Philco PTF 862 User manual

FREEZER
OWNER’S MANUAL
PTF 862

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user’s manual.
Copyright © 2019, Fast ČR, a. s. Revision 05/2019

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 1
CONTENTS
PART 1: SAFETY INFORMATION......................................................................................................................3
PART 2: DESCRIPTION OF THE APPLIANCE...................................................................................................9
MAIN CONFIGURATION: OPTIONAL ....................................................................................................................................... 9
PART 3: UNPACKING YOUR FREEZER ...........................................................................................................12
PART 4: CLEANING BEFORE USE...................................................................................................................12
PART 5: SPACE REQUIREMENTS ...................................................................................................................12
PART 6: ELECTRICAL REQUIREMENT ...........................................................................................................13
RECOMMENDED EARTHING METHOD ...................................................................................................................................13
PART 7: LEVELING ..........................................................................................................................................13
PART 8: USE OF THE APPLIANCE ..................................................................................................................14
TEMPERATURE CONTROL OPTIONAL...................................................................................................................................14
STORE FROZEN FOODOPTIONAL..........................................................................................................................................14
FREEZING FRESH FOOD................................................................................................................................................................15
DEFROSTING .....................................................................................................................................................................................15
CLEANING YOUR FREEZER...........................................................................................................................................................15
PART 9: TROUBLESHOOTING........................................................................................................................16
PART 10: REFRIGERATOR DOOR INSTALL GUIDELINES ............................................................................17
ABOUT SWAPPING LEFT&RIGHT OPTIONAL............................................................................................17
ENERGY SAVING TIPS.....................................................................................................................................................................21
DAILY USE...........................................................................................................................................................................................21
