Philco PLS 1040 User manual

Automatic Washing Machine
USER'S MANUAL
PLS1040/PLS 1040 DS

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all
the instructions in this user's manual.

EN - 1
01/2011
Copyright © 2011, Fast ČR, a. s.
CONTENTS
PART 1: BEFORE PUTTING INTO OPERATION................................................................................................. 2
• Important safety instructions.....................................................................................................................................................2
• General safety information..........................................................................................................................................................2
• Recommendations.........................................................................................................................................................................3
PART 2: INSTALLATION.................................................................................................................................... 4
• Removal of the transportation screws....................................................................................................................................4
• Levelling the washing machine.................................................................................................................................................5
• Electrical connection.....................................................................................................................................................................5
• Water supply connection.............................................................................................................................................................5
• Water drain connection................................................................................................................................................................6
PART 3: CONTROL PANEL ................................................................................................................................ 7
• Start/Pause button.........................................................................................................................................................................7
• Individual function indicator lights..........................................................................................................................................7
• Function buttons ............................................................................................................................................................................8
• Spinning speed knob ....................................................................................................................................................................8
• Program selector.............................................................................................................................................................................9
PART 4: WASHING YOUR LAUNDRY .............................................................................................................. 10
• First wash cycle.............................................................................................................................................................................10
• Before actually washing ............................................................................................................................................................10
• Operating the washing machine ........................................................................................................................................... 11
• Child lock ........................................................................................................................................................................................ 12
PART 5: MAINTENANCE AND CLEANING...................................................................................................... 14
• Water inlet lters.......................................................................................................................................................................... 14
• Pump lter......................................................................................................................................................................................14
• Detergent drawer ........................................................................................................................................................................15
• Siphon plug ................................................................................................................................................................................... 16
• Cabinet of the washing machine...........................................................................................................................................16
• Drum.................................................................................................................................................................................................16
• Removal of scale deposits from the washing machine..................................................................................................16
PART 6: PRACTICAL INFORMATION.............................................................................................................. 18
PART 7: PREVENTION OF MINOR MALFUNCTIONS ..................................................................................... 18
PART 8: AUTOMATIC MALFUNCTION DETECTION SYSTEM ........................................................................ 21
PART 9: INTERNATIONAL WASHING SYMBOLS............................................................................................ 23
PART 10: TECHNICAL SPECIFICATIONS ........................................................................................................ 24
PART 11: ENERGY SAVING TIPS..................................................................................................................... 24

EN - 2
01/2011
Copyright © 2011, Fast ČR, a. s.
PART 1: BEFORE PUTTING INTO OPERATION
Important safety instructions:
• Read carefully and store for future use.
• The safety of this appliance complies with industry norms and meets legal appliance safety requirements.
However, as manufacturers, we consider it our duty to provide you with the following safety instructions.
• It is essential that you store this user's manual in a safe place so that you can use it in the future.
If you intend to sell the appliance, give it to another owner, or if you move, always make sure that the user's
manualisattachedtotheappliance,so thatthenew ownercanndoutabouttheoperationoftheappliance
and the relevant warnings.
• Before installation or operation of the appliance you MUST carefully read all the safety instructions
and the user's manual.
• Before putting the appliance into operation for the rst time, check that it has not been damaged during
transport.
• Never connect a damaged appliance. If some parts are damaged, contact the supplier.
• If the washing machine is supplied in the winter months, when the temperature falls under 0°C, store the
appliance at room temperature for 24 hours before rst use.
General safety instructions
• Changing the technical parameters, or any making other modications to the appliance is dangerous.
• During the course of the high temperature program the door heats up to a high temperature. Do not
touch the door!
• Ensure that small household pets cannot get into the drum. It is therefore better to always check the inside
of the drum before use.
• Items such as coins, safety pins, nails, bolts, stones and other heavy or sharp items can cause considerable
damage and do not belong in the appliance.
• Use only the recommended amount of fabric softener and washing detergents. If you use a higher amount
than is recommended, the fabric could be damaged.
• Always use the amount of detergent recommended by the manufacturer.
• Small pieces of laundry such as socks, shoelaces, washing bands, etc. should be washed in a special
purpose washing bag or in a pillow case, because the individual items could become jammed between
the tube and the rotating drum.
• Do not use the washing machine to wash products from metal skeletons, fabrics which are not hemmed
or that snag.
• After use, before cleaning or maintenance always disconnect the washing machine from the power supply
and turn o the water inlet.
• Never attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may lead to
injuries or serious damage to the appliance. Contact your local service centre for repairs. Always request
original spare parts.
• Do not use multi-sockets or extension cords.
• Do not plug in the appliance with a defective power cord.
• If the power cord is damaged, have it replaced by the manufacturer or an authorised service technician to
prevent hazardous situations.

