PetTeck PF-18 User manual

8
Notes & FAQ:
a) When the bowl is rotating both the clock setting and mode setting are not allowed
b) Under clock display mode the colon icon (:) will flash. The colon icon (:) is turned
Off when in feeding timer mode
c) A PM icon will be displayed in the afternoon under 12-hour clock mode and turned
off in the AM. The PM icon will not be displayed under 24 hour clock mode
d) In feeding timer mode, three numbers will show up, the first number is the feeding
number (1,2,3,4,5 or 6) and last two digits indicate the feeding time in hours
e) When the feeding timer starts, the BELL icon will turn On. Under feeding-timer
display mode a solid BELL icon means the feeding time has already passed. A
flashing BELL icon means the feeding time has not been reached. This lets the
user know how many feedings are left for feeding
f) If the time for the next feeding is set earlier than the present feeding time, the
feeding will start the next day
g) If the Mode key is pressed and held for more than 2 seconds the number will
rapidly increase automatically until you release the key. When number reaches its
maximum, the number will fall back to the minimum value and start increasing
again
h) If the feeding timer has already begun, pressing the START key will reset the
timer and begin again from the 1st feeding-time set
i) If START TOMORROW key is pressed, both the BELL and Zz icon will be ON.
The Zz icon will turn OFF at 0:00 midnight to indicate the timer has started
j) START TOMORROW is used should you want to set your feeder up today and
have it start tomorrow. This is good for when you have programmed feeding times
that have yet to pass so you can prepare in advance for a possible trip or just
being away the next day and not wanting the feeder to run the day you
programmed it
Rev-1.1
1
Quick Start Guide
Automatic 6 Meal LCD Clock Pet Feeder (PF-18)
Control Panel Keys
MODE - switches between clock or feeding time display. Also increases clock time
during clock / feeding time Set mode
SET – enters settings mode. Also confirms the time you enter and advances to
next setting
START NOW – starts the feeding timer immediately
START TOMORROW- starts the feeding timer the next day
REC – records your personal voice message
PLAY – plays back your recorded voice message
ON SWITCH – turns the feeder on / off. For when the feeder will not be used for
an extended period of time. Turning this switch off will RESET all time and feeding
settings
Getting Started
1. Carefully turn the pet feeder upside down. Remove both battery doors by
squeezing the two tabs and gently pulling each door away
2. Keep the ON switch set to OFF
3. Insert four C size alkaline batteries into the battery tray. Do NOT use old or
-cheap- carbon batteries
4. Close the battery doors, rotate the feeder right-side up and switch ON
5. The feeder will cycle one time until “12:00” is on the LCD display
Note: Your pet feeder makes the food available in this sequence: Tray 1, Tray 2, Tray
3 to Tray 6. When you want only one feeding, you should fill only Tray 1; for only 2
feedings, fill Trays 1 and 2 and so on.
1. Setting the current Clock time
1) During Clock display mode, press and hold the SET key for (2 seconds) to enter
Clock SET mode. The hour number will now be blinking
2) Press the MODE key to increase the hour. Once you have set the hour, press the
SET key to confirm the hour. The minute number will now blink
3) To change the minute number, press the MODE key to increase the minute. Once
you have set the minute, press the SET key to confirm the minute. Both the hour
and minute numbers will now blink
4) If needed, Press the MODE key to change between 12 or 24 hour time.
5) Press the SET key to confirm your current time setting and the numbers will stop
blinking

2
2. Setting the Feeding Time
1) After setting the clock time, press the MODE key one time. (1 1) will show on the
display. This is the feeding-time display mode.
