backrest: forward is front button
2 6 7 Invert Leg rest: up is rear button Invert Leg rest: down is front button
3 1 1 Leg rest linked to backrest Leg rest NOT linked to backrest
Corpus II seat
Legrest angle for ¼ speed
(rear-/mid-wheel driven chairs)
Entry: Button 1, 2 and 7
(all led’s green – led 7 flashes red
/led 8 flashes green)
Setting: Button 1 or 5
Save: Button 8 (2 sec)
3º 15º
6º 18º
9º 21º
12º
Corpus 3G/HD/APE/VS
Seat depth
Entry: Button 3, 4 and 6
(all led’s green – led 7 flashes green
/led 8 flashes red)
Setting: Button 1 or 5
Save: Button 8 (2 sec)
<
470mm/18”
545mm/21”
620mm/24”
495mm/19” 570mm/22”
520mm/20” 595mm/23”
Legrest angle offset for ¼ speed
(rear-/mid-wheel driven chairs)
Entry: Button 1, 2 and 7
(all leds green – led 7 flashes red
/led 8 flashes green)
Setting: Button 1 or 5
Save: Button 8 (2 s ec)
+12º +3º -6º
+9º 0º
-9º
+=6º -3º
-12º
IRM position (Corpus 3G/HD/APE/VS)
Independent Repositioning Mode is
using/replacing Memory 3
Note: IRM needs to be enable (see above: Other
General Settings)
Entry: Button 5 and 7
(all led’s green – led 8 flashes red/green)
Extra step for Corpus APE and Corpus VS only:
- Press button 7. (Led 7 will lit solid green)
Setting backwards position:
Button 1 or 5 Tilt
Button 2 or 6 Legrest
Button 3 or 7 Backrest
Save: Button 4
Setting forwards position:
Button 1 or 5 Tilt
Button 2 or 6 Legrest
Button 3 or 7 Backrest
Save: Button 8

ICS –Quick reference card
V4.10 dd 12-11-2015
For additional information see manual: OM_xx_ICS_OnBoard_Configuration (xx = Language code)
2 of 2
K450 Settings
Transportation Mode (WC19)
Entry: Button 1, 2 and 7
(all led’s green – led 7 flashes red/led 8 flashes green)
Setting: Button 1 or 5
Save: Button 8 (2 sec)
Transportation Mode OFF
Transportation Mode ON
Transportation Mode: Hook position
Entry: Button 6 and 8
all led’s start toggle green.
Release Button 6 and 8 and press Button 4 (for appr. 5 sec):
Led indication changes and seat starts to move
Setting: Button 1 or 5 to move seat elevator up/down
Button 2 or 6 to move hooks backwards/forwards
Button 3 or 7 to move hooks up/down
Button 4 to operate transportation mode
Adjustment process
Press Button 4 until hooks are close to engage loops.
Use Buttons 2/6 and 3/7 to engage hooks:
-Hook centered around loop
-Slight pressure on loop
Save: Button 8
Seat tilt
Entry: Button 1, 2 and 7
(all led’s green – led 7 flashes red/led 8 flashes green)
Setting: Button 3 or 7
Save: Button 8 (2 sec)
Without tilt
With tilt
Seat width / Armrest type restriction
Entry: Button 3, 4 and 6
(all led’s green – keep pressing until rapid beep (5sec)
led 7 flashes red/led 8 flashes green)
Setting: Button 1 or 5
Save: Button 8 (2 sec)
No
restriction MX armrest and seat 25-30-35cm / 10-12-14” wide PSjr armrest and seat 25-30cm / 10-12” wide
Small
restriction PSjr armrest and seat 35cm / 14” wide
High
restriction MX armrest and seat 40cm / 16” wide PSjr armrest and seat 40cm / 16” wide
VS Settings
Leg rest type
Entry: Button 1, 2 and 7
(all led’s green – led 7 flashes red/led 8 flashes green)
Setting: Button 1 or 5
Save: Button 8 (2 sec)
Stand NO Drive
Stand and Drive
VS Standing properties
Entry: Button 5 and 7 (all led’s green – led 8 toggles green/red)
Sequence A (left icon) / Sequence B (right icon)
Setting: Pre-defined sequence A: Button 1, 2 or 3 / Pre-defined sequence B: Button 5, 6 or 7
Pre-defined sequence 1 (45sit – stand) Sequence A: button 1 / Sequence B: button 5 (led 1: green and hold until it gets red)
Pre-defined sequence 2 (90sit – stand) Sequence A: button 2 / Sequence B: button 6 (led 3: green and hold until it gets red)
Pre-defined sequence 3 (lay – stand) Sequence A: button 3 / Sequence B: button 7 (led 5: green and hold until it gets red)
Maximum stand – seat height
Setting: Standing Button 1 or 5
Setting: Seat height: Button 2 or 6
Move standing to max position for user and at the same time keep footplate on the floor by changing the seat height
Seat height: led 8: green=OK / red=Outside range.
