Philips AJ3112/37 User manual

Clock Radio
Register your product and get support at
www.philips.com/welcome
AJ3112/37
AJ3112_37_UM_EN 4/16/10 15:55 Page 1

1
3
4
1
#%^ $
5
9
0
678
2
!
@
AJ3112_37_UM_EN 4/16/10 15:55 Page 2

AJ3112_37_UM_EN 4/16/10 15:55 Page 3

AJ3112_37_UM_EN 4/16/10 15:55 Page 4

IMPORTANT SAFETY INSTRUCTIONS
Class II equipment symbol
This symbol indicates that the unit has
a double insulation system
Clean only with dry cloth.
Where the MAINS plug or an appliance
coupler is used as the disconnet device,
the disconnet device shall remain
readily operable.
materials
9
AJ3112_37_UM_EN 4/16/10 15:55 Page 5

Notice of compliance
The set complies with the FCC-Rules, Part 15 and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1.This device may not cause harmful interference, and
2.This device must accept any interference received, including interfer-
ence that may cause undesired operation.
English
CONTROLS (see fig. 1 )
1DISPLAY - shows the clock/ alarm time and status of the set
2ALARM indicator -
lights up when alarm is activated
3Frequency indicator - shows the radio frequency of your selected waveband
4REPEAT ALARM /
SLEEP OFF
- switches off the active alarm for a 8-9 minute period
- switches off the sleep function
5CLOCK - sets the clock time
6SLEEP
- activates the radio for sleep function
- adjusts the sleep period
7ALARM RESET - stops the active alarm for 12 hours
8ALARM - sets the alarm function
Congratulations on your purchase and welcome to Philips!
To fully benefit from the support that Philips offers, register your
product at www.philips.com/welcome.
AJ3112_37_UM_EN 4/16/10 15:55 Page 6

9RADIO / ALARM
RADIO ON: switches on the radio
RADIO OFF: switches off the radio/alarm
ALARM - RADIO: activates the radio for alarm
ALARM - BUZ: activates the buzzer for alarm
0SET TIME HR / MIN
- adjusts the hours / minutes for clock / alarm / sleep time
!Power cord -
connects to wall outlet
@Pigtail - improve FM reception
#VOLUME - adjusts the sound level
$Battery door - opens to store a 9 volts 6F22 battery (not included) for clock
memory backup.
%FM/AM (MW) - selects FM/AM (MW) waveband
^TUNING - tunes to radio stations
Specifications
AC Power........................................................120 V / 60 Hz
Power Consumption
Active.......................................................................... 5 W
Standby.................................................................... 2.8 W
Dimensions (w x d x h)...............130.4 x 130 x 46.8 (mm)
.............................................................5.1 x 5.1 x 1.8 (inch)
Weight............................................0.395 kg / 0.87 pounds
AJ3112_37_UM_EN 4/16/10 15:55 Page 7

INSTALLATION
POWER SUPPLY
1
Check if the power supply, as shown on the type plate located on the bot-
tom of the set, corresponds to your local power supply. If it does not, consult
your dealer or service center.
2 Connect the plug to the wall outlet.
3 To disconnect the set from the power supply completely, remove the
plug from the wall outlet.
For users in the U.K.: please follow the instructions on the lower left
handed corner of the sheet.
CLOCK MEMORY BACKUP
The clock memory backup allows your alarm and clock time settings to be stored
for up to a day when there is a power interruption e.g. power failure. The com-
plete clock radio and display illumination will be switched off. As soon as the
power supply returns, the display will indicate the correct time.
1 Remove the battery door to insert a 9 volts 6F22 type battery (not included)
for backup.
2 Replace the battery door.
NOTE: If no backup battery is installed or the power interruption is prolonged,
you will need to set the clock and alarm times again.
Batteries contain chemical substances so they should be disposed of
properly.
Perchlorate Material - special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
AJ3112_37_UM_EN 4/16/10 15:55 Page 8

RADIO
You can use this set solely as a radio!
1
Adjust RADIO / ALARM to RADIO ON to switch on the radio.
2 Select your waveband by adjusting the FM/AM (MW) switch .
3
Adjust TUNING to tune to your desired station .
4
Turn the VOLUME control to adjust the volume level .
5
Adjust RADIO / ALARM to OFF to switch off the radio.
To improve reception:
FM: Extend and position the pigtail fully to obtain optimal reception.
AM (MW): uses a built-in antenna inside the set. Direct the antenna
by adjusting the position of your set
.
SETTING THE CLOCK / ALARM TIME
The time is displayed using the 12-hour clock.
1 Hold down CLOCK or ALARM.
2 Press HR or MIN repeatedly, or hold down HR or MIN to adjust minute
and/or hour.
3 Release CLOCK or ALARM and HR or MIN when you reach the correct setting.
™The set clock time will show on the display and start to run.
SELECTING THE ALARM MODE
To use the alarm, you must set the alarm time first. You can choose from two dif-
ferent alarm modes to wake you up: by radio or buzzer.
1 Select your choice of alarm mode by adjusting RADIO / ALARM to RADIO or BUZ .
™ The alarm indicator (AL) will light up.
AJ3112_37_UM_EN 4/16/10 15:55 Page 9

Helpful Hint:
• If you have selected the radio mode, make sure you have adjusted the vol-
ume loud enough to wake you.
• The buzzer is set at a fixed volume and cannot be adjusted.
SWITCHING OFF THE ALARM
There are three ways of switching off the alarm. Unless you cancel the alarm
completely, the 12 hour alarm reset option will be automatically selected after
1 hour and 59 minutes, from the time your alarm time first goes off.
12 HOUR ALARM RESET
If you want the alarm mode to be stopped immediately but also wish to retain
the same alarm setting for the following day:
• Press ALARM RESET during the alarm call.
™ The alarm indicator (AL) will remain on.
CANCELING THE ALARM COMPLETELY
To cancel the set alarm time before it goes off, or during the alarm call:
• Adjust RADIO / ALARM to OFF position.
™ The alarm indicator (AL) will light off.
REPEAT ALARM
This repeats your alarm call at 9-minute intervals.
1 During the alarm call, press REPEAT ALARM / SLEEP OFF .
™ The alarm indicator (AL) will remain on.
AJ3112_37_UM_EN 4/16/10 15:55 Page 10

