PG Drives Technology I-DRIVE Series User manual

I-DRIVE CONTROLLER FAMILY
TECHNICAL MANUAL
SK76977-07

©PG Drives Technology 2009
All rights reserved.
This manual is furnished under copyright and may only be used in accordance with the terms laid out by PG Drives Technology.
The information in this manual is furnished for informational use only, is subject to change without notice, and should not be
construed as a commitment by PG Drives Technology.
Except as permitted by such terms, no part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means electronic, mechanical, recording, or otherwise - without the prior written permission of PG Drives
Technology. [phone].

PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL
TABLE OF CONTENTS
8.1.5 Status Indicator Flashes Rapidly And Continuously
(even with throttle released)................................... 16
About this manual..................................................... 8
Icons ..................................................................... 8 8.2 TruCharge Indicator............................................... 17
8.2.1 TruCharge Indicator Steady................................... 17
Chapter 1 – Operation ................................................................9 8.2.2 TruCharge Indicator Flashing 1 Bar Slowly And
Continuously .......................................................... 17
1Introduction................................................. 11
8.2.3 TruCharge Indicator Flashes Slowly, Pauses, Then
Flashes Slowly Again (even with throttle released) .17
2General....................................................... 11
8.2.4 TruCharge Indicator Blinks On Every 3½ Seconds.. 17
2.1 Handling ................................................................11
8.2.5 TruCharge Indicator Flashing Rapidly .................... 17
2.2 Operating Conditions ............................................11
8.3 Self-Help Guide...................................................... 18
3 Controls....................................................... 11
8.4 Slow or Sluggish Movement ................................... 18
3.1 On/Off Switch......................................................... 11
9Battery Gauge .............................................19
3.2 Status Indicator ......................................................12
9.1 How To Read A Single Bulb (or LED) Battery Gauge19
3.3 Throttle ...................................................................12
9.2 How To Read A TruCharge Battery Gauge............. 19
3.3.1 Wig-wag Throttle ....................................................12
3.3.2 Single-ended Throttle............................................. 12 10 Pushing your Machine .................................19
3.3.3 Unipolar Throttle .....................................................12
11 Programming...............................................20
3.4 Tiller Switch .............................................................12
12 Warranty ......................................................20
3.5 Direction Switches..................................................12
3.6 Reverse Switch.......................................................12 13 Servicing......................................................21
3.7 Speed Limiting Potentiometer ...............................12
3.8 Belly Button ............................................................12 Chapter 2 – Installation ....................................................... 23
3.9 Slow/Fast Switch .....................................................13
1Documentation............................................25
3.10 Audible Alarm ........................................................ 13
1.1 i-Drive Versions ....................................................... 25
4Getting Ready to Drive ............................... 13
1.2 i-Drive Operation.................................................... 25
5Tips for Using Your Controller ....................... 13 1.3 Dimensions ............................................................ 26
5.1 Driving - General....................................................13 1.3.1 i-Drive 45A and 70A Controllers ............................. 26
5.2 Driving Technique ..................................................13 1.3.2 i-Drive 140A and 180A Controllers ......................... 27
1.4 Program Settings.................................................... 27
6Precautions for Use...................................... 14
1.5 Soft-Stop ................................................................ 28
6.1 Hazards.................................................................. 14
1.6 Other Information .................................................. 28
7Safety Checks ............................................. 15 2Immobilizing the Machine ...........................28
7.1 Daily Checks..........................................................15
2.1 Prevention of Unauthorized Use ............................. 28
7.2 Weekly Checks ...................................................... 15
2.2 Charger Interlock ................................................... 28
7.3 Servicing ................................................................15
3Connections ................................................28
8Status Indication ......................................... 16
3.1 General ................................................................. 28
8.1 Single Lamp and LED Status Indicators.................. 16
3.1.1 Wiring Configuration i45 & i70 ............................... 29
8.1.1 Status Indicator Steady ..........................................16
3.1.2 Wiring Configuration i140 & i180 ........................... 30
8.1.2 Status Indicator Flashes Slowly and Continuously ..16
3.2 Connectors & Connector Kits ................................ 30
8.1.3 Status Indicator Flashes Slowly, Pauses, Then
Flashes Slowly Again (even with throttle released)..16 3.2.1 Motor And Battery .................................................. 30
3.2.1.1 i45 & i70 .............................................................. 30
8.1.4 Status Indicator Blinks On Every 3½ Seconds .........16
3.2.1.2 i140 & i180 .......................................................... 31
SK76977-07 3

