S TART Quick-Start Guide
Part No. 81-9059-0647-0 Rev. B
Carefully unpack your Integrity CS Unit from shipping container
and verify package contents against contents listed below.
Visually inspect the unit for any signs of damage in shipment or
transit.
If any components are missing or damaged, contact QuStream
Customer Service.
Q UICK S TART
G UIDE
2
Step
UNPACK THE
PROCESSOR RACK UNIT
1
2
P ACKAGE C ONTENTS :
1
Step
I NTEGRITY CS S ERIES
A2HD516 P ROCESSOR
If any components are missing or damaged, contact QuStream
Customer Service by phone or e mail.
Customer Service: 1+ [phone]
Toll Free: [phone] (US nd C n d )
F x: 1+ [phone]
Em il: [email protected]
V ERIFY A LL I TEMS S HOWN A BOVE A RE
I NCLUDED W ITH U NIT
U NPAC K
S HIP PING
C ONTAIN ER
Considerations for mounting location include proximity to signal sources/destinations, availability
of primary power and availability of a source of external sync.
Mount the chassis frame in an equipment rack and secure frame to rack using four rack mount
screws.
Do not apply power until all external connections are made and verified.
R EAR P ANEL L AYOUT
Complete video and audio connections to the A2HD516 using the diagrams below as a
reference. Highlighted connection points indicate major function connections.
P OWER
C ORD
C OAXIAL
J UMPER
C ABLE
E TH ERN ET
(RJ45)
J U MPER
C ABLE
2
Step
GET ACQUAINTED
The Integrity CS A2HD516 is a self contained format converter
and audio embedder/de embedder. It accepts an input of
composite (NTSC/PAL) analog video or SD SDI digital video
and produces outputs of HD SDI, SD SDI and option outputs
selectable as SD SDI or composite analog.
The included side column keyer accepts an input of HD SDI
video.
Inputs are provided for both AES and analog audio sources for
embedding. De embedded audio is available as both AES
pairs and analog, selectable from any de embedded channel
GET ACQUAINTED (CONT.)
Your Integrity CS Series processing product requires installation of rear panel jumpers for proper
operation. These jumper cables are removed for shipping, but are included in the package with
the processor.
Refer to the following figure, and perform the steps to install these necessary jumper cables prior
to use of the processor.
!! NOTE !!
Your Integrity CS Processor WILL NOT function unless these connections are completed.
Your Integrity CS A2HD516 is composed of a 1RU rack frame with a power supply and three
processing modules, installed in card slots on the rear of the chassis. An illustration of the rear
panel layout is shown below.
In most installations, the processor control panel is installed directly to the chassis frame. If
your system is equipped with the remote panel option, a blank front panel with status LEDs is
attached to the chassis. Whether local or remote, the control panel layout is as shown in the
illustration below.
F RONT P ANEL L AYOUT
Input
Ref
Bypass Test
Freeze
Preset
Setup
Hue
Sel
A1
Menu Video
Back Audio
Take/Enter Gain
A2
Black
A3
Chroma
A4
3
Step
INSTALL REAR PANEL JUMPERS
4
Step
MOUNT A2HD516 CHASSIS FRAME
5
Step
F RAME S YNC M ODULE C ONNECTIONS
VIDEO/AUDIO CONNECTIONS
