Pfaff C1100 Pro User manual

SAFETY INSTRUCTIONS
1
INSTRUCTIONS
When using an electrical appliance, basic safety should always be followed, including the following:
Read all instructions before using this sewing machine.
Never operate the appliance with any air openings blocked
Always use the proper needle plate, as a wrong needle plate can cause the needle to break.
witch the sewing machine off ("O") when making any adjustments in the needle area, such as
threading the needle, changing the needle, threading the bobbin, changing the presser foot or
changing the light.
1. An appliance should never be left unattended when plugged in.
2. Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
3. Always unplug before checking and re-lamping. Contact the authorized retailer or service center for
repair in the event of failure if the machine is with 200mW, 300mW and 200mW LED lamp, which is
not user-replaceable.
1. Do not allow to be used as a toy. Close attention is necessary when this appliance is used by or
near children.
2. Use this appliance only for its intended use as described in this manual. Use only the attachments
recommended by the manufacturer as contained in this manual.
3. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged, or dropped into water. Return the appliance to the nearest authorized
retailer or service center for examination, repair, electrical or mechanical adjustment.
4. . Keep ventilation openings of the
sewing machine and foot control free from accumulation of lint, dust, and loose cloth.
5. Keep fingers away from all moving parts. pecial care is required around the sewing machine needle.
6.
7. Do not use bent needles.
8. Do not pull or push fabric while stitching. It may deflect the needle causing it to break.
9.
10.Always unplug sewing machine from the electrical outlet when removing covers, lubricating, or
when making any other user servicing adjustments mentioned in the instruction manual.
11.Never drop or insert any object into any opening.
12.Do not use outdoors.
13.Do not operate where aerosol spray products are being used or where oxygen is being administered.
14.To disconnect, turn all controls to the off ("O") position, then remove plug from outlet.
15.Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
16.The sound pressure level under normal operating conditions is 75dB(A).
17.
18.Never place anything on the Foot Control.
19. If the supply cord that fixed with Foot Control is damaged, it must be replaced by the manufacturer or
its service agent or a similar qualified person in order to avoid a hazard.
20.This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
21.Children should be supervised to ensure that they do not play with the appliance.
This sewing machine is intended for househo d use on y.
DANGER
WARNING
SAVE THESE INSTRUCTIONS
-To reduce the risk of e ectrica shock:
-To reduce the risk of burns, fire, e ectrica shock, or injury to persons:
Please turn off the machine or unplug when the machine is not operating properly.

For safe operation
For a onger service ife
For repair or adjustment
1. Be sure to keep your eye on the needle while sewing. Do not touch the handwheel, thread take-
up lever, needle or other moving parts.
2. Remember to turn OFF the power switch and unplug the cord when:
Operation is completed.
Replacing or removing the needle or any other parts.
A power failure occurs during use.
Maintaining the machine.
Leaving the machine unattended.
3. Do not store anything on the foot control.
4. Plug the machine directly into the wall.
1. When storing this machine, avoid direct sunlight and high humidity locations. Do not use or
store the machine near a space heater, iron, halogen lamp, or other hot objects.
2. Use only neutral soaps or detergents to clean the machine. Benzene, thinner, and scouring
powder can damage the machine, and should never be used.
3. Do not drop or hit the machine.
4. Always consult this operation manual when replacing or installing any assemblies, the presser
feet, needle or other parts to assure correct installation.
In the event a malfunction occurs or adjustment is required, first follow the troubleshooting guide
in the back of this operation manual to inspect and adjust the machine yourself. If the problem
persists, please consult your local authorized retailer.
