Philips CEM3000B/05 User manual

Register your product and get support at CEM3000B
EN Quick start guide
EN Installation guide
5mm5mm5mm5mm
5mm
I
K
M
J
L
N
b
a
c
d
aa
bcd
ab
ef
cd
gh
b
c
d
183 mm
53mm
5mm
A
C
E
G
B
D
F
H
CEM3000B_05_QSG_V1.0.indd 1 10/15/2010 11:16:58 AM

Installation guide
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
This unit is designed for negative ground
•
(earth) 12 V DC operation only.
Always install this unit in the car dashboard.
•
Other locations can be dangerous as the
rear of the unit heats up during use.
To avoid short-circuit: before you connect,
•
ensure that the ignition is off.
Ensure that you connect the yellow and red
•
power supply leads after all other leads are
connected.
Ensure that all loose leads are insulated with
•
electrical tape.
Ensure that the leads do not get caught
•
under screws orin parts that will move (e.g.
seat rail).
Ensure that all ground (earth) leads are run
•
to a common ground (earth) point.
Use only the supplied mounting hardware
•
for a safe and secure installation.
Improper fuses can cause damage or re.
•
When you need to change the fuse, consult
a professional.
Note on the power supply lead (yellow)
When you connect other devices to this•
apparatus, ensure that the rating of the car
circuit is higher than the total fuse value of all
the connected devices.
Notes on speaker connection
Never connect speaker wires to the metal•
body or chassis of the car.
Never connect speaker wires with stripes to•
one another.
Connector Connect to
5 REAR LINE
OUT L (Socket)
Rear left speaker
6 SUBWOOFER Subwoofer
7 DAB Antenna DAB Antenna
2Cut off the bigger end of the supplied
standard connector.
3Check the car’s wiring carefully and connect
them to the supplied standard connector. E
1 Green/black strip Left speaker (Rear)
2 White/black strip Left speaker (Front)
3 Gray/black strip Right speaker (Front)
4 Purple/black strip Right speaker (Rear)
e RED Ignition key +12V DC when
ON/ACC
f BLUE Motor/electric antenna relay
control lead/Amplier relay
control lead
gBLACK Ground
h YELLOW To the +12V car battery which
is energized at all times
4Connect the supplied standard connector to
the unit. F
Tip
The pin arrangement for the ISO connectors
•
depends on the type of vehicle you drive. Be
sure to make proper connections to prevent
damage to the unit.
Mount into the dashboard
1If the car does not have an on-board drive or
navigation computer, disconnect the negative
terminal of the car battery.
If you disconnect the car battery in a car•
that has an on-board drive or navigation
computer, the computer may lose its
memory.
If the car battery is not disconnected, to•
avoid short-circuit, ensure that the bare
wires do not touch each other.
2Ensure that car dashboard opening is within
these measurements: G
3Remove the two screws on the top of the
unit. H
4Remova o suporte para instalação com as
ferramentas para desmontagem fornecidas. I
5Install the sleeve into the dashboard and
bend the tabs outward to x the sleeve. J
Note
If the unit is not xed by sleeve but by the
•
supplied screws, skip this step.
6Place the supplied rubber cushion over the
end of the mounting bolt. K
7Slide the unit into the dashboard until you
hear a click sound. L
8Reconnect the negative terminal of the car
battery.
Attach the front panel
1Attach the trim plate. M
2Insert the right side of the panel in the
chassis until it is correctly engaged.
3Press the left side of the panel until the
mechanism locks it into place. N
Connection: for cars with ISO connectors
Caution
Ensure that all loose leads are insulated with
•
electrical tape.
1Pull out the ISO connectors from car
dashboard and connect them to the bigger
end of the supplied standard connector. A
2Connect the other end of the supplied
standard connector to the unit. B
3 Connect the antenna and amplier as
illustrated, if applicable.You can connect the
car audio to the amplier through RCA-TO-
RCA cables (not supplied). C
Connector Connect to
1 ANTENNA Antenna
2 FRONT LINE
OUT R (Socket)
Front right speaker
3 FRONT LINE
OUT L (Socket)
Front left speaker
4 REAR LINE
OUT R (Socket)
Rear right speaker
5 REAR LINE
OUT L (Socket)
Rear left speaker
6 SUBWOOFER Subwoofer
7 DAB Antenna DAB Antenna
Connection: for cars without ISO
connectors
Caution
Be sure to connect the black ground (earth)
•
lead rst.
1 Connect the antenna and amplier as
illustrated, if applicable. D
Connector Connect to
1 ANTENNA Antenna
2 FRONT LINE
OUT R (Socket)
Front right speaker
3 FRONT LINE
OUT L (Socket)
Front left speaker
4 REAR LINE
OUT R (Socket)
Rear right speaker
Quick start guide
What’s in the box
Check and identify the contents of your package::
aMain unit bRemote control
cFront panel dTrim plate
eCarrying case for front panel
fSleeve gRubber cushion
hScrews x 4 pcs iISO male connectors
jDisassembly tools x 2 pcs
kUser manual lQuick start guide
mDAB Antenna
Select country/region
1Press to turn on the unit.
2Rotate to select an option:
[USA] (United States)•
[Latin] (Latin America)•
[Europe] (Western Europe)•
[ASIA] (Asia Pacic)•
[Mid-East ] (Middle East)•
[Russia] (Russia)•
3Press to conrm.
Turn on
1Press to turn on the unit.
To turn off the unit, press•for over
3 seconds.
Set clock
1Press MENU.
2Press / repeatedly until [CLK SET]
displays.
3Rotate to set hour.
4Press to conrm.
5Rotate set minute.
6Press to conrm.
Listen to radio
1Press SOURCE repeatedly to select radio
mode.
2Press BAND/ to select band: [FM1], [FM2],
[FM3], [AW1] or [AW2].
3Press or to tune to a radio station
manually.
The radio station is broadcast.
»
To search for a radio station
»
automatically, press or for over
3 seconds.
Listen to DAB
1Press SOURCE on the main unit repeatedly
to select DAB/DAB+.
The system performs auto scan.
»
All the available DAB stations are stored.
»
The radio tunes to the rst available
»
station.
Play a disc
1Insert a CD with the printed side facing up.
Play starts automatically.
»
To pause CD play, press•.
To resume CD play, press•again.
To skip to the previous/next track, press •
or .
To search backward/forward rapidly•
within the current track, press or
for 3 seconds.
Play from USB
1Slide the USB socket cover marked to
the left.
2Insert the USB device into the USB socket.
The unit starts playing from the USB
»
device automatically.
Play from iPod/iPhone
1Slide the USB socket cover marked to
the left.
2Insert USB adaptor on one end of iPod/
iPhone cable to the USB socket on the main
unit.
3Insert the other end of the iPod/iPhone
cable to the iPod/iPhone socket.
The unit starts playing from the USB
»
device automatically.
© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
CEM3000B_QSG_V1.0
