Philco PLWD 14961 CHIVA User manual

AUTOMATIC WASHING
MACHINE WITH DRYER
USER'S MANUAL
PLWD 14961 CHIVA
52213336_EN_CZ_SK_WD_PHILCO.indd 1 05.04.2017 18:54:30

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read
all the instructions in this user's manual.
52213336_EN_CZ_SK_WD_PHILCO.indd 2 05.04.2017 18:54:31

Dear customer,
Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read
all the instructions in this user's manual.
EN - 1
11/2014Copyright © 2014, Fast ČR, a. s.
CONTENTS
PART 1: BEFORE PUTTING INTO OPERATION................................................................................................. 2
 Important safety instructions.....................................................................................................................................................2
 General safety information..........................................................................................................................................................2
 Important safety measures.........................................................................................................................................................4
PART 2: INSTALLATION.................................................................................................................................... 6
 Removal of the transportation screws....................................................................................................................................6
 Levelling the washing machine.................................................................................................................................................7
 Electrical connection.....................................................................................................................................................................8
 Water supply connection.............................................................................................................................................................8
 Water drain connection................................................................................................................................................................9
PART 3: DESCRIPTION OF THE APPLIANCE AND THE CONTROL PANEL..................................................... 10
 Description of the appliance................................................................................................................................................... 10
 Washing detergent drawer ......................................................................................................................................................11
 Control panel................................................................................................................................................................................. 13
 Program selection dial ...............................................................................................................................................................13
PART 4: BASIC SETTINGS............................................................................................................................... 14
 Language selection..................................................................................................................................................................... 14
 Setting an economic time (Economically advantageous time period).................................................................... 15
 Setting the current time............................................................................................................................................................ 15
 Setting audio sounds ................................................................................................................................................................. 16
 Setting the display brightness................................................................................................................................................16
 Setting the display contrast..................................................................................................................................................... 17
 Restore factory settings............................................................................................................................................................. 17
PART 5: WASHING YOUR LAUNDRY .............................................................................................................. 18
 First wash cycle.............................................................................................................................................................................18
 Sorting your laundry .................................................................................................................................................................. 18
 Washing symbols......................................................................................................................................................................... 18
 Placing laundry into the washing machine........................................................................................................................ 19
 Dosage of the washing detergent.........................................................................................................................................20
 Selecting programs and functions........................................................................................................................................ 21
 Child safety lock ........................................................................................................................................................................... 31
 Program chart ............................................................................................................................................................................... 32
PART 6: MAINTENANCE AND CLEANING...................................................................................................... 40
 Water inlet lters.......................................................................................................................................................................... 40
 Pump lter...................................................................................................................................................................................... 40
 Washing detergent drawer ......................................................................................................................................................42
 Siphon plug ................................................................................................................................................................................... 42
 Cabinet of the washing machine...........................................................................................................................................42
 Drum................................................................................................................................................................................................. 43
 Removal of scale deposits from the washing machine.................................................................................................. 43
PART 7: PRACTICAL INFORMATION.............................................................................................................. 44
PART 8: PREVENTION OF MINOR MALFUNCTIONS ..................................................................................... 45
PART 9: AUTOMATIC MALFUNCTION DETECTION SYSTEM ........................................................................ 47
PART 10: TECHNICAL SPECIFICATIONS ........................................................................................................ 49
• Program table ...............................................................................................................................................................................32
PART 6: MAINTENANCE AND CLEANING ......................................................................................................47
• Water inlet Filters .........................................................................................................................................................................47
• Pump Filter .....................................................................................................................................................................................47
• Washing detergent drawer .......................................................................................................................................................49
• Siphon plug ....................................................................................................................................................................................49
• Cabinet of the washing machine ...........................................................................................................................................49
• Drum..................................................................................................................................................................................................50
• Removal of scale deposits from the washing machine...................................................................................................50
PART 7: PRACTICAL INFORMATION ..............................................................................................................51
PART 8: PREVENTION OF MINOR MALFUNCTIONS ......................................................................................52
PART 9: AUTOMATIC MALFUNCTION DETECTION SYSTEM .........................................................................54
PART 10: TECHNICAL SPECIFICATIONS .........................................................................................................56
EN - 1
52213336_EN_CZ_SK_WD_PHILCO.indd 1 05.04.2017 18:54:31

