Philips CTX 320 User manual

Discover your phone
Philips continuously strives to improve its products. Therefore, Philips reserves the rights to revise this
user guide or withdraw it at any time without prior notice. Philips provides this user guide “as is” and
does not accept, except as required by the applicable law, liability for any error, omission or discrepancy
between this user guide and the product described. The device is meant to be connected to GSM/GPRS
networks.
V/WSide volume key
Hang-up and On/
Off key
Back of phone: 2.0MP camera lens
262K TFT LCD
Meeting profile On/
Off, selection of text
Left soft key
Navigation and , keys
Right soft key
Alphanumeric keypad
Lock/unlock key, Symbol
input
Microphone
Pick-up key
Charger, headset
connector & USB port
FFM radio key

1
How to ...
Swith the phone On/Off Long press and release ) .
Enter your PIN code Enter your PIN code using the keypad and press , to confirm.
Lock keypad On idle screen, long press *.
Unlock keypad On idle screen, press right soft key
L Unlock and then *.
Make a call Enter the phone number using the keypad and press ( .
Answer a call When the phones rings, press ( .
End a call Press ) .
Activate/Deativate
handsfree mode
During a call, press right soft key RH-Free/H-Held.
Access contacts list On idle screen, press right soft key RContact.
Listen to FM radio On idle screen, press F to listen to FM radio. To tune to a radio
station, please pull out the atenna on top of your phone or plug the
supplied headset into your phone.
Select text entry method Press # repeatedly on the editing screen. Long press *to turn T9
input on or off. Long press # and release to access Languages screen.
Access main menu On idle screen, press , Menu.

2
Quickly return to idle
when browsing menus
Press ) .
Select/unselect Meeting
profile
On idle screen, long press #.

3
Soft keys
The , , left and right soft keys are located at the
top of the keypad area. Pressing the soft keys
allow you to select the options above them on
the screen. Such options are contexual: they
vary according to current context.
Main Menu
The main menu gives you access to all the
different features of your mobile phone. The
table below summarizes the functional icons on
the main menu. To find more information about
their functions, refer to the pages.
Press , Menu on idle screen to access the main
menu and press +, -, <or >to navigate through
the icons and lists. Press , Select to access the
options related to the selected item. Press right
soft key RBack to return to previous menu.
Press )to return to the idle screen.
Entertainment Browser Media player
第48页 第44页 第49页
Camera Messaging My files
第46页 第21页 第55页
Tools Contacts Profiles
第36页 第32页 第62页
Bluetooth Calls Settings
第59页 第58页 第63页

4
Fast Keys
You can configure the navigation keys +, -, <
or >to access your favorite features directly.On
idle screen, press the keys to access the
features.
Go to Settings >General >Fast keys to check the
default settings of the navigation keys +, -, <
or >.
To change the default settings,
1. Select the item to be changed.
2. Press left soft key REdit to assign a new
shortcut to the key.
3. Press +or -to select, and left soft key
ROK to confirm.
Power-saving mode
After the set time span, the phone has the idle
screen turned off automatically. To exit the
power-saving mode, press any key. For power-
saving purpose, set the time span to a low value
in Settings >Display >Backlight duration &
Backlight level.
Auto keypad lock
In the idle mode, your phone can have the
keypad locked automatically after the set time
span.
To set the auto keypad lock
Go to Settings > General > Security > Auto keypad
lock.
To u n l o c k t h e k e y p a d
Press right soft key L Unlock and then *.
0
Long press to enter “+” when
making international calls.
1
Long press to access the voice
mailbox.
#Long press to select/unselect
Meeting profile (by default,
vibration on or off for incoming
calls or messages).