SLEEP
This set has a built-in timer which enables the set to be automatically switched
off during radio playback after a set period of time. This allows you to lie back,
listen and fall asleep. The maximum sleep time is 1 hour and 59 minutes.
Setting SLEEP
1 Set RADIO / ALARM to OFF position.
2 Set the sleep time to activate sleep function by selecting on the following
ways:
• Simply press SLEEP to set your sleep time to 59 minutes.
• Hold down SLEEP , and press MIN repeatedly to adjust sleep time from 59
minutes downward.
• Hold down SLEEP and press HR to get one more hour sleep time (1:59)
™ To cancel sleep, press REPEAT ALARM / SLEEP OFF .
Notes for battery disposal
Your product contains batteries covered by the European Directive
2006/66/EC, which cannot be disposed of with normal household waste.
Please inform yourself about the local rules on separate collection of batter-
ies. The correct disposal of batteries helps prevent potentially negative conse-
quences on the environment and human health.
AJ3112_37_UM_EN 4/16/10 15:55 Page 11

SAFETY INFORMATION
• Install the unit near the AC outlet and where the AC plug can be easily
reached.
• Where the MAINS plug is used as the disconnect device, the disconnet device
shall remain readily operable.
• Place the set on a hard and flat surface so that the system does not tilt.
• If you do not intend to use the set for a long time, withdraw the power plug
from the wall outlet. In addition to this, it is advisable to remove the battery
from the clock radio. This will prevent any danger of leakage and the clock
radio will not be damaged.
• Do not expose the set, batteries to humidity, rain, sand or excessive heat
caused by heating equipment or direct sunlight.
• The apparatus shall not be exposed to dripping or splashing.
• Adequate ventilation with a minimum gap of 15cm between the ventilation
holes and surrounding surfaces is necessary to prevent heat build-up.
• The ventilation should not be impeded by covering the ventilation openings
with items, such as newspapers, table-cloths, curtains, etc..
• No objects filled with liquids, such as vases, shall be placed on the appartus.
• No naked flame sources, such as lighted candles, should be placed on the
apparatus.
• To clean the set, use a soft, slightly dampened chamois leather. Do not use
any cleaning agents containing alcohol, ammonia, benzene or abrasives as
these may harm the housing.
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
CAUTION
Use of controls or adjustments or performance of procedures other than
herein may result in unsafe operation.
This set complies with the radio interference requirements of the
European Union.
AJ3112_37_UM_EN 4/16/10 15:55 Page 12

TROUBLESHOOTING
If a fault occurs, first check the points listed below before taking the set for repair.
If you are unable to remedy a problem by following these hints, consult your dealer or
service center.
WARNING: Under no circumstances should you try to repair the set yourself, as this
will invalidate the warranty. Do not open the set as there is a risk of
electric shock.
Problem
–Possible Cause
•Remedy
No sound/power
–Volume not adjusted
•Adjust the volume
Occasional crackling sound during FM broadcast
–Weak signal
•
Adjust the position of the Pigtail
Continuous crackling/hiss disturbance during AM (MW) broadcast
–Electrical interference from TV, computer, fluorescent lamp, etc.
•Move set away from other electrical equipment
The alarm does not function
– Alarm time not set and or alarm mode not selected
•Set the alarm time and / select alarm mode
–Volume too low for RADIO
•Adjust the volume
–
Radio alarm not adjusted to radio station
•Tune to a radio station
AJ3112_37_UM_EN 4/16/10 15:55 Page 13

ENVIRONMENTAL INFORMATION
We have reduced packaging to the minimum for easy separation into two
materials: paper and cardboard.
Your set consists of materials which can be recycled if disassembled by a special-
ized company. Please observe local regulations on the disposal of packing materi-
als and old equipment.
Disposal of your old product
Your product is designed and manufactured with high quality
materials and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a
product it means the product is covered by the European Directive 2002/96/EC.
Please inform yourself about the local separate collection system for electrical
and electronic products.
Please act according to your local rules and do not dispose of your old products
with your normal household waste. The correct disposal of your old product will
help prevent potential negative consequences for the environment and human
health.
AJ3112_37_UM_EN 4/16/10 15:55 Page 14

Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
Never dispose of your product with other household waste. Please inform
yourself about the local rules on the separate collection of electrical and elec-
tronic products and batteries. The correct disposal of these products helps pre-
vent potentially negative consequences on the environment and human health.
Your product contains batteries, which cannot be disposed of with normal
household waste. Please inform yourself about the local rules on separate col-
lection of batteries. The correct disposal of batteries helps prevent potentially
negative consequences on the environment and human health.
Please visit www.recycle.philips.com for additional information on a recycling
center in your area.
Removal of the built-in battery invalidates the warranty and may destroy the
product.
AJ3112_37_UM_EN 4/16/10 15:55 Page 15

Printed in China AJ3112_37_UM_V2.1
AJ3112
W
Philips Consumer Lifestyle
A division of Philips Electronics North America
Corporation
P. O. Box 10313
Stamford, CT 06904
Phone: 1-888-PHILIPS (744-5477)
Meet Philips at the Internet
http://www.philips.com/welcome
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
AJ3112_37_UM_EN 4/16/10 15:55 Page 16
