Pescador P330-HF User manual

Fishing Boats
Owner’s manual
EN

Dear customer,
Congratulations on your purchase of the P330-HF. We are proud to bring you a quality product at an affordable price with
excellent performance. Please take the time to read through this manual. It contains details of the P330-HF, its equip-
ment, and information on its operation and maintenance. Familiarize yourself with this inflatable before using it on the
water in order to ensure safety and to prevent accidents.
Indicates an imminently hazardous situation which, if not avoided, could result in death or serious injury
or property damage.
There is a risk of serious injury or death from drowning. Fishing sports and boating can be very dan-
gerous and physically demanding. The user of this product acknowledges, understands, and assumes
the risks involved. Observe the following safety standards and safe operating practices whenever using
this product.
• Always wear an approved personal flotation device.
• Get informed on local regulations and hazards related to water activities and boat operation.
• Do not exceed maximum weight capacity. Regardless of the number of persons on board, the
total weight of persons and equipment must not exceed maximum weight capacity.
• Do not operate the P330-HF under the influence of drugs or alcohol.
• Do not fish alone.
• Children must be supervised by a responsible adult at all times.
• Dress appropriately for weather and marine conditions; cold water and cold weather can result
in hypothermia.
• Beware of offshore winds and currents as they can take you out to sea.
• Check weather forecasts and obtain local knowledge of the marine environment and weather
conditions prior to your voyage.
• Be aware of safe river water levels, tidal changes, currents, and obstacles in and above the water.
• Check your equipment prior to each use for signs of wear, leaks or failure.
• Tie a leash to your oars when appropriate.
• Always inform someone of your fishing route, the time and place of your departure and your
intended time and place of arrival.
• Always carry identification.
• Do not fish in flood conditions.
• Make sure you are able to exit the craft if necessary.
• Scout unfamiliar waters; portage where appropriate.
2

P330-HF
• Material: 1000 Denier Polyester
with double side PVC coating
0.9 mm thick
• 1 front carrying towing
rope (7,50 m)
• Front D-Rings (2 pcs)
• 2 aluminum oars
• 2 x aluminum bench seats
• Foot pump
• Floorboard no. 1, 2, 3, 4
• Pressure Gauge
• High pressure valves (4)
• Self bailing drain valve
• 1 rubbing strakes
• 1 marine Plywood transom
• 2 Life lines
• 6 front strip handles
• 1 carry bag
• 1 Repair kit
• Owner’s manual
3
Standard Equipment
Front carry handle with rope
Front D-Rings (2 pcs)
Bottom keel protection strake
Life Line
Lateral rubbing strake
Oar locks
Oar holders
Alu oars (132xm - 2 pcs)
Capacity plate
Rod holder (2 pcs)
Handles
Marine Plywood transom
Floorboards
Aluminium side-in seat
Self bailing
drain valve
Strip handles
Alu adjustable bench
seats (2 pcs)
Keel valve
Motor plate
Technical features
330 151 41228 x 68 3+1
(keel)
4+1 550/
1212
15 HP =
11 kW
56 ISO 6185
Part 2
Type V
Cat. C
Lenght
(cm)
Width
(cm)
Width
inside
(cm)
Tube
diameter
(cm)
Nr of
chamber
Max.
persons
Capacity
(kg/Lbs)
Max. motor
capacity
Weight
(kg)
Standard

