Persistent Systems Wave Relay MPU5 User manual

MPU5
BASIC OPERATOR MANUAL
VERSION 2.5
03EN073
Rev. G

Copyright 2010 - 2018, Persistent Systems, LLC. All rights reserved. Wave Relay®is a registered trademark of Persistent Systems, LLC
(“Persistent”). This Basic Operator Manual (the “Manual”) contains information that is the sole property of Persistent Systems, LLC.
Therefore, the Manual may not be excerpted, summarized, copied, distributed, or otherwise published, in whole or in part, without
the prior written permission of Persistent Systems, LLC. All other product and service names, trademarks, logos, and brands are
property of their respective owners. All non-Persistent company, product, and service names and all non-Persistent trademarks used
in this Manual are for identification purposes only. Use of these non-Persistent names, trademarks, logos, and brands does not imply
endorsement.

Copyright 2010 - 2018 Persistent Systems, LLC
Issued: July, 2018
READ MANUAL BEFORE OPERATION
DO NOT SWAP RADIO MODULES WHILE UNIT IS POWERED ON!
DO NOT POWER ON UNIT WITHOUT ANTENNAS ATTACHED!

PERSISTENT SYSTEMS
Headquartered in New York City since 2007, Persistent Systems LLC is a global communications technology company
which develops, manufactures and integrates a patented and secure Mobile Ad Hoc Networking (MANET) system: Wave
Relay® . The company’s industry-leading R&D team has designed wireless networking protocols to support their cutting
edge Wave Relay®system and has designed MIMO radios to allow the Wave Relay®MANET to achieve its highest
potential. Wave Relay®is capable of running real-time data, video, voice and other applications under the most difficult
and unpredictable conditions. Their suite of products is field proven and utilized in Commercial, Military, Government,
Industrial, Agriculture, Mining, Oil and Gas, Robotics, and Unmanned System markets.
THE MPU5
The MPU5 is the Next Generation Wave Relay®platform. Leveraging multiple leading edge technologies such as MIMO
and Android™, the MPU5 is a smart radio that delivers increased performance, reliability, and capability to the end user
in a small, cost-efficient package. Stream multiple HD Video feeds, run commercial and custom apps, view situational
awareness, and communicate with high quality audio all with a single device and a minimal number of accessories.
WAVE RELAY®MANET
The Wave Relay®System is a peer-to-peer wireless MANET networking solution in which there is no master node. If any
device fails, the rest of the devices continue to communicate using any remaining connectivity. By eliminating master
nodes, gateways, access points, and central coordinators from the design, Wave Relay®delivers high levels of fault
tolerance regardless of which nodes might fail. The system is designed to maximize the capacity of the radio frequency
(RF) spectrum and to minimize the network overhead. While optimizing efficiency, Wave Relay®also implements tech-
niques that increase multicast reliability. The advanced multicast functionality allows the system to support both multicast
voice and video over IP.
Wave Relay®is designed to maintain high bandwidth connectivity among devices that are on the move. The system
is scalable, enabling it to incorporate unlimited meshed devices into the wireless network, where the devices
themselves form the communication infrastructure. Even in highly dynamic environments, the system is able to

maintain connectivity by rapidly re-routing data as necessary. Wave Relay®is a self-forming and self-healing network
where nodes can move freely within the network. Critical information flows reliably throughout the network while
individual data paths are able to adapt at sub-second intervals. This unique approach creates an ideal environment
for maximizing performance across the available communications medium. Customers leverage Wave Relay®’s
straight forward and effective architecture to enable a true “Plug and Play” capability. Deploying a Wave Relay®
network is as simple as connecting a standard Ethernet cable; customers are immediately connected to everything on
the network.
Wave Relay®is a seamless wireless networking system offering a dynamic and reliable solution for all mobile networking
needs. The MPU5 offers the Wave Relay®MANET combined with other leading edge technologies in a single smart radio.
CONTACT PERSISTENT SYSTEMS
Persistent Systems
Tel: [phone] | www.persistentsystems.com
Persistent Systems Support
Email: [email protected] | OS Ticket: www.persistentsystems.com/ps-support
Persistent Systems RMA
Email: [email protected]
Persistent Systems Sales
Email: [email protected]
Persistent Systems Training
Email: [email protected]