EN - 2
EN - 2
11/2014Copyright © 2014, Fast ČR, a. s.
PART 1: BEFORE PUTTING INTO OPERATION
Important safety instructions
 Read carefully and store for future use.
 The appliance must be installed by an authorised service technician or another responsible person.
Otherwise, there exists a risk of an accident, injury or damage to the appliance.
 The safety of this appliance complies with industry norms and meets legal appliance safety requirements.
However, as manufacturers, we consider it our duty to provide you with the following safety instructions.
 It is essential that you store this user's manual in a safe place so that you can use it in the future.
If you intend to sell the appliance, give it to another owner or if you move, always make sure that the user's
manualis attached to theappliance sothat thenew ownercan ndout about the operation of the appliance
and the relevant warnings.
 Before installation or operation of the appliance you MUST carefully read all the safety instructions
and the user's manual.
 Before putting the appliance into operation for the rst time, check that it has not been damaged during
transport. Never connect a damaged appliance. If some parts are damaged, contact the supplier.
 If the washing machine is supplied in the winter months, when the temperature falls under 0°C, store the
appliance at room temperature for 24 hours before rst use.
 Only use the appliance for washing laundry which is marked by the manufacturer on the label as suitable
for washing and drying in a washing machine.
 You must remove the transportation screws located in the back part of the washing machine before
putting it into operation. Otherwise, the appliance could be damaged and damage to property could
occur. This event is not covered by the warranty.
 The warranty does not cover damaged arising from external factors (oods, re, rodents, etc.).
General safety instructions
 Changing the technical parameters or making any other modications to the appliance is dangerous.
 During the course of a high temperature program the door, cabinet and hoses heat up to a high
temperature. Do not touch the door, the cabinet of the washing machine or the hoses!
 Ensure that small household pets cannot get into the drum. It is therefore better to always check the inside
of the drum before use.
 Items such as coins, safety pins, nails, bolts, stones and other heavy or sharp items can cause considerable
damage and do not belong in the appliance.
 Use only the recommended amount of fabric softener and washing detergents. If you use a greater
amount than is recommended, the fabric could be damaged.
 Always use the amount of detergent recommended by the manufacturer.
 Small pieces of laundry such as socks, shoelaces, washing bands, etc. should be washed in a special
purpose washing bag or in a pillow case because the individual items could become jammed between
the tube and the rotating drum.
 Frozen water in the hoses may damage the hoses and cause a subsequent explosion. In locations where
temperatures fall below the freezing point it is not possible guarantee the proper operation of the
appliance.
 Do not use the washing machine to wash products with metal skeletons, fabrics which are not hemmed
or that snag.
 Before using this appliance, check that the appliance is connected according to the instructions provided
in this manual.
52213336_EN_CZ_SK_WD_PHILCO.indd 2 05.04.2017 18:54:31