Assembly
General procedure
1. Remove any sharp objects from the area where the boat will be assembled and inflated.
2. Unfold and spread out boat flat.
3. Half inflate the boat with pump first.
4. Assemble floor as per Floorboard Assembly Instruction and diagram here after.
5. Assemble alu bench seat.
6. Fully inflate.
7. Check the valves and close carefully to make sure there are no leaks in valves.
Model P330-HF
1. Place floorboard Xat bow part and [into transom of the boat
* Make sure that keel valve is located at the center of X board’s hole and join all floorboards thanks to H connectors/
joints
2. Insert Yfloorboard into X
3. Insert Zfloorboard into Y
4. Press down at the same time to be jointed well and flatly.
Note 1: when installing floor panel, identifying numbers of boards must be face up.
Note 2: Each “H” joint should be installed with larger flat side facing up.
4
Floorboard Assembly Instruction
Assembly instruction / Inflation / Deflation
Inflate your PESCADOR P330-HF with a pump from AQUATEC Europe or any pump designed for inflatable boats, and
other low pressure inflatables. These types of pump will have a hose and adapters to fit the valves on this PESCADOR
P330-HF.
1. Side tube valve(s) and drop stitch floor valve – please see corresponding:
Unscrew the valve cap(1). Push button(2) in and turn approximately 90 degrees so it is
in the “OUT” position. Insert the pump hose end piece and inflate it until you will reach
the required pressure. After inflation tighten all the valve caps (clockwise). Only the
valve(s) cap can ensure final AIR TIGHTNESS. To release air from the side tubes and
bottom floor tube, remove the valve cap (1) and push button(2) in and turn approxima-
tely 90 degrees so it is in the “IN” position.
2. Max. air pressure : the correct pressure for this item is: Side tube valve(s):
0,25 bar / 3,60 psi (= 250 mBar ). Do not exceed it.
Any use of an air compressor may result in poor performance or damage to the PESCADOR P330-HF, and automatically
voids all warranties. If you leave your PESCADOR P330-HF exposed to the hot sun, check the pressure and deflate it
slightly. Otherwise the PESCADOR P330-HF may become over inflated and stretch the material. The ambient tempera-
ture affects the tube’s internal pressure : a variation of 1°C/ 1.8°F causes a variation of the pressure in the tube of +/- 4
mBar (0.06psi).

5
Floorboard Assembly Instruction
(A) Positionnez chaque plancher dans le fond du bateau
(C) Appuyez chaque plancher à fond pour avoir une surface plane
Plancher Plancher PlancherPlancher
(B) Installez les "connecteur H" en alu entre chaque planche
(D) Installez les 2 longerons pour stabiliser les panneaux (comme indiqué sur le schéma)
A. Place each floorboard inside the boat
B. Insert floorboard into alu ‘H’ joint attached to floorboard
C. Press down the ‘H’ and floorboard at the same time to be jointed well and flatly
D. Insert the two long connector
Floorboard Floorboard Floorboard Floorboard

Motor installation
Disassembly / Maintenance
The maximum rated horsepower for our Fishing Boats are:
Read the instruction manual supplied by the outboard motor manufacturer. All outboards are slightly different, and some
require special installation procedures. Below is a general outline:
• Set the motor on tilt and tilt the mounting bracket.
• Place the motor in the center of the transom.
• Screw the mounting brackets securely to the transom.
1. To deflate the P330-HF, remove the valve cap from the valves in the side tubes.
2. Clean and check the P330-HF as well as all the accessories. Make sure the P330-HF is
completely dry before putting it away. Make sure that no sand nor gravel remains inside theP330-HF:
this could result in abrasion or even punctures while storing the P330-HF.
3. Remove bench seats.
4. Remove side joiners from floorboards.
5. Raise the middle panel and detach from “H” joints.
6. Remove floor panels, remove bow and transom floorboards.
7. Fold the 2 sides into the middle, then roll it up from the opposite end of the valves making sure the two rear cones
are folded towards the transom (so remaining air can escape from the valves).
8. When storing your boat, keep it in a clean and dry place.
9. Roll the boat from either end and place in carry bag along with equipment.
Note: If you install a motor larger than the maximum rated horsepower for your boat, you might have
control problems and risk serious injury. Never exceed the maximum rated horsepower.
Note : If the mounting brackets are not tightly secured to the transom, the motor could loosen in use or
even fall from your boat. Make sure they are tight.
6
P330-HF
• Max HP: 15 / 11 kW
Whenever you take your P330-HF out of the water and deflate it, allow time for it to air out and dry.
Neither the skin/hull or the inside chambers will suffer from water damage, but stagnant water could
cause mildew and foul odor.