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
6
TABLE OF CONTENTS
Introduction 4
Persistent Systems 4
The MPU5 4
Wave Relay® MANET 4
Safety 12
Suggested Hardware 16
Part I: Physical Setup 17
Section A: RF Setup 17
Inserting the Radio Module 20
Connecting Antennas 22
Section B: Power 26
Connecting Power 28
Removing Power 30
Powering On the Unit 32
Section C: Side Connector Cables 34

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved 7
TABLE OF CONTENTS
Parts List 35
Connecting a Cable to a Side Connector 36
Part II: Software Setup 40
Section A: Configuring the Management Computer 40
Parts List 40
Configuring the Management Computer (Windows) 42
Configuring the Management Computer (Linux) 48
Section B: Connecting the MPU5 to the Management Computer 49
Parts List 49
Section C: Accessing the Web Management Interface 52
Parts List 52
Section D: Basic Network Setup 60
Security Key 60
Assigning IP Address and Interface Names 62
Rebooting an Individual Node 65

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
8
TABLE OF CONTENTS
Network Node List 66
Part III: Testing Connectivity 70
Check Neighbor Node Status 70
Perform a Throughput Test 72
Throughput Test Logging 74
Part IV: Using the Web Management Interface 76
View Individual Node Information 76
Configuring Radio Settings for a Single Node 78
Upgrading Firmware 80
Creating a Configuration File 82
Loading Settings from a Configuration File 84
Reset Node to Factory Configuration 86
Check GPS Status 87
Network Status Tab 88
Network Visualization 90

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved 9
TABLE OF CONTENTS
Part V: Device Operation 94
Zeroize the Security Key 94
Connect a Camera to the MPU5 96
Configuring Video Settings 98
Video Kiosk Mode 108
Connect an EUD or Handheld Display to the MPU5 114
Connecting a Monitor or TV to the Wave Relay®MPU5 116
Connect USB Accessories to the MPU5 119
Install Android™ Apps on the MPU5 121
Using Android™ Screenshot 124
Network Configuration Tab 126
Connect a PTT Device to the MPU5 128
Configure PTT Settings 130
Enable Push-to-Talk 131
Set Earpiece Volume 131
Set Microphone Level 132

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
10
TABLE OF CONTENTS
Set Transmit Mode 133
Set Transmit or Receive Audible Checktone 134
Enable/Disable Low Battery Audible Notification 135
Selecting Channels 136
Customize a PTT Channel 136
Using Wave Relay®Push-to-Talk 138
Using Flash Override 139
Professional Installer – Compliance 140
Attachments 148

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved 11
TABLE OF CONTENTS

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
12
SAFETY
Lire et comprendre les consignes de sécurité d’emploi et tout
de l’opérateur avant d’utiliser cet équipement
SAFETY WARNINGS
Handle Safely: ▶Falling while installing or removing equipment can cause serious injury.
▶If installing on a tower or any other tall locations, use proper lifting tech-
niques and wear proper protective equipment.
▶Tomber lors de l’installation ou de retirer l’équipment peut causer des
blessures graves.
▶Si vous installez sur une tour ou d’autres endroits de hauteur, utiliser des
techniques de levage appropriées et porter un équipment de protection
approprié.

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved 13
SAFETY
Electrical Shock
and Fires:
▶Understand and follow all local codes and regulations when installing elec-
trical equipment.
▶Only use approved battery and/or power supplies.
▶Comprendre et respecter tous les codes et règlements locaux lors de l’in-
stallation des équipements électriques.
▶Utilisez uniquement la batterie et les alimentations ou approuvé.
RF Exposure: ▶Prevent injury from exposure to high frequency fields.
▶See antenna separation instructions in the Compliance section of this man-
ual.
▶Do not operate with antenna removed. This can increase RF exposure
risks and/or damage the equipment.
▶Prévenir les blessures d l’exposition aux champs de haute fréquence.
▶Voir les instructions de séparation de l’antenne dans la section de la con-
formité de ce manuel.
▶Ne pas faire fonctionner avec antenne enlevé. Cela peut augmenter les
risques d’exposition aux radiofréquences et ou endommager l’équipe-
ment.