5
To l o c k t h e k e y p a d m a n u a l l y
On the idle screen, long press *.

6Table of contents
Table of contents
1 Getting Started 11
Insert the SIM card 11
Charge the battery 13
Set clock 14
Insert the micro-SD card 15
2 Text Entry 16
Selecting text entry methods 16
Entering text 17
3 Calling 20
Making a call 20
Answering and ending a call 21
Options during a call 22
Handling multiple calls
(Network-dependent) 23
Making an emergency call 24
4 Messaging 25
Creating messages 25
Organizing your messages 28
Defining your message settings 29
E-mail 31
Broadcast messages 34
5 Contacts 35
Adding or editing contacts 35
Searching for a contact 36
Managing your contacts 36
Special numbers 38
6 Tools 40
Using your business organizer
Create your to-do list 40
Check your calendar 41
Edit your to-do list 41
Table of contents

Table of contents 7
Delete expired tasks 41
Using your business assistant
Sound recorder 41
Using your clock and timer
Alarm 43
World clock 44
Stopwatch 44
Using your file reader
Text reader 45
Using the torch 45
Using your business assistant
Firewall 46
Others
Calculator 47
Currency converter 47
7 Browser 48
Managing your browser 48
Accessing web sites 48
Enabling/ disabling push messages 48
STK 49
8 Camera 50
Camera 50
Video recorder 57
9 Fun 60
Java games and application 61
10 Music 62
Music player 62
FM radio 65
11 My files 68
Finding your files 68
Managing your files 68
Sharing your files 69

8Table of contents
Using your files 70
12 Calls 71
Call history 71
13 Bluetooth 73
About Bluetooth 73
Connecting to a Bluetooth device 73
Getting connected by
a Bluetooth device 74
Editing your device list 75
14 Profiles 76
Adjusting ringer settings to
different scenes 76
15 Settings 77
General 77
Display 79
Sounds 80
Connectivity 81
Icons & Symbols 83
Precautions 85
Tips 92
Troubleshooting 93
Philips Authentic Accessories 97
Trademark Declaration 100
Specific Absorption Rate Information 101
Limited Warranty 103
Declaration of Conformity 107

Getting Started 9
1 Getting Started
Congratulations on your purchase and welcom
to Philips!
To get the most of your product and enjoy all
Philips has to offer, register your product at
www.philips.com/welcom.
Please read the safety instructions in the
"Precautions" section before use.
To use your phone, you must insert a valid SIM
card supplied by your GSM operator or retailer.
The SIM card contains your subscription
information, your mobile phone number and a
memory in which you can store phone numbers
and messages.
Inserting the SIM card
Follow the steps bellow to insert your new SIM
cards. Remember to switch off your mobile
phone before removing the back cover.
1. Press on the bottom of the back cover, and
slide the cover as shown.
2. As shown, take out the battery.
You may lose all your personal settings if you
remove the battery when the phone is switched
on.

10 Getting Started
3. As shown, align your SIM card with the SIM
care slot, beveled corner facing you and
gold contact downwards. Insert your SIM
card under the metal clip holder.
4. As shown, align the metallic connectors on
the battery and battery slot. Insert the
battery until it is locked.
5. As shown, put on the back cover, and press
it down. You will hear a click when it is
locked.
Remove the protective film covering the screen
and camera lens before using the phone.
Charging the battery
Your phone is powered by a rechargeable
battery. A new battery is partially charged. The
battery symbol indicates the state of the battery.

Getting Started 11
To charge the battery, plug in the connector as
shown below. Then plug the other end into a
power socket.
During charging, the battery symbol scrolls.
Keeping the charger plugged to the mobile
phone when the battery is fully charged will not
damage the battery. The only way to turn off the
charger is to unplug it, so it is advisable to use an
easily accessible power socket.
If you do not intend to use your phone for
several days, we recommend that you remove
the battery.
You can use the phone while it is charging. If the
battery is completely flat, the battery symbol will
only reappear after a few minutes of charging.
Set clock
1. Check that your phone is switched on.
Long press )if necessary. Enter the PIN
code if required. A PIN code is a 4- to 8-
digit secret code of your SIM card. It is
preconfigured and communicated to you
by your network or retailer.
If you enter an incorrect PIN code three times
in succession, your SIM card will be blocked. To
unblock it, you must request the PUK code from
your operator.

