Pettecc SF 106 User manual

SMART PET
FEEDER
SSSSF
SF 106

Please scan the suitable QR code
from start up guide included
with your PETTECC SF106 or
directly from the outer box your
Smart Feeder is Packaged in.
Alternatively please download
APP in APP store or Google Play
Jjj
kkkkk
Please allow App to get the
location information and
network access to calibrate the
current time when installing
app.
Once App is downloaded please
register your PETTECC SF106
Smart Feeder.

Connecting your PETTECC SF106 Smart Feeder
Please plug in power adaptor and turn on the
switch at the bottom of the product
After the power indictor is on, hold the “SET”
button on the operation panel until “LINK”
indicator starts blinking and a chime sounds
Click “NEXT to connect WIFI (make sure your
mobile devise is connected to WIFI and
connection is good) When phone is connected to
WIFI, WIFI name will be displayed automatically.
Input WIFI password and click next. Click next to
enter device WIFI connection. Go to your WIFI
setting page and choose a connection with
PETTECC in the name. If using IOS system return
to the
to the APP from the top left corner or re-
entering APP on main menu. Please note if you
have Android return directly to the APP. Both
Smart phone & feeder are now connected to
WIFI. Now connect Smart phone to pet Feeder.
menu

Click “Next” it will show that the smart phone is
connecting to pet feeder.
Connecting time varies depending on the
networks situation.
Click done to finish connection.
You will now enter the main operation interface
T

Click “Video” to enter the corresponding operation
interface. monitoring, video recording and images
Video function

Press and hold “Manual feeding” until another feeding
interface appears to enable instant feeding. Click icon
to select portions. Or Press “SET” key once on the smart
pet feeder to feed manually.
Manual feeding function

If you would like the feeding process accompanied with
voice recording please record in advance. Click the top right
icon and enter recording setting and then record message
Click “+” icon to add feeding meals and then set the
corresponding feeding time and feeding portion. Press and
hold the existing meal setting to delete the previous setting
content.
Automatic feeding setting

Click the top right menu to enter “Share” interface. Photos
and videos can be shared on Facebook, Twitter, We chat
Sharing function

Other setting
Recording, data storage location (Phone or SD Card) selection,
device unbinding, feeding history view and APP version upgrade can
all be achieved when enter the top right menu.
Other Settings
Recording, data storage location (phone or SD Card)
selection, device unbinding, feeding history view and
APP version upgrade can all be accessed via top right
of the menu

FAQ
1. What should we do when
the smartphone cannot
connect to the pet feeder?
1). Check the status of
power indicator. In normal
situation, the “Power”
indicator is on and “Link”
indicator flashes.
2). Check the WIFI signal
from the pet feeder.
Search for WIFI signal from
the pet feeder with phone to
confirm whether there is a
WIFI signal such as
“PETTECC_XXXXXX”.
3). Upload the APP and
reload it.
Please make sure to
authorize the APP to get
access to the position
information and network
during the APP installation.
Please operate according to
the above procedures and

enter the correct WIFI
passwords.
2. Sometimes My Android
phone connects to
PETTECC_XXXXX
automatically but sometimes
it does not.
There may be SSID around
which could course
interference to the
connection to the Pet feeder
WIFI. Enter “phone setting”
option to connect manually.
3. Why is my timed feeding
not running smoothly?
1) Check the food outlet of
the pet feeder. If food outlet
is blocked the alarm indicator
will flash –Is the
recommended food size being
used? –also check that the
motor is clear of pet food.

4. Why does the feeding time
need to be 3 minutes later
than the current time?
It can take up to 3 minutes for
the setting data on the APP to
upload to the server
5.How can we reconnect to
the pet feeder quickly when
the APP is disconnecting due
to poor networking?
1) Exit the APP and then log in
again and wait for data
update or switch the feeding
interface to video interface
and wait for video refresh
6. SD card capacity and
Images and video storage
position.
SD card –supports 32GB and
the storage position (SD card
or phone) can be set on the
phone.

7. Upgrade Management
The App will remind users to
upgrade as required.
To upgrade APP –Firmware
upgrade –more settings –
device management –
firmware Ver.. –upgrade
Please update the software
when asked. It will take
about 8 minutes to upgrade
the software –please do not
turn off power or disconnect
network during upgrade.