I-DRIVE TECHNICAL MANUAL PG DRIVES TECHNOLOGY
3.2.2 Aux 1 Connector ...................................................31 5Drive Motors.................................................49
3.2.3 Tiller Interface Connector.......................................31 5.1 Gradient Performance .......................................... 49
3.2.4 Programming Connector ......................................31 5.2 Freewheeling ......................................................... 50
3.3 Crimping................................................................32
6Programming Connection ...........................50
3.4 Wire Gauge and Types .......................................... 32
7Batteries.......................................................50
3.5 Battery Connection................................................33
3.6 Motor Connection .................................................33 8Mounting .....................................................51
3.7 Auxiliary 1 Output ................................................... 33 8.1 Mounting the i-Drive............................................... 51
3.7.1 Solenoid Brake .......................................................33 8.1.1 i45 & i70 ................................................................ 51
3.7.2 Auxiliary 1 Other Modes ......................................... 33 8.1.2 i140 & i180 ............................................................ 52
4Tiller Interface.............................................. 35 8.1.3 Orientation............................................................. 52
8.1.4 Position .................................................................. 52
4.1 Throttle Potentiometer Configuration ..................... 35
8.1.5 Cables................................................................... 53
4.2 Speed Limiting Potentiometer / Belly Button Input.. 36
8.2 Mounting the i-Drive & i-Cover............................... 53
4.2.1 Speed Limiting Potentiometer Configuration......... 36
8.2.1 i45 & i70 + i-Cover ................................................ 53
4.2.2 Belly Button Configuration...................................... 37
8.2.2 i140 & i180 + i-Cover ............................................ 54
4.3 Fused B+ Supply....................................................38
8.2.3 Orientation............................................................. 54
4.4 On/Off Switch......................................................... 38
8.2.4 Position .................................................................. 54
4.5 Status Indicator ......................................................38
8.2.5 Cables................................................................... 54
4.5.1 Status Indicator Diagnostic Setting ........................39
4.6 Slow/Fast Switch .....................................................40 9 Battery Gauge .............................................55
4.7 Reverse Switch / Auxiliary 3 Input / Reverse Direction
Switch ....................................................................40 10 Electromagnetic Compatibility (E.M.C.).......55
10.1 Emissions................................................................ 55
4.7.1 Reverse Switch.......................................................40
10.1.1 Motor Suppression ................................................ 55
4.7.2 Auxiliary 3 Input ......................................................40
10.1.2 Cables.................................................................. 55
4.7.3 Reverse Direction Switch........................................ 41
10.2 Immunity................................................................ 56
4.8 Auxiliary 2 Output ................................................... 41
4.8.1 Diagnostic/Reverse Alarm......................................41 11 Electro-Static Discharge (E.S.D.) ...................56
4.8.2 Brake Light .............................................................42
11.1 Electrical Masses ................................................... 56
4.8.3 Auxiliary 2 Other Modes ......................................... 42
11.2 Prevention of Flashover.......................................... 56
4.9 Auxiliary 3 Output ................................................... 43
11.2.1 Control Panels....................................................... 57
4.10 0 Volts ....................................................................44
11.2.2 Electrical System to Chassis Paths ........................ 57
4.11 Inhibit 1 / Forward Direction Switch ........................44
11.2.3 Electrical Components......................................... 57
4.11.1 Inhibit 1 ................................................................. 44
11.2.4 Ensuring Repeatability .......................................... 58
4.11.2 Inhibit 1 Debounce............................................... 44
11.2.5 Drain Path Components ....................................... 58
4.11.3 Inhibit 1 Mode....................................................... 44
12 Production Tests ...........................................59
4.11.4 Inhibit 1 Target ......................................................45
4.11.5 Inhibit 1 Speed .....................................................45 12.1 Mounting ............................................................... 59
4.11.6 Inhibit 1 Operation................................................45 12.2 Cables and Connectors........................................ 59
4.11.7 Forward Direction Switch....................................... 46 12.3 Preset Settings........................................................ 59
4.12 Inhibit 2 / Tiller Switch.............................................. 46 12.4 Operational Test .................................................... 59
4.12.1 Inhibit 2 ................................................................. 46 12.5 Test Drive................................................................ 59
4.12.2 Inhibit 2 Debounce............................................... 47 12.6 Soft-Stop Test ......................................................... 59
4.12.3 Inhibit 2 Mode....................................................... 47
4.12.4 Inhibit 2 Target ......................................................47 Chapter 3 – Programming....................................................61
4.12.5 Inhibit 2 Speed...................................................... 48 1Introduction .................................................63
4.12.6 Inhibit 2 Operation ................................................ 48
1.1 SP1a & DTT ............................................................. 63
4.12.7 Tiller Switch ............................................................ 48
SK76977-074

PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL
1.2 PC Programmer..................................................... 63 7.5 Diagnostic Flash Sequence................................... 73
1.3 Parameters ............................................................63 7.6 Reverse Alarm........................................................ 74
7.7 Pulsed Reverse Alarm ............................................ 74
2Speed Parameters ...................................... 65
7.8 Diagnostic Alarm ................................................... 74
2.1 Forward Acceleration ............................................65
7.9 Brake Disconnected Alarm .................................... 74
2.2 Forward Deceleration ............................................65
7.10 Brake Fault Detect ................................................. 74
2.3 Reverse Acceleration ............................................65
7.11 Brake Light ............................................................. 75
2.4 Reverse Deceleration ............................................66
7.12 Freewheel Speed Limit .......................................... 75
2.5 Max. Forward Speed ............................................. 66
8Motor Parameters ........................................75
2.6 Min. Forward Speed............................................... 66
2.7 Max. Reverse Speed.............................................. 67 8.1 Current Limit........................................................... 75
2.8 Min. Reverse Speed...............................................67 8.2 Boost Drive Current and Boost Drive Time .............. 75
2.9 Speed Limit Pot. Enabled ......................................67 8.3 Current Foldback Threshold, Current Foldback Time,
Current Foldback Level and Motor Cooling Time .. 76
3Operation Parameters................................. 68
8.4 Current Foldback Temperature ............................. 77
3.1 Sleep Timer ............................................................68 8.5 Controlling a Machine on a Slope ........................ 77
3.2 Throttle Invert.......................................................... 68 8.5.1 Motor Compensation ............................................ 77
8.5.2 Slope Factor .......................................................... 78
4Throttle Parameters...................................... 68
8.5.3 Anti-Rollback Level................................................. 78
4.1 Throttle Type........................................................... 68
8.6 Set-up Procedure................................................... 78
4.2 Throttle Deadband ................................................ 68
8.7 Pull-Away Delay ..................................................... 79
4.3 Throttle Gain ..........................................................68
8.8 Anti-Rollback Velocity ............................................ 79
4.4 Throttle Operated At Power-Up ..............................69
4.5 Throttle Reference Test........................................... 69 9 Belly Button ..................................................79
4.6 ISO Tests Resistor ....................................................69 9.1 Belly Button Switch Type ......................................... 79
4.7 Direction Switches..................................................70 9.2 Belly Button Speed................................................. 79
9.3 Belly Button Time .................................................... 79
5Battery Parameters...................................... 70
5.1 Cable Resistance .................................................. 70 10 Factory ........................................................80
5.2 Calibration Factor..................................................70 10.1 Safety Fences ........................................................ 80
5.3 Battery Lockout Parameters ...................................70 10.2 Supply Voltage ...................................................... 80
5.3.1 Battery Lockout Voltage.........................................71
11 Auxiliary Outputs ..........................................80
5.3.2 Battery Lockout Voltage 2......................................71
11.1 Auxiliary 1 Output Mode ........................................ 80
5.3.3 Battery Lockout Time..............................................71
11.2 Auxiliary 1 Output Off Delay ................................... 81
5.3.4 Battery Lockout Type.............................................. 71
11.3 Auxiliary 2 Output Mode ........................................ 81
5.3.5 Battery Lockout Input Select ..................................71
11.4 Auxiliary 2 Output Off Delay ................................... 82
5.4 Low Battery Alarm .................................................. 72
11.5 Auxiliary 3 Output Mode ........................................ 82
6Inhibit Parameters ....................................... 72
11.6 Auxiliary 3 Input Type.............................................. 82
6.1 Inhibit 1 Debounce, Mode, Operation, Speed &
Target.....................................................................72 11.7 Auxiliary 3 Output Voltage ..................................... 82
11.8 Auxiliary 3 Output Off Delay ................................... 83
6.2 Inhibit 2 Debounce, Mode, Operation, Speed &
Target.....................................................................72 12 Memory Functions .......................................83
6.3 Tiller Switch .............................................................72 12.1 Diagnostic Logs ..................................................... 83
12.1.1 Read System Log.................................................. 84
7General Parameters.................................... 73
12.1.2 Clear System Log ................................................. 84
7.1 Soft-Stop ................................................................73
12.1.3 Read Control Log ................................................. 84
7.2 Brake Time .............................................................73
12.1.4 Clear Control Log ................................................. 84
7.3 Output Voltage ...................................................... 73
12.2 Timer...................................................................... 84
7.4 Status Output Type................................................. 73
SK76977-07 5