EN - 3
EN - 3
11/2014Copyright © 2014, Fast ČR, a. s.
 After use, before cleaning or maintenance always disconnect the washing machine from the power supply
and turn o the water inlet.
 Never attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may lead to
injuries or serious damage to the appliance. Contact your local service centre for repairs. Always request
original spare parts.
 Do not use multi-sockets or extension cords.
 Do not plug in the appliance with a defective power cord.
 If the power cord is damaged, have it replaced by the manufacturer or an authorised service technician to
prevent hazardous situations.
 Do not pull the power plug out of the power socket by pulling on the cord. Hold the power cord by holding
the power plug directly.
 Do not connect the power plug if you have wet hands.
 Never touch the appliance if you have wet hands or feet.
 Never open the detergent drawer while washing.
 Never attempt to open the washing machine door while washing.
 Because the washing machine can become very hot during operation, do not touch the hose during the
draining or lling process.
 In the case of any defect, rst turn o the appliance, disconnect it from the power supply and shut o the
water inlet. Do not attempt to repair the device yourself. Contact the nearest authorised service.
 Do not forget that the packaging material from the washing machine may present a danger to children.
 Do not allow children to play with the washing machine.
 Keep household pets at a safe distance from the washing machine.
 The washing machine should only be used by persons fully instructed about the instructions, provisions
and controls described in this user's manual.
 This washing machine is designed for domestic use only. The use of the washing machine for commercial
purposes voids the warranty.
 Do not install the appliance on a carpet or another similar surface, which could block the ventilation vents
on the underside.
 Do not place the drain hose into a container, bucket or sink.
 To avoid the risk of suocation, keep the plastic pouch containing the documentation about the washing
machine out of children's reach.
 Keep small parts out of the reach of small children.
Recommendation
 Long term contact of washing detergents and fabric softeners with air will cause them to dry out and stick
to the walls of the compartments. To prevent this from happening, ll the compartments with washing
detergent and fabric softener only immediately before washing.
 We recommend the use of a prewash only for heavily soiled laundry.
 Do not exceed the maximum loading capacity of the drum.
 This appliance must not be used by persons (including children) with physical, sensory or psychological
impairments or by inexperienced persons, unless properly trained or schooled in the safe use of the
appliance, or unless they have been properly supervised by a person who will be responsible for their
safety. Children should be supervised so as not to play with the appliance.
 If you will not be using the washing machine for an extended period of time, pull it out of the power
socket, shut o the water inlet and leave the door open so that the inside of the washing machine can dry
out and so unpleasant odours are not created.
 As a result of quality control procedures some water may remain in the washing machine. This will not
damage the washing machine in any way.
 We recommend that the rst wash is performed in the White 90 - 95° program (depending on the model)
without any laundry, put 1/2 a measuring cup of washing agent into the second draw for the washing agent.
 Never open the detergent drawer while washing.
 Never attempt to open the washing machine door while washing.
EN - 2
11/2014Copyright © 2014, Fast ČR, a. s.
PART 1: BEFORE PUTTING INTO OPERATION
Important safety instructions
 Read carefully and store for future use.
 The appliance must be installed by an authorised service technician or another responsible person.
Otherwise, there exists a risk of an accident, injury or damage to the appliance.
 The safety of this appliance complies with industry norms and meets legal appliance safety requirements.
However, as manufacturers, we consider it our duty to provide you with the following safety instructions.
 It is essential that you store this user's manual in a safe place so that you can use it in the future.
If you intend to sell the appliance, give it to another owner or if you move, always make sure that the user's
manualis attached to theappliance sothat thenew ownercan ndout about the operation of the appliance
and the relevant warnings.
 Before installation or operation of the appliance you MUST carefully read all the safety instructions
and the user's manual.
 Before putting the appliance into operation for the rst time, check that it has not been damaged during
transport. Never connect a damaged appliance. If some parts are damaged, contact the supplier.
 If the washing machine is supplied in the winter months, when the temperature falls under 0°C, store the
appliance at room temperature for 24 hours before rst use.
 Only use the appliance for washing laundry which is marked by the manufacturer on the label as suitable
for washing and drying in a washing machine.
 You must remove the transportation screws located in the back part of the washing machine before
putting it into operation. Otherwise, the appliance could be damaged and damage to property could
occur. This event is not covered by the warranty.
 The warranty does not cover damaged arising from external factors (oods, re, rodents, etc.).
General safety instructions
 Changing the technical parameters or making any other modications to the appliance is dangerous.
 During the course of a high temperature program the door, cabinet and hoses heat up to a high
temperature. Do not touch the door, the cabinet of the washing machine or the hoses!
 Ensure that small household pets cannot get into the drum. It is therefore better to always check the inside
of the drum before use.
 Items such as coins, safety pins, nails, bolts, stones and other heavy or sharp items can cause considerable
damage and do not belong in the appliance.
 Use only the recommended amount of fabric softener and washing detergents. If you use a greater
amount than is recommended, the fabric could be damaged.
 Always use the amount of detergent recommended by the manufacturer.
 Small pieces of laundry such as socks, shoelaces, washing bands, etc. should be washed in a special
purpose washing bag or in a pillow case because the individual items could become jammed between
the tube and the rotating drum.
 Frozen water in the hoses may damage the hoses and cause a subsequent explosion. In locations where
temperatures fall below the freezing point it is not possible guarantee the proper operation of the
appliance.
 Do not use the washing machine to wash products with metal skeletons, fabrics which are not hemmed
or that snag.
 Before using this appliance, check that the appliance is connected according to the instructions provided
in this manual.
52213336_EN_CZ_SK_WD_PHILCO.indd 3 05.04.2017 18:54:31

EN - 4
EN - 4
11/2014Copyright © 2014, Fast ČR, a. s.
 Always use the amount of detergent recommended by the manufacturer.
 Do not turn o the washing machine while the drying program is running, wait until it nishes.
 However, if it is necessary to turn o the washing machine, remove the laundry without delay and put it
aside to cool down. Attention: the laundry may be very hot.
 Install the washing machine in a location where it will be possible to fully open the door of the washing
machine. (Do not install the washing machine in a location where it will not be possible to fully open the
door).
 Make sure that there is sucient ventilation and air circulation around the washing machine.
Important safety measures
Carefully read all the important safety instructions. Otherwise, there exists a risk of an accident
or a fatal injury.
Risk of burns
 For opening the door, use only the handle. Do not touch the glass door panel as it may become very hot,
especially at the end of the drying program. The risk of burns may arise as a result of high temperatures.
Risk of death/injury by electrical shock
 Do not use multi-sockets or extension cords.
 Do not use damaged or cracked power sockets. Do not plug in the appliance with a defective power cord.
 Never pull on the power cord when disconnecting the appliance from a power socket.
 Hold the power cord by holding the power plug.
 Do not touch the power plug with wet hands to avoid injury by electrical shock.
 Never touch the appliance with wet hands or feet.
 If the power cord is damaged, have it replaced by the manufacturer or an authorised service technician to
prevent hazardous situations.
Risk of ooding
 Check that the water ows in and drains continuously.
 If drainage goes via the wash basin, make sure that the hose is rmly and securely attached.
 Make sure that the inlet and drain hoses are properly connected, tightened and that they cannot be
loosened easily. The reverse thrust of the hose may cause it to come loose if it is not properly attached. Pay
increase attention when the appliance is drained via a wash basin.
Risk of explosion
 Before starting the drying program, check that the laundry is not stained by chemicals, stain removers and
similar substances.
 They could ignite and result in an explosion.
Risk of re
 Dry unwashed laundry must not be dried in the dryer.
 Do not store or place ammable substances near the washing machine.
52213336_EN_CZ_SK_WD_PHILCO.indd 4 05.04.2017 18:54:31