PART 11: INFORMATION SHEET....................................................................................................................22
This appliance has been tested in accordance with the directives in force in the European Union.
This appliance conforms to the relevant safety provisions for electrical appliances in force in the
European Union.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 2
Dear customer:
Thank you for buying this upright freezer. To ensure that you get the best results from your new freezer,
please take time to read through the simple instructions in this booklet.
Please ensure that the packing material is disposed of in accordance with the current environmental
requirements.
When disposing of any Freezer equipment please contact your local waste disposal department for advice on
safe disposal.
This appliance must be only used for its intended purpose.
This appliance is intended to be used in household and similar applications such as
– sta kitchen areas in shops, oces and other working environments;
– farm houses and by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 3
PART 1: SAFETY INFORMATION
WARNING: RISK OF FIRE / FLAMMABLE MATERIALS
THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLD
AND SIMILAR APPLICATIONS SUCH AS STAFF KITCHEN AREAS
IN SHOPS, OFFICES AND OTHER WORKING ENVIRONMENTS;
FARM HOUSES AND BY CLIENTS IN HOTELS, MOTELS AND OTHER
RESIDENTIAL TYPE ENVIRONMENTS; BED AND BREAKFAST
TYPE ENVIRONMENTS; CATERING AND SIMILAR NONRETAIL
APPLICATIONS.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE
MANUFACTURER, ITS SERVICE AGENT OR SIMILARLY QUALIFIED
PERSONS IN ORDER TO AVOID A HAZARD.
DO NOT STORE EXPLOSIVE SUBSTANCES SUCH AS AEROSOL
CANS WITH A FLAMMABLE PROPELLANT IN THIS APPLIANCE.
THE APPLIANCE HAS TO BE UNPLUGGED AFTER USE AND BEFORE
CARRYING OUT USER MAINTENANCE ON THE APPLIANCE.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 4
WARNING! KEEP VENTILATION OPENINGS, IN THE
APPLIANCE ENCLOSURE OR IN THE BUILTIN STRUCTURE,
CLEAR OF OBSTRUCTION.
WARNING! DO NOT USE MECHANICAL DEVICES OR OTHER
MEANS TO ACCELERATE THE DEFROSTING PROCESS, OTHER
THAN THOSE RECOMMENDED BY THE MANUFACTURER.
WARNING! DO NOT DAMAGE THE REFRIGERANT CIRCUIT.
WARNING! THE COOLING SYSTEM CONTAINS REFRIGERANT
UNDER HIGH PRESSURE. DO NOT MANIPULATE WITH THE
SYSTEM. THE SYSTEM MAY BE REPAIRED BY AUTHORISED
PERSONS ONLY.
WARNING! DO NOT USE ELECTRICAL APPLIANCES INSIDE
THE FOOD STORAGE COMPARTMENTS OF THE APPLIANCE,
UNLESS THEY ARE OF THE TYPE RECOMMENDED BY THE
MANUFACTURER.
WARNING! PLEASE ABANDON THE REFRIGERATOR
ACCORDING TO LOCAL REGULATORS FOR IT USE
FLAMMABLE BLOWING GAS AND REFRIGERANT.
WARNING! DO NOT PLACE SEVERAL PORTABLE SOCKETS
TO THE REAR OF THE APPLIANCE.
WARNING! WHEN POSITIONING THE APPLIANCE, ENSURE
THE SUPPLY CORD IS NOT TRAPPED OR DAMAGED.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 5
WARNING! DO NOT LOCATE MULTIPLE PORTABLE SOCKET
OUTLETS OR PORTABLE POWER SUPPLIES AT THE REAR OF
THE APPLIANCE.
WARNING! IF THE SUPPLY CABLE GETS DAMAGED, HAVE IT
REPLACED BY A SPECIALIZED SERVICE CENTER IN ORDER TO
AVOID DANGEROUS SITUATIONS. IT IS PROHIBITED TO USE
AN APPLIANCE WITH THE SUPPLY CABLE DAMAGED.
WARNING! DO NOT USE ANY MECHANICAL DEVICES OR