How to repair small punctures
Warranty Registration Card
Check that the tube is fully deflated and lies flat.
1. Prepare a round patch no less than 3 inches or 7 centimeters in diameter.
2. Clean the patch and the area surrounding the leak with Alcohol.
3. To contain excess glue, use masking tape to tape off the area around the patch.
4. Apply 3 thin, even coats of repair kit adhesive to both the surface of the P330-HF and the patch.
Wait 5 minutes between each coat.
5. After the 3rd coat, wait 10-15 minutes before applying the patch. Use a hand roller to apply the patch evenly.
Pay special attention to the edges.
6. Wait 24 hours before re-inflating.
1. General
Please fill out and mail in the Warranty Registration Card supplied in your order right away. You will void your warranty
by not filing the registration card with us. Be sure to enter the Serial #(HIN code = the 12 digit number) you will find on
the capacity plate.
2. Care and Preservation
There is very little that you have to do to keep your boat in good condition for many years. You may store it inflated or
deflated. If you leave it outside, raise it up off the ground. If it is going to be in direct sunlight or exposed to leaves, berries
or rain, cover it with a tarp (we do not recommend hanging the boat). If you leave it in the water, you will probably have to
drain out rainwater at times. If you store it in a closet, basement or garage, we suggest you pick a cool, dry spot, making
sure the boat is clean and dry before you pack it up - or mold can accumulate. That is all you need to keep your boat
in mint condition for years to come. Most dirt can be removed with a garden hose, a sponge and mild soap. SoftScrub
works exceedingly well. Do not sprinkle with powders. Do not store in an area where it is likely to be exposed to extreme
temperatures (above 60°C or below -12°C).
7
• Perform all of your repairs in a well-ventilated area.
• Avoid inhaling glue vapors.
• Avoid contact with the skin or the eyes.
• Keep all repair materials (glue, solvents, etc) away from the reach of children.
• The repairs on the welds must not be glued. Only the manufacturer of the P330-HF
can perform repairs on the welds themselves.

8
10/15
Guarantee / Warranty
Warranty Registration Card
AQUATEC Europe - 6 rue de l’Europe - F-68500 Bergholtz
Tel : [phone] – Fax : [phone]
Mail : [email protected]
We (“AQUATEC Europe”) shall warrant the new products, accessories and parts manufactured to be free from defects in material and
workmanship, and this warranty shall not cover any commercial and/or professional use of Products.
1. This Warranty Period for the Products is counted from the shipment date of COMPANY and is specified hereunder:
XThe base of fabrics : Two (2) years
YSeam constructions : Two (2) years
ZWorkmanship : Two (2) years
[Accessories & parts : One (1) year
2. The owner’s registration form is the only valid registration identification. If any Products are found to be defective, Customer shall
return to the distributor or AQUATEC Europe for inspection and/or repair as instructed with a copy of the registration form.
3. AQUATEC Europe’s obligation under this warranty shall be limited to, at its option, either repair or replace the same without charge or
provide a credit or refund based on the original price, or less a reasonable amount for actual use. Except as expressly agreed between
both Parties, Customer must return Products for repair at its own expense. The return transportation of the repaired or replaced Products
from AQUATEC Europe to the destination by Customer shall be paid by AQUATEC Europe.
4. Since this warranty applies to defects in material and workmanship, it does not apply to normal wear and tear of fabric or to damage
caused by:
a) neglect, lack of preventive care, modification, accident, abnormal operation, unauthorized repairs, use in a manner not in accordance
with applicable Specifications, racing competition,
b) use of any accessories or parts not manufactured or supplied by AQUATEC Europe.
This warranty does not apply to the haul out, launching, storage charge, telephone or rental charge, inconvenience or less of time and
income.
All incidental and consequential damages are excluded from this warranty. Implied warranties are limited to the life of the warranty.
This card must be completed and signed, and returned to your dealer within 10 days of date of purchase in order for the warranty on
your new fishing boat to be valid.
Customer
Address
City Country Zip
Phone Date of Purchase
Dealer
City Country Zip
Model Serial #
By signing this warranty card, I acknowledge that I have read and understand all cautions and warnings relating to the use of this product,
and I understand that any occupants or users of this product risk injury or death.
Customer Signature Date