EN - 5
EN - 4
11/2014Copyright © 2014, Fast ČR, a. s.
 Always use the amount of detergent recommended by the manufacturer.
 Do not turn o the washing machine while the drying program is running, wait until it nishes.
 However, if it is necessary to turn o the washing machine, remove the laundry without delay and put it
aside to cool down. Attention: the laundry may be very hot.
 Install the washing machine in a location where it will be possible to fully open the door of the washing
machine. (Do not install the washing machine in a location where it will not be possible to fully open the
door).
 Make sure that there is sucient ventilation and air circulation around the washing machine.
Important safety measures
Carefully read all the important safety instructions. Otherwise, there exists a risk of an accident
or a fatal injury.
Risk of burns
 For opening the door, use only the handle. Do not touch the glass door panel as it may become very hot,
especially at the end of the drying program. The risk of burns may arise as a result of high temperatures.
Risk of death/injury by electrical shock
 Do not use multi-sockets or extension cords.
 Do not use damaged or cracked power sockets. Do not plug in the appliance with a defective power cord.
 Never pull on the power cord when disconnecting the appliance from a power socket.
 Hold the power cord by holding the power plug.
 Do not touch the power plug with wet hands to avoid injury by electrical shock.
 Never touch the appliance with wet hands or feet.
 If the power cord is damaged, have it replaced by the manufacturer or an authorised service technician to
prevent hazardous situations.
Risk of ooding
 Check that the water ows in and drains continuously.
 If drainage goes via the wash basin, make sure that the hose is rmly and securely attached.
 Make sure that the inlet and drain hoses are properly connected, tightened and that they cannot be
loosened easily. The reverse thrust of the hose may cause it to come loose if it is not properly attached. Pay
increase attention when the appliance is drained via a wash basin.
Risk of explosion
 Before starting the drying program, check that the laundry is not stained by chemicals, stain removers and
similar substances.
 They could ignite and result in an explosion.
Risk of re
 Dry unwashed laundry must not be dried in the dryer.
 Do not store or place ammable substances near the washing machine.
EN - 5
11/2014Copyright © 2014, Fast ČR, a. s.
 Laundry that has been stained by oil, acetone, alcohol, petrol, kerosene, stain removers, thinners, solvents,
beeswax, beeswax removers and similar substances must rst be washed and the stains must be removed.
Otherwise there is a risk of a re hazard when using the drying program.
 If you select the washing program with drying, do not use gel capsules or washing balls or similar washing
detergents. There is a danger of a re hazard.
 Laundry must not be dried, if:
 the laundry has not been washed.
 the laundry is stained by table oil, creams, etc. and has not been washed.
 the laundry has been dry cleaned.
 the laundry contains a large amount of foam, rubber, etc.
 the laundry is made from rubber (e.g. swimming caps), latex, water-resistant material, laundry with
rubber edges and clothing or pillows containing a rubber sponge, etc.
 damaged pieces of laundry with rubber or foam padding as these could ignite easily.
 the padding could ignite easily.
 prints containing sulphur, which can cause corrosion. Never use fabrics with pictures that can easily
be removed.
 you used a foam or plastic washing detergent dispenser in the washing machine's drum. It could melt
and damage laundry and the drum.
 the laundry was not properly rinsed after a stain remover was used.
 the laundry or the washing detergent contains a solvent.
 you do not remove all foreign items (gels, pins, coins, lighters, matches, etc.) from pockets and the
laundry. There is a danger of a re hazard.
Risk of accident or injury
 Do not climb or hang on the washing machine. The top cover could crack resulting in an injury.
 During installation put the hoses, power cord and packaging materials to the side.
 Do not place the washing machine upside down or on its side.
 Do not move the washing machine by holding moving parts such as the washing detergent compartment,
door, etc. These parts could break and cause an injury.
 After completing the installation, guide the hoses and the power cord according to the instruction
contained herein.
The washing machine must be carried by at least two people.
Child safety
 Do not allow children to play with the washing machine. The appliance has live electric current inside.
 Do not leave children near the washing machine without supervision. They could easily lock themselves
in the drum.
 The outer cover and glass door panel may heat up during operation.
(Therefore it is important that children do not approach or touch the washing machine. There is a danger
of a burns.)
 Keep packaging materials out of the reach of children!
 Store the washing powder and fabric softener out of the reach of children. There is a danger of poisoning,
eye injury or skin irritation if children come into contact with the washing powder or fabric softener. Store
the washing powder and fabric softener out of the reach of children.
52213336_EN_CZ_SK_WD_PHILCO.indd 5 05.04.2017 18:54:31

