Phase-Tech CS PROFESSIONAL CS-6R User manual

Thank you for purchasing Phase Technology®CS Professional speakers. These speakers
offer exceptional performance and power handling in ush-mounted designs. Each model
features extra-high sensitivity to assure concert volume levels, even with low-powered
distribution systems.
The CS Series is engineered to handle the dynamic range of multi-channel audio technologies
like Dolby Digital and DTS as well as traditional two-channel sources. These in-ceiling
speakers deliver high-end tonal balance and a clear distinction between musical notes.
The line comprises two-way models including 6.5” and 8” polypropylene cones with
NBR™surrounds for lasting performance, indoors or out, and dual voice coil, dual tweeter
congurations permit one CS Professional series speaker to deliver stereo sound to any
room.
Regardless of application, serious audiophile listening or home theater, we recommend that
you take the time to read this manual thoroughly before connecting speakers to your amplier
or receiver. In the highly unlikely event that you should experience a problem with set-up or
operation, please contact one of our authorized dealers for assistance, or contact us directly.
Phase Technology Corporation
8005 W. 110th St., Suite 208
Overland Park, KS 66210
855.663.5600 (Domestic)
+1.913.663.5600 (International)
913.663.3200 (Fax)
SAFETY INSTRUCTIONS 2
INSTALLATION GUIDELINES 3
SPEAKER INSTALLATION 3
CARING FOR YOUR SPEAKER 4
MAINTENANCE AND SERVICE 4
WARRANTY 4
SPECIFICATIONS 4
FLANGE CLAMP
SCREWS (4x)
FLANGE CLAMP
SCREWS (4x)
FLANGE CLAMP
SCREWS (4x)
AIMABLE
TWEETER
MICRO-FLANGE GRILLE
CS-6R DVT
CS-6R
&
CS-8R
CS PROFESSIONAL
OWNER’S MANUAL: CS-6R • CS-6R DVT • CS-8R • CS-6R Point • CS-6R IW
FLANGE FLANGE
FLANGE
CS-6R Point
MICRO-FLANGE GRILLE MICRO-FLANGE GRILLE
CS-6R IW
MICRO-FLANGE GRILLE

2
1. Read Instructions - All the safety and operating instructions
should be read before the appliance is operated.
2. Retain Instructions - The safety and operating instructions
should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and other instructions
should be followed.
5. Water and Moisture - The appliance should not be used near
water - for example, near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool, etc.
6. Carts and Stands - The appliance should be used only with a
cart or stand that is recommended by the manufacturer.
PORTABLE CART WARNING
7. Wall or Ceiling Mounting - The appliance should be mounted
to a wall or ceiling only as recommended by the manufacturer.
8. Ventilation - The appliance should be situated so that its
location or position does not interfere with its proper ventilation.
For example, the appliance should not be situated on a bed, sofa,
rug, or similar surface that may block the ventilation openings;
or placed in a built-in installation, such as a bookcase or cabinet
[SAFETY INSTRUCTIONS] that may impede the ow of air through the ventilation openings.
9. Heat - The appliance should be situated away from heat sources
such as radiators, stoves, or other appliances that produce heat.
10. Power Source - The appliance should be connected to
a power supply only of the type described in the operating
instructions or as marked on the appliance.
11. Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked on or pinched by
items placed up or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where they
exit from the appliance.
12. Cleaning - The appliance should be cleaned only as
recommended by the manufacturer.
13. Nonuse Periods - The power cord of the appliance should
be unplugged from the outlet when left unused for a long period
of time.
14. Object and Liquid Entry - Care should be taken so that
neither objects fall nor liquids spill into the inside of the appliance.
15. Damage Requiring Service - The application should be
serviced by qualied service personnel when:
a. the power supply cord or the plug has been damaged,
b. objects have fallen onto or liquid has been spilled into the
appliance,
c. the appliance has been exposed to rain,
d. the appliance does not appear to operate normally or exhibits a
marked change in performance, or
e. the appliance has been dropped or the cabinet damaged.
16. Servicing - The user should not attempt to service the
appliance beyond those means described in the operating
instructions. All other servicing should be referred to qualied
service personnel.
17. Grounding or Polarization - Precautions should be taken so
that the grounding or polarization means of an appliance is not
defeated.
Explanation of Graphical Symbols
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert you to the presence
of un-insulated “dangerous voltage: within the product’s
enclosure that may be off sufcient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert you to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
APPLICABLE FOR USA, CANADA OR WHERE APPROVED FOR
USAGE
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
PLUG TO WIDE SLOT, INSERT FULLY.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRESE ET POUSSER JUSQU AU FOND.