F ORMAT C ONVERTER C ONNECTIONS
IN 1 OUT 1A OUT 1B OU T 2A OUT 2B OPTION BOPTION A GEN LKIN 2
ANA LOG AUDIO 1,2,3,4 AES A VID A SDI IN OUT 1VID B OUT 2
ANALOG IN
(1,2,3,4) AUX 1/ 2 IN 1/2 OUT3/4 IN 3/4 OUT
AES
ANA LOG OUT
(1,2,3,4)
CH1 CH2 CH3 CH4 CH1 CH2 CH3 CH4 DL AES
REF
DL
FRAME SYNC MODULE
AUDIO MODU LE
FORMAT CONVER TER MODUL E
MAIN POWER
CONNEC TOR
POWER
SWITCH
ETHERNET
CONNEC TORS
REDUNDAN T
POWER
CONNEC TOR
EXTERNAL
SYNC
CONNECTOR
AES B
A UDIO M ODULE C ONNECTIONS
ANALOG IN
(1,2,3,4) AUX 1/2 IN 1/2 OUT
3/4 IN 3/4 OUT
AES
ANALOG OUT
(1,2,3,4)
CH1 CH2 CH3 CH4 CH1 CH2 CH3 CH4 DL AES
REF
DL
ANALOG AUDIO
INPUTS
5 & 6 7 & 8
ANALOG AUDIO
OUTPUTS
1 & 2 3 & 4
AES 4
INPUT
AES 5
INPUT
AES 1
OUTPUT
AES 2
OUTPUT
ANALOG AUDIO 1,2,3,4 AES A AES B VID A SDI IN OUT 1
VID B OUT 2
ANALOG AUDIO
INPUTS 1 & 2
ANALOG AUDIO
INPUTS 3 & 4
AES 1
INPUT
AES 2
INPUT
AES 3/
DOLBY-E
INPUT
SD-SDI
SIGNAL
INPUT
ANALOG
SIGNAL
INPUT
SD-SDI OUTPUT OF
CONVERTED ANALOG
SIGNAL
A
COAX JUMPER TO FORMAT
CONVERTER MODULE
IN 1 OUT 1A OUT 1B OUT 2A OUT 2B OPTION BOPTION A GENLOCKIN 2
ANALOG AUDIO 1,2,3,4 AES A AES B VID A SDI IN OUT 1
VID B OUT 2
ANALOG IN
(1,2,3,4) AUX 1/2 IN 1/2 OUT3/ 4 IN 3/4 OUT
AES
ANALOG OUT
(1,2,3,4)
CH1 CH2 CH3 CH4 CH1 CH2 CH3 CH4 DL AES
REF
DL
SUPPLIED COA XI AL
CABLE JUMPER
SUPPLIED ETHERNET
CABLE JUMPER
Locate supplied coaxial cable jumper and supplied Ethernet cable jumper shipped with your
Integrity processor.
Install coaxial jumper between connector labeled Output (OUT) 2 on frame sync module and
connector labeled Input (IN) 2 on format converter module. Refer to figure when installing this
cable.
If you are using the LOCAL control panel on the front of the frame to control this unit, install
Ethernet cable jumper between the two Ethernet (RJ45) port connectors on rear panel of
processor. If you are using a REMOTE control panel over the facility LAN, use an Ethernet switch
or hub to provide an active network connection to BOTH rear panel Ethernet ports.
MATING AUDIO
CONNECTORS
(A TTACH ED TO R EAR
PAN EL AU DIO
CON NE CTORS )
!! NOTE !!
Your A2HD516 Processor is shipped from the factor with the UDC operating mode selected.
This mode allows the processor to function as an analog or SD-SDI to HD converter
WITHOUT using the included side column ke er function.
If ou wish to use the side column ke er, ou MUST provide an HD input signal for use as the
ke er insert video source, and ou MUST change the processor to the UCP operating mode as
shown in Step 8 of this guide. If UCP is selected as the operating mode and an HD signal is
not applied to the ke video input connector, the A2HD516 WILL NOT function properl !!
IN 1 OUT 1A OUT 1B OUT 2A OUT 2B OPTION BOPTION A GENLOCK IN 2
SIDE COLUMN
KEYER VIDEO
INPUT
(SEE NOTE
ABOVE)
HD-SDI
OUTPUTS
1 2
SD-SDI
OUTPUTS
1 2
JUMPER SELECT
SD-SDI or ANALOG
OUTPUTS
1 2
EXTERNAL
SYNC INPUT
A
COAX JUMPER FROM
FRAME SYNC MODULE
Audio Module Connector Pin Outs Shown on Next Page

Quick-Start Guide
Part No. 81-9059-0647-0 Rev. B
6
Step INITIAL POWER UP
I NTEGRITY CS S ERIES
A2HD516 P ROCESSOR
Inspect all connections to the processor. Ensure that all cables are installed securely.
