User manual
Always there to help you
Register your product and get support at
AJ6200DBZ
Question?
Contact
Philips

1EN
Contents
1 Important 2
2 Your clock radio 3
Introduction 3
What's in the box 3
Overview of the clock radio 4
3 Get started 6
Install battery 6
Connect power 6
Set time 6
Turn on 7
4 Play from iPod/iPhone 8
Compatible iPod/iPhone 8
Listen to audio from iPod/iPhone 8
Charge the iPod/iPhone 8
5 Listen to FM radio 9
Tune to FM radio stations 9
Store FM radio stations automatically 9
Store FM radio stations manually 9
Select a preset radio station 9
6 Other features 10
Set alarm timer 10
Set sleep timer 11
Play audio from an external device 11
Adjust volume 11
Adjust display brightness 11
7 Product information 12
Specications 12
8 Troubleshooting 13
9 Notice 14

2EN
1 Important
Warning
• Never remove the casing of this product.
• Never lubricate any part of this product.
• Never place this product on other electrical equipment.
• Keep this product away from direct sunlight, naked
amesorheat.
• Make sure that you always have easy access to the
power cord, plug or adaptor to disconnect the product
from the power.
• Make sure that there is enough free space
around the product for ventilation.
• The product shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
product (e.g. liquid filled objects, lighted
candles).
• Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Only use power supplies listed in the user
manual.
• Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
product:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries when the unit is not
used for a long time.
• The batteries should not be exposed
toexcessiveheatsuchassunshinere
or the like.
Note
• The type plate is located on the bottom of the
apparatus.

3EN
2 Your clock radio
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this clock radio, you can:
• play audio from iPod/iPhone, or other
external devices;
• listen to FM radio;
• view time; and
• set two alarms.
What's in the box
Check and identify the contents of your
package:
• Clock radio
• Short user manual

4EN
Overview of the clock radio
a SOURCE
• Select an audio source: DOCK, FM, or
AUDIO IN.
• Switch to standby mode.
b SLEEP
• Set sleep timer.
c SNOOZE/BRIGHTNESS
• Snooze the alarm.
• Adjust display brightness.
d Display panel
• Show current information.
e Dock for iPod/iPhone
a
b
c
d
k
e
f
g
h
i
j
l
m
n
NIOIDUA
BUZZ
KCOD
FM
f AL1/AL2
• View alarm settings.
• Activate or deactivate alarm timer.
g VOLUME +/-
• Adjust volume.
h First knob (HOUR/PRESET/OK)
• Adjust hour.
• Select a preset radio station.
• Store radio stations automatically.
• Conrmaselection.
i Second knob (MINUTE/TUNING)
• Adjust minute.
• Tune to FM radio stations.
• Skip to the previous or next track.

5EN
j Third knob (SET TIME/SET
RADIO/CLOCK/SET AL1/SET AL2)
• Set time.
• Scan/store FM radio stations.
• Set alarm.
k ALARM (BUZZ/FM/DOCK)
• Select an alarm source for Alarm 1 and
Alarm 2.
l
• Charge your iPod/iPhone through a
USB cable (not supplied).
m AUDIO IN
• Connect an external audio device.
n FM ANT
• Improve FM reception.

6EN
3 Get started
Always follow the instructions in this chapter in
sequence.
Install battery
Caution
• Batteries contain chemical substances, so they should
be disposed of properly.
Note
• Batteries are not supplied with the accessories.
• [bAt] is displayed when the battery level is low.
• Batteries can back up clock and alarm settings when AC
power is disconnected.
1 Open the battery compartment.
2 Insert two AA batteries with correct
polarity (+/-) as indicated.
3 Close the battery compartment.
Connect power
Warning
• Risk of product damage! Make sure that the power
supply voltage corresponds to the voltage printed on
the back or the underside of the unit.
• Risk of electric shock! When you disconnect the AC
power, always pull the plug from the socket. Never pull
the cord.
Connect the AC power adapter to the wall
socket.
Set time
1 In standby mode, rotate the third knob to
SET TIME to activate clock setting mode.
» The hour and minute digits blink.
2 Rotatetherstknobtoadjustthehour.
3 Rotate the second knob to adjust the minute.
4 Press OKontherstknobtoconrm.
» The set time is displayed.
5 Rotate the third knob to CLOCK after
setting.
» The hour and minute digits stops blinking.
Note
• When an iPod/iPhone is connected, the clock radio
synchronizes time from the iPod/iPhone automatically.

