Philco PDI 1568 DTBIS User manual

Dishwasher
OWNER’S MANUAL
PDI 1568 DTBIS

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user’s manual.
Copyright © 2020, Fast ČR, a. s. Revision 12/2021

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 1
CONTENTS
PART 1: SAFETY PRECAUTIONS......................................................................................................................2
PART 2: INSTALLATION....................................................................................................................................5
PART 3: TECHNICAL SPECIFICATIONS ...........................................................................................................7
PART 4: BEFORE USING THE APPLIANCE.......................................................................................................8
PART 5: LOADINGYOUR DISHWASHER .......................................................................................................12
PART 6: PROGRAMME TABLE........................................................................................................................16
PART 7: CONTROL PANEL .............................................................................................................................18
PART 8: CLEANING AND MAINTENANCE.....................................................................................................22
PART 9: TROUBLESHOOTING........................................................................................................................24
PART 10: PRODUCT INFORMATION SHEET .................................................................................................28

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 2
PART 1: SAFETY PRECAUTIONS
WARNING! Please adhere to the precautions below when using
the dishwasher:
This appliance can be used by children aged from 8 years and
above and by persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instructions concerning use of the appliance
in a safe way and if they understand the hazards involved.
Children must not play with the appliance.
Cleaning and user maintenance cannot be performed by children
without supervision.
If the supply cable gets damaged, have it replaced by a specialized
service center in order to avoid dangerous situations. It is
prohibited to use an appliance with the supply cable damaged.
Do not leave the door in the open position to prevent the risk of
tripping.
When storing dishes into the dishwasher:
- WARNING: Knives and other utensils with sharp points
and edges must be placed in the basket with points facing
downwards or stored horizontally.
- Sharp items should be placed so that they cannot damage the
door gasket.

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 3
- Knives and other similar sharp items should always be placed
with their handles pointing upwards so that the sharp edge
would not hurt anybody.
- Do not use the dishwasher to wash plastic items that have
not been labeled as dishwasher safe by the manufacturer. The
presence of plastic dishes in the dishwasher causes worsening
of drying process results. Please adhere to the manufacturer’s
recommendations regarding plastic items that have not been
labeled as dishwasher safe.
This appliance is intended to be used in households and similar
premises, such as
– kitchenettes in shops, oces and other workplaces;
– agricultural facilities;
– hotels, motels, and other accommodation facilities where
appliances are used by guests;
– bed and breakfast facilities.
• Donotsitorstandonthedooranddishbasketsofthe
dishwasher and to not use force during operation.
• Donotplaceanyheavyitemsontheapplianceanddotostand
on the door when it is open. The appliance might tip over
towards the front.
Use only detergents and polishing agents intended to be used with
automatic dishwashers. Never use soap, detergents or washing
agents for manual dish washing.
Make sure to prevent children from accessing detergents and
polishing agents and also open door of the dishwasher that might
contain residues of the agents as they are strongly alcaline and
might be very dangerous.

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 4
The appliance, the power cord or the electric outlet must not lie
in, tough or be submerged in water or any other liquid to avoid
electrical hazards.
If the power cord gets damaged, it must be replaced by the
manufacturer, its service technician or another person with similar
qualication so that safety is not jeopardized.
The appliance must not stand on the power cord.
The appliance should be connected to the water supply using a
new hose, not using a hose that has already been used.
Dispose of packaging in a proper manner.
The power cord must not be excessively or dangerously bent or
compressed during installation.
The controls are not to be played with.
Make sure that the openings in the bottom part of the appliance
are not blocked by the carpet.
The dishwasher should be used only for the purpose it was
intended for - for washing dishes.
This dishwasher is for interior use only.
PLEASE READ THOSE SAFETY PRECAUTIONS CAREFULLY AND
STORE THEM FOR FUTURE REFERENCE

