Philips AVENT SCD630 User manual

English 6
Español 33
Français (Canada) 59
Português 87

English
Introduction
Congratulations on your purchase and welcome to Philips Avent! To fully
benefit from the support that Philips Avent offers, register your product at
www.philips.com/welcome.
The Philips Avent video babymonitor provides you with round-the-clock
support and it allows you to see your baby day and night from anywhere in
the house. The latest digital technology guarantees clear sound and the
clearest image of your baby. This gives you an additional sense of security
without entering your baby’s room and disturbing its sleep.
Know these safety symbols
This “bolt of lightning” indicates uninsulated material within your unit may
cause an electrical shock. For the safety of everyone in your household,
please do not remove product covering.
The exclamation mark calls attention to features that require you to read the
enclosed user information closely to prevent operating and maintenance
problems.
Warning: To reduce the risk of fire or electric
shock, this appliance should not be exposed to
rain or moisture and objects filled with liquids,
such as vases, should not be placed on this
appliance.
IMPORTANT SAFETY INSTRUCTIONS
1Read these instructions.
2Keep these instructions.
3Heed all warnings.
4Follow all instructions.
5Do not use this appliance near water.
6Do not use the product while you are in a bathtub, shower or pool.
Immersion of the product in water could cause an electrical shock.
7Clean only with dry cloth.
8Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
9Do not install near any heat sources such as radiators, heat registers,
stoves or other appliance (including amplifiers) that produce heat.
10 Installed batteries shall not be exposed to excessive heat such as
sunshine, fire or the like.
6English

11 Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
appliance.
12 Only use attachments/accessories specified by the manufacturer.
13 Use this appliance only for its intended use as described in this manual.
14 Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners.
15 Unplug this appliance during lightning or when unused for long periods
of time.
16 Unplug the product immediately and do not use it if the adapter, the cord
or the product itself is damaged.
17 Refer all servicing to qualified service personnel. Servicing is required
when the appliance has been damaged in any way, such as power supply
cord or plug is damaged, liquid has been spilled or objects have fallen
into the appliance, the appliance has been exposed to rain or moisture,
does not operate normally, or has been dropped. Please check the
power cord periodically to prevent potential damages, such as worn or
cut cord. For assistance, visit our website www.philips.com/ support or
contact the Philips Consumer Care Center in your country.You find its
contact details in the worldwide guarantee leaflet.
18 Keep screws and small items out of the reach of the baby.
19 All the required markings are located on the bottom of the appliance and
on the adapter.
WARNING: STRANGULATION HAZARD. Children
have STRANGLED in cords. Keep this cord out of
the reach of children (more than 3.5 feet (1 meter)
away). Do not remove the tag.
Caution
Caution: Prevent risk of explosion, electric shock, short circuit, or
leakage.
-The appliance shall not be exposed to dripping or splashing and
no objects filled with liquids, such as vases, shall be placed on the
appliance.
-To prevent electric shock, do not open the housing of the product.
-Where the power plug is used as the disconnect appliance, the
disconnect appliance shall remain readily operable.
-The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
7
English

-Use the supplied adapter to connect the appliance to the power
outlet.
-If the adapter is damaged, always have it replaced with one of the
original type in order to avoid a hazard.
Adult supervision
-This baby monitor is intended as an aid. It is not a substitute for
responsible and proper adult supervision and should not be used as
such.
-Never place the baby monitor inside or directly over the baby bed or
playpen.
-To prevent overheating, do not cover the baby monitor with a towel,
blanket or any other items.
-For their safety, do not allow children to touch and play with the baby
monitor, the adapter and the accessories. THIS IS NOT A TOY.
General description
1 Parent unit
2 Sound level lights
3 Display
4 ECO light
5 Battery status light
6 Link light
7 Speaker
8 Control button (menu navigation/volume/brightness)
9 Menu button
10 Lullaby button
11 Talk-back button
12 Microphone
13 Socket for power adapter
14 Mode button
15 On/off button
16 Antenna
17 Belt clip
18 Baby unit
19 Camera
20 Power on light
21 Lullaby on/off button
22 Nightlight
23 Microphone
24 Nightlight on/off button
25 On/off slide
26 Antenna
27 Speaker
28 Socket for small plug
29 Screws
30 Temperature sensor
31 Wall mounting holes
32 Adapter(2x)
8English