EN - 3
01/2011
Copyright © 2011, Fast ČR, a. s.
• Do not pull the power plug out of the power socket by pulling on the cord. Hold the power cord by holding
the power plug directly.
• Do not connect the power plug if you have wet hands.
• Never touch the appliance if you have wet hands or feet.
• Never open the detergent drawer while washing.
• Never attempt to open the washing machine door while washing.
• Because the washing machine can become very hot during operation, do not touch the hose during the
draining or lling process.
• In the case of any defect, rst turn o the appliance, disconnect it from the power supply and shut o the
water inlet. Do not attempt to repair the device yourself. Contact the nearest authorised service.
• Do not forget that the packaging material from the washing machine may present a danger to children.
• Do not allow children to play with the washing machine.
• Keep household pets at a safe distance from the washing machine.
• The washing machine should only be used by persons fully instructed about the instructions, provisions
and controls described in this user's manual.
• This washing machine is designed for domestic use only. The use of the washing machine for commercial
purposes voids the warranty.
• Do not install the appliance on a carpet or another similar surface, which could block the ventilation
openings on the underside.
• Do not place the drain hose into a container, bucket or sink.
Recommendation
• Long term contact of washing detergents and fabric softeners with air will cause them to dry out and stick
to the walls of the drawer. To prevent this from happening, ll the drawer with washing detergent and
fabric softener immediately before washing.
• We recommend the use of the prewash only for heavily soiled laundry.
• Do not exceed the maximum loading capacity of the drum.
• This appliance must not be used by persons (including children) with physical, sensory or psychological
impairments or by inexperienced persons, unless properly trained or schooled in the safe use of the
appliance, or unless they have been properly supervised by a person who will be responsible for their
safety. Children should be supervised so as not to play with the appliance.
• If you will not be using the washing machine for an extended period of time, pull it out of the power
socket, shut o the water inlet and leave the door open so that the inside of the washing machine can dry
out and so unpleasant odours are not created.
• As a result of quality control procedures some water may remain in the washing machine. This will not
damage the washing machine in any way.
• We recommend that the rst wash is performed using theWhite 90 - 95° program (depending on the model)
without any laundry, put 1/2 a measuring cup of detergent into the second detergent compartment.

EN - 4
01/2011
Copyright © 2011, Fast ČR, a. s.
PART 2: INSTALLATION
Carefully read the entire user's manual before putting your washing machine into operation and store it in
a safe place for future reference.
Removal of the transportation screws
• You must remove the transportation screws located in the back part of the washing machine before
putting it into operation.
• Loosen the bolts using a correctly sized spanner, turning it anticlockwise. (PIC. 1)
• Remove the bolts by pulling them out. (PIC. 2)
•Insert plastic plugs found in the accessories pouch, into the transportation screw openings.
(PIC. 3)
• Carefully store the transportation screws removed from the washing machine for future transport
purposes.
NOTE:
Defects caused by starting the washing machine with the transportation screws installed are not covered
by the warranty.
PIC. 1 PIC. 2 PIC. 3

