Phanteks GLACIER D120 User manual
INSTALLATION GUIDE V1.0
Distribution plate
GLAC IER D120
PH-D120_01
PACKAGE CONTENTS
WARNING - This product is intended for advanced users. Improper installation may result in damage to your equipment.While all eorts have
been made to provide the most comprehensive information possible, Phanteks assumes no liability expressed or implied for any damage(s) occurring to your
components as a result of using Phanteks cooling products, either due to mistake or omission on our part in the below instructions, or due to failure or defect in
the Phanteks cooling products. Do not disassemble the water block.Warranty will be voided.
Turn o the power to your system and discharge your body’s static electric charge before proceeding with the installation procedure. If you do not feel comfortable
with performing the installation procedure, consult a qualied computer technician.
For latest version check www.Phanteks.com
STEP 1. WATER LOOP PLANNING
STEP 2. CONNECT THE D-RGB CABLE
GLACIER D120
QTY: 1
Glacier Stop Fitting
QTY: 1
M4x8 Screws
QTY: 4
Phanteks D-RGB Cable
QTY: 1
D-RGB MB Adapter
QTY: 1
3mm Allen Key
QTY: 1
Take a look at the port overview and plan
your water loop accordingly.
Fill/Air bleed port
CPU OUT
D120 IN
Make sure to use the correct in and out
ports for the CPU.
The D120 IN and OUT ports can also be
reversed if necessary.
Connect to Phanteks Case
/ Motherboard Cable
CPU IN
D120 OUT
Connect the Phanteks D-RGB Cable to the
LED strip at the top.
You can connect the D-RGB cable to a
compatible motherboard with the
included D-RGB MB adapter.
All Phanteks D-RGB products can be
daisy-chained together.
STEP 3. INSTALL THE DISTRIBUTION PLATE
STEP 4. INSTALLING FITTINGS
Install G1/4 threaded male ttings and
close the remaining port with the
included Stop Fitting.
4x
Always perform a leak test before
providing power to any system
components.
Install the Distribution Plate on the rear
panel of the chassis. Use the 4 included M4
screws.
Do not overtighten the M4 screws.
(Max 1.5N/m)
Carefully loosen the ll port stop tting
to let trapped air bleed out.
