Philco PLD 1061M User manual

AUTOMATIC
WASHING MACHINE
USER'S MANUAL
PLD 1061M

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read
all the instructions in this user's manual.

EN - 1
10/2014Copyright © 2014, Fast ČR, a. s.
CONTENTS
PART 1: BEFORE PUTTING INTO OPERATION................................................................................................. 2
 Safety Precautions..........................................................................................................................................................................2
PART 2: INSTALLATION.................................................................................................................................... 6
 Removal of the transportation screws....................................................................................................................................6
 Levelling the washing machine.................................................................................................................................................6
 Electrical connection.....................................................................................................................................................................7
 Water supply connection.............................................................................................................................................................7
 Water drain connection................................................................................................................................................................8
PART 3: DESCRIPTION OF THE WASHING MACHINE.................................................................................... 10
 Description of the washing machine ................................................................................................................................... 10
 Control panel................................................................................................................................................................................. 10
PART 4: WASHING LAUNDRY......................................................................................................................... 11
 First wash cycle............................................................................................................................................................................. 11
 Before actually washing ............................................................................................................................................................11
 Operating the washing machine ........................................................................................................................................... 12
 Washing program chart............................................................................................................................................................. 15
PART 5: MAINTENANCE AND CLEANING...................................................................................................... 16
PART 6: PRACTICAL INFORMATION.............................................................................................................. 20
PART 7: PREVENTION OF MINOR MALFUNCTIONS ..................................................................................... 21
PART 8: AUTOMATIC MALFUNCTION DETECTION SYSTEM ........................................................................ 22
PART 9: INTERNATIONAL WASHING SYMBOLS............................................................................................ 23
PART 10: TECHNICAL SPECIFICATIONS AND INFORMATION SHEET .......................................................... 24
PART 11: ENERGY SAVING TIPS..................................................................................................................... 25

EN - 2
10/2014Copyright © 2014, Fast ČR, a. s.
PART 1: BEFORE PUTTING INTO OPERATION
Safety Precautions
- If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualied persons in
order to avoid a hazard.
- The new hose-sets supplied with the appliance are to be used
and that old hose-sets should not be reused.
- This washing machine is for indoor use only.
- The openings must not be obstructed by a carpet.
- (This warning is only for EUROPEAN market ). This appliance
can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in
a safeway and understand the hazards involved.Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
- (This warning is not for EUROPEAN market). This appliance is not
intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge,unlesstheyhavebeengivensupervisionorinstruction
concerning use of the applianceby a person responsible for their
safety. Children should be supervised to ensure that they do not
play with the appliance.
- Notes on disposal:
This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent
possible harm to the environment or human health from

EN - 3
10/2014Copyright © 2014, Fast ČR, a. s.
uncontrolled waste disposal,recycle it responsibly to promote
the sustainable reuse of material resources. To return your used
device, please use the collection systems or contact the retailer
where the product was purchased. They return and can take this
product for environmental safe recycling.
- Pull out its plug from the power socket before cleaning or
maintenance.
- Make sure that all pockets are emptied.
- Sharp and rigid items such as coin, brooch,nail,screw or stone etc.
may cause serious damages to this machine.
- Pull out its plug and cut o water supply after the operation.
- Please check whether the water inside the drum has been drained
before opening its door. Please do not open the door if there is
any water visible.
- Pets and kids may climb into the machine. Check the machine
before every operation.
- Glass door may be very hot during the operation.Keep kids and
pets far away from the machine during the operation.
- Take care that power voltage and frequency shall be identical to
those of washing machine.
- Do not use any socket with rated current less than that of washing
machine.Never pull out power plug with wet hand.
- To ensure your safety, power cord plug must be inserted into an
earthed three-pole socket.Check carefully and tmake sure hat
your socket is properly and reliably earthed.
- Children of less than 3 years should be kept away unless
continously supervised.
- Kids should be supervised to ensure that they do not play with
the machine.
- Packing materials may be dangerous to the kids. Please keep all
packing materials (plastic bags, foams etc) far away from the kids.

EN - 4
10/2014Copyright © 2014, Fast ČR, a. s.
- Do not install your washing machine in rooms with high humidity
or in rooms with explosive or caustic gases.
- Makesurethatthe waterandelectricaldevicesmust be connected
by a qualied technician in accordance with the manufacturer’s
instructions and local safety regulations.
- Before operating this machine,all packages and transport bolts
must be removed. Otherwise, the washing machine may be
seriously damaged while washing the clothes.
- Before washing the clothes at rst time, the washing machine
shall be operated in one round of the whole procedures without
the clothes inside.
- The washing machine with single inlet valve only can be
connected to the cold water supply. The washing machine with
double inlet valves can be connected to the hot water and cold
water supply.
- Your washing machine is only for home use and is only designed
for the textiles suitable for machine washing.
- Flammable and explosive or toxic solvents are forbidden. Gasoline
and alcohol etc. Shall not be used as detergents. Please only select
the detergents suitable for machine washing, especially for drum.
- It is forbidden to wash carpets.
- Be careful of burning when washing machine drains hot washing
water.
- Never rell the water by hand during washing.
- After the program is completed, Please wait for two minutes to
open the door.
- Please remember to disconnect water and power supply
immediately after the clothes are washed.
- Do not climb up and sit on top cover of the machine.
- Do not lean against machine door.