Preparing for use
Baby unit
Put the power adapter in the baby unit and the adapter in the wall socket.
Parent unit
The parent unit runs ona built-in rechargeable Li-ion battery.
Follow the below steps to charge the parent unit:
1Put the power adapter in the parent unit and put the adapter in the wall
socket.
-The battery status light turns orange to indicate that the appliance is
charging.
20°CEco 1
-When the battery is fully charged, the battery status light turns green
continuously.
10 hrs=3 hrs
-When you charge the parent unit for 3 hours, it can be used cordlessly for
approx. 10 hours.
-If the parent unit is switched on during charging, charging takes
approximately twice as long.
9
English

20°CEco 1
-When the rechargeable battery of the parent unit is almost empty, the
battery status light turnsred and the parent unit beeps.
-If the battery is completely empty and the parent unit it not connected to
the mains, the parent unit automatically switches off and loses contact
with the baby unit.
Note: The built in rechargeable battery cannot be removed from the
product.
Note: The battery gradually and very slowly discharges, even when the
parent unit is switched off.
Tip: To save battery, switch off the parent unit when you do not use it.
Note: We advise you to keep the parent unit connected to the mains during
the whole night. If the battery of the parent unit runs low during the night,
the parent unit beeps and this may wake you up.
Using the baby monitor
Linking parent unit and baby unit
1Push the on/off slide on the baby unit upwards to the ON position.
2When the baby unit is on, the power-on light on the baby unit lights up
green.
Note: The power-on light on the baby unit always lights up green, even
when there is no connection with the parent unit.
>2.5m/8.2ft
3Make sure that the parent unit and the baby unit are at least 2.5 meters/
8.2 feet away from each otherto avoid acoustic feedback.
10 English

4Press the on/off button on the parent unit to switch on the parent unit.
20°CEco 1
-The display goes on, the linking image appears on the display and the
link light lights up red. The parent unit starts to search for the baby unit.
20°CEco 1
-When the parent unit and baby unit are linked, the link light lights up
green on the parent unit and one or more bars appear on the display.
20°CEco 1
Note: It takes less than 10 seconds to establish the link between the
parent unit and the baby unit.
-When thebaby unit is turned off, the parent unit will show the out of
range image. Make sure that the baby unit is switched on.
-If no connection has been established, the link light turns red, the parent
unit beeps three short beeps every 20 seconds and the out-of-range
image appears on the display.
Positioning the baby monitor
Warning: The cord of the baby unit presents a
potential strangulation hazard. Make sure that
the baby unit and its cord are at least 1 meter /
3.5 feet away from your baby. Never place the
baby monitor inside the baby’s bed or playpen.
11
English

>1-1.5m/3.5-5ft
1For optimal sound detection, make sure that the baby unit is no further
than 1.5 meter/ 5 feet away from the baby. Make sure that the baby unit
is at least 1 meter/ 3.5 feet away from the baby because of potential
strangulation hazard.
>2.5m/8.2ft
2Place the parent unit within the operating range of the baby unit. Make
sure it is at least 2.5 meters / 8.2 feet away from the baby unit to avoid
acoustic feedback.
Note: If you use a cordless phone, wireless video, Wi-Fi network,
microwave oven or Bluetooth on 2.4GHz and you experience interference
on either the parent unit or baby unit, move the parent unit until there is
no more interference.
3There are two ways to position the baby unit:
a Place the baby unit on a stable, level and horizontal surface.
b Mount the baby unit to the wall with the screws supplied.
Tip: The wall mount template (see 'Wall mount') to mount the baby unit
to the wall can be found at the end of this user manual.
Tip: Use the provided template to mark the exact location of the screw
holes on the wall.
Tip: Position the baby unit at a higher level to get a good overview of the
baby’s bed or playpen.
Adjust the baby unit in a way that ensures the best visibility of your baby.
The baby unit can be rotated to position it in the desired way.
Operating range
12 English