EN - 5
01/2011
Copyright © 2011, Fast ČR, a. s.
Levelling the washing machine
• Do not place the washing machine on carpets or similar surfaces.
• To ensure quite and vibration free operation of your washing machine, you should place it on an even,
non-slip and rm surface.
You can level the washing machine by adjusting the adjustable feet:
• First loosen the plastic nut.
• Adjust by screwing out the feet upwards or downwards.
• After levelling the washing machine, re-tighten the plastic nut by screwing it upwards.
• Never level the washing machine on an uneven surface by placing cardboard, wooden blocks, etc. under
the feet.
Electrical connection
• Technical specications of your washing machine: 220-240 V ~ 50 Hz.
• A special grounding plug is attached to the power cord of your washing machine. This plug must be fully
inserted into a grounded power socket (with 10 A). The electrical fuse or circuit breaker to which the
washing machine is connected should be rated at 10A. If you do not have such sockets and fuses in your
home, have them installed by a qualied electrician.
• Our company takes no responsibility for whatever damages caused by using the washing machine without
grounding.
Water supply connection
• Depending on the functions of your washing machine the washing machine is equipped with either a
single water inlet (cold) or a double water inlet (cold/hot). The hose with the white end is intended for the
cold water inlet and the hose with the red end is intended for the hot water inlet (on washing machines
with a hot and cold water inlet).
• So that water does not leak from the connection points, the hose kit also includes 1 seal (for washing
machines with a cold water inlet) or 2 seals (for washing machines with hot and cold water inlets). Install
these seals on the end of the water inlet hose connected to the tap.
• Connect the hose with the white end to the water inlet valve with the white lter and the hose with the red
end to the water inlet valve with the red lter (the second mentioned option applies to washing machines
with a hot and cold water connection). Tighten the plastic connecting parts using your hand. A qualied
plumber will provide a safer connection.
• The water pressure of 0.1 - 1 MPa in your water tap will ensure a more ecient operation of your washing
machine (the pressure of 0.1 MPa equates to a ow rate of more than 8 litres of water per minute from
a fully open tap).

EN - 6
01/2011
Copyright © 2011, Fast ČR, a. s.
• After the connections are complete, check that the connections do leak, by fully opening the tap.
• Check that the supply hoses are not bent, broken or cracked.
• Connect the supply hose to a 3/4" threaded water tap.
• If the washing machine has a dual water inlet (for hot and cold water), the temperature of the hot water
should not exceed 70 °C.
Hot water inlet (valve with a red lter)
Cold water inlet (valve with a white lter)
Water drain connection
• Check that the supply hoses are not bent, twisted, cracked or excessively stretched.
• The drain hose should be installed at a height of min. 60 cm and max. 100 cm above the ground.
• The end of the drain hose may be inserted directly into the drain opening or to a special end tting
attached to the drain of the wash basin.
• Never attempt to extend the length of the drain hose by adding extra parts.
NOTE:
Do not place the drain hose into a container, bucket or sink.

EN - 7
01/2011
Copyright © 2011, Fast ČR, a. s.
PART 3: CONTROL PANEL
Control panel
(4 buttons, spinning speed knob)
1. Drawer for washing detergents 6. Program selector
2. Start/pause indicator light 7. Start/pause button
3. Individual function indicator lights 8. Function buttons
4. Spinning speed knob 9. End of program indicator light
5. Activation of program indicator light
START/PAUSE Button
Intended for starting the selected program or to pause the program that is running.
WARNING!
Before selecting the desired program or changing a program, you must have the program selector
turned to the O position (o).
Individual function indicator lights
If you press any function button or the Start/pause button, the respective indicator light will turn on. The
indicator light will turn o if you press any other function button or the Start/pause button or at the completion
of the selected function.
The function indicator lights are also used for the troubleshooting system, see chapter 8.
1 2 3 4 5 6
7 8 9