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 5
PART 2: INSTALLATION
Machine positioning
When positioning the machine, place it in an area
where dishes can be easily loaded and unloaded. Do
not put the machine in an area where the ambient
temperature falls below 0 °C.
Read all warnings located on the packaging before
removing the packaging and positioning the
machine.
Place the machine close to a water tap and drain. Take
into consideration that the connections will not be
altered once the machine is in position.
Do not hold the machine by its door or panel.
Leave an adequate distance around the machine to
allow ease of movement when cleaning.
CAUTION!
Ensure the water inlet and outlet hoses
are not squeezed or trapped and that the
machine does not stand on the electrical
cable while positioning.
Adjust the feet so the machine is level and balanced.
The machine should be placed on at ground
otherwise it will be unstable and the door of the
machine will not close properly.
Water connection
We recommend tting a lter to your water inlet
supply in order to prevent damage to your machine
due to contamination (sand, rust, etc.) from indoor
plumbing. This will also help prevent yellowing and
deposit formation after washing.
Note printing on the water inlet hose!
If models are marked with 25°, the water temperature
may be max. 25 °C (cold water).
For all other models:
Cold water preferred; hot water max. temperature 60
°C.
Water inlet hose
WARNING!
Use the new water inlet hose supplied with
your machine, do not use an old machine’s
hose.
WARNING!
Run water through the new hose before
connecting.
WARNING!
Connect the hose directly to the water inlet
tap. The pressure supplied by the tap should
be a minimum of 0.03 MPa and a maximum
of 1 MPa. If the pressure exceeds 1 MPa, a
pressure relief valve must be tted between
the connection.
WARNING!
After the connections are made, turn the tap
on fully and check for water leaks. Always
turn o the water inlet tap after a wash
program has nished

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 6
CAUTION!
Ensure the water inlet and outlet hoses
are not squeezed or trapped and that the
machine does not stand on the electrical
cable while positioning.
Electrical connection
WARNING!
Your machine is set to operate at 220-240 V.
If the mains voltage supply to your machine
is 110 V, connect a transformer of 110/220
V and 3000 W between the electrical
connection.
Connect the product to a grounded outlet
protected by a fuse complying with the
values in the “Technical Specications”
table”.
The earthed plug of the machine must be
connected to an earthed outlet supplied
by suitable voltage and current.
In the absence of earthing installation, an
authorised electrician should carry out an
earthing installation. In the case of use
without earthing installed, we will not be
responsible for any loss of use that may
occur.
The plug on this appliance may
incorporate 13A fuse depending on the
target country. (For Example UK, Saudi
Arabia)

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 7
PART 3: TECHNICAL SPECIFICATIONS

General appearance
1. Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Filters
6. Rating plate
7. Control panel
8. Detergent and rinse-aid dispenser
9. Salt dispenser
10. Upper basket track latch
11. Upper Cutlery Basket
12. Turbo Drying Unit: This system provides better
drying performance.
Technical specications
Capacity 15 place settings
Dimensions (mm)
Height
Width
Depth
820-870 (mm)
598 (mm)
550 (mm)
Net weight 37,900 kg
Operating voltage /
frequency
220-240V / 50 Hz
Total current (A) 10 (A)
Total power (W) 1900 (W)
Water supply pressure Maximum: 1 (Mpa)
Minimum: 0.03 (Mpa)

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 8
PART 4: BEFORE USING THE APPLIANCE
Preparing your dishwasher for rst
use
• Makesuretheelectricityandsupplywater
specications match the values indicated in the
installation instructions for the machine.
• Removeallpackagingmaterialinsidethe
machine.
• Setthewatersoftenerlevel.
• Filltherinseaidcompartment.
Salt usage
For a good washing function, the dishwasher needs
soft, i.e. less calcareous water. Otherwise, White lime
residues will remain on the dishes and the interior
equipment. This will negatively aect your machine’s
washing, drying and shining performance. When
water ows through the softener system, the ions
forming the hardness are removed from the water
and the water reaches the softness required to
obtain the best washing result. Depending on the
level of hardness of the inowing water, these ions
that harden the water accumulate rapidly inside the
softener system. Therefore, the softener system has
to be refreshed so that it operates with the same
performance also during the next wash. For this
purpose, dishwasher salt is used.
Machine can only be used by special dishwasher salt
to soften the water. Do not use any small grained
or powdered type of salts which can easily soluble.
Using any other type of salt can damage your
machine.
Fill the salt
To add softener salt, open the salt compartment cap
by turning it counter clockwise. (1) (2) At rst use, ll
the compartment with 1 kg salt and water (3) until it
is almost overowing. If available, using a funnel (4)
will make lling easier. Replace the cap and close it.
After every 20-30 Cycles add salt into your machine
until it lls up (approx. 1 kg).
 
 
6$/7
!!!
The salt compartment should only be lled with
water when the appliance is used for the rst
time.
Only salt intended for use in dishwashers should
be used.
When salt overows and gets out of the salt
container, launch a short washing programme
to protect the dishwasher from corrosion.
Otherwise there is a risk of corrosion forming in
the dishwasher.