7EN
Turn on
Once connected to AC power, the clock radio
turns on automatically.
Switch to standby mode
Press and hold SOURCE for three seconds to
switch to standby mode.
» The source indicator disappears on the
display panel.

8EN
4 Play from iPod/
iPhone
You can enjoy audio from iPod/iPhone through
this clock radio.
Compatible iPod/iPhone
The clock radio supports these iPod and iPhone
models:
Made for.
• iPod touch (5th generation)
• iPod nano (7th generation)
• iPhone 6 Plus
• iPhone 6
• iPhone 5s
• iPhone 5c
• iPhone 5
Listen to audio from iPod/
iPhone
Note
• Make sure that the third knob is switched to CLOCK
before setting.
1 Place the iPod/iPhone in the dock.
2 Press SOURCE repeatedly to select iPod/
iPhone mode.
» The icon is displayed.
3 Play audio on the iPod/iPhone.
4 Rotate the second knob to select the
previous or next track.
To remove the iPod/iPhone:
Pull the iPod/iPhone out of the dock.
Charge the iPod/iPhone
When the clock radio is connected to power,
the docked iPod/iPhone starts charging.

9EN
5 Listen to FM
radio
Tune to FM radio stations
Note
• Make sure that the third knob is switched to CLOCK
before setting.
1 Press SOURCE repeatedly to select FM
tuner source.
» The icon
FM
is displayed.
2 Rotate and hold the second knob for two
seconds.
» The clock radio tunes to a station with
strong reception automatically.
3 Repeat step 2 to tune to more radio
stations.
To tune to a station manually:
Rotate the second knob repeatedly until you
ndoptimalreception.
Tip
• Position the antenna as far as possible from any
radiation source.
• For better reception, fully extend and adjust the
position of the antenna.
Store FM radio stations
automatically
1 In FM mode, rotate the third knob to SET
RADIO.
»
FM
begins to blink.
2 Press and hold OKontherstknobfor
three seconds.
» The clock radio stores all the available
FM radio stations, and broadcasts the
rstavailablestationautomatically.
3 Rotate the third knob to CLOCK after
storing.
Store FM radio stations
manually
Note
• You can store a maximum of 20 FM radio stations.
1 In FM mode, rotate the third knob to SET
RADIO.
»
FM
begins to blink.
2 Rotate and hold the second knob for two
seconds.
» The last selected channel is displayed.
3 Rotatetherstknobagaintoselecta
number.
4 Press OKontherstknobtoconrm.
5 Repeat steps 2-4 to store other stations.
6 Rotate the third knob to CLOCK after
storing.
Tip
• To remove a pre-stored station, store another station
in its place.
Select a preset radio station
Note
• Make sure that the third knob is switched to CLOCK
before setting.
InFMmode,rotatetherstknobrepeatedlyto
select a preset radio station.

10 EN
6 Other features
Set alarm timer
In standby mode, you can set two alarms to ring
at different time.
Note
• Make sure that you have set the clock correctly.
1 Rotate the third knob to SET AL1 or SET
AL2 to activate alarm setting mode.
» The icon / and time digits blink.
2 Rotatetherstknobtoadjustthehour.
3 Rotate the second knob to adjust the
minute.
4 Press OKonrstknobtoconrm.
5 Rotate the third knob to CLOCK after
setting.
Select alarm source
For the alarm sound, you can select buzzer, your
last listened radio chanel, or the latest played
audio on your iPod/iPhone.
BUZZ
KCOD
FM
Tip
• If DOCK is selected as the alarm source, yet the audio
cannot be played, buzzer will sound instead when alarm
time comes.
• If FM is selected as the alarm source, yet the clock radio
is in FM mode, buzzer will sound instead when alarm
time comes.
Activate/deactivate alarm timer
Note
• Make sure that the third knob is switched to CLOCK
before setting.
1 Press AL1/AL2 to view alarm settings.
» The icon / is displayed.
2 Press AL1/AL2 again to activate or
deactivate the alarm timer.
» The icon / appears if the alarm
timer is on, and disappears if it is off.
• To stop the alarm, press the
corresponding AL1/AL2.
» The alarm repeats ringing for the next
day.
Snooze the alarm
When alarm sounds, press SNOOZE.
» The alarm snoozes and repeats ringing
nine minutes later.