EN - 8
01/2011
Copyright © 2011, Fast ČR, a. s.
Function buttons
Rinse hold
We recommend you use this function if you cannot immediately take the laundry out of the washing machine
after the end of the program. This will prevent it becoming crumpled. If you press this button, the water from
the last rinse will not be released. If you want the program to continue from the place where it was interrupted,
press the same button again.
If you do not wish to spin your laundry or you wish it to be spun in a gentle manner, move the program selector
to the O position (o). Turn the program selector to one of the draining or spinning programs, which you
desire and press the Start/pause button. If you selected the rinsing program, the washing machine will drain
the water. If you select the spinning program, the washing machine will activate the spinning and then the
program will end.
Easy ironing
Using this function will ensure that after being washed the laundry will be less crumpled.
You will achieve better results if before lling the washing machine and starting washing you leave the laundry
to soak in the water and detergent. We recommend the use of this function for heavily soiled laundry.
Extra rinse
Apart from the standard rinse you can set an additional rinse, which the washing machine performs using this
function in all washing programs.
WARNING!
If you forget to set an additional function and the washing machine has already started washing,
press the additional function button. If its indicator light turns on, the additional function has been
activated. If its indicator light does not turn on, the additional function has not been activated.
Spinning speed knob
Using the spinning speed knob you can adjust the spinning speed for your laundry. The speed range is from 0
(no spinning) up to the maximum spinning speed of your washing machine.
0
400
550
700
850
1000
NOTE:
Carry out the spinning of your delicate laundry using the most appropriate mode.

EN - 9
01/2011
Copyright © 2011, Fast ČR, a. s.
Program selector
Using the program selector, select a program, in which you wish to wash your laundry. The program selection
may be done by turning the program selector knob in both directions. When making settings, ensure that the
symbol on the program selector exactly matches your selected washing program. If you turn the program
selector to the o position (o) during the wash, the program will remain unchanged.
1. Cotton 90°C 13. Synthetics 50°C
2. Cotton 60°C with prewash 14. Synthetics in cold water
3. Cotton 60°C 15. Washing curtains/drapes
4. Cotton 40°C 16. Delicates 30°C
5. ECO wash 17. Delicates in cold water
6. Cotton 30°C 18. Hand wash
7. Quick wash 19. Wool 30°C
8. Cotton in cold water 20. Wool in cold water
9. Mix wash 21. Rinse
10. Syntetics 60°C 22. Spin (spinning)
11. Antiallergic wash 23. Drain ( draining)
12. Synthetics 40°C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

EN - 10
01/2011
Copyright © 2011, Fast ČR, a. s.
PART 4: WASHING LAUNDRY
• Connect the washing machine to the power socket.
• Open the water tap.
First wash cycle
There may be some water left over inside the washing machine from the factory tests.We therefore recommend
to perform the rst wash without laundry so as to drain this water; put half a measure of standard detergent
into compartment 2, which is used for washing detergents and select the program for cotton at 90 °C.
Before actually washing
Sorting laundry
• Sort the laundry according to its type (cotton, synthetics, delicates, wool, etc.), washing temperature and
the level of dirtiness.
• Never wash whites together with coloured laundry.
• Because your new coloured laundry may release some of its colour, wash it separately.
• Before placing the laundry into the washing machine check pockets for any forgotten items. In this way
you will prevent damaging your clothes and the washing machine.
• Do up zips and buttons on the laundry.
• From curtains and drapes remove the plastic or metal hooks or insert the into a wash bag and tie it up.
• Turn clothing such as pants, knitted fabrics, T-shirts and singlets inside out.
• Wash small items such as socks and handkerchiefs in a wash bag.
Washing up to 90 ˚C Washing up to 60 ˚C Washing up to 30 ˚C Do not wash in a washing machine
Placing clothing inside the washing machine
• Open the door of the washing machine.
• Spread the laundry evenly inside the washing machine.
• Insert one item at a time.
• When closing the door, make sure that no laundry has been caught in the door.
• Firmly close the washing machine door, otherwise the washing machine will not start.
Detergent dosage
The amount of detergent you use in the washing machine depends on the following criteria:
• The consumption of detergent changes with the degree of dirtiness of the laundry. Do not use a prewash
for lightly soiled laundry and use a small amount of detergent in the 2 compartment for washing
detergents.
• For excessively soiled laundry select a program with a prewash, put ¼ of a detergent measuring cup into
compartment 1 for washing detergents and put the remainder of the measuring cup into compartment 2.
• Use washing detergents specially made for automatic washing machines. The dosage of the detergent is
shown on the packaging.
• Increased water hardness necessitates the use of an increased amount of detergent in the wash.
PART 4
:
WA
S
HING LA
U
NDRY