12 Getting Started
2. On idle screen, press , Menu and go to
Settings > General > Time and date.
Set home city: Select a city that is within the
same time zone as yours.
Set date/Set time: Press +or -repeatedly
until you reach the desired digits.
Set format: Select the time (12-hour or 24-
hour clock) and date format by pressing the
navigation keys +, -, < or > and left soft key
L OK.
Clock type: To display time and date on idle
screen, press +or - show the time in a
clock (Analog) or digits (Digital). Press left
soft key L OK to confirm.
Display local and international
clocks
You can display two clocks on the idle screen,
one showing your local time and the other the
time of your destination.
1. Check that you have set your local time and
date.
2. Go to Tools > World clock, press < or > to
select a city that is within the same time
zone as your destination city.
3. Press left soft key L Options:
Daylight saving time for foreign city: Turn on
the daylight saving mode if applicable.
Set world clock: Set your destination city.
World clock status: Press left soft key L OK to
turn on the international clock.
Inserting Micro-SD card (memory
card)
You can expand the memory of your phone by
adding a micro-SD card.
Supported capacity: up to 8GB
1. Follow Step 1 and Step 2 under "Inserting
the SIM card" .

Getting Started 13
2. As shown, push down the card holder and
lift it up. Aligh your micro-SD card with the
slot. Put it in place.
3. Press down the card holder and pull it until
it is locked.

14 Text Entry
2 Text Entry
Your mobile phone supports a number of text
entry methods, including T9 input, multi-tap
input, numeric input and symbol input.
Select text entry methods
1. To select your desired language on the
editing screen, press # more than 3
seconds, and then, release it.
2. Press #repeatedly to select your desired
inputs:
//:forEnglishentry
: for numeric entry
: Phonetic input for simplified
Chinese
/:
Stroke input for Simplified /Tranditional
Chinese
Depending on the language you select for your
phone, the supported input methods may vary.
3. To switch the T9 English input on or off,
press *more than 3 seconds, and then
release it.
4. To enter a symbol and punctuations, press
*.
The text editor remembers the last input
method you have used before you exit the
editing screen. When you access the editor
again, it will automatically select the last input
method you have used.
Entering text
1. Select your desired text entry methods.
2. Enter text by using the alphanumeric
keypad.
2to 9To input letters (T9/ phonetic input)
Press repeatedly to input desired
letters (multi-tap input).
1 to 6To enter strokes (stroke input)

Text Entry 15
<,> To browse candidate words (T9/ phonetic/
multi-tap input)
+,- To browse the candidate words on the
previous/next page (T9 input/multi-tap
input)
R Select To confirm the selection
0To input a space
R Clear Short press to clear a letter,
Long press to clear all entries.
3. If necessary, press R Back to exit the input
mode.
T9®input
T9®predictive text input is an
intelligent editing mode for
messages, which includes a
comprehensive dictionary. It
allows you to quickly enter text.
You need to press only once on the key
corresponding to each letter needed to spell a
word: keystrokes input are analyzed and the
word suggested by T9®is displayed at the pop-
up window.
Examples: how to enter the word "home":
1. Press 4, 6, 6, 3.
The screen displays the first word of a list:
Good.
2. Press -to scroll and select Home.
3. Press RSelect to confirm.
Multi-tap input (ABC/Abc/abc)
Press the keys that are marked with the
corresponding letter you wish to enter. Press
once to get the first letter on the key, press
twice quickly to get the second letter and so on
until the letter you want is displayed on the
screen.
Example: how to enter the word "home":
Press 4, 4(GHI), 6, 6, 6(MNO), 6
(MNO), 3, 3(DEF).
Tegic Euro. Pat.
App. 0842463

16 Text Entry
Stroke input
The principle of stroke input is to dissect and
separate every stroke of a Chinese character
according to sequence. When you wish to input
the character, press the keys corresponding to
the required strokes according to sequence to
get the desired character. The stroke input
method in this phone classifies a Chinese
character into 5 basic strokes: (horizontal,
vertical, left falling stroke, right falling stroke and
over-down) as well as a special stroke. When
the stroke you need does not correspond to the
5 basic strokes, replace it with the special
stroke(?).