<50m/165ft
<300m/985ft
The operating range is up to 50 meters/ 165 feet indoors and 300
meters/985 feet outdoors. The operating range of the baby monitor varies
depending on the surroundings and factors that cause interference. Wet
and moist materials cause so much interference that the range loss is up to
100%.
Dry materials Material
thickness Loss of range
Wood, plaster, cardboard, glass (without metal,
wires or lead)
< 30cm (12in) 0-10%
Brick, plywood < 30cm (12in) 5-35%
Reinforced concrete < 30cm (12in) 30-100%
Metal grilles or bars < 1cm (0.4in) 90-100%
Metal or aluminium sheets < 1cm (0.4in) 100%
Features and settings
Volume
You can adjust the speaker volume of the parent unit to the level you prefer.
1Press the top or bottom part of the control button to adjust the volume.
20°C
1
Tip: Make sure that the volume is adapted to the current conditions.
Under noisy conditions, the vibration alert can be turned on as well.
The volume bar appears on the display to show the selected volume.
Note: If the volume is set to a high level, the parent unit consumes more
power.
Note: When the volume bar is at its minimum, the volume is muted. The
parent unit shows a mute icon in the status bar and you will only receive
alerts and video from the parent unit.
13
English

Brightness
You can adjust the display brightness of the parent unit to the level you
prefer.
1Press the left or right part of the control button to adjust the brightness
of the display of the parent unit.
20°C
1
The brightness bar appears on the display to show the selected display
brightness.
Note: If the brightness is set to a high level, the parent unit consumes more
power.
Sound level lights
The parent unit continuously monitors the sound level in your baby’s room,
and the sound level lights on the parent unit let you know if there is any
sound picked up in the baby room.
20°C
1
VIDEO
As long as no sound is detected, the sound level lights are out.
20°C
1
VIDEO
When the baby unit picks up a sound, one or more sound level lights on the
parent unit light up green. The number of lights that go on depends on the
loudness of the sound picked up by the baby unit. The louder your baby
cries, more sound level lights light up green.
14 English

Modes
This baby monitor has four different modes that allows you to choose how
you want to look after your baby: VIDEO, AUDIO, VOX and ECO.
With the baby monitor on, you can switch between these 4 different modes
by pressing the mode button on the side of the parent unit.
The display shows the selected mode. The selected mode is also indicated
in the status bar. When turning on the device, the mode that was last used
will be active.
VIDEO mode
VIDEO
VIDEO
Press the mode button on the side of the parent unit to select theVIDEO
mode.
20°C
1
VIDEO
When the VIDEO mode is activated, the screen is always on, so you can see
your baby. All sounds are directly transmitted to the parent unit.
Note: Set the sensitivity level to 'very high' to have continuous sound on the
parent unit. Please see the Sensitivity level chapter for more information.
20°C
1
VOX
If your baby cries, the sound level lights light up green. As long as no sound
is detected, the sound level lights are off.
AUDIO mode
AUDIO
AUDIO
1Press the mode button on the side of the parent unit to switch to AUDIO
mode.
15
English

VOXAUDIO
When the AUDIO mode is activated, the display of the parent unit switches
off. After 3 seconds the display will completely turn off and the status bar
will disappear.
Note: The status bar is not visible when the display is off.
20°C
1
AUDIO
Note: The link light shows that the parent unit is still on and connected to
the baby unit.
Note: When sensitivity level is not set to 'very high', low sounds will be
muted.
Note: Set the sensitivity level to 'very high' to have continuous sound on the
parent unit. Please see the Sensitivity level chapter for more information.
All sounds are constantly transmitted to the parent unit. If your baby cries,
the display of the parent unit is still off, but the sound level lights light up
green and the sounds detected by thebaby unitare transmitted to the
parent unit. As long as no sound is detected, the sound level lights are off.
VOX mode
VOX
VOX
1Press the mode button on the side of the parent unit to switch to VOX
mode.
Note: When the display is on, the selected mode is shown in the status bar.
The status baris not visible when the display is off.
VOX VOX
VOX 20°C
1
VOX
When the VOX mode is activated, the display and sound of the parent unit
switch off, if there is no sound detected for 20 seconds.
20°C
1
VOX
Whensound is picked up by the baby unit, the displayand sound of the
parent unit switch on immediately.The sounds are transmitted to the parent
unit and the sound level lights light up green. As long as no sound is
detected, the sound level lights are off.
Note: The minimum sound level to activate sound and display is defined by
the sensitivity setting.
ECO mode
16 English

