Phasemation T-1000 User manual
Owner’s Manual
T-1000
MC STEPUP TRANSFORMER
3
Table of Contents
Safety Instructions
.................................................................................................... 4
Usage Cautions
........................................................................................................ 5
Care of Equipment ................................................................................................... 5
Names and Functions ...........................................................................................6, 7
Connections ..........................................................................................................7, 8
Trouble Shooting Guide ............................................................................................9
User Support ...........................................................................................................10
Specifications ..........................................................................................................10
Thank you for purchasing Phasemation product.
Read your Owner’s Manual thoroughly for proper operation before starting to
use your equipment.
Please keep your Owner’s Manual with caution.
4
Safety Instructions
Electric Shock Caution Disassembly Prohibited
Indication Mark Ex. / Inside the diagrams or nearby shows in detail what is prohibited.
Pull out the power
plug from the outlet
Before starting
to use
In this owner’s manual and on the product, various pictures are used
to show our customers how to use Phasemation T-2000 safely and
properly in order to avoid the loss of customer’s assets and to protect
our customers from harm.
Never remodel the
equipment.
Disassembling or remodeling this unit not only causes it to be damaged
but can affect other devices. Therefore never disassemble or remodel.
Never install the
equipment near
water.
Do not use the equipment in the bathroom. This can result in a risk of fire
or electric shock.
The equipment is designed for using indoors. Do not expose the
equipment to water. This can result in a risk of failures, fire, and electric
shock.
Never put an object
filled with water on
the equipment.
Do not put a vase, flower pot, glass or any object filled with skin lotion,
cup, chemical, water, or small metal object on the equipment. In case the
liquids are spilled or fall inside the equipment, this can result in a risk of
fire or electric shock.
Never put an object
inside the equipment.
If a foreign object has fallen inside the equipment, contact the dealer. To
keep using the equipment can result in a risk of fire or electric shock.
This sign states that there are
contents that urges caution
(including danger/warning).
This sign states prohibited
action.
This sign states that there
are contents that forces or
instructs action.
If this indication is ignored and handled incorrectly, these contents show
that there is a possibility that can cause death or severe injury of a person.
WARNINGS
CAUTION
Do not use the
equipment being
broken.
If this indication is ignored and handled incorrectly, these contents show that
there is a possibility that people can get injured or objects can get damaged.
In case this equipment falls or is damaged, or the abnormal sound is
brought, stop it and consult your dealer. If continuing using without
measure, it can be caused to malfunction. Never repair it because repairs
done by the user is very dangerous.
When connecting with other audio equipments, read the manual of the
equipments, turn the power switch off, and connect according to the
instructions.
Do not place on top of unstable places such as wobbling stands or tilted
areas. It can fall or drop on the ground and cause injury.
Do not set anything heavy or any big object that sticks out of the edge of
this unit. It can loose its balance and fall or drop on the ground, and cause
injury.
When moving it, turn the power switch off of connected devices and
disconnect cords and then move it. If not, the cords could get damaged
and can cause fire or electric shock.
Places where it comes into contact with soot or steam such as kitchen
counters and humidifiers.
Places where there is too much humidity or dust.
Hot areas such as near heaters or places where it comes into contact with
direct sunlight. It may cause fire or electric shock.
Connection
Places which are not
suitable for installation
Do not place on top
of unstable places.
Do not set anything
heavy on top.
When moving it
5
Installation place
Repair
Usage Cautions
Care of Equipment
In order to use the equipment for a long time, follow the instructions
shown in below:
Do not install this equipment near a heat source such as direct sun light, a stove and so on.
Do not use this equipment at a poorly-ventilated, humid or dusty place.
Do not install this equipment at an unstable place such as a slope or a vibrating place.
Do not install this equipment near the window where the equipment can be exposed to rain.
Do not place this equipment somewhere that can come in contact with soot or steam such as
a kitchen counter or humidifier.
Avoid using this equipment on an equipment generating heat such as an amplifier.
Do not place this equipment near a power supply transformer or a motor of another equipment.
If the equipment is covered with dust or dirt clean it with a soft cloth.
If the equipment is covered with heavy dust put a very thin mild detergent on a soft cloth.
Wring the cloth and wipe off the dust and dirt. Then clean with a dry soft cloth.
Never use chemical agents such as thinner, naphtha or alcohol when cleaning it.
If any of them is attached to the equipment, the silk printing can be flaked or the surface can
lose metal luster.
In case of the equipment failure consult the dealer.
6
For the input, do not connect the RCA terminal and XLR terminal at the same time.
This unit is designed for a balanced connection due to a 2 core shield line.
Therefore, for an unbalanced connection due to a 1 core shield line, it is liable to
receive noises. Be especially careful when using a cartridge with high impedance.
Caution
(1) Phono Input Terminals
(2) Phono Output Terminals
Names and Functions
Connect the audio cables, L and R, from your analog disc player. There are RCA
terminals and XLR terminals. If both of them are connected at the same time, the
sound may lose quality and may cause noises.
Connect them with the MM input terminals of a pre-amplifier or phono amplifier.
*For a balanced connection, compatible phono cables should be connected to
the XLR or RCA terminals.
*No.1 of the XLR terminal is GND, No.2 is HOT and No.3 is COLD.
*Never connect them to the MC terminals or the excessive input will distort
the sound.