2) Now press and hold the SET key for (2 seconds) to enter Feeding time SET
mode. Feeding will start from the first feeding number & time. The 1st digit shows
the feeding number (Food Tray 1)
3) The hour digit will now blink (2nd and 3rd digit). Press the MODE key to increase
the time, then press the SET key to confirm the time you set
4) After confirming the 1st feeding time, the next feeding number & time will show on
the display. (1st digit will change to the next feeding number, e.g. 2 or 3 or 4 or 5 or
6 and back to 1) To change the feeding time, repeat step-3
5) Repeat step-3 until all 6 feeding times are set. The display will change back to
clock display mode when all 6 feedings have been set
Program examples:
1) Feed once a day at 13:00hr (24hrs display) and feed for 6 days
Feed time 1 & 2 & 3 & 4 & 5 & 6 all equal = 13:00hr
2) Feed twice a day at 10:00 and 20:00 and feed for three days
Feed time 1 = 10, feed time 2 = 20, feed time 3 = 10, feed time 4 = 20, feed
time 5 = 10 and the last time 6 = 20
3) Feed three times a day at 6:00am, 12:00 and 18:00 (6:00pm)
Feed time 1 = 06, feed time 2 = 12, feed time 3 = 18 and so on…
3. Review and Start the feeding timer
1) Use the MODE key to cycle through clock and your set feeding times (clock - then
1st feed time→2nd feed time→3rd feed time→4th feed time→5th feed time→6th
feed time→back to clock…) The sequence will repeat
2) Press the START NOW key to start the feeding timer immediately. The bowl will
rotate to the pre-set starting position (Tray 6) and your recorded message will play
once. The BELL icon will now be On
3) Or press the START TOMORROW key and the feeding timer will start at 0:00-
Midnight. The bowl will rotate to the pre-set starting position (Tray 6) and your
recorded message will play once. The BELL and Zz icon will now be On
Bell
Hours Minutes
Start
Tomorrow
PM
1s
t
digit 2n
d
digit 3r
d
digit
Feeding
Numbe
r
Feeding
Time
7
LOCK-(marked F on diagram) – Used to lock the LID to the FEEDER BASE. Push
in the middle of each LOCK and pull up using your fingertips to remove LID.
FEEDER BASE-(marked G on diagram) – Place the FEEDER BASE on a flat level
surface at a height that is easy for you to see what you are doing

6
7. Play back recorded Voice Message
1) Press the PLAY key
2) Your recorded message will now play
3) At each Feeding your recorded message will play back 3 times
8. Battery Replacement
Change all batteries when the Red LED (Low battery indicator) flashes. Use only
new Alkaline batteries.
9. Disassembly and Assembly
Your Automatic Pet Feeder comes pre-assembled. However, there may be times
when you wish to remove some parts of the bowl for cleaning, load food, or to
replace the batteries.
Disassembly (refer to diagram on pg. 7)
LOCK-(marked F on diagram) – Push in the middle of each LOCK and pull up
using your fingertips. Now remove the LID-(marked A on diagram), being careful
not to pull the LID off from only one side as this can damage the locking pins. The
SLIDE COVER-(marked B on diagram) easily lifts off, as does the FOOD BOWL-
(marked D on diagram)
Assembly (refer to diagram on pg. 7)
LID-(marked A on diagram) – Place the SLIDE COVER on top of the FOOD
BOWL so the FINGER TAB is in the opening of the LID. Now align LID pins with
the FEEDER BASE and push down. The LID pins only align one way on the
FEEDER BASE. Do not use excessive force when installing the LID. Check for
proper alignment if you have trouble getting the LID to lock down on the FEEDER
BASE
SLIDE COVER-(marked B on diagram) – For keeping your pet from eating until
the 1st programmed feeding starts.
FINGER TAB-(marked C on diagram) – For closing the SLIDE COVER which will
lock into the LID
FOOD BOWL-(marked D on diagram) – The FOOD BOWL will seat into the HUB
in the FEEDER BASE in only one position. Be sure the FOOD BOWL seats
properly onto the HUB
HUB-(marked E on diagram) – The FOOD BOWL slides into this and is what
rotates the FOOD BOWL
3
Instruction Manual
Automatic 6 Meal LCD Clock Pet Feeder (PF-18)
Features
12 or 24 hour clock display
6 second personal voice message recorder
Personal Voice message calls your pet when its feeding time
Food Bowl rotates according to your set time
The 6 Feeding times can be set for any time of day or night
C size alkaline batteries (4pc’s required) last over 1 year
Red LED indicates Low batteries
Extra compartment atop for ice-pack or water
Control Panel Keys
MODE - switches between clock or feeding time display. Also increases clock time
during clock / feeding-time Set mode
SET – enters settings mode. Also confirms the time you enter and advances to
next setting
START NOW – starts the feeding timer immediately
START TOMORROW- starts the feeding timer the next day
REC – records your personal voice message
PLAY – plays back your recorded voice message
ON SWITCH – turns the feeder on / off. For when the feeder will not be used for
an extended period of time. Turning this switch off will RESET all time and feeding
settings
Getting Started
1) Carefully turn the pet feeder upside down. Remove both battery doors by
squeezing the two tabs and gently pulling each door away
2) Keep the ON switch set to OFF
3) Insert four C size alkaline batteries into the battery tray. Do NOT use old or
-cheap- carbon batteries
4) Close the battery doors, rotate the feeder right-side up and switch ON
5) The feeder will cycle one time until “12:00” is on the LCD display
Note: Your pet feeder makes the food available in this sequence: Tray 1, Tray 2, Tray 3,
Tray 4, Tray 5 and last Tray 6. When you want only one tray of food, you should fill only
Tray 1; for only 2 feedings, fill Trays 1 and 2 and so on.