MEANS OTHER THAN RECOMMENDED BY THE
MANUFACTURER TO SPEED UP THE DEFROSTING PROCESS.
WARNING! DO NOT USE ELECTRIC APPLIANCES IN THE
AREA DESIGNED FOR KEEPING FOOD, UNLESS THESE ARE
TYPES RECOMMENDED BY THE MANUFACTURER.
DANGER! RISK OF CHILD ENTRAPMENT. BEFORE YOU
THROW AWAY YOUR OLD REFRIGERATOR OR FREEZER:
TAKE OFF THE DOORS.
LEAVE THE SHELVES IN PLACE SO THAT CHILDREN MAY
NOT EASILY CLIMB INSIDE.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 6
REFRIGERANT
REFRIGERANT AND CYCLOPENTANE FOAMING MATERIAL USED
FOR THE REFRIGERATOR ARE FLAMMABLE. THEREFORE, WHEN
THE REFRIGERATOR IS SCRAPPED IT SHALL BE KEPT AWAY
FROM ANY FIRE SOURCE AND BE RECOVERED BY A SPECIAL
RECOVERING COMPANY WITH CORRESPONDING QUALIFICATION
OTHER THAN BE DISPOSED BY COMBUSTION, SO AS TO PREVENT
DAMAGE TO THE ENVIRONMENT OR ANY OTHER HARM.
FOR EN STANDARD: THIS APPLIANCE CAN BE USED BY CHILDREN
AGED FROM 8 YEARS AND ABOVE AND PERSONS WITH REDUCE
PHYSICAL SENSORY OR MENTAL CAPABILITIES OR LACK OF
EXPERIENCE AND KNOWLEDGE IF THEY HAVE BEEN GIVEN
SUPERVISION OR INSTRUCTION CONCERNING USE OF THE
APPLIANCE IN A SAFE WAY AND UNDERSTAND THE HAZARDS
INVOLVED. CHILDREN SHALL NOT PLAY WITH THE APPLIANCE.
CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY
CHILDREN WITHOUT SUPERVISION. CHILDREN AGED FROM 3 TO
8 YEARS ARE ALLOWED TO LOAD AND UNLOAD REFRIGERATING
APPLIANCES.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 7
TO AVOID CONTAMINATION OF FOOD, PLEASE RESPECT THE
FOLLOWING INSTRUCTIONS:
 OPENING THE DOOR FOR LONG PERIODS CAN CAUSE A
SIGNIFICANT INCREASE OF THE TEMPERATURE IN THE
COMPARTMENTS OF THE APPLIANCE.
 CLEAN REGULARLY SURFACES THAT CAN COME IN CONTACT
WITH FOOD AND ACCESSIBLE DRAINAGE SYSTEMS.
 CLEAN WATER TANKS IF THEY HAVE NOT BEEN USED FOR 48 H;
FLUSH THE WATER SYSTEM CONNECTED TO A WATER SUPPLY
IF WATER HAS NOT BEEN DRAWN FOR 5 DAYS. NOTE 1
 STORE RAW MEAT AND FISH IN SUITABLE CONTAINERS IN THE
REFRIGERATOR, SO THAT IT IS NOT IN CONTACT WITH OR DRIP
ONTO OTHER FOOD.
 TWOSTAR FROZENFOOD COMPARTMENTS ARE SUITABLE
FOR STORING PREFROZEN FOOD, STORING OR MAKING ICE
CREAM AND MAKING ICE CUBES. NOTE 2
 ONE ,TWO AND THREESTAR COMPARTMENTS
ARE NOT SUITABLE FOR THE FREEZING OF FRESH FOOD. NOTE
3
 IF THE REFRIGERATING APPLIANCE IS LEFT EMPTY FOR LONG
PERIODS, SWITCH OFF, DEFROST, CLEAN, DRY, AND LEAVE THE
DOOR OPEN TO PREVENT MOULD DEVELOPING WITHIN THE
APPLIANCE.
NOTE 1,2,3: PLEASE CONFIRM WHETHER IT IS APPLICABLE
ACCORDING TO YOU PRODUCT COMPARTMENT TYPE.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 8
THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLDS AND
SIMILAR PREMISES, SUCH AS
 KITCHENETTES IN SHOPS, OFFICES AND OTHER WORKPLACES;
 APPLIANCES USED BY GUESTS IN HOTELS, MOTELS, AND
OTHER ACCOMMODATION FACILITIES;
 APPLIANCES USED IN BED AND BREAKFAST FACILITIES;
 APPLIANCES USED IN CATERING AND OTHER SIMILAR NON
VENDING ENVIRONMENTS.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 9
PART 2: DESCRIPTION OF THE APPLIANCE
This type of refrigerator is widely used in places such as hotels ,oces, student dormitories and houses. It is
mostly suitable for refrigerating and preserving foods such as fruits and beverage. It enjoys the advantages of
small size, Lightweight, Low electric consumption and easy use.
Main conguration: (optional)