EN - 6
EN - 6
11/2014Copyright © 2014, Fast ČR, a. s.
PART 2: INSTALLATION
Carefully read the entire user's manual before putting your washing machine into operation and store it in
a safe place for future reference.
The appliance must be installed by an authorised service technician or another responsible person.
Removal of the transportation screws
 You must remove the transportation screws located in the back part of the washing machine before
putting it into operation.
 Loosen the bolts using a correctly sized spanner, turning it anticlockwise.
 Remove the bolts by pulling them out.
 Insert plastic plugs found in the accessories pouch into the transportation screw holes.
 Carefully store the transportation screws removed from the washing machine for future transport
purposes.
NOTE:
You must remove the transportation screws located in the back part of the washing machine before
putting it into operation. Defects caused by starting the washing machine with the transportation
screws installed are not covered by the warranty.
52213336_EN_CZ_SK_WD_PHILCO.indd 6 05.04.2017 18:54:31

EN - 7
EN - 6
11/2014Copyright © 2014, Fast ČR, a. s.
PART 2: INSTALLATION
Carefully read the entire user's manual before putting your washing machine into operation and store it in
a safe place for future reference.
The appliance must be installed by an authorised service technician or another responsible person.
Removal of the transportation screws
 You must remove the transportation screws located in the back part of the washing machine before
putting it into operation.
 Loosen the bolts using a correctly sized spanner, turning it anticlockwise.
 Remove the bolts by pulling them out.
 Insert plastic plugs found in the accessories pouch into the transportation screw holes.
 Carefully store the transportation screws removed from the washing machine for future transport
purposes.
NOTE:
You must remove the transportation screws located in the back part of the washing machine before
putting it into operation. Defects caused by starting the washing machine with the transportation
screws installed are not covered by the warranty.
EN - 7
11/2014Copyright © 2014, Fast ČR, a. s.
Levelling the washing machine
Do not place the washing machine on carpets or similar surfaces.
To ensure quiet and vibration free operation of your washing machine, you should place it on an even, non-slip
and rm surface.
You can level the washing machine by adjusting the adjustable feet.
First loosen the plastic nut. Adjust by screwing out the feet upwards or downwards.
After levelling the washing machine, re-tighten the plastic nut by screwing it upwards.
Never level the washing machine on an uneven surface by placing cardboard, wooden blocks, etc. under the
feet.
52213336_EN_CZ_SK_WD_PHILCO.indd 7 05.04.2017 18:54:32

EN - 8
EN - 8
11/2014Copyright © 2014, Fast ČR, a. s.
Electrical connection
 Technical specications of your washing machine: 220-240 V ~ 50 Hz.
 A special grounding plug is attached to the power cord of your washing machine. This plug must be fully
inserted into a grounded power socket (with 10 A). The electrical fuse or circuit breaker to which the
washing machine is connected should be rated at 10A. If you do not have such sockets and fuses in your
home then have them installed by a qualied electrician.
 Our company takes no responsibility for any damages caused by using the washing machine without
grounding.
Water supply connection
 Depending on the functions of your washing machine, the washing machine is equipped with either
a single water inlet (cold) or a double water inlet (cold/hot).The hose with the white end is intended for the
cold water inlet and the hose with the red end is intended for the hot water inlet (on washing machines
with a hot and cold water inlet).
 To prevent water from leaking from the connection points, the hose kit also includes 1 seal (for washing
machines with a cold water inlet) or 2 seals (for washing machines with hot and cold water inlets). Install
these seals on the end of the water inlet hose that is to be connected to the tap.
 Connect the hose with the white end to the water inlet valve with the white lter and the hose with the red
end to the water inlet valve with the red lter (the second mentioned option applies to washing machines
with a hot and cold water connection). Tighten the plastic connecting parts using your hand. A qualied
plumber will provide a safer connection.
 The water pressure of 0.1 - 1 MPa in your water tap will ensure a more ecient operation of your washing
machine (the pressure of 0.1 MPa equates to a ow rate of more than 8 litres of water per minute from
a fully open tap).
 After completing all connections, check that the connections do leak, by fully opening the tap.
 Check that the supply hoses are not bent, broken or cracked.
 Connect the supply hose to a 3/4" threaded water tap.
52213336_EN_CZ_SK_WD_PHILCO.indd 8 05.04.2017 18:54:32