EN - 11
01/2011
Copyright © 2011, Fast ČR, a. s.
• Increases laundry amounts also necessitate the use of an increased amount of detergent in the wash.
• Pour fabric softeners (conditioners) into the fabric softener compartment in the detergent drawer. Do
not go over the MAX mark. Otherwise the fabric softener will ow out the siphon into the water used for
washing.
• If the fabric softener is very thick then dilute it with water before placing it in the compartment. The thick
fabric softener could clog up your siphon and so prevent the fabric softener from entering the washing
machine.
• You can use liquid detergents for all washing programs without a prewash. For this purpose install into the
second detergent compartment in the drawer a measuring cup and pour in the detergent according to the
mark shown on the measuring cup.
Operating the washing machine
Selecting programs and functions
Select a program and additional functions appropriate for your laundry according to table 1.
Start/pause button
Press this button to start the selected program or to stop a currently running program.
Starting a program
• Set to program selector to the desired program.
• The program indicator light will turn on.
• If necessary you may select one or more additional functions.
• Start the selected program by pressing the Start/pause button.
Changing a program
If you have selected a program and you do not wish it to run to its completion:
• Press the Start/pause button.
• Turn the program selector by turning it to O (o).
• Set the program selector to the desired program. (You may select a program according to table 1.)
• The program indicator light will turn on.
• Start the selected program by pressing the Start/pause button
Cancelling a program
If you want to stop a program that is running sooner:
• Press the Start/pause button.
• Turn the program selector by turning it to O (o).
• Turn the program selector to the drain or spinning program.
• The program indicator light will turn on.
• Start the selected program by pressing the Start/pause button.

EN - 12
01/2011
Copyright © 2011, Fast ČR, a. s.
Ending a program
• After the completion of a selected program the washing machine will automatically stop.
• The end of program indicator light will turn on.
• Turn the program selector by turning it to O (o).
• The door will unblock itself about two minutes after the end of the program. Open the door by pulling on
the door handle towards yourself and take the laundry out of the washing machine.
• After taking the laundry out of the washing machine, leave the door open so that the washing machine
can dry out.
• Disconnect the washing machine from the power socket.
• Shut o the water inlet.
WARNING!
If at any washing stage the washing machine is turned o and then on again, the washing machine
will activated the program in the place where it was interrupted. This will not damage the washing
machine in any way.
Child safety lock
The child safety lock is designed to prevent a program from being changed by a button being pressed during a
wash. The child lock is activated by simultaneously pressing the rst and third function buttons on the control
panel and holding them down for at least 3 seconds. After it has been activated the LED indicator lights will
ash on the function buttons indicating that the child lock is on. Deactivate the child lock by pressing the same
buttons (the rst and third) and holding them down for at least 3 seconds. The LED indicator light on the Start/
pause button will ash to indicate that the lock has been turned o.
WARNING!
After the child lock is turned on the washing machine will disable the program selector, spinning
speed knob and the function buttons.