1 Thermostat
2 Drawer
3 Leveler leg

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 10



1 Thermostat
2 Drawer
3 Leveler leg

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 11




1 Thermostat
2 Drawer
3 Leveler leg

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 12
PART 3: UNPACKING YOUR FREEZER
WARNING!
Use two or more people to move Freezer. Failure to do so can result in back or other injury.
· Remove tape and any labels from your Freezer before using(except the rating label).
· To remove any remaining tape or glue, rub the area briskly with your thumb.
· Tape or glue residue can also be easily removed by rubbing a small amount of liquid dish soap over the
adhesive with your ngers. Wipe with warm water and dry.
· Do not use sharp instruments, rubbing alcohol, ammable uids, or abrasive cleaners to remove tape or
glue. These products can damage the surface of your Freezer.
· When moving the Freezer, do not tilt the Freezer beyond 45°from upright position.
PART 4: CLEANING BEFORE USE
After you remove all of the packaging materials, (especially the foam between outside condenser and cabinet
should be removed) clean the inside of your Freezer before using it.
PART 5: SPACE REQUIREMENTS
WARNING!
Keep ammable materials and vapors, such as gasoline, away form Freezer. Failure to do so can result in
death, explosion, ne or burns.
· To ensure proper ventilation for your Freezer, allow for 200mm space on each side between walls, 200mm
space between back of your Freezer and the wall, and 300mm space between counter top and the roof or
ceiling.
· If you are installing your Freezer next to a xed wall, leave sucient space on the hinge side to allow for
the door to swing open.
· Never install your Freezer near heat source and direct sun shins.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 13
PART 6: ELECTRICAL REQUIREMENT
WARNING!
DO NOT REMOVE GROUND PRONG.
DO NOT USE AN ADAPTOR.
DO NOT USE EXTENSION CORD.
Failure to follow these instructions can result in death, re or electrical shock.
Before you move your Freezer into its nal location, it is important to make sure you have the proper
electrical connection.
Recommended Earthing Method
A 220 ~ 240 Volt /50 Hz AC only 10 ampere fused and properly earthed electrical supply is required. It is
recommended that a separate circuit serving only this appliance be provided. Use a receptacle which cannot
be turned o with a switch or pull chain. Do not use an extension cord.
NOTE!
Before performing any type of installation, disconnect the Freezer from the electrical source. When you are
nished, connect the Freezer to the electrical source and reset the control to the desired setting.
PART 7: LEVELING
If the Freezer is not leveled during installation. The doors may not close or seal properly, causing cooling,
frost, or moisture problems. It is very important of the Freezer to be level in order to function properly.
To level your Freezer you may either turn the level leg clockwise to raise that side to the Freezer or turn
counter – clockwise to lower that side.
NOTE!
Having someone push against the top of the Freezer take some weight o the leveling leg. This makes it
easier to adjust the leveling leg.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 14
PART 8: USE OF THE APPLIANCE
To obtain the best possible results form your Freezer, it is important that you operate it properly.
Temperature Control (optional)
The temperature in the freezer is controlled by the thermostat control knob. It is loaded in the top-front of
the freezer. Turn the thermostat control knob up or down to regulate the temperature inside the freezer.
The markings on control knob indicated the“1~4” for the dierent temperature grades. The temperature
decreases with position“1” being the warmest and position“4”being the coldest.
Set the control to position between“1”and “4”for normal use, the exact position is beyond the temperature
in the freezer, generally , choose the number“2”.
The temperature in the freezer is controlled by the thermostat control knob. It is loaded in the top-front of
the freezer. Turn the thermostat control knob up or down to regulate the temperature inside the freezer. The
markings on control knob indicated the “cold~colder” for the dierent temperature grades. The temperature
decreases with position“cold” being the warmest and position“colder” being the coldest.
Set the control to position between“cold” and“colder”for normal use, the exact position is beyond the
temperature in the freezer, generally , choose the “.”.
Store Frozen Food(optional)
When using the freezer for the rst time or after defrosting, turn the temperature control to set“4”for at least
two hours before introducing the food to be stored.
All frozen food products you purchase should be placed in the freezer as soon as possible to avoid the frozen
food from defrosting.
Storage recommendation printed on the packaging of frozen food by the manufacturers should be always be
followed.
Be careful that the drawer mustn’t mangle the refrigeration pipeline.
When using the freezer for the rst time or after defrosting, turn the temperature control to set“colder”for at