CAUTION: To reduce the risk of electric shock, do not remove cover
(or back). No user-serviceable parts inside. Refer servicing to qualied
service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

3
[INSTALLATION GUIDELINES]
For proper connection and therefore full enjoyment of your new Phase Technology®speakers, we
encourage you to read this owners’ manual thoroughly, even if you are very familiar with installing
speakers. Speaker placement is very subjective. Placement follows the guidelines for the developers of in-
ceiling speakers, yet is also guided by personal preferences. The proper spacing, location and adjustment
of in-ceiling speakers are critical for complete enjoyment of your new speakers. This manual covers these
topics thoroughly. Choose the appropriate mounting location for each speaker.
NOTE: When deciding upon a location, consider the following:
• Be certain your speaker wires can be run to or are accessible from these locations.
• Make certain the wall or ceiling material is sturdy enough to support the weight and vibration of the
speakers.
• It is recommended that our pre-construction rough-in brackets (part number RB21 for CS-6R, CS-6R
DVT & CS-6R Point, AC-CS-8R-PCB for CS-8R and RB25 for CS-6R IW) be used whenever possible in
new construction.
• Be certain the area behind the speaker is free of obstacles such as wall studs, electrical wiring, pipes,
etc.
• Each speaker should be positioned properly, relative to the listening area for good coverage.
• Audio performance and room-to-room isolation will be improved if there is some berglass insulation
placed loosely behind the speaker.
[SPEAKER INSTALLATION]
STEP 1: Using the supplied cutout template,carefully mark the area to be cut out. Using a drywall knife
or saw, cut a hole in the drywall and prepare the speaker wires for connection to the speaker terminals.
(Fig. 1.1 for CS-6R, CS-6R DVT, CS-6R Point & CS-8R - Fig.1.2 for CS-6R IW).
STEP 2: Remove the grille from the speaker assembly (Fig. 2). If it is necessary to paint the speaker
grille to match the ceiling, we recommend that you do so with several light coats of matching spray paint.
STEP 3: Connect the speaker wires to the input terminals on the rear of the speaker, making sure no
loose strands are exposed (Fig. 3).
STEP 4: NOTE: For the CS-6R DVT there are several hookup options. For stereo point-source operation,
connect the speaker wires to the left AND right channel input terminals on the rear of the speaker (Fig.
4). Make sure no loose strands are exposed. Please make sure to check your hookup polarity for proper
operation.
For Surround/Mono: The CS-6R DVT may also be used as a surround speaker for home theater
applications. For the SURROUND or MONO mode of operation, connect your speaker wire to either the
left OR right channel input as above (Fig. 5). Next, connect 2 jumper wires from this same input terminal
to the corresponding input terminals on the opposite side of the speaker. Connect the red positive terminal
to opposite red terminal and black negative terminal to opposite black terminal.
This speaker may be set to either the bipole OR dipole mode of operation using the selector
switch on the rear panel.
Please note that the speaker is a 4 ohm speaker in this conguration.
STEP 5: Carefully position the speaker in the cutout hole. Using a Phillips screwdriver, rotate the four
clamps to secure the speaker to the drywall (Fig. 6). CAUTION: DO NOT OVER-TIGHTEN.
Note: The CS6R Point has an angled bafe which allows the speaker to be pointed toward the listening
position. Rotate the bafe in the cutout until it is pointing in the desired direction prior to tightening the
clamping screws.
STEP 6: Carefully replace the grille by pressing it into the gap between the ange and the bafe. Enjoy!
_
[FIG. 2]
[FIG. 1.1]
[FIG. 3]
[FIG. 4]
[FIG. 5]
[FIG. 6]
R
L
1u6 1u6
100v 100v
Bi
Di
1u6 1u6
100v 100v
R
L
1u6 1u6
100v 100v
Bi
Di
1u6 1u6
100v 100v
STEREO POINT-SOURCE CONFIGURATION
SURROUND OR MONO CONFIGURATION
[FIG. 1.2]

4
Copyright © 2018 MS Electronics, LLC. All rights reserved. MSE Audio, Phase Technology and PhaseTech are registered trademarks and
“Speakers for your Life” is a trademark of MSE Audio, Overland Park, Kansas USA. Phase Technology is part of MSE Audio®. www.phasetech.com.