EN - 13
01/2011
Copyright © 2011, Fast ČR, a. s.
Table 1
PROGRAM DETERGENT
COMPARTMENT
MAX. DRY
LAUNDRY
CAPACITY (kg)
TYPE OF LAUNDRY EXPLANATION
COTTON 90˚ 2 4 Dirty cotton and linen laundry for boiling
Underwear, bed linen,
table cloths, T-shirts, shirts,
towels
COTTON 60˚ (PREWASH) 1+2 4 Heavily soiled coloured cotton
and linen laundry
COTTON 60˚ 2 4 Dirty coloured cotton and linen laundry
COTTON 40˚ 2 4Lightly soiled coloured cotton
and linen laundry leaking colour
ECO WASH 2 4 Soiled coloured cotton and linen laundry
COTTON 30˚ 2 4 Lightly soiled coloured cotton
and linen laundry
QUICK WASH 2 2 Slightly dirty coloured cotton
and linen laundry
WOOL IN COLD WATER 2 4 Lightly soiled coloured cotton and linen laundry
leaking colour without water heating.
MIX
WASH (MIX) 24
Dirty or very dirty coloured cotton or linen
laundry with stains.
SYNTHETICS 60˚ 2 2 Dirty laundry from synthetics or synthetic blends Nylon stockings, blouses
ANTIALLERGIC 2 2 Children's laundry All children's laundry
SYNTHETICS 40˚ 2 2 Slightly dirty laundry from synthetics or synthetic
blends Nylon stockings, blouses
SYNTHETICS 50˚ 2 2 Sports laundry All sports laundry and
jeans
SYNTHETICS IN COLD
WATER 22
Slightly dirty delicate laundry from synthetics or
synthetic blends. Washing without heating water. Nylon stockings, blouses
WASHING CURTAINS/
DRAPES 1+2 2 Tulle netting and curtains as delicate laundry Tulle netting, drapes,
diolen, dralon
DELICATES 30˚ 2 1 Slightly soiled delicate coloured laundry
from cotton and synthetics or synthetic blends Silk blends, blouses,
polyester, polyamide,
blended fabrics
DELICATES IN COLD WATER 2 1
Very slightly soiled delicate coloured laundry
from cotton and synthetics or synthetic blends,
washing in cold water
HAND WASH 2 1 Slightly soiled coloured laundry from cotton and
synthetics or synthetic blends, hand wash Hand wash of all laundry
WOOL 30˚ 2 1 Dirt woollen laundry intended for hand wash and
machine wash
All woollen laundry
WOOL IN COLD WATER 2 1
Very lightly soiled woollen laundry intended
for hand washing and for machine washing in
cold water
RINSE If you need to rinse the washed laundry once more, you can use this program for any type of laundry.
SPIN (spinning) If you need to spin the washed laundry once more, you can use this program for any type of laundry.
DRAIN (DRAINING) This program is intended for draining dirty water from the washing machine after the laundry has been washed. If you
wish to drain the water out of the washing machine before the completion of a program, you may use this program.
NOTE:
(*) Softeners (conditioners) can be used for all programs (except for spinning and draining). When selecting
a softener dose follow the instructions of the softener’s manufacturer. Pour the fabric softener into the softener
compartment in the detergent drawer.

EN - 14
01/2011
Copyright © 2011, Fast ČR, a. s.
PART 5: MAINTENANCE AND CLEANING
• Disconnect the washing machine from the power socket.
• Shut o the water inlet.
The water inlet lters
There are lters connected to the hose ends at the tap end and at the end of the inlet valves, which prevent dirt
and foreign materials contained in water entering the washing machine. If the washing machine is not lling
up with a sucient amount of water despite the water inlet being open, clean these lters.
• Disconnect the supply hose.
• Using tweezers take the lters out of the inlet valves and wash them with a brush.
• Using your hand take out the lters on the supply hoses at the end connected to the tap together with the
seals and clean them.
• After cleaning the lters put them back in the same way.
Attention:
The water inlet valves may be blocked by a contaminated water supply or because of inadequate
necessary maintenance, or the valves may be damaged, which may cause a water to constantly
ow through. For these reasons such types of malfunctions are not covered by the warranty.
The pump lter
The pump ltration system extends the life of the pump, which is used for draining dirty water. It ensures that
lint from the laundry does not enter the pump. We recommend you clean the pump lter every 2-3 months.
Clean the pump lter as follows:
• Open the cover on the kickplate.
• Before opening the lter cover, place a container in front of it, into which the water remaining in the
washing machine will ow.
• Loosen the lter cover by turning it anticlockwise and drain the water.
• Remove all foreign material from the lter.
• Check by hand that the pump rotates.
• After cleaning the pump, return the lter by turning it clockwise.
PART
5:
MAINTENAN
C
E AND
C
LEANIN
G