11EN
Set sleep timer
Note
• Make sure that the third knob is switched to CLOCK
before setting.
This clock radio can switch to standby mode
automatically after a preset period.
• Press SLEEP repeatedly to select the sleep
timer period (in minutes).
» When the sleep timer is activated,
appears.
To deactivate the sleep timer:
• Press SLEEP repeatedly until [OFF] (off)
appears.
Play audio from an external
device
You can listen to audio from an external device
through this clock radio.
Note
• Make sure that the third knob switched to CLOCK
before setting.
15 30 60 90 120
OFF
1 Connect an audio input cable (not
supplied) with a 3.5 mm connector on
both ends to
• the AUDIO IN socket on the clock
radio.
• the headphone socket on an external
device.
2 Press SOURCE repeatedly to select the
Audio-in source.
» The icon is displayed.
3 Play the external device (refer to its user
manual).
Adjust volume
During play, press VOLUME +/- repeatedly to
adjust volume.
Adjust display brightness
SNOOZE
BRIGHTNESS

12 EN
7 Product
information
Note
• Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 5W RMS
Tuner
Tuning Range FM: 87.5 -
108 MHz
Sensitivity
- Mono, 26dB S/N Ratio FM: <22 dBf
Search Selectivity FM: <35 dBf
Total Harmonic Distortion FM: <2 %
Signal to Noise Ratio FM: >50 dB
Number of Presets 20
Speaker
Speaker Impedance 8 ohm
Speaker Driver 1 X 2.5” full
range
Sensitivity 85± 3dB/m/W
General information
AC power Model: AS190-090-
AD160;
Brand name: PHILIPS;
Input: 100-240 V~,
50/60 Hz, 0.7 A;
Output: 9 V 1.6 A;
Battery 2 X AA batteries (not
supplied)
Operation Power
Consumption
<15 W
Standby Power
Consumption
<1 W
USB Charging 5 V, 1 A
Dimensions - Main
Unit (W x H x D) 195 x 99 x 123 mm
Weight - Main Unit 0.79 kg

13EN
8 Troubleshooting
Warning
• Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support).When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.
No power
•Make sure that the AC power plug of the
unit is connected properly.
•Make sure that there is power at the AC
outlet.
No response from the clock radio
•Disconnect and reconnect the AC power
plug, then turn on the clock radio again.
Poor radio reception
•Keep the clock radio away from other
electronic devices to avoid radio
interference.
•Fully extend and adjust the position of the
FM antenna.
Alarm does not work
•Set the clock/alarm correctly.
Clock/alarm setting erased
•Power has been interrupted or the power
plug has been disconnected.
•Reset the clock/alarm.

14 EN
9 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
Gibson Innovations may void the user’s
authority to operate the equipment.
Care of the environment
Disposal of your old product
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Do not throw away the product with the
normal household waste at the end of its life,
buthanditinatanofcialcollectionpointor
recycling. By doing this, you help to preserve the
environment.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
“Made for iPod” and “Made for iPhone”
mean that an electronic accessory has been
designedtoconnectspecicallytoiPodor
iPhonerespectively,andhasbeencertiedby
the developer to meet Apple performance
standards. Apple is not responsible for the
operation of this device or its compliance with
safety and regulatory standards. Please note that
the use of this accessory with iPod or iPhone
may affect wireless performance.
iPod and iPhone are trademarks of Apple Inc.,
registered in the U.S. and other countries.
Note
• The type plate is located on the bottom of the
apparatus.

Specifications are subject to change without notice.
2015 © Gibson Innovations Limited.All rights reserved.
This product has been manufactured by, and is sold under the responsibility of Gibson
Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation to this product.
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V.
and are used under license from Koninklijke Philips N.V.
AJ6200DBZ_98_UM_V1.0