4
General Operation
1. Filling the bowl with Food
1) Please refer to the section, Disassembly, to open the LOCK-(F) and remove LID-
(A) and SLIDE COVER-(B)
2) Pour pet food into the feeder bowl food trays (1,2,3,4,5,6) being careful not to
over-fill each food tray past the bowls edge as this can cause the feeder to
malfunction
3) Please refer to the section, Assembly, to replace the SLIDE COVER-(B)
and LID-(A) and LOCK-(F)
4) Make sure the SLIDE COVER-(B) locks into position with the LID-(A)
2. Setting the current Clock Time
1) During Clock display mode, press and hold the SET key for (2 seconds) to enter
Clock SET mode. The hour number will now be blinking
2) Press the MODE key to increase the hour. Once you have set the hour, press the
SET key to confirm the hour. The minute number will now blink
3) To change the minute number, press the MODE key to increase the minute. Once
you have set the minute, press the SET key to confirm the minute. Both the hour
and minute numbers will now blink
4) If needed, Press the MODE key to change between 12 or 24 hour time
5) Press the SET key to confirm your current time setting and the numbers will stop
blinking
3. Setting the Feeding Time
1) After setting the clock time, press the MODE key one time. (1 1) will show on the
display. This is feeding time display mode.
2) Now press and hold the SET key for (2 seconds) to enter Feeding-time SET
mode. Feeding will start from the first feeding number & time. The 1st digit
represents the feeding number (Food Tray 1)
3) The hour digits will now blink (2nd and 3rd digit). Press the MODE key to increase
the time, then press the SET key to confirm the time you set
4) After confirming the 1st feeding time, the next feeding number & time will show on
the display. (1st digit will change to the next feeding number, e.g. Food Tray 2 or 3
or 4 or 5 or 6 and back to 1) To change the feeding time, repeat step-3
5) Repeat step-3 until all 6 feeding times for each Food Tray are set. The display will
change back to clock display mode when all 6 feedings have been set
5
Program examples:
1) Feed once a day at 13:00hr (24hrs display) and feed for 6 days
Feed time 1 & 2 & 3 & 4 & 5 & 6 all equal = 13:00hr
2) Feed twice a day at 10:00 and 20:00 and feed for three days
Feed time 1 = 10, feed time 2 = 20, feed time 3 = 10, feed time 4 = 20, feed
time 5 = 10 and the last time 6 = 20
3) Feed three times a day at 6:00am, 12:00 and 18:00 (6:00pm)
Feed time 1 = 06, feed time 2 = 12, feed time 3 = 18 and so on…
4. Review and Start the feeding timer
1) Use the MODE key to cycle through clock and your set feeding times (clock - then
1st feed time→2nd feed time→3rd feed time→4th feed time→5th feed time→6th
feed time→back to clock…) The sequence will repeat
2) Press the START NOW key to start the feeding timer immediately. The bowl will
rotate to the pre-set starting position (Tray 6) and your recorded message will play
once. The BELL icon will now be On
3) Or press the START TOMORROW key and the feeding timer will start at 0:00-
Midnight. The bowl will rotate to the pre-set starting position (Tray 6) and your
recorded message will play once. The BELL and Zz icon will now be On
5. Display Mode (to check Feeding times you have set)
Use the MODE key to cycle through clock and feeding settings (clock - then 1st
feed time→2nd feed time→3rd feed time→4th feed time→5th feed time→6th feed
time→back to clock…) The sequence will repeat
6. Record Voice Message to be played at feeding times
1) Press and hold the REC key, the Red LED will turn on
2) Speak your message. You have up to 6 seconds
3) When finished release the REC key
1s
t
digit 2n
d
digit 3r
d
digit
Feeding
Numbe
r
Feeding
Time