EN - 5
10/2014Copyright © 2014, Fast ČR, a. s.
- Please do not close the door with excessive forces. If it is found
dicult to close the door, please check if the excessive clothes are
put in or distributed well.
- The household washing machine isn’t intended to be built-in.
- Cautions during Handling Machine
1. Transport bolts shall be reinstalled to the machine by
a specialized person.
2. The accumulated water shall be drained out of the machine.
3. Handle the machine carefully.Never hold each protruded part
on the machine while lifting. Machine door can not be used as
the handle during the conveyance.

EN - 6
10/2014Copyright © 2014, Fast ČR, a. s.
PART 2: INSTALLATION
Removal of the transportation screws
• You must remove the transportation screws located in the back part of the washing machine before
putting it into operation.
• Loosen the screws using a correctly sized spanner, by turning them anticlockwise.
• Remove the screws by pulling them out.
• Insert plastic plugs found in the accessories pouch, into the transport screw holes.
• Carefully store the transportation screws removed from the washing machine for future transport purposes.
NOTE:
Defects caused by starting the washing machine with the transportation screws installed are not covered
by the warranty.
Levelling the washing machine
• Do not place the washing machine on carpets or similar surfaces.
• To ensure quiet and vibration free operation of your washing machine, you should place it on an even,
non-slip and rm surface.
You can level the washing machine by adjusting the adjustable feet:
• First loosen the plastic nut.
• Adjust by screwing out the feet upwards or downwards.
• After levelling the washing machine, re-tighten the plastic nut by screwing it upwards.
• Never level the washing machine on an uneven surface by placing cardboard, wooden blocks, etc. under
the feet.

EN - 7
10/2014Copyright © 2014, Fast ČR, a. s.
Electrical connection
• Technical specications of your washing machine: 220-240 V ~ 50 Hz.
• A special grounding plug is attached to the power cord of your washing machine. This plug must be
fully inserted into a grounded power socket (with 10A). The electrical fuse or circuit breaker to which the
washing machine is connected should be rated at 10A. If you do not have such sockets and fuses in your
home, have them installed by a qualied electrician.
• Our company takes no responsibility for whatever damages caused by using the washing machine without
grounding.
Water supply connection
• Depending on the functions of your washing machine, the washing machine is equipped with either
a single water inlet (cold) or a double water inlet (cold/hot). The hose with the white end is intended for the
cold water inlet and the hose with the red end is intended for the hot water inlet (on washing machines
with a hot and cold water inlet).
• So that water does not leak from the connection points, the hose kit also includes 1 seal (for washing
machines with a cold water inlet) or 2 seals (for washing machines with hot and cold water inlets). Install
these seals on the end of the water inlet hose that is to be connected to the tap.
• Connect the hose with the white end to the water inlet valve with the white lter and the hose with the red
end to the water inlet valve with the red lter (the second mentioned option applies to washing machines
with a hot and cold water connection). Tighten the plastic connecting parts using your hand. A qualied
plumber will provide a safer connection.
• The water pressure of 0.1 - 1 MPa in your water tap will ensure a more ecient operation of your washing
machine (the pressure of 0.1 MPa equates to a ow rate of more than 8 litres of water per minute from
a fully open tap).
• After the connections are complete, check that the connections do leak by fully opening the tap.
• Check that the supply hoses are not bent, broken or cracked.
• Connect the supply hose to a 3/4" threaded water tap.
• If the washing machine has a dual water inlet (for hot and cold water), the temperature of the hot water
should not exceed 70 °C.

EN - 8
10/2014Copyright © 2014, Fast ČR, a. s.
Water drain connection
• Check that the supply hoses are not bent, twisted, cracked or excessively stretched.
• The drain hose should be installed at a height of min. 60 cm and max. 100 cm above the ground.
• The end of the drain hose may be inserted directly into the drain opening or to a special end tting
attached to the drain of the wash basin.
• Never attempt to extend the length of the drain hose by adding extra parts.
NOTE:
Do not place the drain hose into a container, bucket or sink.
NOTE:
If the appliance is equipped with a drain hose, install it according to the picture shown below.