T-1000 MC STEPUP TRANSFORMER
SER.NO.
OUTPUT
INPUT
RIGHT
GND
MODEL T-1000
KYODO DENSHI ENG. CO.,LTD.
MADE IN JAPAN
3
21
PUSH
SER.NO.
MODEL T-1000
KYODO DENSHI ENG. CO.,LTD.
MADE IN JAPAN
GND
3
21
PUSH
OUTPUT
INPUT
LEFT
Rear Panel (Left)Rear Panel (Right)
Front Panel *The left and right are in common for the front panel.
●
●
7
Connections
Pre-amplifier
Analog Disc Player
Attached GND connecting cable
(Y-type / 1.5m)
Attached GND connecting cable
(Y-type / 1.5m)
Earth Cable *Connection through an RCA cable
*Connection through an XLR cable
(3) GND Terminals
Connect the earth cables from the analog disc player and from the GND terminals
of the phono amplifier or others.
*The earth cable shall essentially be connected between the transformer and the
pre-amplifier or phono amplifier.
Do not apply testers to the input/output terminals. The transformer’s
performance will deteriorate.
Caution
PHONO INPUT
(MM)
RIGHT LEFT GND
Do not connect the RCA and
XLR cables at the same time
for the input.
Caution
SER.NO.
OUTPUT
INPUT
RIGHT
GND
MODEL T-1000
KYODO DENSHI ENG. CO.,LTD.
MADE IN JAPAN
3
21
PUSH
SER.NO.
MODEL T-1000
KYODO DENSHI ENG. CO.,LTD.
MADE IN JAPAN
GND
3
21
PUSH
OUTPUT
INPUT
LEFT
8
Connection 2 (If the phono amplifier boxes are separate for left and right)
Phono Amplifier Phono Amplifier
Analog Disc Player
Earth Cable
*There are times when this does not need to be connected
PHONO INPUT
(MM)
RIGHT GND
PHONO INPUT
(MM)
LEFT GND
*Connection through an RCA cable
*Connection through an XLR cable
SE R.NO.
OUTPUT
INPUT
RIGHT
GND
MOD EL T-10 00
KYODO DENSHI ENG. CO.,LTD.
MAD E IN JA PAN
3
2 1
PUSH
SE R.NO.
MOD EL T-10 00
KYODO DENSHI ENG. CO.,LTD.
MAD E IN JA PAN
GND
3
2 1
PUSH
OUTPUT
INPUT
LEFT
Attached GND connecting cable
(Y-type / 1.5m) Attached GND connecting cable
(Y-type / 1.5m)
Do not connect the RCA and
XLR cables at the same time
for the input.
Caution
9
Trouble Shooting Guide
Trouble Causes Measures
In case the equipment does not operate properly, check out the followings.
If it does not operate properly even after checking the advised points, then
contact the dealer.
The sound is not
heard.
A hum noise is
heard.
The audio wires are not plugged
in completely.
The audio wires are not plugged
in completely.
Insert the audio wires completely.
Sounds warp
and the volume
decreases.
The unit’s output is connected to
the MC input terminal of a
pre-amp or phono amp.
The load resistance of the phono
amplifier is not 47k ohms.
Connect to the pre-amp or phono
amp MM input terminal.
Receive the output from the
transformer at high impedance.
If there is an exchanging switch of
the load resistance, set it to 47k
ohms.
Insert the audio wires completely.
The earth cable with the analog
disc player is disconnected.
Surely connect the earth cable.
A power supply transformer or
motor in another equipment is
installed near this equipment.
Place this equipment apart from
the power supply transformer or
motor of other equipments.
Both XLR and RCA are
connected to the input terminal.
Both XLR and RCA are
connected to the input terminal.
Connect either one of them into
the input terminal.
Test using a phono cable that is for
a balanced connection.
Connect either one of them into
the input terminal.
The earth cable with the phono
amplifier is diconnected.
The RCA cable connected to the
output terminal is a shield floating
type
The input is an unbalanced
connection
Surely connect the earth cable.
Test it by also connecting the
grounds of the phono amplifier and
pre-amplifier with the earth cable
although usually it is not
necessary.
Cables with the shield being
floated may induce noises. For
ones with an earth cable, it may
improve if the earth cable is
connected. For ones without an
earth cable, connect using a
different cable.
10
Specifications
User Support
As for the unclear matters with regards to the after service, please contact the dealer.
The appearance and specifications of this equipment are subject to change without notice in order
to improve it.
Accessories : GND connecting cable (Y-type / 1.5m) x 2
Best Cartridge’s Output Impedance
Load Impedance
Step-up Ratio ( voltage gain )
Frequency Response
Dimensions
Weight
Input/Output Terminals
1.5 - 40 ohms (4 ohms is best)
47k ohms
26dB
10 - 70kHz (within ±3dB)
W : 174mm H : 90mm D : 173mm
2.1kg x 2 units
Rhodium plated terminals of FURUTECH
Product MC Stepup Transformer Supporting
Phono Balanced Transmission
Kyodo Denshi Engineering Co., Ltd.
8-40-17 Shinyoshidahigashi Kohoku-ku Yokohama-shi Kanagawa 223-0058 Japan
TEL 81-45-710-0975
FAX 81-45-710-0976
E-mail [email protected]
URL http://phasemation.com
is the original audio brand of Kyodo Denshi Engineering Co., Ltd.