Attach power cord to rear panel main power connector and a source of power.
Move power switch to the “ON” position.
Input
Ref
Bypass Test
Freeze
Preset
Setup
7
Step BASIC OPERATION
C ONTROL P ANEL L AYOUT AND O PERATION
Setup –Setup causes control panel to access system set up menu regardless of
which menu screen is currently displayed.
System Status Indicators
Input – The Input LED illuminates if video input signal is lost for any reason.
Reference (Ref) – The Ref LED illuminates if genlock reference source is lost for any
reason.
Bypass and Preset
Bypass and Preset pushbuttons and Bypass LED are not used in current configuration
of processor.
Direct Entry Pushbuttons
Test – Pressing Test switches output signal
from active video source to a user selectable
test signal. A second pressing cancels test
output and returns to video source. The Test
LED illuminates when test output is active.
Freeze – Pressing Freeze freezes video
output signal based on a user selectable
freeze frame type. A second pressing
cancels freeze output and returns to video
source. The Freeze LED illuminates when
freeze function is active.
Text Line1
Text Line2
Text Line3
Text Line4
Text Line5
Text Line6
Menu Display Screen
Menus, operational parameters and system status
are displayed on a six line screen, as illustrated.
=A2HD516=
--
Video Config
--
Proc Controls
Color Corrector
Input Select
Function Select Pushbuttons
Menu – Pressing Menu advances to next level of menu tree structure as
determined by highlighted menu screen selection.
Back – Pressing Back causes previous menu to be recalled.
ideo – Pressing ideo accesses top level video status screen.
Audio – Pressing Audio accesses top level audio configuration menu.
Take/Enter – When Take/Enter pushbutton is illuminated green, it is “live” and
used in the current menu to execute a function or command. Once commands is
executed, LED in button extinguishes. Take/Enter performs a function only when
illuminated green.
Some menus use Function Pushbuttons to execute commands on screen. Any
button press required is prompted on individual menus.
Rotary Controls
A1 (Sel) – The Select (Sel) control, also labeled A1, scrolls through menu entries
on scrollable screens. On data entry screens, A1 selects commands or values for
entry mapped to it.
A2 thru A4 – On data entry screens with more than one selectable entry, control
knobs A2 thru A4 are software mapped sequentially to data entry prompts.
7
Step
BASIC OPERATION (CONT.)
Values and parameters are modified by selecting new value or selection from a
scrolling list of available options, or increasing/decreasing numerical values, by
using rotary knobs on control panel. Data entry screens have a maximum of four
selectable values or functions, each is software mapped to one control knob,
beginning with knob A1 for first selectable entry and continuing in sequence to knob
A4 for fourth selectable entry. In this example, HUE vector may be selected by
rotating control knob A1, GAIN percentage by rotating knob A2, BLACK level by
rotating A3 and CHROMA percentage by rotating A4.
Pushbuttons and rotary controls located to right of display screen navigate menu
screens and select or modify parameters.
Hue
Sel
A1
Menu Video
Back Audio
Take/Enter Gain
A2
Black
A3
Chroma
A4
S YSTEM I NITIALIZATION
On power up, a system initialization boot
up procedure commences. Upon
completion of initialization, the screen
message shown here is displayed.
Press SETUP to advance to next screen.
7
Step
BASIC OPERATION (CONT.)
S ELECT C ARD S CREEN
This screen allows selection of frame or device
to control.
Use SEL knob to highlight A2HD516 menu entry,
as shown to right.
Press MENU to advance to next screen.
A2HD516 T OP L EVEL M ENU S CREEN
Top level screen displays status of input and
output signals and major/minor alarm status, as
shown. From this screen you can branch to main
video and audio operation menus.
Press MENU or IDEO to select main video
menu screen.
Press AUDIO to select main audio menu screen.
A2HD516 IDEO - T OP L EVEL M ENU S CREEN
Video configuration menus and sub menus are
accessed through the Video Config screen, as
shown to right.
