Phenix Technologies VMS-3 User manual

VMS-3
PORTABLE POWER SUPPLY
MODEL NUMBER VMS-3
VERSION 1.1
Copyright © Phenix Technologies, Inc.
Rev 10/11/2019 (Format)

VMS-3
TABLE OF CONTENTS
Section Number
DANGER / GENERAL SAFETY PRECAUTIONS
INTRODUCTION AND TECHNICAL SPECIFICATIONS 1
CONTROL AND METERING DESCRIPTION 2
OPERATION AND CALIBRATION 3
CIRCUIT DIAGRAM SYMBOLS 4
ELECTRICAL DRAWINGS 5
PARTS LIST 6
RECOMMENDED SPARE PARTS 7
PARTS ORDERING INFORMATION 8
RETURNED MATERIAL 9
CUSTOMER COMMENTS / SUGGESTIONS 10

VMS-3
DANGER / WARNINGS
WARNING !!
Complete Grounding of this unit is necessary for
the safe operation of this equipment. Disconnect
inputs before ungrounding this equipment

VMS-3
GENERAL SAFETY PRECAUTIONS
This equipment can produce POTENTIALLY LETHAL VOLTAGES!
Improper operation or test practices may result in injury or death to the
operator or surrounding personnel.
The operation of High Voltage test equipment should only be performed by
personnel familiar with HIGH VOLTAGE testing and safety procedures. The
operator of this equipment must be aware of all hazards associated with
High Voltage testing. The operator is responsible for himself and others in
close proximity of the testing area.
Some General Safety Practices for working with High Voltage Test
Equipment have been listed below for your reference.
•Become familiar with your instrument before performing an actual
test
•Know your work area, check that all circuits are de-energized and
locked out.
•Never work alone; always work with another qualified worker.
•Mark off entire work area with barriers and warning tape.
•Make all personnel aware of your testing activities.
•Be aware of dangerous conditions that may arise from energizing a
test specimen.
•Never modify test equipment, modifications to equipment could
introduce an unknown hazard or hinder a designed-in safety feature.
•DO NOT operate damaged equipment. Remove power, and do not
use the equipment until safe operation can be verified by service-
trained personnel.
Phenix Technologies, Inc. assumes no liability for unsafe or improper use of test
equipment.

VMS-3
1-1
SECTION 1: INTRODUCTION & SPECIFICATIONS
The Phenix Technologies VMS-3 Portable Power Supply is well equipped with the various features
listed on the specifications page to allow for the easy testing of the operational voltage/current of
electro-mechanical devices. The VMS-3 allows the user to dial in an output voltage or current to
determine the operational voltage or current levels of various electro-mechanical devices. Both the
voltage and current output levels can be simultaneously read and monitored with the highly
accurate, onboard meters. The VMS-3 is ideal for running small motors, energizing power circuits,
operating circuit breakers, powering substation relays or for unregulated charging of substation
batteries. The separate output terminals for both AC and DC voltage provide convenient hookup
configurations depending on the type of component being tested.

VMS-3
1-2
TECHNICAL SPECIFICATIONS
Model:
VMS-3 Portable Power Supply
Input:
115/120 Volts, 10 Amps, 60 Hz, Single Phase
Output:
0-120VAC; 10AAC MAX through binding posts (Will not reach 120VAC with the 115VAC
input. Output will be 0-115VAC)
0-150VDC; 5ADC MAX through binding posts
Instrumentation:
AC Meters:
Digital Voltmeter, 3 ½ digit resolution
Scale: 0-199.9VAC. Accuracy: 0.4% FS 2 counts
Digital Ammeter, 3 ½ digit resolution
Scale: 0-19.99AAC. Accuracy: 0.15% FS 6 counts
DC Meters
Digital Voltmeter, 3 ½ digit resolution
Scale: 0-199.9VDC. Accuracy: 0.1% FS 1 count
Digital Ammeter, 3 ½ digit resolution
Scale: 0-04.99ADC. Accuracy: 0.1% FS 1 count
Features:
Main power circuit breaker with indicator lamp
Independent overloads for both outputs: AC –overload breaker; DC –output fuse
Output via binding posts (AC) and binding posts (DC)
Simultaneous digital readouts of both RMS Voltage and Current in both AC & DC
Two copies of instruction manual, parts list, and schematics
Size: 20” L x 16” W x 7” H; 26 lbs.
508 mm L x 406 mm W x 178 mm H, 13.15 kg