EN - 9
EN - 8
11/2014Copyright © 2014, Fast ČR, a. s.
Electrical connection
 Technical specications of your washing machine: 220-240 V ~ 50 Hz.
 A special grounding plug is attached to the power cord of your washing machine. This plug must be fully
inserted into a grounded power socket (with 10 A). The electrical fuse or circuit breaker to which the
washing machine is connected should be rated at 10A. If you do not have such sockets and fuses in your
home then have them installed by a qualied electrician.
 Our company takes no responsibility for any damages caused by using the washing machine without
grounding.
Water supply connection
 Depending on the functions of your washing machine, the washing machine is equipped with either
a single water inlet (cold) or a double water inlet (cold/hot).The hose with the white end is intended for the
cold water inlet and the hose with the red end is intended for the hot water inlet (on washing machines
with a hot and cold water inlet).
 To prevent water from leaking from the connection points, the hose kit also includes 1 seal (for washing
machines with a cold water inlet) or 2 seals (for washing machines with hot and cold water inlets). Install
these seals on the end of the water inlet hose that is to be connected to the tap.
 Connect the hose with the white end to the water inlet valve with the white lter and the hose with the red
end to the water inlet valve with the red lter (the second mentioned option applies to washing machines
with a hot and cold water connection). Tighten the plastic connecting parts using your hand. A qualied
plumber will provide a safer connection.
 The water pressure of 0.1 - 1 MPa in your water tap will ensure a more ecient operation of your washing
machine (the pressure of 0.1 MPa equates to a ow rate of more than 8 litres of water per minute from
a fully open tap).
 After completing all connections, check that the connections do leak, by fully opening the tap.
 Check that the supply hoses are not bent, broken or cracked.
 Connect the supply hose to a 3/4" threaded water tap.
EN - 9
11/2014Copyright © 2014, Fast ČR, a. s.
Water drain connection
 Check that the supply hoses are not bent, twisted, cracked or excessively stretched.
 The drain hose should be installed at a height of min. 60 cm and max. 100 cm above the ground.
 The end of the drain hose may be inserted directly into the drain opening or to a special end tting
attached to the drain of the wash basin.
 Do not place the drain hose into a container, bucket or sink.
 Never attempt to extend the length of the drain hose by adding extra parts.
52213336_EN_CZ_SK_WD_PHILCO.indd 9 05.04.2017 18:54:32

EN - 10
EN - 10
11/2014Copyright © 2014, Fast ČR, a. s.
PART 3: DESCRIPTION OF THE APPLIANCE AND THE
CONTROL PANEL
Description of the appliance
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
1. Top cover
2. Washing detergent drawer
3. Program selection dial
4. LCD display
5. Function buttons
6. Door
7. Pump lter cover
8. Power cord
9. Drain hose
10. Transportation screws
11. Adjustable levelling feet
12. Plastic holder for the drain hose
(Removing this holder may negatively aect the operation of the washing machine. Do not remove this
plastic holder.)
52213336_EN_CZ_SK_WD_PHILCO.indd 10 05.04.2017 18:54:33

EN - 11
EN - 10
11/2014Copyright © 2014, Fast ČR, a. s.
PART 3: DESCRIPTION OF THE APPLIANCE AND THE
CONTROL PANEL
Description of the appliance
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
1. Top cover
2. Washing detergent drawer
3. Program selection dial
4. LCD display
5. Function buttons
6. Door
7. Pump lter cover
8. Power cord
9. Drain hose
10. Transportation screws
11. Adjustable levelling feet
12. Plastic holder for the drain hose
(Removing this holder may negatively aect the operation of the washing machine. Do not remove this
plastic holder.)
EN - 11
11/2014Copyright © 2014, Fast ČR, a. s.
Washing detergent drawer
Main washing
compartment
Fabric softener
compartment
Prewash compartment
Close up of powder
measurement
Washing detergent
dosage measure
If you are going to use a liquid washing detergent, it is necessary to use a special liquid detergent adapter.
(You will nd it in the washing machine‘s accessories.) You can use liquid detergents for all washing programs
without a prewash. Place the adapter into the main wash compartment – see illustration above; and pour
in the liquid washing detergent as necessary. Do not go over the maximum mark. Always remove the adapter
when using a powder washing detergent.
52213336_EN_CZ_SK_WD_PHILCO.indd 11 05.04.2017 18:54:33

EN - 12
EN - 12
11/2014Copyright © 2014, Fast ČR, a. s.
Main washing compartment
Into this part of the drawer, place only washing detergent (liquid or powder), lime scale remover, etc.
When using a liquid washing detergent use the special adapter. You will nd it in the washing machine‘s
accessories.
Fabric softener compartment
In this part only use fabric softener (we recommend that you use the amount and type of fabric softener
according to the instructions of the manufacturers of the fabric softener and the laundry). Sometimes remains
of the fabric softener may remain in the compartment. This is because fabric softeners are viscous (sticky).
To prevent this from occurring, we recommend that you use a fabric softener that is less viscous (i.e. sticky)
or you can dilute it using water.
Prewash compartment
Fill this compartment only if the prewash function is selected. We recommend that you use this function only
for heavily soiled laundry. More information further in this user's manual.
52213336_EN_CZ_SK_WD_PHILCO.indd 12 05.04.2017 18:54:33