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
14
SAFETY
CAUTION
DEVICE UTILIZES LITHIUM ION BATTERY
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
----------------------------------------------------------------------
MISE EN GARDE
Dispositif utilise la batterie Ion Lithium
RISQUE D’EXPLOSION SI LA BATTERIE EST REMPLACE PAR UN TYPE INCORRECT.
Jetez les piles usagées selon
LES INSTRUCTIONS
Lithium Batteries Handling
▶Lithium ion batteries are defined as Class 9 dangerous goods by the IATA Dangerous Goods
Regulations.
▶Handle with care.
▶Do not use if package is damaged - it can cause fire.
Disposing of Used Batteries
▶Disposal should be done in accordance with applicable regulations, which vary from country to
country as well as by state and local governments. In most countries, trashing of used batteries
is forbidden and disposal can be done through non-profit organizations mandated by local au-

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved 15
SAFETY
thorities or organized by professionals.
▶Incineration of lithium cells and batteries by consumers is not recommended. Incineration
should be done at a properly permitted facility that can handle this waste.
---------------------------------------------------------------------------------------------------
Manipulation des batteries lithium
▶Les batteries au lithium-ion sont définis comme Classe 9 marchandises dangereuses par le Régle-
ment sur les marchandises dangereuses de l’IATA.
▶Manipuler avec soin.
▶Ne pas utiliser si l’emballage est dommage, il peut provoquer un incendie.
Mise au rebut des batteries usagées
▶L’élimination doit être effectuée conformément aux réglementations applicables, qui varient
d’un pays à l’autre ainsi que par les gouvernements d’État et locaux. Dans la plupart des pays
saccage des batteries usagées est interdit et l’élimination peut être fair par les organisations à
but non lucratif mandatés par les autorités locales ou organisées par des professionnels.
▶Incinération des dellules et batteries au lithium par les consommateurs est déconseillée. In-
cinération devrait être fait dans une installation dûment autorisée qui peut gérer ces déchets.
See Attached Battery Spec Sheet, MSDS, and compliance document for more information

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
16
SUGGESTED ADDITIONAL HARDWARE
Suggested Additional Hardware
▶#1 Phillips Head Screwdriver: Used to attach/detach radio module
▶TPI Kit: Allows for antenna and RF cable matching
▶RF cable at various lengths (LMR-400): Allows for flexibility in antenna setup
▶Ethernet Cables
▶Ethernet Female-to-Female Extenders
▶HD Screen or TV with HDMI input: Displays Android™ computer interface and/or streaming
video
▶Laptop with Administrator Access: Used for device configuration
▶USB Thumb Drives: Used for software configuration storage and loading

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved 17
PHYSICAL SETUP: RF SETUP
What Will I Learn?
▶How to insert radio modules into the MPU5 chassis
▶How to attach antennas to the MPU5
→
Section A: RF Setup
Part I: Physical Setup

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
18
PHYSICAL SETUP: RF SETUP

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved 19
PHYSICAL SETUP: RF SETUP
?How do I tell if my antennas and radio modules are compatible?
Find the part numbers on the antennas. Antenna part numbers are on a sticker wrapped around the base
of the antenna.
1
Find the part number on the radio module. The radio module part number is on a sticker on the back of
the radio module.
2
Each part number will begin with ANT- (antennas) or RF- (radio modules) followed by four (4) digits. The
first digit references the radio band of the part. Make sure that the first digit of the antennas and radio
module match.
3
!WARNING!: DO NOT use mismatched antennas and radio modules. This configuration will result in very
poor performance and/or damage to the device. If you do not have matching antennas and radio modules,
contact Persistent Systems.
!WARNING!: DO NOT switch radio modules while device is powered on. Power off device before changing
radio modules.
!WARNING!: the MPU5 is not IP68 rated when the radio module is not attached. Ensure you are in a dry,
dust-free environment before changing radio modules.
!WARNING!: User MUST refer to the Professional Installer – Compliance Section of this manual for ap-
proved antenna types. This warning applies only to RF-2100 with the FCC ID 2AG3J-RF-2100 and RF-5100 with
the FCC ID 2AG3J-RF-5100.

© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
20
PHYSICAL SETUP: RF SETUP
Inserting the Radio Module
1If there are rubber caps
on the radio module
contacts, remove them.
2Align the radio module
with the chassis. 3Apply even force and press the radio module
into the chassis.