VMS-3
2-1
SECTION 2: CONTROL AND METERING DESCRIPTION
(Key numbers refer to Figure 1)
1. Input Power. Plug the included power cord into the unit and a 120VAC, 10A supply.
2. Main Power Indicator Lamp. Lights when main power circuit breaker is energized and in
the ON position.
3. Main Power Circuit Breaker. Serves dual function as main switch and provides overload
protection for all circuits in test set.
4. AC Digital Voltmeter. Provides continuous display of AC output voltage in Volts.
5. AC Digital Ammeter. Provides continuous display of AC output current in Amps.
6. DC Digital Voltmeter. Provides continuous display of DC output voltage in Volts.
7. DC Digital Ammeter. Provides continuous display of DC output current in Amps.
8. AC Overload Circuit Breaker. Circuit Breaker will open once AC output exceeds 10A.
Close switch to reset breaker.
9. Main Variac Knob. Adjusts voltage and current output levels.
10. DC Overload Fuse. Fuse will blow when DC output exceeds 5A. Replace fuse via panel
fuse holder when needed.
11. AC/DC Output Selector Switch. Toggle to select either AC or DC output.
12. AC Supply Binding Posts. Connect included output leads here to apply AC voltage to a
test object.
13. DC Supply Binding Posts. Connect included output leads here to apply DC voltage to a
test object.

VMS-3
2-2
CONTROL AND METERING DESCRIPTION
Figure 1: VMS-3 Front Panel
TECHNOLOGIES

PHENIX


U
F
S
E
U
F
E
S






























VMS-3
3-1
SECTION 3: OPERATION AND CALIBRATION
OPERATION
Setup
1. Connect input power supply to on board terminal block on the rear of the panel with
115VAC or 120VAC, 10A source.
2. Ensure Main Variac knob is dialed to its zeroed out position before connecting output
terminals.
3. If either of the two Overloads is tripped, close the switch to reset the AC output breaker or
replace the DC output fuse.
4. Verify power is off and then connect the output supply via the two sets of binding posts
depending on whether AC or DC will be used and hook up the component to be tested with
the leads provided.
Operation
5. Turn on main circuit breaker switch to power on unit. Note indicator light comes on.
6. Slowly raise the output voltage by turning the Main Variac clockwise until the desired output
voltage or current is reached for the intended application or test.
7. Upon completion of testing, turn off main power by switching off the main breaker before
disconnecting the output leads from the test component.
8. WARNING: For safety reasons, dial back the Main Variac knob to its zeroed-out position
before and after each use.

VMS-3
3-2
OPERATION AND CALIBRATION
CALIBRATION
Your VMS-3 portable power supply itself does not require any calibration for normal operation.
The onboard digital Voltmeters and Ammeters will also hold their normally calibrated settings
during the lifetime of your VMS-3 for all normal indoor operations. In the rare case that any meter
needs calibration adjustments, the procedure for doing so should be performed by qualified
technical personnel such as the Phenix Technologies Service Department during a scheduled
service appointment.
MAINTENANCE
During the lifetime of your portable power supply, certain items will need replacement. Common
replacement parts are listed on page 7-1 under “Recommended Spare Parts.”

