1.0 PURPOSE
This document establishes the functional test and inspection procedures for the second level service repair of the
PHILIPS XENIUM 9@9 e transceiver.
2.0 SCOPE
The test plan is applicable to all levels of service repair of the PHILIPS XENIUM 9@9 e transceiver.
3.0 REFERENCE
None.
4.0 GLOSSARY / ACRONYM LIST
Window or Bezzel Protective plastic over the LCD display
SW Software
PN Hardware Configuration of the Mobile
CN Matrix for Types of SW used on the different hardware
HW Hardware
ASC Authorized Service Center
NSC National Service Center
Test SIM Card Used for functionality of PHILIPS Mobile Phones
Test SIM Card « SP » SIM Card used to simulate the user interface and enable radio tests
5.0 TEST EQUIPMENT AND TOOLS
Equipment / Tools
- Test SIM Card « Production » - Part No. : 4311 255 00781
- Test SIM Card « SP » - Part No. : 4311 255 00782
- Data Connect Cable - Part No. : 4311 255 22276
- Digital Multimeter - Recommended Model : Fluke (Specification with current reading in mA).
- Standard Screwdriver : Torx 0.6
- Paper Cut tool
- Digital Radio communication Tester.
- Coupling system with shielded chamber ONLY.
or in part is prohibited without the written
consent of the copyright owner.

Depart. Technical support- CM640 PROCEDURE COMPANY RESTRICTED
PHILIPS Consumer
Communications
Centre du Mans
Service Repair Support
VY-V-640-P661
Page : 6 of 70
Langue : EN
Date : 19/09/05
© PHILIPS ELECTRONICS N.V. 1999 VY-V-640-P661
All rights reserved. Reproduction in whole
6.0 TEST AND INSPECTION PLAN
The test plan is derived from the Product Test Reference of PHILIPS XENIUM 9@9 e.
6.1 User Interface Test
Use the Test SIM Card to test the transceivers as follows :
• On/Off button
• LCD Backlight
• Keyboard Test
• Side Keys
• Vibrator Test
• Audio Test
• Antenna Test ( to measure the radiated power level. Not necessary when using an antenna coupler)
• LCD (big & small)
• IRDA
• IMEI
• Tester Status/Eeprom Status
With a fast Charger connected with the PRODUCT’s bottom connector, check the full scrolling from one mode to
the next when charging IGN (Ignition) – Battery.
6.2 RF Test
The purpose of the radio test is to prove that the tested phone is compliant to the Standard.
The radio test must be performed with a
Digital Radio Test Set. The mobile has to
be set on the antenna coupler inside the
shielded chamber.
Due to a not accessible RF connector when the Product is closed, it will be necessary to make radio test inside
Shielded chamber only.
See Help Radio Files Over the antenna - RF Calibration.pdf & Over the antenna - The equipments.pdf under the
Internet Web Site :
http://philipscscc.soft2you.net/ in " Technical Support \ Component List \ Wireless \ PHILIPS 639 " section