ECO
ECO
1Press the mode button on the side of the parent unit to switch to ECO
mode.
Note: When the display is on, the selected mode will be visible in the
status bar. The status bar is not visible when the display is off.
ECO
When the ECO mode is activated the display and sound of the parent unit
switch off when no sound is detected for 20 seconds. TheECO light lights up
green to indicate that the ECO mode is activated. During ECO mode the
display and sound transmissions are turned off.
20°C
1
ECO
Whensound is picked up by the baby unit, the displayand sound of the
parent unit switch on immediately.The sounds are transmitted to the parent
unit and the sound level lights light up green. As long as no sound is
detected, the sound level lights are off.
Note: The minimum sound level to activate sound and display is defined by
the sensitivity setting.
Nightlight
1Press the nightlight on/off button on the baby unit to switch on the
nightlight feature.
The nightlight of the baby unit goes on.
Note: It is not possible to control the nightlight from the parent unit. You
can only switch the nightlight on or off on the baby unit.
17
English

2Press the nightlight on/off button again to switch off the nightlight.
Lullabies
You can activate the lullaby feature either from the parent unit or from the
baby unit.
To activate the lullaby feature from the parent unit, follow the instructions
below:
Talk-back
You can use the talk-back button on the parent unit to talk to your baby.
1Press and hold the talk-back button on the parent unit.
2Talk clearly into the microphoneat the front of the parent unit from a
distance between 15-30cm /0.5-1ft.
As long as the talk-back button is pressed, there is an open sound
connection to the baby unit. The display of the parent unit shows the
talk-back icon, indicating the active connection.
3Release the talk-back button when you have finished talking..
Note: As long as the talk-back button is pressed, theparent unitcannot
process sounds coming from the baby unit.
Menu features
All features described in the following sections can be operated through the
menu of the parent unit.
18 English

1Press the menu button to enter the menu.
Note: When pressing the menu button again, you will leave the menu.
2Use the control button to navigate through the menu. The selected menu
item is highlighted purple.
Note: If you are already in one of the sub menus and you want to switch
between menu features,press the left part of the control button to
navigate back to the main menu.
3Press the top or bottom part of the control button to scroll through the
different menu items.
When you are navigating through the menu features and do not want to
save any change, press the menu button. You will leave the menu
without changing any settings.
Note: If you are in the menu but do not press a button for 5 seconds, the
menu will exit without saving changed settings.
Zoom
20°CVIDEO 1
Zoom
O
On
1Press the right part of the control button toenter the zoom menu.
Zoom
O
On Pan
20°CVIDEO 1
2Press the bottom part of the control button to switch on the zoom
feature.
19
English

20°CVIDEO
Menu
1
3To adjust the video image press the right part of the control button. Now
you can use the top/bottom/right/left part of the control button to
choose what image will be shown on the parent unit.
4Press the menu button to save the new setting. The image is
automatically saved after 5 seconds.
5Go to the zoom menu and turn off the zoom function, if you want to
zoom out the image on the parent unit.
Sensitivity
The sensitivity level of the baby unit defines what you hear through the
parent unit. When the level is set high, you will hear many sounds, including
soft background sounds. When the sensitivity level is set low, you will hear
only the louder sounds.
20°C
1
VIDEO
Sensitivity
Low
Medium
High
Very High
1Press the right part of the control button to access the sensitivity levels.
Note: When pressing the left part of the control button again, you will
leave the menu.
20°C
1
Sensitivity
Low
Medium
High
Very High
VIDEO
2Press the top or bottom part of the control button to select the desired
sensitivity level.
20°C
120°C
1
VIDEO
Sensitivity
Low
Medium
High
Very High
If your baby only makes soft sounds, the sensitivity of the baby unit
needs to be set to a high sensitivitylevel on the parent unit.
Sensitivity
Low
Medium
High
Very High
20°C
120°C
1
VIDEO
The louder your baby sounds, the lower the sensitivity can be set on the
parent unit.
Note: In AUDIO and VIDEO mode, you will have continuous sound when
the sensitivity level is on 'very high'. Otherwise, low sounds will be muted.
Tip: The sensitivity level can be adjusted so you will always hear your
baby without the disruption of other sounds. When there is a lot of
background noise, turn the sensitivity lower so you will not hear these
sounds through the parent unit.
3Press the left part of the control button to save the new setting and to
return to the main menu.
20 English