Calling 17
3 Calling
Making a call
From idle screen
1. Enter the phone number.
2. Press ( to dial the number.
3. Press ) to hang up.
For international calls, long press 0to
enter the "+" sign for the international prefix.
Use the phonebook (see “Contacts”
on page 32)
1. Go to Contacts >View contacts to open the
contacts list.
To search for a contact, enter the contact
name (up to 5 characters) using the
alphanumeric keypad, or select a contact
from the list.
2. Press (to dial the selected number.
For IP calls (China only), select Options >
IP dial.
You can preset your IP service number
under Settings >Connectivity > Call options >
IP prefix.
3. Press ) to hang up.
Speed dial
On the idle screen, you can call a preset speed-
dial number by long pressing a numeric key (2
to 9).
Set your speed-dial number before dialing it.
To assign a speed-dial key to a contact:
1. Go to Settings > General > Speed dial.
2. If necessary, press left soft key Rto turn
speed dial on.
To make a speed dial, always check
that the speed-dial function is enabled.
3. In Set number, select one of the locations
(corresponding to the numeric keys 2to 9).

18 Calling
4. Assign to the location a contact from your
phonebook.
Answering and ending a call
When you receive a call, the number of the caller
may be displayed, depending on whether or not
the calling party has chosen to display his or her ID.
If the number is stored in the phonebook, then the
corresponding name is displayed.
•Answer the call: Press (.
•Hang up: Press ).
• To answer or end a call using the supplied
one-key headset, see “Headset” on page 82 .
To reject calls from certain contacts, you
can add the contacts or numbers to your
blacklist. In Contacts > View contacts or Calls > View
calls > All calls , select a contact or phone number,
and press ROptions > Set black (For more
information about blacklist, see “Firewall” on
page 42).
Options during a call
During a call, you can press right soft key Rto
select H-free or H-held mode. Press left soft key
ROptions to access the following options:
-Hold single call:Put current call on hold
-End single call: End current call
-New call:Make a new (a second) call
-Phonebook:Add or view contacts
-Messaging: Send or check messages
-Sound recorder: Record conversation
during a call. (see “Sound recorder” on
page 38)
-Background sound:Select the background
sound for your calls.
-Mute: Mute/unmute the call
-DTMF: Enable the touch tone dialing
system
Sound recorder
In most countries, recording of telephone
conversation is subject to legislation. We advise

Calling 19
you to notify the caller if you intend to record
the conversation and only do so if they agree.
You should also ensure confidentiality of the
recordings.
To record a conversation during a call, select
Options and select Sound recorder. Recorded
sound is saved in *.amr format and stored in Audio
of My files menu. (see “Finding your files” on
page 55).
Mute or unmute a call
During a call, select Options and select to set the
Mute function On / Off . If you select Mute , the
microphone will be deactivated.
Adjust the volume
During a call, press side volume key Vor W
to increase or decrease the volume.
Handling multiple calls (Network-
dependent)
You can handle two or more calls at the same
time, as well as make conference calls with your
phone. The availability of this feature is
dependent on your network operator and/or
your subscription.
Make a second call
You can make a second call when there is an
active call or with a call on hold. While on the
phone, enter the number (or select a contact
from the phonebook) and press ( . The first call
is put on hold and the second number is dialed.
You can then select Options to access the
following options:
-Swap:To toggle between 2 calls.
-Conference:To introduce the caller into a
conference call.
-End single call:To disconnect one party
from the call.