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 9
Test Strip
Run water through
the tap (1min.)
Keep the strip in
the water (1sec) Shake the strip. Wait (1min.)
Set the hardness
level of your
machine.
1
minute
1
second
1
minute






NOTE:
The level is set to 3 as default. If the water is well water or has a hardness level above 90 dF, we recommend
that you use lter and renement devices.
Water Hardness Table
Level German dH French dF British dE Indicator
1 0-5 0-9 0-6 L1 is seen on the display.
2 6-11 10-20 7-14 L2 is seen on the display.
3 12-17 21-30 15-21 L3 is seen on the display.
4 18-22 31-40 22-28 L4 is seen on the display.
5 23-31 41-55 29-39 L5 is seen on the display.
6 32-50 56-90 40-63 L6 is seen on the display.
Water Softener System
The dishwasher is equipped with a water softener which reduces the hardness in the mains water supply. To
nd out the hardness level of your tap water, contact your water company or use the test strip (if available).
Setting
• TurnthemachineonbypressingtheOn/Obutton.
• PresstheProgrambuttonforatleast3secondsimmediatelyafterthemachineisturnedon.
• ReleasetheProgrambuttonwhen“SL”isshown.Next,thelastsettinglevelisdisplayed.
• Presstheprogrambuttontosetthedesiredlevel.Eachpressoftheprogrambuttonincreasesthelevel.
Once level 6 has been reached, the next press returns the level to 1.
• ThelastselectedwaterhardnesslevelisstoredinthememorybyturningthemachineowiththeOn/O
button.

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 10
Detergent usage
Only use detergents specically designed for
domestic dishwashers. Keep your detergents in cool,
dry places out of reach of children. Add the proper
detergent for the selected program to ensure the
best performance. The amount of detergent needed
depends on the cycle, load size, and soil level of
dishes. Do not ll detergent into the detergent
compartment more than required; otherwise you
can see whitish streaks or bluish layers on glass and
dishes and may cause glass corrosion. Continued use
of too much detergent may cause machine damage.
Using little detergent can result in poor cleaning and
you can see whitish streaksin hard water. See the
detergent manufacturer’s instructions for a further
information.
Filling the detergent
Push the latch to open the dispenser and pour in the
detergent.
Close the lid and press it until it locks in place. The
dispenser should be relled just before the start of
each programme. If the dishes are heavily soiled,
place additional detergent in the pre-wash detergent
chamber.
Using combined detergents
These products should be used according to the
manufacturer’s instructions.
Never put combined detergents into the interior
section or the cutlery basket.
Combined detergents contain not only the detergent
but also rinse-aid, salt replacement substances
and additional components depending on the
combination.
We recommend you do not use combined detergents
in short programmes.
Please use powder detergents in such programmes.
If you encounter problems when using combined
detergents, please contact the detergent
manufacturer.
When you stop using combined detergents, make
sure that water hardness and rinse aid settings are set
to the correct level.
Rinse-aid usage
The rinse aid helps to dry the dishes without streaks
and stains. Rinse-aid is required for stain-free utensils
and clear glasses. The rinse aid is automatically
released during the hot rinse phase. If rinse aid
dosage setting set too low, whitish stains remains on
dishes and dishes do not dry and washed clean.
If rinse aid dosage setting set too height, you can see
bluish layers on glass and dishes.
Filling the rinse-aid and setting
To ll the rinse aid compartment, open the rinse-aid
compartment cap. Fill the compartment with rinse
aid to the MAX level and then close the cap. Be
careful not to overll the rinse aid compartment and
wipe up any spills.
In order to change the rinse aid level, follow the
below steps before turning on the machine:
• Turn on the machine by pressing the On/O
button.
• PresstheProgrammebuttonforatleast5seconds
immediately after the machine is turned on.
• Release the Programme button when “rA” is
shown. Rinse aid level setting follows water
hardness level setting. Next, the last setting level
is displayed.
• Setthelevelbypushingtheprogrammebutton.
• Switchothemachinetosavethesetting.
• Thefactorysettingis“4”.
If the dishes are not drying properly or are spotted,
increase the level. If blue stains form on your dishes,
decrease the level.

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 11
Level Brightener Dose Indicator
1Rinse-aid not
dispensed
r1 is shown on
the display.
21 dose is
dispensed
r2 is shown on
the display.
32 doses are
dispensed
r3 is shown on
the display.
43 doses are
dispensed
r4 is shown on
the display.
54 doses are
dispensed
r5 is shown on
the display.