Save: Button 8 (2 sec) short beep – led’s 7 and 8: green
Switch chair off.
VS Take Me Down (Emergency UN-Standing)
Entry: Button 6 and 8
(after appr. 30 sec all led’s red – all Led’s toggle flashes
green)
Button 1 and 5: Standing actuator
Button 2 and 6: Seat elevator
Button 3 and 7: Backrest actuator
Button 4 and 5: Legrest actuator
Switch chair off.
CorpusAPE (>V12) / CorpusVS (>V9) - Specific Attributes
Disable Drive in Standing
Entry: Button 1, 2 and 7
(all leds green – led 7 flashes red
/led 8 flashes green)
Setting: Button 1 or 5
Save: Button 8 (2 sec)
Access to CorpusAPE / CorpusVS attributes
Entry: Button 5 and 7
(all leds green – led 7off / led 8 flashes red/green)
-Button 1: Standing sequence 1 / transfer sequence adjustment
-Button 2: Standing sequence 2 adjustment
-Button 3: Adjustment of Legrest extension in standing/transfer position
-Button 4: Ground clearance / Ground touch adjustment
-Button 7: Set IRM positions (See other side: IRM Position)
Note: Pressing button 1-3 > 15 sec resets selected function to presets
Pressing button 4 > 15 sec sets ground clearance/touch to 0
(Led 1-4 start flashing green – release: reset)
Ground Touch / Ground Clearance
The Ground Touch procedure should be performed first and redone
after every mechanical adjustment of the footplate height!
Entry: Button 4 (Led 4 - solid green)
Setting: Button 1-5: Seat elevator
Button 2-6: Set Legrest extension
Save: Button 7: Save ground clearance (Led 6)
Button 8: Save ground touch (Led 8)
Led 6 / 8 - flashing green, new position can be saved
Led 6 / 8 - solid green while holding button8, position saved
Led 6 / 8 - solid yellow, can't save leg extension position
Legrest extension for standing / transfer
Entry: Button 3 (Led 3 - solid green)
Setting: Seat in the maximum standing/transfer position:
Button 1-5: Position footplate to required extension
Save: Button 8: Save legrest extension
Led 8 - flashing green, new position can be saved
Led 8 - solid green while holding sw8, position saved
Led 8 - solid yellow when seat is in a position that doesn't allow saving
Standing sequence 1 / Transfer sequence
Entry: Button 1:
Standing Sequence 1 / Transfer Sequence adjustment (Led 1: solid red)
Checkpoints (CP1-4) are indicated by Led 1-4 Green
Setting: Button 1-5: Control stand sequence up/down
Button 2-6: Set backrest angle
Button 3-7: Set legrest angle
Save: Button 8
Process:
Press Button 1 until CP1 is reached (LED 8 flashes green)
Set back/leg and save with button 8
Press Button 1 until required stand position: CP2 (LED 8 flashes green)
Set back/leg and save with button 8
Press Button 5 until CP3 is reached (LED 8 flashes green)
Set back/leg and save with button 8
Press Button 5 until CP4 is reached (LED 8 flashes green)
Set back/leg and save with button 8
Led 8 - flashing green, position can be saved
Led 8 - solid green while holding button 8, position saved
Led 8 - flashing red while holding button 8, can't save sequence position
Note: In CP2 de previous max set standing / transfer angle can be overruled
by pressing Button 1 for more than sec.
Standing sequence 2
Entry: Button 2
Standing Sequence 2 adjustment (Led 2: solid red)
Check Point (CP1-4) are indicated by Led 1-4 Yellow
Follow the same procedure as for Sequence 1
