Philips CEM1000/00 User manual

www.philips.com/welcome
Register your product and get support at
Registre su producto y obtenga asistencia en
Registre seu produto e obtenha assistência em
CEM1000
EN Quick Start Guide

1ab
efg
45
32
h
d
c
b
a
c
d
aa
bcd
ab
ef
cd
ghi
b
c
d

5
5mm
5mm5mm5mm5mm

English
Overview of parts 1
These are the supplied parts needed to connect
and install this unit.
aMain unit
bSleeve
cFront panel
dTrim plate
eRubber cushion
fDisassembly tools
gScrews (4 pieces)
hStandard ISO connector
Select country/region
1Press to turn on the unit.
2Rotate to select an option:
[USA] (United States)•
[Latin] (Latin America)•
[Europe] (Western Europe)•
[ASIA](AsiaPacic)•
[Mid-East ] (Middle East)•
[Russia] (Russia)•
3Press toconrm.
Connection
For cars with ISO connectors 234
1Pull out the ISO connectors from car
dashboard and connect them to the bigger
end of the supplied standard connector.
2Connect the other end of the supplied
standard connector to the unit.
3Connecttheantennaandamplieras
illustrated, if applicable.You can connect the
caraudiototheamplierthroughRCA-TO-
RCA cables (not supplied).
Connector Connect to
1 ANTENNA Antenna
2 REAR LINE
OUT R
Rear right speaker
3 REAR LINE
OUT L
Rear left speaker
For cars without ISO connectors 4 5
1 Connecttheantennaandamplieras
illustrated, if applicable.
2Cut off the bigger end of the supplied
standard connector.
3Check the car’s wiring carefully, then connect
them to the supplied standard connector.
1 Green/black strip Left speaker (Rear)
2 White/black strip Left speaker
(Front)
3 Gray/black strip Right speaker
(Front)
4 Purple/black strip Right speaker
(Rear)
e RED Ignition key +12V DC when
ON/ACC
f BLUE Motor/electric antenna relay
controllead/Amplierrelay
control lead
g BLACK Ground
h YELLOW To the +12V car battery
which is energized at all times
4Connect the supplied standard connector to
the unit.
Mount into the dashboard 6
1If the car does not have an on-board drive or
navigation computer, disconnect the negative
terminal of the car battery.
2Remove the two screws on the top of the
unit.
3Remove the mounting sleeve with the
supplied disassembly tools.
4Install the sleeve into the dashboard and bend
thetabsoutwardtoxthesleeve.

5Place the supplied rubber cushion over the end of the mounting bolt.
6Slide the unit into the dashboard until you hear a click sound.
7Reconnect the negative terminal of the car battery.
Attach the front panel 6
1Attach the trim plate.
2Insert the right side of the panel in the chassis until it is correctly engaged.
3Press the left side of the panel until the mechanism locks it into place.
Turn on
1Press to turn on the unit.
To turn off the unit, press•for over 3 seconds.
Set clock
1Press MENU.
2Press or repeatedly until current time is displayed.
3Rotate clockwise to set hour.
4Press toconrm.
5Rotate anti-clockwise to set minute.
6Press toconrm.
View clock
1Press and hold OPTIONS repeatedly until the clock is displayed.
Listen to radio
1Press SOURCE repeatedly to select Tuner.
2Press or to select band: [FM1], [FM2], [FM3], [AM1], or [AM2].
3Press or to tune to a radio station manually.
The radio station is broadcast.•
To search for a radio station automatically, press•or for over 3 seconds.

© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
Document order number: CEM1000_00_QSG_V3.0
