Pet Essentials Deluxe Cat Tree User manual

G
E
B
A
C
F
D
D
Sisal Post Size Chart
A
A
Deluxe Cat Tree
Assembly
Instructions
Level 2
Base
Level 1
(Base)
Large
Condo
Perch 3
Perch 2
Ramp
Perch 1
1. Attach three Aposts
to the base with 3
bolts.
Small
Condo
Deck
2. Rest assembled
small condo on top of
sisal posts attached
to base.
3A. Using 2 double thread rods,
attach Bpost to the left of the
small condo deck and Cpost to
the right side.
3B. Place 1 Dpost on top of small condo roof
and secure with 1 Bolt from inside. Install 1
double thread rod to the top. Reach into the
small condo and secure the Apost below
with 1 bolt. Rest on top deck as shown.
Deck
4B. Place large condo on top of
posts as shown. Reach inside
condo and secure with 2 bolts.
4A. Place 1 Dpost to right side of
deck and secure onto the
exposed end of the double
threaded rod. Install 1 double
threaded rod to the left side of
deck.
5. Secure Esisal post onto the exposed end of the
double threaded rod. Install Posts Gand F to the top of
the large condo as shown. Secure with 2 bolts. Attach
perches as shown. Completed Deluxe Cat Tree
12
3
4
5
Phase Two: Final Assembly
Build the Level 1 (Base)
A A
A
B C
D
Deck
If you need assistance with this product or replacement parts,
do not return your item to the store. Please call 800-955-2879.
We are happy to help and appreciate your purchase.

Completed Large Condo
Assembly takes approximately one hour
Parts List:
Platforms and Condos
Towers and Hardware
8.75” - 4 Pieces Each
10.50” - 4 Pieces Each
Phase One: Building the Condos
Step One: Build Level Two, Small Condo
8 Wingnuts
9 Pieces
1 Piece
Double
Treaded Rods
4 Pieces
Allen
Wrench
Cat Perch, 2 Pieces
Cat Perch
with Back, I Piece
A: 9.75” Sisal Post, 3 Pieces
B: 10.75 “ Sisal Post, 1 piece
C: 14.625” Sisal Post with bolt,
1 piece
D: 3.125“ Sisal Post, 2 pieces
E: 13.75“ Sisal Post with bolt,
1 piece
F. 11.50“ Sisal Post with bolt,
1 piece
G: 8.625“ Sisal Post with bolt,
1 piece
Double Threaded Metal Rods
Small Condo Top,
1 piece
Level 2
Small Condo Base,
1 piece
Ramp, 1 piece
Large Condo Base,
1 piece
Large Condo Top,
1 piece
1. Attach 8.75” threaded
dowels
into smooth side of
small condo roof.
Smooth Side
Smooth Side
2. Place all 4 side
panels of small condo
in place, as shown.
3. Align the Level 2 Base on
top of the bottom side of
the Small Condo, as shown.
4. Secure with 4
wingnuts and flip right-
side up.
5. Attach ramp with
Large Bolt (only 1 bolt that size is provided).
Set aside.
Step Two: Build Large Condo
1. Attach 10.50”
threaded dowels
into smooth side of
Large Condo roof.
2. Place all 4 side
panels of Large Condo
in place, as shown.
3. Align the Large Condo Bottom
piece to the bottom side of the
Large Condo, as shown. Bottom
should be smooth-side up.
4. Secure with 4 wingnuts
and flip right-side up. Set
aside.
Smooth Side
Completed Small
Condo
123
45
12
3
4
Small Condo Side,
2 pieces
Small Condo Side,
2 pieces
Large Condo Side,
1 piece
Large Condo Side,
1 piece
Large Condo End,
2 pieces
Main Base,
1 piece
Deck Between Condos,
1 piece