I-DRIVE TECHNICAL MANUAL PG DRIVES TECHNOLOGY
12.2.1 Read Timer ........................................................... 84 2.1 Surface Variant ...................................................... 96
12.2.2 Clear Timer ...........................................................84 2.2 Inset Variant ........................................................... 96
3Mounting .....................................................97
Chapter 4 – Diagnostics......................................................85 3.1 Handling ................................................................ 97
1Introduction................................................. 87 3.2 Surface Variant ...................................................... 97
3.2.1 Fixing...................................................................... 97
1.1 Diagnostic Procedure ............................................87
3.2.2 Sealing................................................................... 97
1.2 Detecting A Trip Has Occurred ..............................87
3.3 Inset Variant ........................................................... 98
2 Trip Types And Possible Causes ................... 88
3.3.1 Fixing...................................................................... 98
2.1 Trip Type 1 – Low Battery Voltage........................... 89 3.3.2 Sealing................................................................... 98
2.1.1 Low Battery Voltage ............................................... 89
4Wiring...........................................................99
2.1.2 Very Low Battery Voltage .......................................89
4.1 Wire Gauge ........................................................... 99
2.2 Trip Type 2 – Motor Open Circuit............................ 89
4.2 Connectors............................................................ 99
2.3 Trip Type 3 – Motor Wiring Trip ................................89
4.2.1 Surface Mount Variant ........................................... 99
2.3.1 Motor Shorted To Battery Positive ...........................89
4.2.2 Inset Variant ........................................................... 99
2.3.2 Motor Shorted To Battery Negative ........................89
2.4 Trip Type 4 – Not Used............................................89 5Connections ..............................................100
2.5 Trip Type 5 – Not Used............................................89 5.1 Surface Variant .................................................... 100
2.6 Trip Type 6 – Inhibit Active ......................................89 5.2 Inset Variant ......................................................... 100
2.6.1 Inhibit 1 Active .......................................................89 5.3 Controller Connections........................................ 101
2.6.2 Inhibit 2 Active .......................................................90 5.4 ESD Connection .................................................. 101
2.6.3 Blink – Sleep Mode................................................. 90 5.4.1 Surface Mount Variant ......................................... 101
2.7 Trip Type 7 – Throttle Trip......................................... 90 5.4.2 Inset Mount Variant .............................................. 101
2.7.1 Parallel Speed Pot. Wiper Error ............................... 90
6Electromagnetic Compatibility (EMC)........101
2.7.2 Throttle Reference Error..........................................90
6.1 Immunity and Emissions ...................................... 101
2.7.3 Series Speed Pot. Wiper Error .................................90
6.2 Electro-Static Discharge (ESD).............................. 101
2.7.4 Throttle Displaced At Start-Up.................................90
2.7.5 Belly Button Active At Start-Up ................................90 7Production Tests .........................................102
2.8 Trip Type 8 – Possible Controller Fault.....................91 7.1 Mounting ............................................................. 102
2.8.1 Possible Controller Fault ......................................... 91 7.2 Cables and Connections .................................... 102
2.8.2 Record Of Possible Controller Fault........................91 7.3 Operational Test .................................................. 102
2.9 Trip Type 9 – Solenoid Brake Trip............................. 91
2.9.1 Short Circuit In Solenoid Brake................................91
Chapter 6 – Warning Summary.................................. 103
2.9.2 Open Circuit In Solenoid Brake .............................. 91
1Introduction ...............................................105
2.10 Trip Type 10 – High Battery Voltage........................ 91
2.10.1 High Battery Voltage .............................................91 2Warnings....................................................105
2.10.2 Very High Battery Voltage .....................................91 2.1 Driving Technique ................................................ 105
2.11 Programmable Setting Changed .......................... 91 2.2 Hazards................................................................ 105
3 Servicing Of Defective Units ........................ 92 2.3 Safety Checks...................................................... 106
2.4 Pushing Your Machine ......................................... 106
2.5 Programming ...................................................... 106
Chapter 5 – TruCharge Module......................................93
2.6 Servicing .............................................................. 106
1Introduction................................................. 95
2.7 Program Settings.................................................. 106
1.1 Surface Mount Variant ...........................................95 2.8 Charger Interlock ................................................. 107
1.2 Inset Variant ...........................................................95 2.9 General ............................................................... 107
2 Dimensions.................................................. 96 2.10 Motor And Battery ................................................ 107
SK76977-076

PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL
2.11 i140 & i180 ..........................................................107
2.12 Programming Connector ....................................107
2.13 Crimping..............................................................107
2.14 Wire Gauge and Types ........................................ 108
2.15 Battery Connection..............................................108
2.16 Belly Button Configuration.................................... 108
2.17 Fused B+ Supply..................................................108
2.18 Inhibit 1 & 2 Speed ..............................................108
2.19 Drive Motors .........................................................108
2.20 Freewheeling .......................................................109
2.21 Programming Connection...................................109
2.22 Position.................................................................109
2.23 Production Tests ...................................................109
2.24 Introduction .........................................................109
2.25 Forward Acceleration ..........................................109
2.26 Forward Deceleration ..........................................110
2.27 Reverse Deceleration ..........................................110
2.28 Max. Forward Speed ........................................... 110
2.29 Speed Limit Pot. Enabled ....................................110
2.30 Throttle Operated At Power-Up ............................110
2.31 Soft-Stop ..............................................................110
2.32 Brake Fault Detect ...............................................110
2.33 Freewheel Speed Limit ........................................110
2.34 Current Foldback Temperature ...........................111
2.35 Motor Compensation ..........................................111
2.36 Pull-Away Delay ...................................................111
2.37 Belly Button Time ..................................................111
2.38 Safety Fences ......................................................111
Chapter 7 – Specifications..................................................113
1Electrical Specifications ............................ 115
SK76977-07
7

I-DRIVE TECHNICAL MANUAL PG DRIVES TECHNOLOGY
About this manual
This manual is divided into 7 chapters.
Chapter 1 – Operation
This chapter deals with the controls and functionality of the i-Drive controller.
Chapter 2 – Installation
This chapter deals with the mounting, connection, wiring and set-up procedures of the i-Drive controller.
Chapter 3 – Programming
This chapter provides an overview of the programmable parameters held within the i-Drive controller.
Chapter 4 – Diagnostics
This chapter provides an overview of the diagnostic capabilities of the i-Drive controller.
Chapter 5 – TruCharge Module
This chapter deals with the mounting, connection and wiring of the TruCharge control panel module.
Chapter 6 – Warning Summary
This chapter summarizes the warnings shown throughout the manual.
Chapter 7 – Specifications
This chapter lists the electrical specifications of the i-Drive controller.
Icons
Throughout this manual, icons are used to draw the reader’s attention.
The icons used are:
Note – A general point for best practice.
Caution – A point of safety which if ignored could result in damage to the control system or the
vehicle.
Warning – A point of safety which if ignored could cause injury to the individual.
PG Drives Technology accepts no liability for any losses of any kind if these points are not followed.
SK76977-078

PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL – OPERATION
CHAPTER 1 – OPERATION
SK76977-07 9