Use SEL knob to highlight desired menu entry, as
shown.
Press MENU to select desired configuration
menu screen.
A2HD516 A UDIO - T OP L EVEL M ENU S CREEN
Audio configuration menus and sub menus are
accessed through the Audio Config screen, as
shown to right.
Use SEL knob to highlight desired menu entry,
as shown.
Press MENU to select desired configuration
menu screen.
=A2HD516=
Video Out ProcControls
HUE
GAIN
BLACK
CHROMA
0.0 deg
100.0%
0mV
100.0%
Menus are arranged in a tree structure, and in
many instances, selecting an item brings up a
branch menu with additional entries. Often a
menu page has more items than can be shown on
the display lines. To navigate these menus, use
selector (SEL) knob to right of display to scroll
through entries until desired entry is highlighted.
Underscore marks before and after text identify a
text entry that describes the function of the menu
items below it. Example:
–
ideo Config
–
indicates scroll list under entry contains menu
selection options for video configuration function.
Data entry screens allow changes to operating
parameters or adjustments to system settings.
Integrity CS menu structure uses a highlighted
entry to indicate a selectable function modifiable
value. In the example shown here, the value of
all four entries are highlighted, and can be
changed as desired.
P ANEL S ETUP S CREEN
Panel Setup options allow operator to check
status and change panel operating parameters.
To initiate operation of A2HD516, use SEL
knob to highlight Select Frame/Card menu
entry, as shown to right.
Press MENU to advance to next screen.
5
Step
VIDEO/AUDIO CONNECTIONS (CONT.)
A NALOG A UDIO C ONNECTORS
The illustration and chart identify pin out
for a typical 6 pin analog audio connector.
Pin Function
+
G
-
Positive Audio Signal
Shield
Negative Audio Signal
SUPPLIED MATING
AUDIO CONNECTOR
G - G -
WIRE RELEASE
WIRE SLOT

Quick-Start Guide
Part No. 81-9059-0647-0 Rev. B
I NTEGRITY CS S ERIES
A2HD516 P ROCESSOR
M ENU T REE C ONTINUED ON N EXT P AGE
7
Step
BASIC OPERATION (CONT.)
M ENU S CREEN A CCESS C ODE
Certain menus are password protected. When a
protected menu is accessed, password entry
screen is displayed, as shown at right.
Use rotary knobs to set four highlighted digits to
0999, as shown.
Press TAKE to enter password and access
desired configuration menu screen.
USING SIDE COLUMN KEYER
(I F D ESIRED )
8
Step
Your A2 D516 Processor is shipped from the factory with the UDC operating mode selected.
This mode allows the processor to function as an analog or SD-SDI to D converter
WITHOUT using the included side column keyer function.
To use the side column keyer, you MUST provide an D keyer input video signal and change
the processor to the UCP operating mode.
NOTE
If UCP is selected as the operating mode and an D signal is not applied to
the key video input connector, the A2 D516 WILL NOT function properly!!
C ONFIGURING A2HD516 FOR S IDE C OLUMN K EYING
Connect the keyer video source to the Input (IN) 1 BNC on the rear panel of the format
converter module as shown below. This video source must be an D signal.
Access the Change Mode function from the
Video Configuration menu as directed in the
A2 D516 Video Configuration command listing
of the Menu Tree Reference portion of this guide.
Access to the Change Mode function is password
protected, as shown at right.
Use rotary knobs to set four highlighted digits to
0999, as shown.
Press TAKE to enter password and access
Change Mode menu screen.
Rotate the Select (Sel) control (A1) until the
“Switch to UCP” option is displayed, as shown.
Press TAKE to reboot the processor and change
operating mode of processor.
If you wish to return to UDC mode, access
Change Mode and select the “Switch to UDC”
option and press TAKE to change operating
mode.
SIDE
COLUMN
KEYER
VIDEO INPUT
K EYER V IDEO I NPUT (F ORMAT C ONVERTER M ODULE )
IN 1 OUT 1A OUT 1B OUT 2A OUT 2B OPTION BOPTI ON A GENLOCKIN 2
A2HD516 V IDEO C ONFIGURATION
V IDEO C ONFIGURATION M ENU S CREEN
Video configuration menus and sub-menus are
accessed through the Video Config screen, as
shown to right.