least two hours before introducing the food to be stored.
All frozen food products you purchase should be placed in the freezer as soon as possible to avoid the frozen
food from defrosting.
Storage recommendation printed on the packaging of frozen food by the manufacturers should be always be
followed.
Be careful that the drawer mustn’t mangle the refrigeration pipeline.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 15
Freezing Fresh Food
Ensure that your freezing operations are carried out under the most hygienic conditions as freezing alone
does not sterilize the food. It is advisable to freeze the food by packing it into separate meal portions and not
in bulk form. Never put hot or even warm foodstus into the freezer. Prior to storing the frozen food, pack it
in plastic bags, aluminum sheets or freezing containers and place into the freezer. See the data sheet at the
rear of this booklet for the maximum permissible amount in kilograms of fresh food that can be frozen in any
24 hour period with a room temperature of 25°C. Never freeze more than the maximum permissible.
NOTE!
Never put bottled food or drinks in the freezer compartment.
For best performance, leave enough space in the Freezer compartment for air to circulate around the
packages. You can use it without drawer under some conditions.
Defrosting
Remove the mains plug from the wall socket, open the door and remove all the food to a cool place.
Defrost using a plastic scraper, or let the temperature rise naturally until the frost melts. Then wipe away the
remaining ice and water, after this plug the freezer back into the mains supply.
NOTE!
To avoid damaging the freezing compartment wall, do not use any sharp objects to remove the frost or
separate the frozen food.
Cleaning your freezer
Before you start to clean your freezer remove the mains plug from the power supply.
• Dustsbehindtherefrigeratorandonthegroundshallbetimelycleanedtoimprovethecoolingeectand
energy saving.
• Checkthedoorgasketregularlytomakesuretherearenodebris.Cleanthedoorgasketwithasoftcloth
dampened with soapy water or diluted detergent.
• Theinterioroftherefrigeratorshouldbecleanedregularlytoavoidodor.
• Pleaseturnothepowerbeforecleaninginterior,removeallfoods,drinks,shelves,drawers,etc.
• Useasoftclothorspongetocleantheinsideoftherefrigerator,withtwotablespoonsofbakingsodaand
a quart of warm water. Then rinse with water and wipe clean. After cleaning, open the door and let it dry
naturally before turning on the power.
• Forareasthatarediculttocleanintherefrigerator(suchasnarrowsandwiches,gapsorcorners),itis
recommended to wipe them regularly with a soft rag, soft brush, etc. and when necessary, combined with
some auxiliary tools (such as thin sticks) to ensure no contaminants or bacterials accumulation in these
areas.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 16
• Donotusesoap,detergent,scrubpowder,spraycleaner,etc.,asthesemaycauseodorsintheinteriorof
the refrigerator or contaminated food.
• Cleanthebottleframe,shelvesanddrawerswithasoftclothdampenedwithsoapywaterordiluted
detergent. Dry with a soft cloth or dry naturally.
• Wipetheoutersurfaceoftherefrigeratorwithasoftclothdampenedwithsoapywater,detergent,etc.,
and then wipe dry.
• Donotusehardbrushes,cleansteelballs,wirebrushes,abrasives(suchastoothpastes),organicsolvents
(such as alcohol, acetone, banana oil, etc.), boiling water, acid or alkaline items, which may damage the
fridge surface and interior. Boiling water and organic solvents such as benzene may deform or damage
plastic parts.
• Donotrinsedirectlywithwaterorotherliquidsduringcleaningtoavoidshortcircuitsoraectelectrical
insulation after immersion.
PART 9: TROUBLESHOOTING
In case of malfunction, you can solve many common problems easily.
Your Freezer will not operate…Check if
- The power supply cord is unplugged.
The doors will not close completely…Check if
- The drawers are out of position.
- The gaskets are dirty.
- The Freezer is not level.
The freezer is noisy when running…Check if
- Check the freezer is level and it is not in contact with another appliance or kitchen furniture.
The freezer does not cool suciently…Check if
- If the door has been opened too often, or it has been left open for a while it will take time for the freezer to
reach its set temperature.
- Check the airow the rear of the freezer has not been reduced due to insucient clearance.
The following characteristics should not be looked upon as a problem.
- A gentle tricking sound caused by coolant owing the pipe.
- Compressor operating at high temperature.

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 17
PART 10: REFRIGERATOR DOOR INSTALL GUIDELINES
ABOUT SWAPPING LEFT&RIGHT OPTIONAL
1 Disassemeble the screws behind the xed roof with cross-slot screwdriver and remove the cover from the
refrigerator.
2 Remove the screws xed the top-hinge with cross-slot screwdriver.
The screws xed
the top-hinge

Copyright © 2019, Fast ČR, a. s. Revision 05/2019
EN - 18
3 Replace the top-hinge and the door limit block and the door bearing bush to the other side
A replace the top-hinge.
B replace the door bearing bush and the limit block.