I-DRIVE TECHNICAL MANUAL – OPERATION PG DRIVES TECHNOLOGY
SK76977-0710

PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL – OPERATION
1 Introduction
The relevant contents of this chapter should be included in the machine operating guide. Further copies are available from PGDT
in either written or disk (Microsoft Word) format. Copies should not be made without the express permission of PG Drives
Technology.
Operation of the i-Drive controller is simple and easy to understand. The controller incorporates state-of-the-art electronics, the
result of many years of research, to provide you with ease of use and a very high level of safety. In common with other electronic
equipment, correct handling and operation of the unit will ensure maximum reliability.
This chapter covers all types of operation. It is the responsibility of the machine manufacturer to ensure that only the relevant
sections of this chapter are included in the i-Drive’s operating manual.
Please read this chapter carefully - it will help you to keep your machine reliable and safe.
2 General
2.1 Handling
Avoid knocking your controller and especially the connectors. Be careful not to strike obstacles with the controller. Never drop the
controller.
When transporting your machine, make sure that the controller is well protected. Avoid damage to cables.
2.2 Operating Conditions
Your controller uses industrial-grade components throughout, ensuring reliable operation in a wide range of conditions. However,
you will improve the reliability of the controller if you keep exposure to extreme conditions to a minimum.
Do not expose your controller or its components to damp for prolonged periods.
3 Controls
Depending on the specification of the machine to which the i-Drive is fitted, some or all of the following controls will be used.
3.1 On/Off Switch
The On/Off switch applies power to the controller electronics, which in turn supplies power to the machine’s motor. Do not use the
On/Off switch to stop the machine unless there is an emergency. (If you do, you may shorten the life of the machine drive
components).
Some machines may have a keyswitch in addition to the normal On/Off switch; the function of the
keyswitch is the same as the On/Off switch.
SK76977-07 11

I-DRIVE TECHNICAL MANUAL – OPERATION PG DRIVES TECHNOLOGY
3.2 Status Indicator
Depending on the machine model, the status indicator may be a single bulb (or LED) or a PGDT TruCharge battery and
diagnostics indicator.
The status indicator shows you that the machine is switched on. It also indicates the operating status of the machine. Details are
given in Section 8.
3.3 Throttle
The throttle controls the speed of the machine. The further you push the throttle, the faster your machine will move. When you
release the throttle, the brake is automatically applied.
Depending on the machine model, the throttle configuration may be one of three types – wig-wag, single-ended or unipolar.
3.3.1 Wig-wag Throttle
In this configuration, the throttle controls both the speed and the direction of the machine. To drive forwards, push the throttle in
one direction; to drive in reverse, push the throttle in the other direction.
3.3.2 Single-ended Throttle
In this configuration, the throttle controls just the speed of the machine. When the throttle is pushed, depending on the position of
the reverse switch (refer to Section 3.6), the machine will drive in either the forward or reverse direction.
3.3.3 Unipolar Throttle
In this configuration, the throttle controls just the speed of the machine. When the throttle is moved, in either direction, depending
on the position of the reverse switch (refer to Section 3.6), the machine will drive in either the forward or reverse direction.
3.4 Tiller Switch
A tiller switch is generally fitted on ‘walkie’ type machines to provide a safety interlock. The tiller arm is usually sprung to the vertical
position and is pulled towards the horizontal to remove a drive inhibit.
3.5 Direction Switches
Direction switches are sometimes used in combination with the throttle to effect drive. After switching on the machine, either the
forward or reverse direction switch must be operated in conjunction with the throttle to enable drive.
3.6 Reverse Switch
This switch will be fitted to the machine if the throttle configuration is single-ended or unipolar (refer to Sections 3.3.2 & 3.3.3). The
switch is used to change between forward and reverse drive.
3.7 Speed Limiting Potentiometer
This control sets the maximum speed of the machine. Turn the knob clockwise to increase the maximum speed setting or anti-
clockwise to decrease the maximum speed setting.
3.8 Belly Button
This device is a safety feature that is activated each time the machine is placed in reverse. If the button is activated, the
machine will stop its reverse drive and immediately begin to move forwards at a programmed speed.
SK76977-0712

PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL – OPERATION
3.9 Slow/Fast Switch
This switch selects the driving mode – either slow or fast – of the machine. You can use this switch to limit the machine’s driving
behavior in environments where that may be desirable or necessary, e.g. if you are driving in an enclosed space.
3.10 Audible Alarm
This provides an audible warning when the machine is being driven in the reverse direction. The alarm may also be used to signal
other conditions, such as when the machine is in freewheel.
4 Getting Ready to Drive
Check that the speed limiting control is turned to a position that suits you.
Operate the On/Off switch. Either:
A TruCharge type status indicator will blink and remain on after half a second.
A single bulb (or LED) type status indicator will blink and remain on after half a second.
During the first half-second after the machine is switched on, the controller is performing important safety checks within itself and
the rest of the machine’s electrical system. Therefore, if you push the throttle during this time, you will not be able to drive until you
have returned the throttle to the rest position and switched the controller off and on again.
If the machine has a single-ended or unipolar throttle, use the reverse switch to select the direction you want to drive in and then
push the throttle to control the speed. If the machine has a wig-wag throttle, push the throttle in the direction you want to drive.
Depending on the configuration of the machine, you may also have to operate a direction switch and/or a tiller switch before
drive commences.
If you do not push the throttle as you switch the machine on and the status indicator flashes rapidly, then there may be a trip.
Refer to Section 8 for details.
5 Tips for Using Your Controller
5.1 Driving - General
Make sure that all the controls are within easy reach and are comfortable to operate.
5.2 Driving Technique
The controller interprets the throttle movements and reverse switch setting (if fitted) and drives the machine in the correct direction
at the appropriate speed. You will need very little concentration to control the machine, which is especially useful if you are
inexperienced.
The further you push the throttle away from the rest position, the faster the machine will go.
The intelligent speed controller minimizes the effects of slopes and different types of terrain.
The machine user must be capable of driving a machine safely. PGDT accepts no liability for
losses of any kind arising from failure to comply with this condition.
SK76977-07 13

I-DRIVE TECHNICAL MANUAL – OPERATION PG DRIVES TECHNOLOGY
6 Precautions for Use
In the event of the machine moving in an unexpected way, RELEASE THE THROTTLE. This action
will stop the machine under any circumstances.
6.1 Hazards
Do not drive the machine:
Beyond restrictions indicated in your machine user manual, for example inclines, curb heights etc.
In places or on surfaces where a loss of wheel grip could be hazardous, for example on wet grassy slopes.
If you know that the controller or other crucial components require repair.
Although the i-Drive is designed to be extremely reliable and each unit is rigorously tested during
manufacture, the possibility of system malfunction always exists (however small the probability).
Under some conditions of system malfunction the controller must (for safety reasons) stop the
machine instantaneously. If there is any possibility of the user falling out of the machine as a
result of a sudden braking action, it is imperative that a restraining device such as a seat belt is
supplied with the machine and that it is in use at all times when the machine is in motion. PGDT
accepts no liability for losses of any kind arising from the unexpected stopping of the machine, or
arising from the improper use of the machine or controller.
Do not operate the i-Drive if the machine behaves erratically or shows abnormal signs of heating,
sparks or smoke. Turn the i-Drive off at once and consult your service agent. PGDT accepts no
liability for losses of any kind arising from failure to comply with this condition.
Electro Magnetic Interference (EMI) can affect electronic equipment. Such interference may be
generated by radio stations, TV stations, other radio transmitters and cellular phones. If the
machine exhibits erratic behavior due to EMI, turn the controller off immediately and consult your
service agent. PGDT accepts no liability for losses of any kind arising from failure to comply with
this condition.
It is the responsibility of the machine manufacturer to ensure that the machine complies with
appropriate National and International EMC legislation. PGDT accepts no liability for losses of
any kind arising from failure to comply with this condition.
The machine user must comply with all machine safety warnings. PGDT accepts no liability for
losses of any kind arising from failure to comply with this condition.
SK76977-0714

PG DRIVES TECHNOLOGY I-DRIVE TECHNICAL MANUAL – OPERATION
7 Safety Checks
The electronic circuits in the i-Drive have been designed to be extremely safe and reliable. The on-board microprocessor carries
out safety checks at up to 100 times per second. To supplement this safety monitoring you should carry out the following periodic
checks.
If the controller fails any of these checks, do not use the machine and contact your service agent.
These checks should be conducted in an open space and a restraining device such as a seat belt
should always be used. PGDT accepts no liability for losses of any kind arising from failure to
comply with this condition.
7.1 Daily Checks
Throttle:
• With the machine switched off, check that the throttle mechanism is not bent or damaged and that it returns
to the rest position when you push and release it. If there is a problem, do not continue with the safety
checks and contact your service agent.
7.2 Weekly Checks
Throttle:
• Put the throttle to the full speed forward position and switch the machine on. The machine should not move.
To show you that you have switched the machine on with the throttle already pushed, a TruCharge type
status indicator may flash seven bars, whereas a single bulb (or LED) type status indicator will flash seven