Use SEL knob to highlight desired menu entry, as
shown.
Press MENU to select desired configuration menu
screen.
Follow menu tree screen and command listings
below
M ENU T REE R EFERENCE
T HIS PORTION OF THE A2HD516 Q UICK S TART G UIDE PROVIDES A LISTING , INDENTED
BY LEVEL , OF ALL MAIN AND SUB MENUS AND THE ASSOCIATED COMMANDS FOR VIDEO
AND AUDIO CONFIGURATION FUNCTIONS OF THE PROCESSOR .
Video
{Video Config}
Proc Controls (A1 – Hue, A2 – Gain, A3 – Blac , A4 – Chroma)
Hue (A1 to adjust setting)
Gain (A2 to adjust setting)
Black (A3 to adjust setting)
Chroma (A4 to adjust setting)
Color Corrector
White Balance
Red (A2 to change alue)
Green (A3 to change alue)
Blue (A4 to change alue)
Black Balance
Red (A2 to change alue)
Green (A3 to change alue)
Blue (A4 to change alue)
Gamma Balance
Red (A2 to change alue)
Green (A3 to change alue)
Blue (A4 to change alue)
Black
Blk Stretch (A2 to change alue)
Blk L l (A3 to change alue)
CC Memory Sa e
Mem Bank (A2 to select desired memory location)
Press TAKE to sa e settings to memory location
CC Memory Recall
Mem Bank (A2 to select desired memory location)
Press TAKE to recall settings from memory location
Input Select
Input Sel
Input 1,2 (A1 to select desired setting)
OnVidLoss
Off, Black (A2 to select desired setting)
Anlg-SD Select
SDI, Analog-A, Analog-B (A1 to select desired setting)
Output
{Output Config}
Primary Output
Format
A1 to select desired ideo format from listing
Freeze Frame
Frame, Field 1, Field 2 (A2 to select desired setting)
TAKE to set Aspect Ratios
UC-AspRatio
A1 to change alue
DC-AspRatio
A1 to select desired setting
DC-AR TrimH
A1 to change alue
DC-AR TrimV
A1 to change alue
Sec Asp Ratio
4X3-Crop, 4X3-Squeeze, 16X9-Lbox
A1 to select desired setting
HD Config
{HD Config}
HD CloCap
Off, On (A1 to select desired setting)
HD TimeCode
Off, On (A1 to select desired setting)
{HD Timing}
HD H Phase
A1 to change alue
HD V Phase
A1 to change alue
HD H Video Pos
A1 to change alue
HD V Video Pos
A1 to change alue
SD Config
{SD Config}
SD CloCap
Off, On (A1 to select desired setting)
Translate Timecode
Off, On (A1 to select desired setting)
SD Legalizer
Luma Limit
Off, Loose, Nominal, Tight
A1 to select desired setting
Encoded Limit
Off, Loose, Nominal, Tight
A1 to select desired setting
RGB Limit
Off, Loose, Nominal, Tight
A1 to select desired setting
VBI Legalizer
Is Off, Follows Main
A1 to select desired setting

Quick-Start Guide
Part No. 81-9059-0647-0 Rev. B
I NTEGRITY CS S ERIES
A2HD516 P ROCESSOR
M ENU T REE R EFERENCE (C ONT .)