[CARING FOR YOUR PHASE TECHNOLOGY SPEAKER]
All Phase Technology®speakers are nished with a high degree of craftsmanship in either hand polished paint or vinyl laminates.
We recommend using a lint-free rag with a small amount of glass cleaner to maintain the long-lasting beauty of the nish. Avoid
products containing silicones, oils, oil derivatives, or solvents. Use a damp cloth on enclosures nished in vinyl laminates.
[MAINTENANCE AND SERVICE]
Because of Phase Technology’s uncompromising quality control programs, it’s unlikely that your speakers will ever need service if
connected and used as outlined in this Owners’ Manual. In the unlikely event that a problem does occur, please contact your Phase
Technology®dealer. Your dealer has the necessary factory-authorized parts and trained technicians to quickly restore your speaker
to its original performance specications.
[WARRANTY]
LIMITED WARRANTY: Phase Technology®warrants its loudspeakers to be free from defects in material and workmanship for a
period of ten (10) years for speaker product, limited lifetime for CI speakers, and three (3) years for the electronic components to
the original purchaser. Purchase must be made from an authorized Phase Technology®dealer.
This warranty does not cover service or parts to repair damage caused by misuse, abuse, damage while in transit, alterations,
unauthorized repairs, failure to follow instructions, re, ood or any other cause beyond the reasonable control of Phase Technology®.
Defects in speaker cabinets or grilles must be brought to the attention of your dealer immediately after purchase. This warranty will
be void if the products’ serial number has been altered or removed.
Should your Phase Technology®product require service, please call the MSE Audio®customer service department for a return
authorization. All merchandise returned to Phase Technology®without prior authorization will be refused. For your return authorization
number, please call 855.663.5600 or email [e-mail].
CS-6R CS-6R DVT CS-8R CS-6R Point CS-6R IW
Description: 6.5” Coax In-Ceiling w/
Micro-Flange Grille
6.5” Coax Dual Voice Coil
w/ Micro-Flange Grille
8” Coax In-Ceiling w/
Micro-Flange Grille
6.5” Coax In-Ceiling w/
Micro-Flange Grille
6.5” Dual Voice Coil w/
Micro-Flange Grille
Nominal Impedance: 8Ω 8Ω 8Ω 8Ω 8Ω
Sensitivity: 87 dB 87 dB 87 dB 87 dB 87 dB
Frequency Response: 50 Hz - 20 kHz 50 Hz - 20 kHz 42 Hz - 20 kHz 50 Hz - 20 kHz 50 Hz - 20 kHz
Recommended Power: 5 - 100 Watts 5 - 100 Watts 5 - 120 Watts 5 - 100 Watts 5 - 100 Watts
Tweeter(s): .75” Variable Axis Soft Dome (2) .75” Soft Dome .75” Variable Axis Soft Dome .75” Soft Dome .75” Soft Dome
Midrange: N/A N/A N/A N/A N/A
Woofer(s): 6.5” Polypropylene w/ NBR
Surround
6.5” Polypropylene w/ NBR
Surround
8” Polypropylene w/ NBR
Surround
6.5” Polypropylene w/ NBR
Surround
6.5” Polypropylene w/ NBR
Surround
Inputs: Metal Push Terminals Metal Push Terminals Metal Push Terminals Metal Push Terminals Metal Push Terminals
Grille: White Powder-Coated
Galvanized Magnetic
Micro-Flange (paintable)
White Powder-Coated
Galvanized Magnetic
Micro-Flange (paintable)
White Powder-Coated
Galvanized Magnetic
Micro-Flange (paintable)
White Powder-Coated
Galvanized Magnetic
Micro-Flange (paintable)
White Powder-Coated
Galvanized Magnetic
Micro-Flange (paintable)
Dimensions: 9.1” Diameter 9.1” Diameter 10.625” Diameter 9.3” Diameter 12.4” H x 8.5” W
Cutout Dimensions: 8.062” 8.062” 9.625” 8.2” 10.6” H x 6.6” W
Mounting Depth: 3.375” 3” 3.375” 4.8” 3.4”
Weight: 2 lbs 2.5 lbs 4.75 lbs 3 lbs 3.5 lbs
Included Accessories: N/A N/A N/A N/A N/A
Optional Accessories: Pre-Construction Bracket
(RB21)
Pre-Construction Bracket
(RB21)
Pre-Construction Bracket
(RB22)
Pre-Construction Bracket
(RB21)
Pre-Construction Bracket
(RB25)