VMS-3
4-1
SECTION 4: CIRCUIT DIAGRAM SYMBOLS

VMS-3
5-1
SECTION 5: ELECTRICAL DIAGRAMS
Drawing Number
Description
1.
9907020
VMS-3 Electrical Schematic

VMS-3
6-1
SECTION 6: VMS-3 PARTS LIST
QTY.
ITEM #
PHENIX
PART #
DESCRIPTION
1
CASE
2100479
CASE
1
BRIDG1
1789205
BRIDGE RECTIFIER
1
PWR CORD
1077164
16/3 PWR CORD 10 FT
1
C1
1094520
CAPACITOR, 3Uf, 400V
1
CB1
1601310
CKT BRKR
1
CB2
1601423
CKT BRKR
1
CM1 (AC)
1506512
CURRENTMETER, AC
1
CM2 (DC)
1506513
CURRENTMETER, DC
1
CON 1
1153328
RECEPT, 15A, 250V
2
CON 2,5
1351100
BINDING POST, BLACK
1
CON 3
1351104
BINDING POST, WHITE
1
CON 4
1351102
BINDING POST, RED
2
CON 2,4
1353040
GATOR BT, RED
2
CON 3,5
1353041
GATOR BT, BLACK
4
CON 2-5
1353042
GATOR CLIP
2
CON 3,5
1356212
MULTILAM PLUG, BLACK 4mm
2
CON 2,4
1356213
MULTILAM PLUG, RED 4mm
3
F1-3
1603601
FUSE, AGC-1
3
F1-3
1603910
ONE POLE FUSEBLOCK
1
F4
1603605
FUSE, AGC-5
1
F4
1603920
FUSEHOLDER
1
LP1
1432270
NEON LAMP, AMBER
1
R1
1742195
RESISTOR, 25W,10K
1
SH1
1509895
SHUNT
1
SW1
1865021
TOGGLE, DPDT
1
T1
1890209
VARIABLE XFMR
1
VM1 (AC)
1506511
AC VOLTMETER, 200 VAC
1
VM2 (DC)
1506514
METER, 200VDC

VMS-3
7-1
SECTION 7: RECOMMENDED SPARE PARTS
QTY.
PHENIX
PART #
DESCRIPTION
4
1603601
AGC-1 Fuse
5
1603605
AGC-5 Fuse
1
1423270
Neon Lamp Amber
2
N/A
Output lead wires
2
1356212
Multilamm Plug Black
2
1356213
Multilamm Plug Red
4
1353042
Gator Clip –20 Amp
2
1353041
Gator Clip Boot Black
2
1353040
Gator Clip Boot Red

VMS-3
8-1
SECTION 8: PARTS ORDERING INFORMATION
Replacement parts are available from Phenix Technologies, Inc.
Changes to Phenix Technologies' products are sometimes made to accommodate improved
components as they become available, and to give you the benefit of the latest technical
improvements developed in our Engineering Department. It is, therefore, important when
ordering parts to include the serial number of the unit as well as the part number of the
replacement part. When your purchase order is received at our office, a representative of Phenix
Technologies will contact you to confirm the current price of the part being ordered. If a part you
order has been replaced with a new or improved part, an Applications Engineer will contact you
concerning any change in part number.
Send orders for replacement parts to:
Service Department
Phenix Technologies, Inc.
75 Speicher Drive
Accident, Maryland 21520
PH: 1 [phone]
FAX: [phone]
E-mail: [e-mail]

VMS-3
9-1
SECTION 9: RETURNED MATERIAL
If for any reason it should become necessary to return this equipment to the factory, the Service
Department of Phenix Technologies, Inc. must be given the following information:
Name Plate Information
Model Number
Serial Number
Reason for Return
Cause of Defect
If Phenix Technologies, Inc. deems return of the part appropriate, it will then issue an
"Authorization for Return."
If return is not deemed advisable, other inspection arrangements will be made.
NOTE: Material received at this plant without the proper authorization shall be held as
"Customer's Property" with no service until such time as the proper steps have been taken.
Your cooperation is requested in order to ensure prompt service.

VMS-3
10-1
SECTION 10: CUSTOMER COMMENTS/SUGGESTIONS
Phenix Technologies made significant efforts to ensure that the materials in this
Operator’s Manual are correct. If there are concerns or comments as you have
used this information, Phenix Technologies appreciates any feedback.
Unit Serial Number:
Sect
Page(s)
Comment
Please return to Phenix Technologies, Engineering Department, 75 Speicher
Drive, Accident, MD 21520 USA.
Phone: [phone]; Fax [phone]; or E- mail [email protected]