M ENU T REE C ONTINUED ON N EXT P AGE
Eng Config
Password Prompt Screen
Use A1, A2, A3, A4 to select “0999”
Press TAKE to proceed to Eng onfig screens
{Engineering Cnfgs}
Frame onfig
Set Frame IP
A1 moves cursor left and right to select digit to change
A2 to change value of highlighted digit
Reboot Frame
Password Prompt Screen
Use A1, A2, A3, A4 to select “0999”
Press TAKE to initiate frame reboot
Status
Status display of frame operating parameters
Press TAKE to refresh
{Module1 Cnfgs}
Vid Processing
Full YUV Gamut
ON, Off (A1 to select desired setting)
Press TAKE to advance to next menu
NoiseReduce
On, Off (A1 to select desired setting)
NR Level
A1 to change value
Detail Enh
A1 to change value
{Module2 Vid Cnfgs}
Test Patterns
Test Pattern (A1 to select desired test pattern from listing)
Dynamic Filters
En/Dis (Press TAKE to enable/disable dynamic filter)
oring (A1 to change value)
Luma Filter
Wide, Soft, Shaped, Dynamic (A2 to select desired setting)
hr Filt
Flat, Shaped Dynamic, Flat Dynamic (A3 to select desired
setting)
Averaging
Off, Forced, High, Medium, Low (A4 to select desired setting)
Video-In Proc
Hue (A1 to adjust setting)
Gain (A2 to adjust setting)
Black (A3 to adjust setting)
hroma (A4 to adjust setting)
{Analog In Config}
omb Mode
Off, Line Adaptive, Frame Adaptive, Normal
A1 to select desired setting
omb Sensitivity
Frame In-Ph (A1 to change value)
Frame Out-Ph (A2 to change value)
Line In-Ph (A3 to change value)
Line Out-Ph (A4 to change value)
Video TB
Off, On, Auto (A1 to select desired setting)
Video AG
Off, On (A1 to select desired setting)
{Additional Config}
Video Standard
Displays current operating video standard: NTS /525 or PAL/625
Press TAKE to toggle between NTS and PAL standards
Video Timing
Genlock
Genlock Status
Genlock Source Status Display (OK)
Genlock Source
Frame onnector, Board onnector
A1 to select desired source
Genlock Timing
V Phase (A1 to change value)
H Phase (A2 to change value)
Video Pos
H Video Pos
A1 to set desired position
V Video Pos
A1 to set desired position
Freeze Mode
Frame, Field 1, Field 2 (A1 to select desired setting)
onfigure VBI
onfig Line/Field
10/1, 10/2….22/1, 22/2 (A1 to select desired setting)
Signal
A2 to select desired signal type from listing
Setup
0.0, 7.5 IRE (A3 to select desired setting)
omb
Off, On (A4 to select desired setting)
User Reset
Press TAKE to initiate User Reset
{SD Timing}
SD H Phase
A1 to change value
SD V Phase
A1 to change value
SD H Pos
A1 to change value
SD V Pos
A1 to change value
Genlock Source
Frame onnector, Board onnector
A1 to select desired source
Frame Rate
A1 to select desired frame rate setting
Test Pattern
A1 to select desired test pattern output from listing
Encoder Mode
On, Test Bars, Off (A1 to select desired setting)
Noise Reduction
Recursive Filter
Off, Auto, High, Low (A1 to change value)
Measured SNR (display)
ot Switch
A1 to select desired Hot Switch action from listing
Status and Alarms
OvrTempThr
Over Temperature Alarm Threshold (A1 to change value)
Error Secs
Press TAKE to reset error seconds display
User Reset
Press TAKE to initiate User Reset
Change Mode
Password Prompt Screen
Use A1, A2, A3, A4 to select “0999”
Press TAKE to proceed to hange Mode screen
hange Mode
UD , U P (A1 to select desired setting)
Press TAKE to toggle mode selection
Info
Module 1 Info
Displays operational parameters for selected module
Frame Info
Displays operational parameters for chassis frame

Quick-Start Guide
Part No. 81-9059-0647-0 Rev. B
I NTEGRITY CS S ERIES
A2HD516 P ROCESSOR
M ENU T REE R EFERENCE (C ONT .)