EN - 13
EN - 12
11/2014Copyright © 2014, Fast ČR, a. s.
Main washing compartment
Into this part of the drawer, place only washing detergent (liquid or powder), lime scale remover, etc.
When using a liquid washing detergent use the special adapter. You will nd it in the washing machine‘s
accessories.
Fabric softener compartment
In this part only use fabric softener (we recommend that you use the amount and type of fabric softener
according to the instructions of the manufacturers of the fabric softener and the laundry). Sometimes remains
of the fabric softener may remain in the compartment. This is because fabric softeners are viscous (sticky).
To prevent this from occurring, we recommend that you use a fabric softener that is less viscous (i.e. sticky)
or you can dilute it using water.
Prewash compartment
Fill this compartment only if the prewash function is selected. We recommend that you use this function only
for heavily soiled laundry. More information further in this user's manual.
EN - 13
11/2014Copyright © 2014, Fast ČR, a. s.
Control panel
Allergy Safe
Cotton
6 Kg. wash & 6 Kg. Dry
Quick Wash
& Dry 29´/60´
Cotton Dry
Gentle Dry
Daily Fast
60° 30´/60´
Super rapid 12´
Memory
Cotton
Cotton Eco
Eco 20°
Synthetics
Delicates
Duvet
Extras
STOP
Wash & DryDryRapid
1. 2. 3. 4. 5.
1. Washing detergent drawer
2. Program selection dial: Select the appropriate washing program.Turn the program selection dial in both
directions to select the desired program. Make sure that the mark on the dial points exactly to the given
program.
3. Display: Here you can see the washing or drying program functions, which you selected and also
information about the condition of the washing machine.
4. Function buttons: These are touch buttons. Press a button to select the respective function.
5. Start/Pause button Press this button once to start a program, press again to pause the program.
Program selection dial
Allergy Safe
Cotton
6 Kg. wash & 6 Kg. Dry
Quick Wash
& Dry 29´/60´
Cotton Dry
Gentle Dry
Daily Fast
60° 30´/60´
Super rapid 12´
Memory
Cotton
Cotton Eco
Eco 20°
Synthetics
Delicates
Duvet
Extras
STOP
Wash & DryDryRapid
Using the program selection dial, select a program with which you wish to wash your laundry. The program
selection may be done by turning the program selection dial in both directions. When making settings, ensure
that the symbol on the program selection dial exactly matches your selected washing program. If you switch
the program selection dial to position STOP (o), the washing machine will drain the water so as to complete
(cancel) the program cycle. After completing the draining operation the washing machine will switch to the
stand-by mode. Now you can select another program that you want to start.
Bavlna
Praní a Sušení
Bavlna 6 Kg
Praní a Sušení
Rychlé 29’/60’
Bavlna
Sušení
Super
Rychlé 12'
Jemné
Sušení
Jemné
Syntetika
Eko 20°C
Bavlna Eko
Další
Muj program Antialergický
Denní Rychlé
60°C 30'/60'
Lužkoviny
PLWD 14961 Chiva
9 / 6 Kg
1 2 3 4 5
52213336_EN_CZ_SK_WD_PHILCO.indd 13 05.04.2017 18:54:34

EN - 14
EN - 14
11/2014Copyright © 2014, Fast ČR, a. s.
PART 4: BASIC SETTINGS
In order to perform the initial settings, it is necessary to:
 insert the power plug into the power socket;
 open the water valve;
 turn the program selection dial.
Language selection
The rst item that appears on the display are the language settings.
 Select a language that you wish to set and use the button with the symbol.
 If you wish to enter the menu and do not wish to set the language, select the button with the symbol.
 Select a language that you wish to set and use the button with the symbol.
 Conrm the language selection using the button with the symbol.
 If you wish change the language selection again, enter the language selection menu and use the buttons
with the symbols.
 Conrm using the button with the symbol to save the selection. You will be asked to conrm your
language selection.
 Conrm the language selection using the button with the symbol.
 If you selected incorrectly, select the button with the symbol and perform the language selection
again. As soon as you conrm the change in the language, the selected language will be active.
52213336_EN_CZ_SK_WD_PHILCO.indd 14 05.04.2017 18:54:35