EN - 15
01/2011
Copyright © 2011, Fast ČR, a. s.
• Reattach the kickplate cover.
• Don't forget that if you do not attach it correctly, water will leak from your washing machine.
WARNING!
Danger of scalding!
Because the water in the pump may be very hot, wait until it has cooled down.
The drawer for washing detergents
Over time washing detergent deposits may accumulate in the drawer and in the washing machine opening.
Therefore, the washing detergent drawer needs to be regularly cleaned from accumulated deposits. Take the
drawer out as follows:
• Pull the drawer out completely (PIC. 1).
• Fully press down the lid of the siphon inside the drawer and pull the drawer until you pull it out (PIC. 2).
• Wash with water and an old toothbrush.
• Remove the deposits accumulated inside the drawer opening without them being allowed to enter the
washing machine.
• Once the drawer is dry, insert it back into the washing machine in the reverse sequence here described.
PIC. 1 PIC. 2

EN - 16
01/2011
Copyright © 2011, Fast ČR, a. s.
The siphon plug
Take out the washing detergent drawer. Pull out the siphon plug and thoroughly clean o fabric softener
residue. Reinsert the cleaned siphon plug in its place. Check that it is properly inserted.
Siphon plug
The washing machine cabinet
Clean the washing machine from the outside using lukewarm water and a gentle cleaning agent, which will
not damage the surface coat of the washing machine cabinet. After rinsing with clean water, wipe the washing
machine with a soft and dry wiping cloth.
WARNING!
If you have installed the washing machine in a place where the ambient temperature falls below
0°C and you will not be using it, do the following:
• Connect the washing machine to a power socket.
•Close the water tap and disconnect the supply hose or hoses.
•Insert the end of the drain hose and supply hose into a container on the ground.
• Set to program selector to the drain program.
•The program indicator light will turn on.
•Start the program by pressing the Start/pause button.
•After the program has nished (the end indicator light will turn on) disconnect the washing
machine from the power socket.
After completing these steps the remaining water in the washing machine will be drained, which
will avoid the danger of it freezing inside the washing machine. If you wish to use the washing
machine again, ensure that the ambient temperature is above 0°C.
The Drum
Do not leave any metal items inside the washing machine, such as needles, clips or coins, etc. These items can
cause rusty stains to appear on the drum. If you wish to remove these stains, use a cleaning agent
not containing chloride and follow the instruct of the cleaning agent's manufacturer. Never use steel wool
used for dishes, or any other similar abrasive items to clean the rusty stains.
Removal of scale deposits from the washing machine
We recommend the use of a commonly available scale remover and to follow the instructions printed on the
packaging.
WARNING!
Scale removal mixes contain acids and may cause discolouration of your laundry and may have
a negative eect on your washing machine.