M ENU T REE C ONTINUED ON N EXT P AGE
Lip-Sync
Tracking
Slow, Medium, Fast (A1 to select desired setting)
Add Offset (A2 to change value)
Tone Gen Freq
Tone en 1 (A1 to select desired operating frequency)
Tone en 2 (A2 to select desired operating frequency)
Tone en 3 (A3 to select desired operating frequency)
Tone en 4 (A4 to select desired operating frequency)
Tone Gen Level
Tone en 1 (A1 to change value)
Tone en 2 (A2 to change value)
Tone en 3 (A3 to change value)
Tone en 4 (A4 to change value)
Embed Enable
On, Off (A1 to select desired setting)
{Adj Audio Board}
DeEmbed to DAS
None, rp 1, rp 2, rp 3, rp 4 (A1 to select desired setting)
Embed DAS Audio
None, rp 1, rp 2, rp 3, rp 4 (A1 to select desired setting)
Audio onfig (Ext 1)
Output Sources
Chan (A1 to select channel 1 to 16)
IsSource (A2 to select source from listing)
SumWith (A3 to select source from listing)
SumBalance (A4 to change value)
AES Sources
AES-1.1 (A1 to select source from listing)
AES-1.2 (A2 to select source from listing)
AES-2.1 (A3 to select source from listing)
AES-2.2 (A4 to select source from listing)
han Lvl-Mute-Ph
Audio Out Level (A1 to select group containing channel to adjust)
(Using Chan 1...4 entry for reference)
Ch 1 (A1 to change value)
Ch 2 (A2 to change value)
Ch 3 (A3 to change value)
Ch 4 (A4 to change value)
Audio Out Mute (Same steps as Audio Out Level, above)
Audio Out Phase (Same steps as Audio Out Level, above)
Bank Lvl-AL -Lim
Bank Level
Bank 1 (A1 to change value)
Bank 2 (A2 to change value)
Bank 3 (A3 to change value)
Bank 4 (A4 to change value)
ALC
Bank Select 1-4(A1 to select bank)
ALC Enable
Off, On (A2 to select desired setting)
ALC Level (A3 to change value)
ALC Rate (A4 to change value)
Limiter
Bank Select 1-4(A1 to select bank)
Lim Enable
Off, On (A2 to select desired setting)
Lim Level (A3 to change value)
Lim Rate (A4 to change value)
Bank Config
(A1 to assign groups to bank 1)
(A2 to assign groups to bank 2)
(A3 to assign groups to bank 3)
(A4 to assign groups to bank 4)
Lip-Sync
Tracking
Slow, Medium, Fast (A1 to select desired setting)
Add Offset (A2 to change value)
Analog In Gain Trim
Analog In 1 (A1 to change value)
Analog In 2 (A2 to change value)
Analog In 3 (A3 to change value)
Analog In 4 (A4 to change value)
Tone Gen Freq
Tone en 1 (A1 to select desired operating frequency)
Tone en 2 (A2 to select desired operating frequency)
Tone en 3 (A3 to select desired operating frequency)
Tone en 4 (A4 to select desired operating frequency)
Tone Gen Level
Tone en 1 (A1 to change value)
Tone en 2 (A2 to change value)
Tone en 3 (A3 to change value)
Tone en 4 (A4 to change value)
Embed Enable
On, Off (A1 to select desired setting)
A2HD516 A UDIO C ONFIGURATION
A UDIO C ONFIGURATION M ENU S CREEN
Audio configuration menus and sub-menus are
accessed through the Audio Config screen, as
shown to right.
Use SEL knob to highlight desired menu entry, as
shown.
Press MENU to select desired configuration menu
screen.