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 12
PART 5: LOADING YOUR DISHWASHER
For best results, follow these loading guidelines.
Loading the household dishwasher up to the capacity
indicated by the manufacturer will contribute to
energy and water savings.
Manual pre-rinsing of tableware items leads to
increased water and energy consumption and is not
recommended
You can place cups, glasses, stemware, small plates,
bowls, etc. in upper basket. Do not lean long glasses
against one another or they cannot remain steady
and may receive damage.
When placing long stem glasses and goblets, lean
them against the basket edge or rack and not against
other items.
Place all containers such as cups, glasses and pots into
the dishwasher with the opening facing downwards
otherwise water can collect on items.
If there is cutlery basket in machine, you are
recommended to use the cutlery grid in order to
obtain the best result. Place all large (pots, pans, lids,
plates, bowls etc.) and very dirty items in the lower
rack.
Dishes and cutlery should not be placed above each
other.
WARNING!
Take care not to obstruct the rotation of
spray arms.
WARNING!
Make sure after loading the dishes do not
prevent opening the detergent dispenser.
Recommendations
Remove any coarse residue on dishes before placing
the dishes in the machine. Start the machine with full
load.
NOTE:
Do not overload the drawers or place dishes in the
wrong basket.
WARNING!
To avoid any possible injuries, place long-
handle and sharp- pointed knives with their
sharp points facing down or horizontally on
the baskets.
Upper Basket
The upper basket includes a mechanism which
enables the height of the basket to be adjusted up
(1) or down (2) without having to remove the basket.
Hold the basket on both sides and pull it up or push it
down, ensuring both sides of the upper basket are in
the same position.



Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 13
Height Adjustable Rack (peg type)
The height adjustable racks enable glasses and cups
to be placed on or under the racks. The racks can be
adjusted to 2 dierent heights. Cutlery and utensils
can also be placed on the racks horizontally.


Height Adjustable Rack (peg type)
The foldable racks in the upper basket enable the
placementoflargeitemssuchaspotsandpans.Each
section can be folded separately. The foldable racks
can be either raised up or folded down.
Four Folding Racks
The folding racks are designed so that large items,
such as pots and pans, can be easily placed in the
dishwasher. Each section can be folded separately.
The racks can be folded down or raised up, as shown
in the images below.





Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 14
Upper Cutlery Basket
The upper cutlery basket is designed for the
placement of large and small cutlery and utensils.
The basket is easily removed from the dishwasher,
therefore allows ease of use when removing your
items, along with the basket, after washing.
The upper cutlery basket is composed of two pieces
that can be separately removed. Remove the left or
right section of the cutlery basket in order to obtain
more space for items in the upper basket.
WARNING!
Knives and other sharp objects must be
placed horizontally in the cutlery basket.

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 15
Alternative Basket Loads
Lower Basket
Upper basket
Incorrect Loads
Incorrect loading can cause poor washing and drying
performance. Please follow the manufacturer’s
recommendations for a good performans result.
Unsuitable items for dishwashing
• Cigarette ashes, candle leftovers, polish, paint,
chemical substances, ironalloy materials.
• Forks, spoons and knives with wooden, bone,
ivory or nacrecoated handles; glued items, items
soiled with abrasive, acidic or base chemicals.
• Temperature-sensitive plastics, copper or
tincoated containers.
• Aluminiumandsilverobjects.
• Some delicate glasses, ornamental printed
porcelains; some crystal items, adhered cutlery,
lead crystal glasses, cutting boards, synthetic
bred items.
• Absorbentitemssuchasspongesorkitchenrugs.
IMPORTANT:
In future, purchase dishwasher-proof kitchenware.
Important Note for Test Laboratories
For detailed information required for tests
accordingtoENnormativesandasoftcopy
of the manual, please send the model name
and serial number to the following address:
[e-mail]