EN - 17
01/2011
Copyright © 2011, Fast ČR, a. s.
PART 6: PRACTICAL INFORMATION
Alcoholic beverages: First prewash the stain in cold water, then apply glycerine
and water and rinse in a solution of water and vinegar.
Shoe polish: First lightly scrub the stain without damaging the fabric using washing detergent
and rinse. If the stain does not go away, apply a solution of one part pure alcohol (96 percent)
and two parts water and subsequently wash in lukewarm water.
Tea and coee: Strech the part of the laundry with the stain over the top of a pot and rinse with
water that is as hot as the fabric will handle. If it is appropriate for your laundry, wash the stain in
bleaching lye.
Chocolate and cocoa: Leave your laundry in cold water and scrub with soap or washing
detergent, then wash in water that is as hot as the fabric will handle. If an oily stain remains on
your laundry, wash in hydrogen peroxide (concentration 3%).
Ketchup:Afterscratchingawaydriedresidueswithoutdamagingthelaundry,leavetosoakforabout
30 minutes in cold water and wash with a washing detergent.
Bouillon, eggs: Remove dried residues and wipe with a sponge or a soft wiping cloth dipped in
cold water. Apply washing detergent and wash in diluted lye.
Greasy and oily stains: First wipe away residues. Apply washing powder to the stain and then
wash in lukewarm water soapy water.
Mustard: First apply glycerine to the stain. Apply washing powder and then wash. If the stain
does not disappear, apply alcohol to the stain (for synthetics and coloured laundry use a solution
of 1 part alcohol and 2 parts water)
Blood: Leave your laundry to soak in cold water for 30 minutes. If the stain does not disappear,
dip into a solution of water and ammonia (3 spoons of ammonia per 4 litres of water) for about
30 minutes.
Cream, ice cream and milk: Leave your laundry in cold water and apply washing detergent to the
stain. If the stain does not disappear, apply lye to it in the correct concentration for the given type
of fabric (do not use lye on coloured laundry).
Soil: Remove soil stains as soon as possible. Wash in washing detergent and if it does not
disappear, apply oxygenated water (concentration 3%).
Ink: Dip the stain in cold water and wait until the ink dissolves in the water. Then apply water with
lemon juice a washing detergent to the stain, wait about 5 minutes and then wash.
Fruit: Stretch the part of the laundry with the stain over the top of a pot and pour cold water on
it. Pour hot water on to the stain. Apply cold water and glycerine.Wait 1-2 hours and sprinkle with
white vinegar, then rinse.
Grass stains: Apply washing detergent to the stain. If it is appropriate for this type laundry, wash
the stain in lye. To woollen clothing apply alcohol. (For coloured clothing us a solution of 1 part
pure alcohol and 2 parts water).
Oil paints: You should remove the stains before they dry using a solvent. Then apply a washing
detergent and wash.
Scorch stains: If your laundry will allow it, you can put lye into the washing water.
For woollen laundry you should cover the stain with a wiping cloth dipped in oxygenated water,
place a dry wiping cloth over this and iron over the stain. After rinsing you should thoroughly was
the laundry.
PART
6:
PRA
C
TI
C
AL INF
O
RMATI
O
N

EN - 18
01/2011
Copyright © 2011, Fast ČR, a. s.
PART 7: PREVENTION OF MINOR MALFUNCTIONS
All necessary repairs of the washing machine should be performed by an authorised service centre. If it is
necessary to repair your washing machine or you are unable to remedy the malfunction using the information
below:
• Disconnect the washing machine from the power socket.
• Shut o the water inlet.
• Contact the nearest authorised service.
MALFUNCTION POSSIBLE CAUSE REMEDY
You washing machine is not
working.
It is not connected to a power
socket.
Connect the power plug to the
power socket.
The fuse has burnt out. Replace the fuse.
A power outage occurred. Check whether the electricity is
working.
You didn't press the Start/pause
button. Press the Start/pause button.
The program selector is in the
position O (o).
Turn the program selector to the
desired position.
The washing machine door is not
properly shut.
Close the door properly. You
should hear it click in.
Your washing machine is not
lling up with water.
The water inlet is shut o. Open the water inlet.
The supply hose may be bent. Check the supply hose.
The supply hose is clogged. Clean the supply hose lters. (*)
The inlet valve lter is clogged. Clean the inlet valve lters. (*)
The washing machine door is not
properly shut.
Close the door properly. You
should hear it click in.
Your washing machine is not
draining water.
The drain hose is clogged or bent. Check the drain hose.
The pump lter is clogged. Clean out the pump lter. (*)
You didn't place the laundry
evenly into the washing machine.
Arrange the laundry inside the
washing machine so that it is
evenly arranged in the drum.
The washing machine is vibrat-
ing.
The washing machine is standing on
an uneven surface or is not level.
Check that it is standing on an even
surface and that it is level. (**)
You didn't remove the transport-
ing screws.
Remove the transporting screws.
(**)
(*) See chapter referring to cleaning and maintenance.
(**) See chapter referring to the installation of your washing machine.
PART 7
:
PREVENTI
O
N
O
F MIN
O
R MALF
U
N
C
TI
O
NS