Follow menu tree screen and command listings
below
Audio
{Audio Config}
Audio onfig (Demb)
Output Sources
Chan (A1 to select channel 1 to 16)
IsSource (A2 to select source from listing)
SumWith (A3 to select source from listing)
SumBalance (A4 to change value)
han Lvl-Mute-Ph
Audio Out Level
A1 to select group containing channel to adjust
(Using Chan 1...4 entry for reference)
Ch 1 (A1 to change value)
Ch 2 (A2 to change value)
Ch 3 (A3 to change value)
Ch 4 (A4 to change value)
Audio Out Mute (Same steps as Audio Out Level, above)
Audio Out Phase (Same steps as Audio Out Level, above)
Bank Lvl-AL -Lim
Bank Level
Bank 1 (A1 to change value)
Bank 2 (A2 to change value)
Bank 3 (A3 to change value)
Bank 4 (A4 to change value)
ALC
Bank Select 1-4(A1 to select bank)
ALC Enable
Off, On (A2 to select desired setting)
ALC Level (A3 to change value)
ALC Rate (A4 to change value)
Limiter
Bank Select 1-4(A1 to select bank)
Lim Enable
Off, On (A2 to select desired setting)
Lim Level (A3 to change value)
Lim Rate (A4 to change value)
Bank Config
(A1 to assign groups to bank 1)
(A2 to assign groups to bank 2)
(A3 to assign groups to bank 3)
(A4 to assign groups to bank 4)

Quick-Start Guide
Part No. 81-9059-0647-0 Rev. B
I NTEGRITY CS S ERIES
A2HD516 P ROCESSOR
M ENU T REE R EFERENCE (C ONT .)
{Configuration}
Delay Setup
CHANNEL
All, A1, A2, A3, A4, D1, D2, D3, D4 (A1 to select desired setting)
Tracking
Internal, None, Ext TTL1, Ext TTL2 (A2 to select desired setting)
lew Rate
low, Medium, Fast (A3 to select desired setting)
Offset (A4 to change value)
Embedding
Embed to Group
Group1, 2, 3, 4, None (A1 to select desired setting)
Headroom
Analog 1 (A1 to change value)
Analog 2 (A2 to change value)
Analog 3 (A3 to change value)
Analog 4 (A4 to change value)
Test Tone Config
CHANNEL
A1, A2, A3, A4, D1, D2, D3, D4 (A1 to select desired channel)
Frequency (A2 to change value)
Level (A3 to change value)
AES Config
Output ample Rate
32, 44.1, 48, 96 kHz (A1 to select desired setting)
Output Word Length
16, 20, 24 bits (A1 to select desired setting)
Output ample Ref
AE Blk, Video (A1 to desired setting)
Audio Config (Ext 2)
{ nput Control}
nput Gain A1 A2
Linking
Mono, tereo (A1 to select desired setting)
Gain A1 (Mono), Gain ( tereo), A2 to change value
Gain A2 (Mono), Balance ( tereo), A3 to change value
nput Gain A3 A4
Linking
Mono, tereo (A1 to select desired setting)
Gain A3 (Mono), Gain ( tereo), A2 to change value
Gain A4 (Mono), Balance ( tereo), A3 to change value
nput Gain D1 D2
Linking
Mono, tereo (A1 to select desired setting)
Gain D1 (Mono), Gain ( tereo), A2 to change value
Gain D2 (Mono), Balance ( tereo), A3 to change value
nput Gain D3 D4
Linking
Mono, tereo (A1 to select desired setting)
Gain D3 (Mono), Gain ( tereo), A2 to change value
Gain D4 (Mono), Balance ( tereo), A3 to change value
Phase/Mute/Bypass
CHANNEL
A1, A2, A3, A4, D1, D2, D1-D2, D3, D4, D3-D4
A1 to select desired setting
Phase
Normal, Invert (A2 to select desired setting)
Mute
Off, On (A3 to select desired setting)
Bypass
Off, On (A4 to select desired setting)
{Routing Config}
Routing Presets
Cfg-A, Cfg-B, Follow-VideoIn (A1 to select desired setting)
Dig Source
Group 1, Group 2, Group 3, Group 4, BNC
A1 to select desired setting)
Source
Output Chan
A1, A2, A3, A4, D1, D2, D3, D4
A1 to select desired setting
ource
A1, A2, A3, A4, D1, D2, D3, D4, Tone
A2 to select desired setting
um With
A1, A2, A3, A4, D1, D2, D3, D4, Tone
A3 to select desired setting
IN THE EVENT OF TROUBLE
If you have any problems with or questions about your QuStream A2HD516 video
pro essor, onta t QuStream Customer Servi e by phone or e-mail.
Customer ervice: 1+ [phone]
Toll Free: [phone] (U and Canada)
Fax: 1+ [phone]
Email: [email protected]om