EN - 15
EN - 14
11/2014Copyright © 2014, Fast ČR, a. s.
PART 4: BASIC SETTINGS
In order to perform the initial settings, it is necessary to:
 insert the power plug into the power socket;
 open the water valve;
 turn the program selection dial.
Language selection
The rst item that appears on the display are the language settings.
 Select a language that you wish to set and use the button with the symbol.
 If you wish to enter the menu and do not wish to set the language, select the button with the symbol.
 Select a language that you wish to set and use the button with the symbol.
 Conrm the language selection using the button with the symbol.
 If you wish change the language selection again, enter the language selection menu and use the buttons
with the symbols.
 Conrm using the button with the symbol to save the selection. You will be asked to conrm your
language selection.
 Conrm the language selection using the button with the symbol.
 If you selected incorrectly, select the button with the symbol and perform the language selection
again. As soon as you conrm the change in the language, the selected language will be active.
EN - 15
11/2014Copyright © 2014, Fast ČR, a. s.
Setting an economic time (Economically advantageous time period)
The price of electricity can vary during the day depending on the power company's tari time intervals. You
can obtain more information about these intervals from your power company and then you can set a time
when the price of electricity is low and when the washing machine will be in operation.
NOTE:
It is necessary for a clock with the respective energy saving feature to be installed.
 Press the button with the symbol to make the settings.
 If you want to make the settings at a later time, press the button with the symbol.
 You can set an economically advantageous interval by pressing buttons with the symbols. More
information further in the manual about the activation of an economically advantageous interval.
 Conrm the using the button with the symbol.
Setting the current time
It is recommended that you correctly set the time when installing the appliance.
When you turn on the appliance you will be asked to set the time.
Enter the settings menu using the button with the symbol.
The button with the symbol serves to end and exit the settings.
NOTE:
Check that you have set the correct time. Otherwise this could negatively aect all other time-related
functions. If you disconnect the appliance for a period longer than 15 days, the information about time
will be erased. In such an event it is necessary to set the time again the next time you turn on the washing
machine.
 Set the hours and minutes using the buttons with the symbols.
 After setting the clock, conrm using the button with the symbol.
 The appliance will automatically return to the main screen of the selected program. To enter the settings
menu press the button with the symbol.
52213336_EN_CZ_SK_WD_PHILCO.indd 15 05.04.2017 18:54:35

EN - 16
EN - 16
11/2014Copyright © 2014, Fast ČR, a. s.
12
Setting audio sounds
You can set audio sounds to be made when the buttons are pressed.
symbol indicates that audio sounds are activated.
symbol indicates that audio sounds are deactivated.
Setting the display brightness
Set the display brightness using the buttons with the symbols.
To move to the display contrast setting, use the button with the symbol.
52213336_EN_CZ_SK_WD_PHILCO.indd 16 05.04.2017 18:54:35

EN - 17
EN - 16
11/2014Copyright © 2014, Fast ČR, a. s.
12
Setting audio sounds
You can set audio sounds to be made when the buttons are pressed.
symbol indicates that audio sounds are activated.
symbol indicates that audio sounds are deactivated.
Setting the display brightness
Set the display brightness using the buttons with the symbols.
To move to the display contrast setting, use the button with the symbol.
EN - 17
11/2014Copyright © 2014, Fast ČR, a. s.
Setting the display contrast
Set the display contrast using the buttons with the symbols.
To restore factory settings, use the button with the symbol.
Restore factory settings
This menu serves to restore the factory set values. All performed settings will be erased.
 Press the button with the symbol.
 You will be asked to conrm your intention to restore factory settings.
 To conrm, press the button with the symbol.
 If you do not wish to restore factory settings, press the button with the symbol.
 To return to the main screen, use the button with the symbol.
52213336_EN_CZ_SK_WD_PHILCO.indd 17 05.04.2017 18:54:36

EN - 18
EN - 18
11/2014Copyright © 2014, Fast ČR, a. s.
PART 5: WASHING LAUNDRY
 Connect the washing machine to a power socket.
 Open the water inlet.
First wash cycle
There may be some water left over inside the washing machine from the factory tests. We therefore recommend
to perform the rst wash without laundry so as to drain this water; put half a measure of standard detergent
into compartment 2, which is used for washing detergents and select the program for cotton at 90 °C.
Sorting laundry
 Sort the laundry according to its type (cotton, synthetics, delicates, wool, etc.), washing temperature and
the level of dirtiness.
 Never wash whites together with coloured laundry.
 Because your new coloured laundry may release some of its colour, wash it separately.
 Before placing the laundry into the washing machine check pockets for any forgotten items. In this way
you will prevent damaging your clothes and the washing machine.
 Do up zips and buttons on the laundry.
 From curtains and drapes remove the plastic or metal hooks or insert the into a wash bag and tie it up.
 Turn clothing such as pants, knitted fabrics, T-shirts and singlets inside out.
 Wash small items such as socks and handkerchiefs in a wash bag.
Washing symbols
Resistant fabric Maximum ironing temperature
is 110°C
Fine fabric Must not be ironed
Maximum washing temperature
is 95°C Dry cleaning with all types of agents
Maximum washing temperature
is 60°C
Cleaning only with
perchloroethylene, gas, alcohol or
R113
Maximum washing temperature
is 40°C
Cleaning only with perchloroethylene,
gas, alcohol or R113
Maximum washing temperature
is 30°C Must not be dry cleaned
Hand wash Dry on a at underlay
Only dry cleaning Hang after spin drying
Bleaching only in cold water Hang to dry
Do not bleach. Drying at the normal temperature
of the dryer
Maximum ironing temperature
is 200°C Low drying temperature
Maximum ironing temperature is
150°C Do not place in a dryer.
52213336_EN_CZ_SK_WD_PHILCO.indd 18 05.04.2017 18:54:36