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 16
PART 6: PROGRAMME TABLE
P1 P2 P3 P4 P5 P6 P7 P8
Program
Name: Mini 14' Quick 30' Eco Dual Pro
Wash 60°C Super 50' Smart
30°C - 50°C
Smart
50°C - 60°C
Smart
60°C - 70°C
Type of Soil
Fastest
program for
lightly soiled
and recently
used dishes
and suitable
for 4 place
settings.
Suitable for
lightly soiled
dishes and
quick wash.
Standard
program for
normally
soiled daily
using dishes
with reduced
energy
and water
consumptions.
Suitable
for both
lightly soiled
delicate
glassware on
upper rack
and heavily
soiled
crockery on
lower rack.
Suitable for
normally
soiled daily
dishes
with faster
program.
Auto
program for
normally
soiled
delicate
dishes.
Auto
program for
normally
soiled dishes.
Auto
program
for heavily
soiled dishes.
Level of Soil: Light Light Medium Heavy Medium Medium Medium Heavy
Amount of
Detergent:
A: 25 cm3
B:15cm3”
B A A A A A A A
Program
Duration
(h:min)
00:14 00:30 04:30 01:53 00:50 01:12 - 01:31 01:47 - 02:02 01:49 - 02:59
Electiricity
consumption
(kWh/cycle)
0.340 0.650 0.861 1.600 1.000 0.650 - 0.850 1.050 - 1.325 1.250 - 1.900
Water
consumption
(l/cycle)
6.6 10.9 9.0 15.4 9.5 10.6 - 17.7 10.9 - 18.5 11.8 - 24.0

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 17
• Theprogramdurationmaychangeaccordingtotheamountofdishes,thewatertemperature,theambient
temperature and selected additional functions.
• Valuesgivenforprogrammesotherthantheecoprogrammeareindicativeonly.
• Ecoprogrammeis suitable toclean normally soiled tableware, that forthis use,it isthe most ecient
programme in terms of its combined energy and water consumption, and that it is used to assess
compliancewiththeEUecodesignlegislation.
• Washing tableware in a household dishwasher usually consumes less energy and water in the use
phase than hand dishwashing when the household dishwasher is used according to the manufacturer’s
instructions.
• Onlyusepowderdetergentforshortprograms.
• Shortprogramsdonotincludedrying.
• Toassistdrying,werecommendslightlyopeningthedoorafteracycleiscomplete.
• YoucanaccesstheproductdatabasewherethemodelinformationisstoredbyreadingtheQRcodeonthe
energy label.
NOTE:
Accordingtoregulations1016/2010and1059/2010,Ecoprogramenergyconsumptionvaluesmaydier.
This table is in line with regulations 2019/2022 and 2017/2022.

Copyright © 2020, Fast ČR, a. s. Revision 12/2021
EN - 18
PART 7: CONTROL PANEL

 


   
  

 
1. On/O Button
2. Program Selection Button
2.1. Program Indicators
3. Delay Button
3.1. Delay Indicator
4. Remaining Time Indicator
5. Start/Pause Button
6. Options Button
7. Select Button
8. Rinse Aid Indicator
9. Salt Indicator
10. Tablet Indicator
11. Half Load Indicators
12. ExtraHygieneIndicator
13. ExtraRinseoption
14. ExtraDryingIndicator
15. Washing Step Indicators
a- Washing Step Indicator
b- Rinse Step Indicator
c- Drying Step Indicator
d- EndStepIndicator
1. On/O Button
Turn the machine on by pressing the On/O button.
2. Program Selection Button
Select a suitable programme by pressing the
Programme button. The selected program indicator
(2.1) will be on. For the details of the programs refer
to section Program Table.
3. Delay Button
You can delay the start time of the programme for
1-2...24 hours by pressing the delay button (3) before
the programme starts. The delay indicator (3.1) will
be on. If you want to change the delay time,rst
press the Start/Pause button and then the delay
button to select a new delay time. To activate the
new delay time, press the Start/Pause button. To
cancel the delay, you need to switch to 0 hour by
using the delay when the machine is paused.
4. Remaining Time Indicator
Programme ow can be monitored via the Wash,
Rinse,Dry,EndindicatorsandRemainingTime
Indicator.
5. Start/Pause Button
Press the Start/Pause button to start the programme.
The wash lamp turns on and the Remaining Time
Indicator shows the programme duration. It also
indicates the remaining time during the programme
ow. If you open the door of your machine when
the programme is running the duration of the
programme pauses,and related washing step
indicator blinks.
6. Options Button
Options can be selected by pressing the Options
button repeatedly. The chosen option will be
indicatedbyablinkingLED.
7. Select Button
Select the option by pressing the Select button. The
LEDforthechosenoptionwillthenremainlit.
8. Rinse Aid Indicator
When the rinse aid level is low, the rinse aid lack
warning indicator turns on and you should ll the
rinse aid chamber.
